Epson EB-810E User manual

User's Guide

Contents 2
Notations Used in This Guide 7
Using the Manual to Search for Information .................................. 8
Searching by Keyword................................................................................................................... 8
Jumping Directly from Bookmarks............................................................................................ 8
Printing Only the Pages You Need............................................................................................ 8
Getting the Latest Version of the Documents................................. 9
Introduction to Your Projector 10
Projector Features............................................................................ 11
Providing a New Videoconferencing Experience with a High Sense of
Presence and Imparting Information at a Glance............................................................. 11
Realizing a Space-saving Large Screen................................................................................. 11
Quick and Easy Setup .................................................................................................................. 12
Flexible Connectivity.................................................................................................................... 12
Projector Parts and Functions ........................................................ 14
Projector Parts - Front.................................................................................................................. 14
Projector Parts - Top/Side .......................................................................................................... 15
Projector Parts - Base ................................................................................................................... 16
Projector Parts - Interface Ports ............................................................................................... 17
Projector Parts - Control Panel................................................................................................. 18
Projector Parts - Remote Control ............................................................................................ 19
Setting Up the Projector 21
Projector Placement ........................................................................ 22
Projector Setup and Installation Options............................................................................. 23
Precautions on Installation ........................................................................................................ 24
Installing the Safety Wire................................................................ 26
When Using the Ceiling Mount ELPMB22............................................................................ 26
When Using the Ceiling Mount ELPMB30............................................................................ 27
When Using the Setting Plate ELPMB75............................................................................... 28
Projector Connections ..................................................................... 31
Connecting to a Computer........................................................................................................ 31
Connecting to a Computer for USB Video and Audio............................................... 31
Connecting to a Computer for HDMI Video and Audio ........................................... 32
Connecting to Video Sources ................................................................................................... 32
Connecting to an HDMI Video Source ............................................................................ 32
Connecting to External USB Devices ..................................................................................... 33
USB Device Projection ........................................................................................................... 33
Connecting to a USB Device ............................................................................................... 33
Disconnecting a USB Device ............................................................................................... 34
Connecting to a Document Camera ...................................................................................... 34
Connecting to an HDBaseT Transmitter .............................................................................. 34
Connecting Multiple Projectors of the Same Model .................... 36
Projecting the Same Image in a Daisy-Chain Connection............................................. 36
Attaching and Removing the Side Cover....................................... 37
Installing Batteries in the Remote Control.................................... 38
Remote Control Operation.............................................................. 39
Using Basic Projector Features 40
Turning On the Projector ................................................................ 41
Home Screen................................................................................................................................... 42
Turning Off the Projector ................................................................ 44
Setting the Date and Time .............................................................. 45
Selecting the Language for the Projector Menus ......................... 47
Projection Modes ............................................................................. 48
Changing the Projection Mode Using the Remote Control.......................................... 48
Changing the Projection Mode Using the Menus ............................................................ 48
Setting the Screen Type .................................................................. 50
Adjusting the Image Position Using Screen Position...................................................... 51

