Epson 7900p - PowerLite XGA LCD Projector User manual

Epson® PowerLite®7900p
Multimedia Projector
User’sGuide

2
Important Safety Information
WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.
Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and
filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically
explained in this User’s Guide, do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by
the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with
this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
Epson, Quick Corner, and Wall Shot are registered trademarks and Exceed Your Vision, EasyMP, and
Easy Management are trademarks of Seiko Epson Corporation.
PowerLite, PrivateLine, and Presenters Club are registered trademarks and Epson Connection, Epson Store, and
Extra Care are service marks of Epson America, Inc.
Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
© 2006 by Epson America, Inc. 4/06
.CPD-18737R2

3
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Getting the Most from Your Projector . . . . . . . . . . . . . . . . . 10
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 11
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . 11
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Additional Components. . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1Setting Up the Projector . . . . . . . . . . . . . . . . . . . . . 17
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting to Video Equipment . . . . . . . . . . . . . . . . . . . . . 20
Connecting a Composite Video Source . . . . . . . . . . . . . 21
Connecting an S-Video Source . . . . . . . . . . . . . . . . . . . 22
Connecting a Component Video Source . . . . . . . . . . . . 23
Connecting an RGB Video Source. . . . . . . . . . . . . . . . . 24
Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . . 26
Connecting to the Computer Port . . . . . . . . . . . . . . . . . 27
Connecting to the BNC Connectors . . . . . . . . . . . . . . . 28
Connecting to the DVI Port . . . . . . . . . . . . . . . . . . . . . 29
Using the Macintosh Desktop Adapter . . . . . . . . . . . . . 30
Connecting the Cable for Remote Mouse Control . . . . 31
Connecting an External Monitor . . . . . . . . . . . . . . . . . . . . . 32
Playing Sound Through the Projector. . . . . . . . . . . . . . . . . . 33
Connecting Audio Equipment to the Projector . . . . . . . 33
Connecting External Speakers . . . . . . . . . . . . . . . . . . . . 34

4Contents
2Projecting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Turning On Your Equipment . . . . . . . . . . . . . . . . . . . . . . . 36
Turning On the Projector . . . . . . . . . . . . . . . . . . . . . . . 36
Selecting the Image Source. . . . . . . . . . . . . . . . . . . . . . . 38
What To Do If You See a Blank Screen . . . . . . . . . . . . . 39
The Projector and Notebook
Don’t Display the Same Image . . . . . . . . . . . . . . . . 39
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Focusing and Zooming Your Image. . . . . . . . . . . . . . . . 42
Adjusting the Height of Your Image . . . . . . . . . . . . . . . 43
Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 44
Correcting Computer Images. . . . . . . . . . . . . . . . . . . . . 47
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Projecting Images Without a Screen . . . . . . . . . . . . . . . . . . . 48
Making Initial Color Corrections. . . . . . . . . . . . . . . . . . 48
Adjusting Color Corrections for a New Surface . . . . . . . 49
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . . . . 49
3Using the Remote Control . . . . . . . . . . . . . . . . . . . 51
Activating and Using the Remote Control . . . . . . . . . . . . . . 52
Using the Navigation Buttons . . . . . . . . . . . . . . . . . . . . 53
Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . 54
Controlling the Picture and Sound. . . . . . . . . . . . . . . . . . . . 55
Switching Between Picture Sources . . . . . . . . . . . . . . . . 55
Previewing Picture Sources . . . . . . . . . . . . . . . . . . . . . . 56
Turning Off the Picture and Sound . . . . . . . . . . . . . . . 57
Stopping Action. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Zooming Your Image. . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Displaying a Picture-in-Picture Video . . . . . . . . . . . . . . 58
Highlighting Your Presentation . . . . . . . . . . . . . . . . . . . . . . 59
Using the Pointer Tool . . . . . . . . . . . . . . . . . . . . . . . . . 59
Customizing the Pointer Tools . . . . . . . . . . . . . . . . . . . 60
Operating Your Computer with the Remote Control . . . . . . 62
Controlling Multiple Projectors . . . . . . . . . . . . . . . . . . . . . . 63
Setting the Projector ID. . . . . . . . . . . . . . . . . . . . . . . . . 63
Setting the Remote Control ID . . . . . . . . . . . . . . . . . . . 64

