User's Guide

Safety Instructions
Safety indications
The documentation and the projector use graphical symbols to show how to use the projector safely.
The indications and their meaning are as follows. Make sure you understand them properly before reading the guide.
Warning
This symbol indicates information that, if ignored, could result in personal injury or even death due to incorrect handling.
Caution
This symbol indicates information that, if ignored, could result in personal injury or physical damage due to incorrect handling.
General information indications
Attention
Indicates contents that could cause damage or malfunction to the projector.
a
Indicates additional information and points which may be useful to know regarding a topic.
sIndicates a page where detailed information regarding a topic can be found.
g Indicates that an explanation of the underlined word or words in front of this symbol appears in the glossary of terms. See the "Glossary" section of the
"Appendix".
s"Glossary" p.226
[Name] Indicates the name of the buttons on the remote control or the control panel.
Example: [Esc] button
Menu Name Indicates the Configuration menu items.
Example:
Select Brightness from Image.
Image - Brightness

Make sure you read the following before you use the projector.
sSafety Instructions
Warning and Cautions on Installation
An optional ceiling mount is required when suspending the projector from
a ceiling.
s"Optional Accessories" p.198
Warning
•Do not use or install the projector where it may be subject to water or rain,
or high humidity, such as outdoors, in a bathroom, or shower room, and so
on. Otherwise, it could cause a fire or electric shock.
•A special method of installation is required when suspending the projector
from a ceiling (ceiling mount). If installation work is not carried out
correctly, the projector could fall down. This may result in injury or
accidents. Contact your local dealer or the nearest address provided in the
Epson Projector Contact List.
sEpson Projector Contact List
•When installing the projector on the ceiling, make sure you take measures to
prevent it from falling such as passing a wire through the handles.
•If you use adhesives on the ceiling mount fixing points to prevent the screws
from loosening, or if you use things such as lubricants or oils on the
projector, the projector case may crack causing it to fall from its ceiling
mount. This could cause an accident or injury to anyone under the ceiling
mount.
When installing or adjusting the ceiling mount, do not use adhesives to
prevent the screws from loosening and do not use oils or lubricants and so
on.
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents is covered, the internal temperature could rise and cause a fire.
•Do not place flammable objects in front of the lens. If you set the schedule to
turn on the projector automatically, any flammable objects placed in front of
the lens could cause a fire.
•Do not tie the power cord and other connection cables together. Otherwise, it
could cause a fire.
•Only use the specified power-supply voltage. Otherwise, it could cause a fire
or electric shock.
Safety Warning and Cautions
3

Warning
•Be careful when handling the power cord. Otherwise, it could cause a fire or
electric shock. Note the following when handling the power cord.
- Do not plug multiple power cords in a single electric outlet.
- Do not plug in the power cord if there are any foreign substances, such
as dust, stuck to it.
- Make sure you insert the power cord all the way in.
- Do not plug in or unplug the power cord with wet hands.
- Do not pull the cord when unplugging the power cord. Make sure you
hold it by the plug.
•Do not use a damaged power cord. Otherwise, it could cause a fire or electric
shock. Note the following when handling the power cord.
- Do not alter the power cord.
- Do not place any heavy objects on the power cord.
- Do not bend, twist, or pull the power cord forcibly.
- Do not layout the power cord near a heating device.
•When using the power cord in an area where the power-supply voltage is less
than 120 V, make sure that the power is supplied from an outlet with more
than 15 A.
•Do not share the outlet that you are using for the projector with other
devices.
Caution
Do not place the projector on an unstable surface, such as on an unstable table
or tilted surface. When projecting vertically, install the projector appropriately
to prevent the projector from falling.
Otherwise it may cause an injury.
Attention
•Do not install the projector in a location that is subject to vibration or
shock.
•Do not install the projector near a high-voltage line or object that generates
magnetism. Otherwise the projector may not work correctly.
•Do not use or store the projector in a location that is subject to extreme
temperatures. Also, avoid sudden temperature changes.
Make sure you use or store the projector in a place that is within the
following operating or storage temperature ranges.
- Operating temperature range: 0 to +50˚C
*
(No condensation)
- Storage temperature range: -10 to +60˚C (No condensation)
*At an altitude of 0 to 1,499 m, the operating temperature is 0 to
+50˚C when Power Consumption is set to ECO or Temp
Interlock, and 0 to +45˚C when it is set to Normal.
At an altitude of 0 to 1,500 m, the operating temperature is 0 to
+45˚C when Power Consumption is set to ECO or Temp
Interlock, and 0 to +40˚C when it is set to Normal.
•When using at an altitude of 1,500 m or more, set High Altitude Mode to
On.
sExtended - Operation - High Altitude Mode p.122
Safety Warning and Cautions
4