Contents 3
Adjusting the Image Height............................................................ 53
Displaying a Test Pattern ................................................................ 54
Focusing the Image Using the Focus Lever................................... 56
Image Shape ..................................................................................... 57
Correcting Distortion in the Image Using the Wizard..................................................... 57
Correcting the Image Shape with Quick Corner ............................................................... 58
Correcting Image Shape with Arc Correction..................................................................... 61
Correcting Image Shape with Point Correction................................................................. 63
Loading Image Shape Setting from Memory ..................................................................... 65
Resizing the Image with Digital Zoom........................................... 66
Adjusting the Image Position Using Image Shift.......................... 67
Selecting an Image Source .............................................................. 69
Image Aspect Ratio .......................................................................... 71
Changing the Image Aspect Ratio.......................................................................................... 71
Available Image Aspect Ratios ................................................................................................. 71
Adjusting Image Quality (Color Mode) .......................................... 73
Changing the Color Mode ......................................................................................................... 73
Available Color Modes................................................................................................................. 73
Turning On Automatic Luminance Adjustment................................................................ 73
Setting Frame Interpolation ........................................................... 75
Adjusting the Image Color .............................................................. 77
Adjusting the Hue, Saturation, and Brightness.................................................................. 77
Adjusting the Gamma ................................................................................................................. 78
Adjusting the Image Resolution ..................................................... 80
Adjusting the Brightness................................................................. 82
Light Source Operation Time.................................................................................................... 83
Controlling the Volume with the Volume Buttons ....................... 85
Adjusting the Sound Settings (Sound Mode) ............................... 86
Available Sound Modes .............................................................................................................. 86
Inverting the Audio Channels......................................................... 88
Adjusting Projector Features 89
Projecting Two Images Simultaneously ........................................ 90
Unsupported Input Source Combinations for Split Screen Projection..................... 91
Split Screen Projection Restrictions........................................................................................ 91
Projecting a PC Free Presentation.................................................. 92
Supported PC Free File Types................................................................................................... 92
Precautions on PC Free Projection ......................................................................................... 93
Starting a PC Free Slide Show .................................................................................................. 93
Starting a PC Free Movie Presentation ................................................................................. 95
PC Free Display Options ............................................................................................................. 96
Projecting in Content Playback Mode ........................................... 97
Switching to Content Playback Mode................................................................................... 97
Projecting Your Playlists ............................................................................................................. 98
Creating Playlists Using Epson Web Control................................................................. 98
Adding Effects to Your Projected Image............................................................................ 100
Content Playback Mode Restrictions................................................................................... 102
Shutting Off the Image and Sound Temporarily ........................ 103
Stopping Video Action Temporarily ............................................ 104
Zooming Images ............................................................................ 105
Saving a User's Logo Image .......................................................... 106
Saving a User Pattern .................................................................... 108
Saving Settings to Memory and Using Saved Settings ............. 110
Using Multiple Projectors ............................................................. 111
Projector Identification System for Multiple Projector Control................................. 111
Setting the Projector ID...................................................................................................... 111
Selecting the Projector You want to Operate............................................................ 112
Adjusting Color Uniformity ..................................................................................................... 113
Tiling Images into One Image................................................................................................ 115