Contents 5
4Fine-tuning the Projector. . . . . . . . . . . . . . . . . . . . 65
Using the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . 67
Adjusting the Image Quality. . . . . . . . . . . . . . . . . . . . . . . . . 68
Adjusting Images from Video Sources . . . . . . . . . . . . . . 68
Adjusting Computer Images. . . . . . . . . . . . . . . . . . . . . . 69
Adjusting the Image Size, Shape, and Position . . . . . . . . . . . 71
Adjusting the Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Adjusting the Sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . . 74
Image Setup Options . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Communication Setup Options . . . . . . . . . . . . . . . . . . . 75
Miscellaneous Setup Options . . . . . . . . . . . . . . . . . . . . . 76
Using the Projector’s Security Features . . . . . . . . . . . . . . . . . 77
Creating Your Own Screen Logo . . . . . . . . . . . . . . . . . . 78
Setting a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Turning On Password Protect and
User’s Logo Protect . . . . . . . . . . . . . . . . . . . . . . . . . 81
Starting the Projector with a Password . . . . . . . . . . . . . . 82
Disabling the Projector’s Buttons. . . . . . . . . . . . . . . . . . 83
5Managing the Projector
from a Remote Computer. . . . . . . . . . . . . . . . . . . . 85
Installing the Easy Management Software. . . . . . . . . . . . . . . 86
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Connecting and Configuring the Projector. . . . . . . . . . . . . . 87
Using EMP Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Opening and Closing EMP Monitor . . . . . . . . . . . . . . . 90
Registering a Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Monitoring Your Projectors . . . . . . . . . . . . . . . . . . . . . . 93
Controlling Your Projectors . . . . . . . . . . . . . . . . . . . . . . 95
Configuring the Monitoring Interval . . . . . . . . . . . . . . . 95

6Contents
Using EMP NetworkManager . . . . . . . . . . . . . . . . . . . . . . . 96
Selecting the Projectors to Monitor . . . . . . . . . . . . . . . . 96
Setting a Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Creating the E-Mail Settings . . . . . . . . . . . . . . . . . . . . . 97
Understanding the Notification Messages . . . . . . . . . . . 99
6Maintaining the Projector. . . . . . . . . . . . . . . . . . 101
Cleaning the Lens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . 102
Cleaning the Air Filters and Vents . . . . . . . . . . . . . . . . . . . 103
Replacing the Lamp and Air Filters . . . . . . . . . . . . . . . . . . 104
Resetting the Lamp Timer . . . . . . . . . . . . . . . . . . . . . . 107
Transporting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . 108
7Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Using On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Checking Projector Status . . . . . . . . . . . . . . . . . . . . . . . . . 111
What To Do When the Lights Flash . . . . . . . . . . . . . . 111
Viewing Lamp Usage and Other Information . . . . . . . 113
Solving Problems with the Image or Sound . . . . . . . . . . . . 114
Solving Easy Management Problems . . . . . . . . . . . . . . . . . 120
Solving Problems with the Remote Control . . . . . . . . . . . . 120
Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Internet Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Speak to a Support Representative . . . . . . . . . . . . . . . . 121
AAppendix A: Projector Installation . . . . . . . . . 123
Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
BAppendix B: Technical Specifications . . . . . . 125

Contents 7
CAppendix C: Notices. . . . . . . . . . . . . . . . . . . . . . . . 131
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 131
Remote Control Information . . . . . . . . . . . . . . . . . . . . . . . 133
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . 134
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . 135
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

8Contents

9
-
Welcome
The Epson® PowerLite®7900p is a versatile, lightweight projector
designed to ensure that your presentations are easy and trouble-free,
whether you use it in the classroom or conference room. When space
is limited, you can project against a surface less than five and one-half
feet away. The projector’s keystone correction function automatically
corrects image distortion, and Epson’s unique Wall Shot™function
lets you project against blackboards and colored walls without loss
of image color, regardless of ambient lighting. In addition, the
PowerLite 7900p offers outstanding image quality, with up to 4000
lumens of brightness, a resolution of 1024 × 768 pixels, and a 700:1
contrast ratio.
Your Epson PowerLite projector can be connected to three computers
at the same time, or four video sources (up to a total of five sources at
the same time). You can include an independent sound channel for
each source. A preview feature lets you see all the sources at a glance,
so you can easily switch between them.
Use the remote control to take charge of your presentation. Freeze the
action, zoom in on part of the picture, or display a picture-in-picture
video. Use the remote as a pointer, or to draw on the screen. You can
even use it in place of your computer’s mouse to control your
computer and change slides in PowerPoint.
®
With the projector’s Easy Management™system, you can use a
Windows®PC to remotely monitor and control the projector.