Attention
•When projecting with the projector tilted, do not tilt it at more than the
specified angle. This may cause malfunctions or accidents to occur.
Angle of tilt (when a standard lamp is attached)
Do not use the projector upside down.
Using the projector at angles not shown in the illustrations above may
damage it or cause an accident.
For the operating conditions when attaching the lamp unit (for portrait use),
see the following.
s"Notes on portrait projection" p.6
•Once installation is complete, make sure you set the Direction. Otherwise the
lamp's operating life may be reduced significantly.
s"Setting the direction" p.30
•Using the projector at an improper angle or setting the Configuration menu
incorrectly causes malfunctions and shortens the operating life of optical
parts.
Attention
•Make sure there is a gap at least as wide as shown in the following
illustration between the wall and the air exhaust vent and the air intake
vent.
Air exhaust vent Air intake vent
•When setting up multiple projectors, make sure there is a gap at least as wide
as shown in the following illustration between the projectors. Also, make sure
that the heat from the air exhaust vent does not go into the air intake
vent.
•Do not place the projector directly on top of another projector.
Safety Warning and Cautions
5

Attention
•When installing the projector on a surface other than the floor, use the four
ceiling mount fixing points to secure the projector. Never detach the handles.
If you use the projector without handles, it may cause a malfunction.
•When installing the projector on the ceiling, remove the feet and attach the
supplied foot covers.
•The feet can be attached and removed. Note that the feet will detach if they
are extended more than 10 mm.
After removing the feet, make sure you attach the supplied foot covers.
•Do not use the screw holes for the feet to secure the projector or attach other
screws, and so on. Otherwise malfunctions may occur.
a
•We recommend setting the focus, zoom, and lens shift at least 20
minutes after you start the projection, because images are not stable
right after turning on the projector.
•When adjusting the vertical lens shift, adjust by moving the image
from the bottom to the top. If it is adjusted from the top to the
bottom, the image position may move down slightly after adjusting.
Notes on portrait projection
An optional frame is required for portrait projection.
s"Optional Accessories" p.198
Attention
•When performing portrait projection, attach lamp units (for portrait use) on
both Lamp 1 and Lamp 2. If dedicated lamps are not used, the projector does
not cool down correctly, and it may cause a malfunction.
s"Optional Accessories" p.198
•Make sure you install the projector with the air intake vent facing down. If
the air intake vent is facing up, the projector does not cool down correctly,
and it may cause a malfunction.
Angle of tilt
Using the projector at angles not shown in the illustrations above may
damage it or cause an accident.
•Make sure that you install the projector with the air intake vent facing down
and that there is a gap at least as wide as shown in the following illustration
between the projector and the floor and so on.
Safety Warning and Cautions
6

a
•You cannot rotate the display direction for the menu, message, and
so on.
•When performing portrait projection, you do not need to set the
Direction.
•Power Consumption is disabled.
sSettings - Power Consumption p.121
Warning and Cautions on Usage
Warning
•Do not cover the projector's air intake vent or air exhaust vent. If either of
the vents is covered, the internal temperature could rise and cause a fire.
•Do not look into the lens while projecting.
Caution
Do not place objects that may become warped or otherwise affected by heat
near the air exhaust vent and do not put your face or hands near the vent
while projection is in progress.
Attention
•Do not repeatedly turn off the power and immediately back on. Turning the
power on and off frequently may shorten the lamp's operating life.
•Only remove the lens unit when necessary. If dust or dirt enters the
projector, projection quality deteriorates or it could cause a malfunction.
•Try not to touch the lens section with your hand or fingers. If fingerprints or
oils are left on the surface of the lens, projection quality deteriorates.
•Store the projector with the lens unit attached.
If the projector is stored without the lens unit, dust and dirt may get inside
the projector and cause malfunctions or lower the quality of projection.
•Do not store the projector with the front side facing up.
•When storing, make sure you remove the batteries from the remote control.
If the batteries are left in the remote control for an extended period of time,
they may leak.
Safety Warning and Cautions
7