Contents 4
Configuring Tiling ................................................................................................................. 116
Blending the Image Edges ...................................................................................................... 116
Matching the Image Colors..................................................................................................... 118
Adjusting the Black Level......................................................................................................... 119
Modifying the Black Level Adjustment Area .............................................................. 121
Adjusting RGBCMY..................................................................................................................... 122
Scaling an Image......................................................................................................................... 122
Projector Security Features .......................................................... 125
Password Security Types.......................................................................................................... 125
Setting a Password ............................................................................................................... 125
Selecting Password Security Types ................................................................................ 126
Entering a Password to Use the Projector................................................................... 127
Locking the Projector's Buttons ............................................................................................ 127
Unlocking the Projector's Buttons.................................................................................. 128
Installing a Security Cable ....................................................................................................... 128
Using the Projector on a Network 130
Wired Network Projection............................................................. 131
Connecting to a Wired Network ........................................................................................... 131
Selecting Wired Network Settings........................................................................................ 131
Wireless Network Projection ........................................................ 134
Safety Instructions for Built-in Wireless LAN Module.................................................... 134
Connection Methods for Wireless Network Projection................................................ 134
Installing the Wireless LAN Module..................................................................................... 135
Selecting Wireless Network Settings Manually ............................................................... 136
Selecting Wireless Network Settings in Windows.......................................................... 140
Selecting Wireless Network Settings in Mac .................................................................... 140
Setting Up Wireless Network Security for Simple AP Mode....................................... 140
Setting Up Wireless Network Security for Infrastructure Mode................................ 141
Supported Client and CA Certificates............................................................................ 143
Using a QR Code to Connect a Mobile Device ................................................................ 143
Using a USB Key to Connect a Windows Computer...................................................... 144
Using the Wireless Presentation System to Connect Windows/Mac
Computers..................................................................................................................................... 144
Setting Up the Wireless Presentation System for the First Time........................ 144
Projecting with the Wireless Presentation System................................................... 145
Wireless Network Projection from a Mobile Device (Screen
Mirroring)........................................................................................ 147
Selecting Screen Mirroring Settings .................................................................................... 147
Connecting Using Screen Mirroring with the Miracast Function............................. 149
Connecting Using Screen Mirroring in Windows 10..................................................... 150
Connecting Using Screen Mirroring in Windows 11..................................................... 150
Secure HTTP.................................................................................... 151
Importing a Web Server Certificate Using the Menus.................................................. 151
Supported Web Server Certificates................................................................................ 152
Screen Sharing ............................................................................... 153
Sharing the Screen ..................................................................................................................... 153
Finishing the Screen Sharing............................................................................................ 154
Receiving Shared Screen Images.......................................................................................... 155
Monitoring and Controlling the Projector 156
Epson Projector Management ...................................................... 157
Controlling a Networked Projector Using a Web Browser ........ 158
Web Control Options................................................................................................................. 159
Registering Digital Certificates from a Web Browser................. 166
Setting Up Projector Network E-Mail Alerts ............................... 167
Network Projector E-mail Alert Messages ......................................................................... 167
Setting Up Monitoring Using SNMP............................................. 168
Using ESC/VP21 Commands ........................................................ 169
ESC/VP21 Command List ......................................................................................................... 169
Cable Layouts ............................................................................................................................... 169
PJLink Support ............................................................................... 170

Contents 5
Art-Net ............................................................................................ 171
Crestron Connected Support ........................................................ 172
Setting Up Crestron Connected Support........................................................................... 172
Web API........................................................................................... 174
Enabling Web API ....................................................................................................................... 174
Setting Projector Event Schedules ............................................... 175
Adjusting the Menu Settings 178
Using the Projector's Menus ......................................................... 179
Using the Displayed Keyboard..................................................... 180
Available Text Using the Displayed Keyboard................................................................. 180
Image Quality Settings - Image Menu ......................................... 181
Input Signal Settings - Signal I/O Menu....................................... 183
Projector Installation Settings - Installation Menu .................... 186
Projector Display Settings - Display Menu.................................. 188
Projector Feature Settings - Operation Menu............................. 190
Projector Administration Settings - Management Menu .......... 193
Event ID Code List....................................................................................................................... 195
Projector Network Settings - Network Menu.............................. 197
Network Menu - Network Settings Menu.......................................................................... 198
Network Menu - Wireless LAN Menu............................................................................. 199
Network Menu - Wired LAN Menu ................................................................................. 201
Network Menu - Mail Notification Menu ..................................................................... 202
Network Menu - Projector Control Menu .................................................................... 202
Network Menu - Network Projection Settings........................................................... 204
Multiple Projector Operation Settings - Multi-Projection
Menu ............................................................................................... 205
Image Quality Memory Settings - Memory Menu....................... 207
Projector Setup Settings - ECO Menu .......................................... 208
Projector Initial Settings and Reset Options - Initial/All
Settings Menu ................................................................................ 209
Copying Menu Settings Between Projectors (Batch Setup) ...... 211
Transferring Settings From a USB Flash Drive ................................................................. 211
Transferring Settings From a Computer ............................................................................ 212
Batch Setup Error Notification ......................................................................................... 213
Maintaining the Projector 214
Projector Maintenance .................................................................. 215
Cleaning the Projection Window.................................................. 216
Cleaning the Obstacle Sensor....................................................... 217
Cleaning the Projector Case.......................................................... 218
Air Filter and Vent Maintenance .................................................. 219
Cleaning the Air Filter .............................................................................................................. 219
Replacing the Air Filter ............................................................................................................. 220
Cleaning the Air Intake Vents ............................................................................................... 221
Adjusting the Color Convergence (Panel Alignment) ................ 223
Updating the Firmware ................................................................. 225
Updating Firmware Using a USB Storage Device........................................................... 225
Updating Firmware Using a Computer and USB Cable ............................................... 226
Solving Problems 228
Projection Problems ...................................................................... 229
Projector Indicator Status ............................................................. 230
Solving Image or Sound Problems............................................... 233
Solutions When No Image Appears..................................................................................... 233
Solutions When Image is Incorrect Using the USB Display Function ..................... 233

