Projection System Epson original LCD prism technology

Projection Method Front/rear/ceiling mount

LCD

Size 1.0"

Driving method Epson Poly-silicon TFT Active Matrix

Pixel number 786,432 pixels x 3 (1024 x 768) LCDs

Native resolution XGA

Aspect ratio 4:3 (supports 16:9; 5:4)

Pixel arrangement Stripe

Projection Lens

Type Manual zoom/focus

F-number 1.7 to 2.3

f-number 28 to 37mm

Zoom ratio 1.0:1.35

Lamp

Type 250W UHE

Life (typical) 2000H (High Brightness), 3000H (Low Brightness)

Screen Width Ratio: (Distance/Width) 1.32 to 1.8:1

Screen Size (Projected Distance) 30" to 300" (2.6' to 36.1')

Keystone Correction Vertical: ±40 degrees, Horizontal: ±20 degrees

Auto keystone correction (vertical only)

Brightness (Typical) 3500 ANSI lumens, 2500 ANSI lumens (Low Brightness)

Contrast Ratio 700:1

Brightness Uniformity (Typical) 90%

Color Reproduction 24 bit; 16.7 mil

Audio Output 5W Monaural

Operating Temperature 41ºF to 95ºF (5ºC to 35ºC)

Power Supply Voltage 100-120V/200-240V ±10%, 50/60Hz AC

Power Consumption 350W, 47W at sleep mode: Network ON

1.5W at sleep mode: Network OFF

Dimension (includes lens and feet) 12.8" x 16.5" x 5.4"

Dimension (excludes lens and feet) 12.8" x 16.5" x 4.6"

Weight 12.8 lb/5.8 kg

Fan Noise 36db (High Brightness), 33db (Low Brightness)

Effective Scanning Frequency Range

Analog

Pixel clock 13.5MHz to 230MHz

Horizontal 15KHz to 107KHz

Vertical 50Hz to 120Hz

Digital

Pixel clock 25MHz to 135MHz

Horizontal 15KHz to 80KHz

Vertical 50Hz to 85Hz

Remote Control Features

Features Keystone, brightness, source selection, power,

PinP, preview, page up/page down, color mode,

volume, presets, e-zoom, a/v mute, freeze,

effects, resize, EasyMP, WallShot

Operating angle Right/left ± 30 degrees

Upper/lower ± 15 degrees

Operating distance 33 ft (10m)

RGB Analog RGB I/O Digital RGB Input

Display performance

Native 1024 x 768 1024 x 768

Resize 1600 x 1200 1280 x 1024

1280 x 1024 800 x 600

800 x 600 640 x 480

640 x 480

Input terminal

Video Mini D-sub 15pin x 1 DVI TypeD x1

5-BNC x 1

Audio Stereo mini jack Stereo mini jack

(for Mini D-sub),

RCA x 2 (for 5-BNC)

RGB (cont.) Analog RGB I/O

Output terminal

Video Mini D-sub 15pin

(monitor out) x1

Audio Stereo mini jack

Video I/O

Display performance NTSC: 560 line

PAL: 560 line

(Depends on observation of the

multi burst pattern)

Input signal NTSC/NTSC4.43/PAL/M-PAL/

N-PAL/PAL60/SECAM

HDTV: 480i, 480p, 720p, 1080i

Input terminal

Video Composite video: RCA (Yellow) x 1

S-Video: Mini DIN

Component video: BNC

Video-RGB: Mini D-sub 15pin (in common

with Analog RGB connector)

Audio RCA (White/Red) x 2

Audio signal 500m Vrms/47Kohm

Card I/O

PC card slot PCMCIA type I/II

Memory card CompactFlash,

™SmartMedia,,

™Memory Stick,

compatibility SD, MMC, 3.3 volts type ATA Flash card,

5 volts type ATA Flash card, IBM MicroDrive™

Other Epson wireless LAN card (802.11b) included

Wired LAN card

Control I/O

USB I/O USB connector series A x 1 (for digital cameras)

USB connector series B x 1 (for mouse, keyboard)

Serial I/O Mini D-sub 9pin x 1

RS-232C

Security Kensington®-style lock provision

Warranty

Two-year limited warranty, two-year international warranty, 90-day lamp

warranty, Epson Road Service program and Epson PrivateLine dedicated

toll-free support (U.S. and Canada only)

Supplied Accessories

Power cable, remote control, 2 AA batteries, computer cable, audio cable,

USB mouse cable, RCA video cable, RCA audio cable, wireless LAN card,

CD-ROM (Windows®-based EasyManagement software, Start Here Kit.