Notes on Transporting
There are many glass parts and precision components inside the projector.
To prevent damage due to impacts when transporting, handle the projector
as follows.
Caution
The projector should not be carried by one person. Two people are needed to
unpack or carry the projector.
Attention
•When Moving Nearby
- Turn off the power to the projector and disconnect all cables.
- Attach the cover to the lens.
•When Transporting
After checking the points in "When Moving Nearby", prepare the following
and then pack up the projector.
- Retract the feet for storing.
- Remove the lens unit if an optional lens, other than the standard zoom
lens, is attached.
Attach the standard zoom lens if the projector has a built-in lens. If the
projector does not have a lens, attach the cover that was on the lens
mount when you purchased the projector.
- The vertical and horizontal lens shifts are positioned in the center.
- Enclose the projector securely in packaging material to protect it from
shock, and place it into a strong cardboard container. Be sure to notify
the carrier company that it is precision equipment.
Safety Warning and Cautions
8

Safety Instructions ..................................... 2
Introduction
PartNamesandFunctions .................................. 14
Front/Top...................................................14
Rear.......................................................15
Base......................................................16
Interface...................................................16
Controlpanel ................................................18
RemoteControl...............................................20
Replacingtheremotecontrolbatteries.............................23
Remotecontroloperatingrange................................. 24
Preparing the Projector
Installing the Projector ..................................... 26
AttachingtheProjectorLensUnit ..................................26
Attaching.................................................26
Removing.................................................27
AttachingandRemovingtheInterfaceCover ...........................28
Removing.................................................28
Attaching.................................................29
InstallationSettings............................................30
Settingthedirection.........................................30
Changingthedirectionoftheimage(Projection) ......................31
Selectingthelamp...........................................31
ScreenSettings...............................................32
Adjustingthepositionoftheimageontheprojectedscreen..............33
DisplayingaTestPattern........................................34
AdjustingthePositionoftheProjectedImage(Lensshift)..................35
Adjustingthetiltoftheprojectedimage(fornormalinstallment)...........36
AdjustingtheZoom............................................37
AdjustingtheFocus............................................37
WhenusingashortthrowzoomlensELPLU02 ........................ 38
IDSettings..................................................39
SettingtheprojectorID.......................................39
CheckingtheprojectorID......................................39
SettingtheremotecontrolID ................................... 40
Connecting Equipment ..................................... 41
ConnectingaComputer......................................... 41
ConnectingImageSources.......................................42
ConnectingtoanExternalMonitor ..................................44
ConnectingaLANCable.........................................45
ConnectinganHDBaseTTransmitter................................46
InstallingtheWirelessLANUnit(ELPAP07)............................47
UsingtheQuickWirelessConnectionUSBKey........................ 48
BatchSetup ............................................... 49
SetupUsingaUSBflashdrive.....................................49
SavingsettingstotheUSBflashdrive..............................49
Reflectingsavedsettingstootherprojectors.........................51
SetupbyConnectingtheComputerandProjectorwithaUSBCable...........53
Savingsettingstoacomputer ...................................53
Reflectingsavedsettingstootherprojectors.........................54
WhenSetupFails..............................................56
Basic Usage
ProjectingImages ......................................... 58
Automatically Detect Input Signals and Change the Projected Image (Search) . . . . 58
SwitchingtotheTargetImage .....................................59
AdjustingProjectedImages ................................ 60
CorrectingDistortionintheProjectedImage...........................60
H/V-Keystone..............................................61
QuickCorner ...............................................62
CurvedSurface.............................................63
PointCorrection............................................65
CornerWall ................................................ 67
SelectingtheProjectionQuality(SelectingColorMode)...................70
Contents
9