Contents 6
Solutions When "No Signal" Message Appears............................................................... 234
Displaying From a Windows Laptop.............................................................................. 234
Displaying From a Mac Laptop........................................................................................ 234
Solutions When "Not Supported" Message Appears .................................................... 235
Solutions When Only a Partial Image Appears................................................................ 235
Solutions When the Image is not Rectangular................................................................ 235
Solutions When the Image Contains Noise or Static..................................................... 236
Solutions When the Image is Fuzzy or Blurry .................................................................. 236
Solutions When the Image Brightness or Colors are Incorrect ................................. 236
Solutions When an Afterimage Remains on the Projected Image .......................... 237
Solutions to Sound Problems................................................................................................. 237
Solutions When Image File Names are not Displayed Correctly in PC Free......... 238
Solutions When You Cannot Project Images Using the PC Free Feature.............. 238
Solving Projector or Remote Control Operation Problems....... 239
Solutions to Projector Power or Shut-Off Problems...................................................... 239
Solutions to Problems with the Remote Control............................................................ 239
Solutions to Password Problems........................................................................................... 240
Solution When "The Battery that Saves Your Clock Settings is Running Low"
Message Appears........................................................................................................................ 240
Solutions to Problems in Content Playback Mode ..................... 241
Solving Network Problems ........................................................... 242
Solutions When You Cannot Search for an Access Point............................................ 242
Solutions When Wireless Authentication Fails ................................................................ 242
Solutions When You Cannot Access the Projector Through the Web ................... 242
Solutions When Network Alert E-Mails are not Received............................................ 243
Solutions When the Image Contains Static During Network Projection............... 243
Solutions When You Cannot Connect Using Screen Mirroring................................. 243
Solutions When You Cannot Use Two Screen Mirroring Sources............................ 243
Solutions When the Image or Sound Contains Static During Screen Mirroring
Connection.................................................................................................................................... 244
Solutions When You Cannot Receive Shared Images................................................... 244
Solutions When HDMI Link does not Function ........................... 245
Appendix 246
Optional Accessories and Replacement Parts............................. 247
Screens............................................................................................................................................ 247
Mounts............................................................................................................................................ 247
External Devices .......................................................................................................................... 247
Replacement Parts...................................................................................................................... 247
For Wireless Connection .......................................................................................................... 247
Compatible Accessories from Other Projectors .............................................................. 248
Screen Size and Projection Distance............................................ 249
Supported Monitor Display Resolutions ..................................... 251
Projector Specifications ................................................................ 252
Connector Specifications ......................................................................................................... 252
External Dimensions...................................................................... 253
USB Display System Requirements .............................................. 254
Supported Features for Epson Projector Content Manager...... 255
List of Safety Symbols and Instructions ...................................... 256
Laser Safety Information............................................................... 258
Laser Warning Labels................................................................................................................. 258
Glossary .......................................................................................... 261
Notices ............................................................................................ 263
FCC Compliance Statement.................................................................................................... 263
Indication of the manufacturer and the importer in accordance with
requirements of EU directive.................................................................................................. 264
Indication of the manufacturer and the importer in accordance with
requirements of United Kingdom directive...................................................................... 264
Restriction of Use........................................................................................................................ 264
Operating System References................................................................................................ 264
Trademarks.................................................................................................................................... 265
Copyright Notice......................................................................................................................... 265
Copyright Attribution................................................................................................................ 265