10 Welcome
To prevent unauthorized use of your PowerLite 7900p, you can assign
a password, create a user logo which is displayed at startup to identify
the projector, and disable the projector’s buttons through the
Operation Lock feature. For more information about security features,
see page 77.
Getting the Most from Your Projector
Depending on your presentation, you can take advantage of any or all
of these options:
■Connecting to a notebook or other computer
If you want to connect the projector to a notebook or desktop
computer, see page 26. For additional presentation control, you
can connect the USB cable to the projector for running slide
shows, and connect an external monitor to view the presentation
on your computer simultaneously.
■Connecting to video sources
You can connect a DVD player, VCR, HDTV, camcorder, laser
disc player, digital camera, and other video sources to your
projector. See page 20 for instructions.
■Using the remote control
The remote control lets you switch from computer to video
sources, zoom in on part of your image, freeze or mute the
presentation, and adjust many other projector features. For
details, see Chapter 3.
■Including sound in your presentation
If your presentation includes sound, you can connect the audio
cable that came with your projector to use the projector’s built-in
speaker. See page 33.

Welcome 11
Using Your Documentation
Your documentation includes a Quick Setup sheet, warranty
brochures, and Epson PrivateLine®Support card.
The Quick Setup sheet gives instructions for setting up your projector
and connecting it to a notebook or PowerBook®computer.
This book contains all the information you need to set up and use
your projector. Please follow these guidelines as you read through it:
■Warnings must be followed carefully to avoid bodily injury.
■Cautions must be observed to avoid damage to your equipment.
■Notes contain important information about your projector.
■Tips contain additional projection hints.
Getting More Information
Need tips on giving presentations? Quick steps for setting up your
projector? Here’s where you can look for help:
■presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club®—and it’s free.
■built-in help system
Press the Help button on the remote control or projector to get
quick solutions for common problems. See page 110 for details.
■support.epson.com
Download FAQs (frequently-asked questions) and e-mail your
questions to Epson support.
If you still need help after checking this User’s Guide and the sources
listed above, you can use the Epson PrivateLine Support service to get
help fast. Call [phone] and enter the PIN on your PrivateLine
Support card. See page 121 for more information.

12 Welcome
Registration and Warranty
Your projector comes with a basic carry-in warranty as well as an
international warranty that let you project with confidence anywhere
in the world. For details, see page 136 and the warranty brochure
included with your projector.
In addition, for customers who register their projector, Epson offers
free Extra CareSM Road Service. In the unlikely event of an equipment
failure, you won’t have to wait for your unit to be repaired. Instead,
Epson will ship you a replacement unit anywhere in the United States
or Canada, usually via overnight delivery. See the brochure in your
Start Here kit for details.
To register, simply fill out the registration card that came with your
projector and mail it to Epson. Or you can register online at:
http://www.epson.com/webreg
Registering also lets you receive special updates on new accessories,
products, and service.

Welcome 13
Unpacking the Projector
After unpacking the projector, make sure you have all the parts
shown below:
Save all packaging in case you need to ship the projector. Always use
the original packaging (or the equivalent) when you need to send the
projector to another location. If you are moving the projector by
hand, use a carrying case (either an Epson case or something similar,
such as a well-padded notebook case). See page 15 for ordering
information, and page 108 for transportation instructions.
Projector Remote control and
batteries
Projector software
CD-ROM
Power cable VGA computer cable

14 Welcome
Additional Components
Depending on how you plan to use the projector, you may need
additional components:
■To receive an S-Video signal, you’ll need an S-Video cable. One
may be provided with your video equipment, or you can purchase
one from Epson; see page 15.
■To receive a component video signal from a VCR or other video
device, you’ll need a component video cable. One may be
provided with your video equipment, or you can purchase one
from Epson; see page 15.
■To receive an RGB video signal from a video device that has three
connectors labeled R/G/B, you’ll need a BNC-style video cable
(one may be included with your video equipment). See page 25
for details.
■Some older PowerBooks and Macintosh®desktop models may
need the Macintosh adapter set shown on page 30 (available from
Epson; see page 15). Older iMac®systems may need a special
adapter to provide a VGA output port; see your computer dealer.