SettingAutoIris..............................................71
ChangingtheAspectRatiooftheProjectedImage.......................72
Changingmethods..........................................72
AdjustingtheImage...........................................76
AdjustingtheHue,Saturation,andBrightness........................76
Gammaadjustment..........................................76
Frame Interpolation (EB-Z10005U/EB-Z10000U/EB-Z9875U/EB-Z9870U/EB-
Z9750U only) . . ............................................78
Projecting3DImages...........................................78
Useful Functions
Multi-Projection Function . ................................. 80
Preparation.................................................80
EdgeBlending ............................................... 81
Adjusttheoverlappingareaoftheimages(EdgeBlending)...............81
Correctingthebrightness ......................................83
Fine-tuningthecolorbalance...................................85
CombiningScaledImages.......................................89
ProjectionFunctions ....................................... 91
ProjectingTwoImagesSimultaneously(SplitScreen)..................... 91
Operatingprocedures........................................91
Restrictionsduringsplitscreenprojection ...........................93
HidingtheImageTemporarily(Shutter)..............................94
FreezingtheImage(Freeze) ......................................95
EnlargingPartoftheImage(E-Zoom)................................95
SavingaUser'sLogo...........................................96
MemoryFunction .......................................... 98
Saving/Loading/ErasingtheMemory ................................98
SchedulingFunction ...................................... 100
SettingtheTime............................................. 100
SavingaSchedule ............................................ 101
Settingaschedule.......................................... 101
LampRelayMode.......................................... 102
Checkingaschedule........................................ 104
Editingaschedule.......................................... 105
Security Functions ........................................ 107
ManagingUsers(PasswordProtection).............................. 107
KindsofPasswordProtection .................................. 107
SettingPasswordProtection ................................... 108
EnteringthePassword....................................... 109
RestrictingOperation.......................................... 110
ControlPanelLock.......................................... 110
LensOperationLock........................................ 111
RemoteControlButtonLock................................... 111
Anti-TheftLock.............................................. 112
Installingthewirelock ....................................... 112
Configuration Menu
Using the Configuration Menu ............................. 114
ListofFunctions .......................................... 115
ConfigurationMenuTable ...................................... 115
NetworkMenu............................................ 116
ImageMenu ................................................ 117
SignalMenu................................................ 119
SettingsMenu...............................................121
ExtendedMenu .............................................. 122
NetworkMenu.............................................. 127
NotesonoperatingtheNetworkmenu ............................128
Softkeyboardoperations..................................... 128
Basicmenu...............................................129
WirelessLANMenu......................................... 130
Searchaccesspointscreen.................................... 131
Securitymenu.............................................132
WiredLANmenu ........................................... 133
Mailmenu............................................... 134
Othersmenu..............................................135
ResetMenu...............................................136
Contents
10

InfoMenu(DisplayOnly) ........................................136
ResetMenu.................................................138
Troubleshooting
UsingtheHelp ........................................... 140
Reading the Indicators . . . . . . .............................. 141
ReadingStatusMonitor ................................... 150
CheckingtheStatus........................................... 150
Understandingthescreen .....................................151
Settingthescreendisplay(LCD) .................................152
ExplanationsoftheDisplayContent................................153
ProblemSolving .......................................... 160
ProblemsRelatingtoImages..................................... 160
Noimagesappear.......................................... 160
Movingimagesarenotdisplayed................................160
Projectionstopsautomatically..................................161
Notsupported.isdisplayed....................................161
NoSignal.isdisplayed....................................... 161
Imagesarefuzzy,outoffocus,ordistorted ......................... 162
Interferenceordistortionappearinimages ......................... 162
The image is truncated (large) or small, the aspect is not suitable, or the image has
beenreversed............................................. 163
Imagecolorsarenotcorrect ................................... 164
Imagesappeardark......................................... 165
ProblemswhenProjectionStarts .................................. 166
Theprojectordoesnotturnon................................. 166
OtherProblems.............................................. 167
Theremotecontroldoesnotturnon............................. 167
Nothingappearsontheexternalmonitor.......................... 168
Iwanttochangethelanguageformessagesandmenus ................ 168
Emailisnotreceivedevenifaproblemoccursintheprojector ............ 168
Thebatterythatsavesyourclocksettingsisrunninglow.isdisplayed....... 169
CannotchangesettingsusingaWebbrowser....................... 169
EventID ................................................. 170
Maintenance
Cleaning ................................................. 172
CleaningtheProjector'sSurface ...................................172
CleaningtheLens............................................ 172
CleaningtheAirFilter..........................................172
ReplacingConsumables ................................... 175
ReplacingtheLamp........................................... 175
Lampreplacementperiod.....................................175
Howtoreplacethelamp......................................176
Resettingthelamphours..................................... 179
ReplacingtheAirFilter......................................... 179
Airfilterreplacementperiod................................... 179
Howtoreplacetheairfilter .................................... 179
ImageMaintenance ....................................... 181
PanelAlignment............................................. 181
ColorUniformity............................................. 183
Appendix
Monitoring and Controlling ............................... 186
AboutEasyMPMonitor ......................................... 186
AboutMessageBroadcasting.................................. 186
ChangingSettingsUsingaWebBrowser(WebControl) ...................186
Settingtheprojector........................................ 186
DisplayingtheWebControlScreen .............................. 187
UsingtheUsingMailNotificationtoReportProblems.................... 187
Readingerrornotificationemails................................ 188
ManagementUsingSNMP ...................................... 189
DisplayingtheWebRemoteScreen................................ 189
Operatingthelens ..........................................190
ESC/VP21Commands ..........................................191
Contents
11