Notations Used in This Guide
Safety Symbols
The projector and its manuals use graphical symbols and labels to indicate content that tells you how to use the projector safely.
Read and carefully follow the instructions that are marked with these symbols and labels to avoid injury to persons or damage to property.
Warning
This symbol indicates information that, if ignored, could possibly result in personal injury or even death.
Caution
This symbol indicates information that, if ignored, could possibly result in personal injury or physical damage due to incorrect handling.
General Information Notations
Attention
This label indicates procedures that may result in damage or injury if sufficient care is not taken.
This label indicates additional information that may be useful to know.
[Button name] Indicates the name of the buttons on the remote control or the control panel.
Example: [Esc] button
Menu/Setting name Indicates projector menu and setting names.
Example:
Select the Image menu
This label indicates links to the related pages.
sThis label indicates the projector's current menu level.
gg Related Links
• "Using the Manual to Search for Information" p.8
• "Getting the Latest Version of the Documents" p.9

Using the Manual to Search for Information 8
The PDF manual allows you to search for information you are looking for by
keyword, or jump directly to specific sections using the bookmarks. You can
also print only the pages you need. This section explains how to use a PDF
manual that has been opened in Adobe Reader X on your computer.
gg Related Links
• "Searching by Keyword" p.8
• "Jumping Directly from Bookmarks" p.8
• "Printing Only the Pages You Need" p.8
Searching by Keyword
Click Edit >Advanced Search. Enter the keyword (text) for information you
want to find in the search window, and then click Search. Hits are displayed
as a list. Click one of the displayed hits to jump to that page.
Jumping Directly from Bookmarks
Click a title to jump to that page. Click +or >to view the lower level titles in
that section. To return to the previous page, perform the following operation
on your keyboard.
• Windows: Hold down Alt, and then press ←.
• Mac OS: Hold down the command key, and then press ←.
Printing Only the Pages You Need
You can extract and print only the pages you need. Click Print in the File
menu, and then specify the pages you want to print in Pages in Pages to
Print.
• To specify a series of pages, enter a hyphen between the start page and the
end page.
Example: 20-25
• To specify pages that are not in series, divide the pages with commas.
Example: 5, 10, 15

Getting the Latest Version of the Documents 9
You can get the latest version of the manuals and specifications on the Epson
Web site.
Visit epson.sn, and enter your model name.

Introduction to Your Projector
Refer to these sections to learn more about your projector's features and part names.
gg Related Links
• "Projector Features" p.11
• "Projector Parts and Functions" p.14

Projector Features 11
This projector comes with these special features. Refer to these sections for
more details.
gg Related Links
• "Providing a New Videoconferencing Experience with a High Sense of
Presence and Imparting Information at a Glance" p.11
• "Realizing a Space-saving Large Screen" p.11
• "Quick and Easy Setup" p.12
• "Flexible Connectivity" p.12
Providing a New Videoconferencing Experience with
a High Sense of Presence and Imparting Information
at a Glance
• This projector supports ultra wide aspect ratio 21:9. By holding a video
conference with horizontally wide and large screen images, you can realize
remote communication with a high sense of presence.
• You can also change multiple setting items for the video conference room at
once using the Settings for Video Conference Rooms setting in the
projector's Installation menu.
gg Related Links
• "Projector Installation Settings - Installation Menu" p.186
• "Setting the Screen Type" p.50
Realizing a Space-saving Large Screen
You can easily install an impressive, 100 inch screen in a small space.
• 5,000 lm of high brightness realizes crisp, clean images even in bright
environments.
• The high resolution of 4K enhancement technology allows you to display
more information than when using WUXGA or Full HD.
• The projector can be carried by one person and can be easily installed by
just placing it beside a wall.
• You can project a 100 inch screen from the projector installed close to the
wall. Since the projected light is not blocked by shadows, you can make
effective use of your meeting space.
• You can install the projector in a variety of positions such as on a desk, wall,
or ceiling.