Welcome 15
Optional Accessories
To enhance your use of the projector, Epson provides the following
optional accessories:
You can purchase these accessories from an Epson authorized reseller.
To find the nearest reseller, call 800-GO-EPSON (800-463-7766).
Or you can purchase online at www.epsonstore.com (U.S. sales) or
www.epson.ca (Canadian sales).
Product Part number
Replacement lamp V13H010L22
Air filter replacement set V13H134A01
Middle throw zoom lens (standard lens)
Wide throw zoom lens
Long throw zoom lens
V12H004M03
V12H004W03
V12H004L05
ATA shipping case
ATA molded hardshell case
ELPKS46
ELPKS48
Ceiling mount
Suspension adapter
False ceiling plate
Adjustable ceiling channel
Security bracket/cabling
ELPMB40
ELPMBAPL
ELPMBFCP
ELPMBACC
ELPMBSEC
Kensington®security lock ELPSL01
Projection screens:
50-inch portable screen
60-inch portable pop-up screen
80-inch portable pop-up screen
83.6-inch hanging pull-down screen
ELPSC06
ELPSC07
ELPSC08
ELPSC09
Macintosh adapter set (includes monitor adapter
and desktop adapter)
ELPAP01
Remote control cable set V12H005C28
DVI to DVI digital video cable, 10 ft.
DVI to DFP digital video cable, 10 ft.
S-Video cable
Component video cable, 10 ft.
ELPKC20
ELPKC21
ELPSV01
ELPKC19
Distribution amplifier ELPDA01
High resolution document imager V12H162020

16 Welcome

17
1
Setting Up the Projector
This chapter gives you basic information on setting up the projector:
where to position it and how to connect it to a video source (such as a
VCR or DVD player) or to a notebook or desktop computer.
Follow the instructions in this chapter on:
■Positioning the projector
■Connecting to video equipment
■Connecting to a computer
■Connecting an external monitor
■Playing sound through the projector

18 Setting Up the Projector
Positioning the Projector
If you’re setting up the projector yourself and it isn’t already installed
in the theater or conference room you’re using, you’ll probably want
to place it on a table in front of the screen, as shown. x art below
This lets you stand in the front of the room, face the audience, and
remain close enough to the equipment to be able to control it. Try to
leave as much space as possible between the projector and the screen to
get a good-size image.
Use the figure below to help you determine placement. Image size
increases with distance, but can vary depending on how you position
the zoom ring and whether you’ve adjusted the image with other
settings.
Also keep these considerations in mind:
■Place the projector on a sturdy, level surface.
■Make sure there is plenty of space for ventilation around and
under the projector. Do not set the projector on top of loose
papers that could block the vents under the projector.
■Make sure the projector is within 10 feet of a grounded electrical
outlet or extension cord.
note
You can mount the projector
on the ceiling, or place it
behind a translucent screen
for rear projection. See
page 123 for details.
2.5 to 3.5 ft7 to 9.5 ft27 to 36.5 ft distance from screen
TBD

Setting Up the Projector 19
Ideally, you should place the projector directly in front of the center of
the screen, facing it toward the screen squarely. The base of the lens
should be at about the level of the bottom of the screen.
If you place the projector below screen level, you’ll have to tilt it up by
extending its feet. This causes the image to become “keystone” shaped,
but you can correct the distortion by pressing the Sync buttons on the
projector. See page 44 for detailed information about correcting the
image shape.
For instructions on installing the projector in a permanent location,
such as a theater or conference room, see page 123.
note
After positioning the
projector, you may want to
connect a Kensington
MicroSaver®anti-theft
device to the lock port on the
projector’s left side. You can
purchase this from Epson;
see “Optional Accessories” on
page 15.
Screen
Projector

20 Setting Up the Projector
Connecting to Video Equipment
You can connect up to four video sources to the projector at the same
time. Before starting, look at your video equipment to determine its
available video-output connections:
■If your video player has a yellow RCA-style video output
connector, see “Connecting a Composite Video Source” on
page 21.
■If your video player has an S-Video connector, see “Connecting
an S-Video Source” on page 22.
■If your video player has a component video port (three connectors
labeled either Y/Cb/Cr or Y/Pb/Pr), see “Connecting a
Component Video Source” on page 23.
■If your video player has an RGB video port (either a single
connector for a VGA-style monitor cable, or three connectors
labeled R/G/B), see “Connecting an RGB Video Source” on
page 24.
After connecting the video cables, you may also want to connect an
audio cable to play sound through the projector; see page 33.
RCA connector
(composite video)
S-Video connector
(4-pin mini-DIN)
BNC connector
(component video)