Product/Accessory Part Numbers

Epson PowerLite 7850p projector V11H120020

Replacement lamp V13H010L22

Air filter set V13H134A01

Middle throw zoom lens V12H004M03

Long throw zoom lens V12H004L05

Remote control cable set V12H005C28

Ceiling mount ELPMB40

Suspension adapter ELPMBAPL

False ceiling plate ELPMBFCP

Distribution amplifier ELPDA01

Digital video cable DVI to DVI, 3m ELPKC20

Digital video cable DVI to DFP, 3m ELPKC21

S-Video cable ELPSV01

Mac adapter set ELPAP01

ATA shipping case ELPKS46

ATA molded hardshell case ELPKS48

50" portable screen ELPSC06

60" portable pop-up screen ELPSC07

80" portable pop-up screen ELPSC08

High resolution document imager ELPDC02

High resolution document camera V12H064020

Kensington security lock ELPSL01

Support–The Epson ConnectionSM

Pre-Sales Support U.S. and Canada 800-463-7766

Automated Technical Support 800-922-8911

Internet Web Site www.epson.com

presentersonline.com

The Epson PowerLite 7850p takes high-performance portables

to a whole new level, with out-of-the-box networking capability,

PC-free presentations, and the ability to operate with or without a

hard-wired video connection. IS personnel will appreciate its easy

monitoring and maintenance, while presenters will enjoy its

remarkable functionality.

Even with these notable features, you won’t have to sacrifice image

quality. This powerful portable provides 3500 ANSI lumens and XGA

resolution for exceptional clarity and detail.

The Epson PowerLite 7850p can address virtually any presentation

requirement. With optional lenses available, it offers enhanced

positioning flexibility. And, it provides monitor out capability, plus

multiple image correction tools. For easy setup and operation, this

accommodating performer includes both vertical and horizontal

keystone correction. And, no matter where it is situated, the projector

offers a unique feature designed to assist theft prevention, which can

be a costly impact to any business. Its enhanced security feature was

engineered to guard against unauthorized users and disable the

projector through a convenient password protection function.

A multi-faceted product, the Epson PowerLite 7850p delivers superior

power and versatility–from the world leader in high-performance

projectors. And, it’s backed by legendary Epson reliability.

Convenient networking capability with

EasyManagement™technology

• Offers information on projector status via:

- EMP Monitor software utility (included)

- Web browser—no special software required!

- SNMP (Simple Network Management Protocol) with

HP OpenView plug-in available

• Allows easy monitoring of source status, power status, lamp

status and resolution input status

• Provides e-mail notification via SMTP to alert administrators

immediately of any troubleshooting issues

• Enables secure access via password protection features

including web

• Provides real-time status information and projector error detection

PC-free presenting with improved Epson EasyMP™

• PCMCIA card slot available to save presentations and run your

presentations from the projector

• More animation and PowerPoint®functionality than ever before

• High-speed image transfers

Wireless presenting at its best

• 802.11b wireless technology (WiFi certified)

• Two wireless modes for individual or LAN users

• No video cable required—laptop and projector can be

positioned independently for optional viewing and control

• Page up and page down feature via wireless remote

• Allows for a seamless presentation with less down time

connecting cables when there are multiple presenters

Ultra bright 3500 ANSI lumens, weighs only 12.8 lb

• Remarkable brightness that’s great for conference rooms

• Three XGA (1024 x 768) 1.0" Epson high-aperture LCDs for

evenly distributed color across the screen

• 700:1 contrast ratio for blacker blacks and whiter whites

Easy installation, setup and operation

• Enhanced security function, including password protection, to

disable the projector from unauthorized users

• Image correction tools for flexible setup and installation

- Keystone correction (±40˚ vertical, ±20˚ horizontal)

- QuickCorner™to display perfectly square images

- WallShot™for instant color correction when projecting on

a colored surface

• Great connectivity including computer, Component Video

(BNC), DVI, S-Video, and Composite Video; dedicated audio

for each signal

• Low fan noise for undisturbed presentations

• Multiple lens options for installation flexibility

Comprehensive Epson service and support (free for

the duration of the two-year warranty)

• 90-day bulb warranty for added dependability

• Epson Road Service program provides a replacement projector,

typically within 24 hours

• Epson PrivateLineSM service provides a dedicated toll-free support

line available from 6 a.m. to 6 p.m. PST Monday - Friday

(Calls are answered live, typically in about one minute.)

• International warranty in over 45 countries

stylish metallic

silver finish

EPSON®

Epson PowerLite 7850p Specifications

Epson PowerLite®7850p

The wireless wonder that networks like a pro

Specifications and terms are subject to change without notice. Epson is a registered trademark and EasyManagement, WallShot and QuickCorner are trademarks of Seiko Epson Corporation. PowerLite is a registered trademark,

SizeWise is a trademark and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective

Front View optional lenses/

zoom lens

WallShot

full-featured

IR remote control

high

performance,

low profile

Back View

USB type A

s-video

USB type B

RS-232

monitor

out

computer

DVI

BNC

composite video

PCMCIA slot for

wireless LAN

and memory

card wired/

Ethernet card

hard-wired remote option