Projector Features 12
Quick and Easy Setup
• You can use the Epson Setting Assistant application on a smart phone or
tablet that has a camera function to correct distortion more easily.
gg Related Links
• "Correcting Distortion in the Image Using the Wizard" p.57
Flexible Connectivity
This projector supports a wide variety of connectivity options as shown
below.
• You can use an HDMI cable to output video and audio from your computer
or video source.
• To send an HDMI or RS-232C signal over a long distance, you can connect
the projector to an HDBaseT transmitter using a 100Base-TX network cable.
• You can connect a USB device or a document camera.
• Connect with one USB cable to project images and output audio (USB
Display).
• Epson iProjection (Windows/Mac) to project up to four images at the same
time by splitting the projected screen. You can project images from
computers on the network, or from smartphones or tablet devices on which
Epson iProjection is installed.
See the Epson iProjection Operation Guide (Windows/Mac) for details.

Projector Features 13
a• You can download the necessary software and manuals from the
following Web site:
epson.sn
• Epson iProjection (iOS/Android) to connect your projector and mobile
device wirelessly using the app available on the App Store or Google Play.
aAny fees incurred when communicating with the App Store or
Google Play are the responsibility of the customer.
• Epson iProjection (Chromebook) to connect your projector and
Chromebook device wirelessly using the app available on the Google Play.
See the Epson iProjection Operation Guide (Chromebook) for details.
aAny fees incurred when communicating with the Google Play are the
responsibility of the customer.
• Screen Mirroring to connect your projector and mobile device wirelessly
using Miracast technology.
gg Related Links
• "Wired Network Projection" p.131
• "Wireless Network Projection" p.134
• "Wireless Network Projection from a Mobile Device (Screen Mirroring)"
p.147
• "Connecting to a Computer for USB Video and Audio" p.31

Projector Parts and Functions 14
The following sections explain the projector parts and their functions.
gg Related Links
• "Projector Parts - Front" p.14
• "Projector Parts - Top/Side" p.15
• "Projector Parts - Base" p.16
• "Projector Parts - Interface Ports" p.17
• "Projector Parts - Control Panel" p.18
• "Projector Parts - Remote Control" p.19
Projector Parts - Front
Name Function
ASpeaker Outputs audio.
BAir filter cover Open to access the air filter.
Name Function
CAir filter cover latch Slide to remove the air filter cover.
DAir intake vent (air
filter)
Takes in air to cool the projector internally.
EFront cover Open to access the air filter cover.
FRemote receiver Receives signals from the remote control.
GStatus indicator Indicates the projector's status.
gg Related Links
• "Air Filter and Vent Maintenance" p.219
• "Remote Control Operation" p.39
• "Projector Indicator Status" p.230

Projector Parts and Functions 15
Projector Parts - Top/Side
Name Function
AObstacle sensors Detects obstacles that are interfering with the
projection area and reduces the brightness of the light
source for safety.
BRemote receiver Receives signals from the remote control.
Name Function
CProjection window Images are projected from the lens inside the projector.
Warning
• Do not look into the projection window
while projecting.
• Do not place any objects or put your hand
near the projection window. It could cause
burns, fire, or the object to warp because this
area reaches a high temperature due to the
concentrated projection light.
DControl panel Operates the projector.
EFocus lever Adjusts the image focus.
FSide cover latch Slide to remove the side cover.
GAir exhaust vent Exhaust vent for air used to cool the projector
internally.
Caution
While projecting, do not put your face or
hands near the air exhaust vent, and do not
place objects that may become warped or
damaged by heat near the vent. Hot air from
the air exhaust vent could cause burns,
warping, or accidents to occur.
HSecurity slot The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
IPower inlet Connects the power cord to the projector.
JSide cover Open to access the interface ports, focus lever, and
control panel.