Commandlist............................................. 191
Cablelayouts ............................................. 191
AboutPJLink ................................................192
About Crestron RoomView
®
..................................... 193
Operatingtheprojectorfromthecomputer.........................194
OptionalAccessoriesandConsumables .................... 198
OptionalAccessories.......................................... 198
Consumables ............................................... 199
Screen Size and Projection Distance ........................ 200
for EB-Z10005U/EB-Z10000U/EB-Z9875U/EB-Z9870U/EB-Z9750U/EB-Z11000W/EB-
Z9900W/EB-Z9800W . . . ....................................... 200
StandardzoomlensELPLS04................................... 200
ShortthrowzoomlensELPLU02................................. 201
RearprojectionwidelensELPLR04 ............................... 202
WidezoomlensELPLW04..................................... 203
MiddlethrowzoomlensELPLM06............................... 205
MiddlethrowzoomlensELPLM07............................... 206
LongthrowzoomlensELPLL07 ................................. 207
Projection Distances for EB-Z11005/EB-Z11000/EB-Z9870 . . . . . . . . . . . . . . . . . 208
StandardzoomlensELPLS04................................... 209
ShortthrowzoomlensELPLU02................................. 210
RearprojectionwidelensELPLR04 ............................... 211
WidezoomlensELPLW04..................................... 212
MiddlethrowzoomlensELPLM06............................... 213
MiddlethrowzoomlensELPLM07............................... 214
LongthrowzoomlensELPLL07 ................................. 216
SupportedMonitorDisplays ............................... 218
SupportedResolutions......................................... 218
Computersignals(analogRGB)................................. 218
Componentvideo.......................................... 218
Compositevideo........................................... 218
Input Signals from the DVI-D input port, HDMI input port, and HDBaseT port*
1
.
........................................................219
Input Signals from SDI Input Port(For EB-Z10005U/EB-Z10000U/EB-Z9875U/EB-
Z9870U only) . ............................................ 219
Specifications ............................................ 220
ProjectorGeneralSpecifications...................................220
Appearance .............................................. 225
Glossary ................................................. 226
GeneralNotes ............................................ 228
AboutNotations............................................. 228
TrademarksandCopyrights ......................................229
Index .................................................... 230
Contents
12

Introduction
This chapter explains the names for each part.

The illustrations in this guide are for projectors with the standard zoom
lens ELPLS04.
Front/Top
Name Function
AHandles Use these handles when carrying the projector. Also, you
can pass an anti-theft wire lock through the handle to
secure the projector.
s"Installing the wire lock" p.112
BSecurity slot ( )The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
s"Installing the wire lock" p.112
Name Function
CAir intake vent
(Air filter)
Takes in air to cool the projector internally. If dust collects
here it can cause the internal temperature to rise, and this
can lead to problems with operation and shorten the
optical engine's service life. Be sure to clean the air filter
regularly.
s"Cleaning the Air Filter" p.172
s"Replacing the Air Filter" p.179
DFront feet When setting up on a desk, turn to extend and retract to
adjust the horizontal tilt.
The front feet can be removed when the projector is
installed on a ceiling.
s"Adjusting the tilt of the projected image (for normal
installment)" p.36
ERemote receiver Receives signals from the remote control.
s"Remote control operating range" p.24
FInterface cover Remove this cover to connect cables to the ports inside
when connecting the projector to video equipment.
s"Interface" p.16
s"Attaching and Removing the Interface Cover"
p.28
GProjection lens Images are projected through here.
HInterface cover
removal switch
Operate this when removing the interface cover.
s"Attaching and Removing the Interface Cover"
p.28
IInterface cover
removal button
Operate this when removing the interface cover.
s"Attaching and Removing the Interface Cover"
p.28
JCable wiring slot (top) Remove the cover, and pass the cable up through here.
s"Attaching and Removing the Interface Cover"
p.28
KLens replacement
cover
Remove when attaching or removing the lens.
s"Attaching the Projector Lens Unit" p.26
Part Names and Functions
14