Projector Parts and Functions 16
Name Function
KSecurity cable
attachment point
Pass a commercially available wire lock through here
and lock it in place.
Remove the cover when using the security cable
attachment point.
You can attach the security cable attachment point
cover to the back of the side cover so that it does not
get lost.
gg Related Links
• "Air Filter and Vent Maintenance" p.219
• "Projector Parts - Control Panel" p.18
• "Remote Control Operation" p.39
• "Cleaning the Obstacle Sensor" p.217
• "Cleaning the Projection Window" p.216
• "Focusing the Image Using the Focus Lever" p.56
• "Installing a Security Cable" p.128
• "Attaching and Removing the Side Cover" p.37
Projector Parts - Base
Name Function
AFront adjustable feet When the projector is setup on a surface such as a desk,
turn the feet to correct image distortion.
Caution
Remove all feet when you install the projector
on a wall or suspend it from a ceiling.
BAir intake vent (air
filter)
Takes in air to cool the projector internally.
CWire clamp fixing
point
When you use the optional setting plate or ceiling
mount, fix the carabiner here to attach the safety wire
and prevent the projector from falling from the wall or
ceiling.
This point is marked with a on the projector.
DAir exhaust vent Exhaust vent for air used to cool the projector
internally.
Caution
While projecting, do not put your face or
hands near the air exhaust vent, and do not
place objects that may become warped or
damaged by heat near the vent. Hot air from
the air exhaust vent could cause burns,
warping, or accidents to occur.
EFixing points (four
points)
Use these points to attach the optional mount when
installing the projector on a wall or suspending the
projector from a ceiling.
This point is marked with a on the projector.
FAir intake vent Takes in air to cool the projector internally.

Projector Parts and Functions 17
Name Function
GRear adjustable foot When setup on a surface such as a desk, extend the foot
to adjust the position of the image.
Caution
Remove all feet when you install the projector
on a wall or suspend it from a ceiling.
HVESA mount fixing
points (four points)
Use these points to attach the commercially available
mount compatible with the VESA Mounting Interface
Standard (100 × 200 mm) when installing the projector
on a wall or suspending the projector from a ceiling.
gg Related Links
• "Air Filter and Vent Maintenance" p.219
• "Installing a Security Cable" p.128
Projector Parts - Interface Ports
Name Function
AUSB-A port (USB-
A1)
Use to connect a USB memory device or digital camera
for projecting movies or images using the PC Free
feature or in Content Playback mode.
Use to connect the optional document camera.
Use to connect a USB memory device to save error and
operation log files.
Use to connect the wireless LAN module.
aIn this guide, USB-A1 and USB-A2
ports are collectively referred to as
the USB-A port.
BUSB-B port Use to connect a USB cable to the computer to project
computer images.
CHDBaseT port
(RJ-45)
Use to connect a LAN cable to the HDBaseT
Transmitter. You can use a network cable up to 100 m
in length. To ensure proper data transmission, use a
Category 5e STP cable or better. However, operation is
not guaranteed for all input/output devices and
environments.
This port is compatible with HDCP2.3.
Check the following settings:
• To enable communication from the Ethernet and
serial ports on the transmitter, select On as the
Control Communications setting in the projector's
Signal I/O menu.
sSignal I/O >HDBaseT >Control
Communications
• If you have connected an Extron XTP transmitter or
switcher, select On as the Extron XTP setting in the
projector's Signal I/O menu.
sSignal I/O >HDBaseT >Extron XTP

Projector Parts and Functions 18
Name Function
DUSB-A ( )
port (USB-A2)
Use to connect a USB memory device or digital camera
for projecting movies or images using the PC Free
feature or in Content Playback mode.
Use to connect the optional document camera.
Use to connect a USB memory device to save error and
operation log files.
Provides a connection for a commercially available
streaming media player allowing you to power it.
a• You cannot install the wireless
LAN module.
• In this guide, USB-A1 and USB-
A2 ports are collectively referred
to as the USB-A port.
ERS-232C port Use to connect an RS-232C cable to control the
projector from a computer. (This port is for control use
and should not normally be used.)
FLAN port Use to connect a LAN cable to connect to a network.
GHDMI Out port Outputs signals to an external monitor or another
projector.
Connecting an HDMI cable from this port to the
HDMI port on another projector allows you to project
the same image from multiple projectors.
The image is output from the HDMI Out port only
when HDMI1 is selected as the image source.
This port is compatible with HDCP2.3.
HHDMI1 port Inputs video signals from HDMI compatible video
equipment and computers.
Compatible with HDCP 2.3.
IHDMI2 port Inputs video signals from HDMI compatible video
equipment and computers.
Compatible with HDCP 2.3.
gg Related Links
• "Projector Connections" p.31
• "Installing a Security Cable" p.128
Projector Parts - Control Panel
Name Function
APower button [ ] Turns the projector on or off.
B[Menu] button Displays and closes the projector's menu.
CVolume buttons Adjusts the speaker volume.
Selects menu items while displaying the projector's
menu.
D[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu.
EArrow buttons Selects menu items while displaying the projector's
menu.
F[Home] button Displays and closes the Home screen.
G[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
H[Source] button Changes to the next input source.

Projector Parts and Functions 19
gg Related Links
• "Home Screen" p.42
• "Turning On the Projector" p.41
• "Selecting an Image Source" p.69
• "Adjusting the Menu Settings" p.178
Projector Parts - Remote Control
Name Function
APower button [ ] Turns the projector on or off.
B[HDMI] button Switches the image source between the HDMI and
HDBaseT ports.
C[Computer] button This button is not used.
DNumeric buttons Enters numbers in the projector's menu while holding
down the [Num] button.
In Content Playback mode, enter numbers while
holding down the [Num] button to play back your
favorite playlists.
E[Auto] button The [Auto] function is not available.
F[Num] button Hold down this button to enter numbers using the
numeric buttons.
G[Menu] button Displays and closes the projector's menu.
HArrow buttons Selects menu items while displaying the projector's
menu.
I[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu.
J[User] button Performs settings assigned in the User Button setting
in the projector's Management menu.
K[Color Mode] button Changes the color mode.
L[Aspect] button Changes the aspect mode.
M[E-Zoom] +/–
buttons
Resizes the projected image.
N[A/V Mute] button Turns the video and audio on or off temporarily.
O[Split] button Projects up to two images from different image sources
simultaneously by splitting the projected screen.
P[Home] button Displays and closes the Home screen.
Q[Freeze] button Pauses or resumes images.
R[Volume] up/down
buttons
Adjusts the speaker volume.
S[Default] button Returns the selected setting to its default value.

Projector Parts and Functions 20
Name Function
T[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
U[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
using the remote control.
V[LAN] button Switches the image source between the network
connected devices.
W[USB] button Switches the image source between the USB Display
and USB-A port.
X[Source Search]
button
Switches to the next input source.
YRemote control light
emitting area
Outputs remote control signals.
gg Related Links
• "Projecting in Content Playback Mode" p.97
• "Adjusting Image Quality (Color Mode)" p.73
• "Image Aspect Ratio" p.71
• "Home Screen" p.42
• "Remote Control Operation" p.39
• "Turning On the Projector" p.41
• "Selecting an Image Source" p.69
• "Zooming Images" p.105
• "Shutting Off the Image and Sound Temporarily" p.103
• "Projecting Two Images Simultaneously" p.90
• "Stopping Video Action Temporarily" p.104
• "Controlling the Volume with the Volume Buttons" p.85
• "Setting the Projector ID" p.111
• "Adjusting the Menu Settings" p.178