Name Function
LCeiling mount fixing
points
(4 points)
Attach the optional ceiling mount here when suspending
the projector from a ceiling.
s"Optional Accessories" p.198
Rear
Name Function
AAir exhaust vent
(Lamp cover)
Exhaust vent for air used to cool the projector internally.
Open this cover to replace the projector's lamps.
BRear feet When setting up on a desk, turn to extend and retract to
adjust the horizontal tilt.
The front feet can be removed when the projector is
installed on a ceiling.
s"Adjusting the tilt of the projected image (for normal
installment)" p.36
CLamp cover open lever Use this lever to open the lamp cover.
s"Replacing the Lamp" p.175
DRemote receiver Receives signals from the remote control.
s"Remote control operating range" p.24
EStatus indicators The color of the indicators and whether they are flashing
or lit indicate the status of the projector.
s"Reading the Indicators" p.141
FControl panel s"Control panel" p.18
Part Names and Functions
15

Base
Name Function
ACable wiring slot
(bottom)
Remove the cover, and pass the cable down through here.
s"Attaching and Removing the Interface Cover"
p.28
BFront feet s"Adjusting the tilt of the projected image (for normal
installment)" p.36
CRear feet s"Adjusting the tilt of the projected image (for normal
installment)" p.36
Interface
You can access the following ports by removing the interface cover. For
information on how to remove the interface cover and connect video
equipment, see the following.
s"Attaching and Removing the Interface Cover" p.28
s"Connecting Equipment" p.41
Name Function
ASDI input port
(For EB-Z10005U/EB-
Z10000U/EB-Z9875U/
EB-Z9870U only)
Inputs SDI signals from video equipment.
BBNC input port For analog RGB signals from a computer and component
video signals from other video sources.
CVideo input port For composite video signals from video sources.
Part Names and Functions
16

Name Function
DS-Video input port For S-video signals from video sources.
EComputer input port For analog RGB signals from a computer and component
video signals from other video sources.
FCable holder Insert the supplied cord clamp here to prevent the cord
from falling out.
GPower inlet Connects the power cord to the projector.
The shape may differ depending on your projector model.
HRemote port Connects the optional remote control cable set and inputs
signals from the remote control. When the remote control
cable is plugged into this port, the remote receiver on the
projector is disabled.
s"Optional Accessories" p.198
IRS-232C port When controlling the projector from a computer, connect
it to the computer with an RS-232C cable.
s"Serial connection" p.191
JService port This port is used by maintenance personnel to control the
projector. This is used for batch settings.
s"Batch Setup" p.49
Name Function
KWireless LAN unit port •Connects the optional wireless LAN unit.
s"Installing the Wireless LAN Unit (ELPAP07)"
p.47
•Connects the optional Quick Wireless Connection USB
Key.
s"Using the Quick Wireless Connection USB Key"
p.48
•This is used for batch settings.
s"Batch Setup" p.49
LMonitor out port Outputs analog RGB signals input from the Computer
input port or the BNC input port to an external monitor.
This is not available for component video signals or other
signals being input from any port other than the
Computer input port or the BNC input port.
s"Cable layouts" p.191
MHDMI input port Inputs image signals from HDMI compatible video
equipment and computers. This projector is compatible
with HDCP
g .
NCable holder Insert the supplied HDMI cable clamp here to prevent the
HDMI cable from falling out.
ODVI-D input port Inputs the computer DVI-D signals.
Part Names and Functions
17

Name Function
PLAN port Connects a LAN cable to connect to a network.
s"Connecting a LAN Cable" p.45
QHDBaseT port Connects a LAN cable to the optional HDBaseT
Transmitter.
s"Connecting an HDBaseT Transmitter" p.46
Control panel
Name Function
A[] button Press to turn on the projector.
B[t] button Press to turn off the projector.
CChange input buttons Press to change to signals from each input port.
s"Switching to the Target Image" p.59
The [SDI] button is only available for EB-Z10005U/EB-
Z10000U/EB-Z9875U/EB-Z9870U.
D[Auto] button If pressed while projecting analog RGB signals from the
Computer input port or the BNC input port, you can
automatically optimize Tracking, Sync., and Position.
Part Names and Functions
18

Name Function
E[Lens Shift] button Press to adjust the lens shift.
s"Adjusting the Position of the Projected Image (Lens
shift)" p.35
If pressed for more than five seconds, the lens position
returns to the center.
F[Zoom] button Press to adjust the zoom.
s"Adjusting the Zoom" p.37
G[Focus] button Press to adjust the focus.
s"Adjusting the Focus" p.37
H[Shutter] button Press to turn the signals on or off temporarily.
s"Hiding the Image Temporarily (Shutter)" p.94
I[Test Pattern] button Displays a test pattern.
s"Displaying a Test Pattern" p.34
J[] button If pressed while the Configuration menu or the Help
screen is displayed, it determines an item or moves to the
next level.
s"Using the Configuration Menu" p.114
K[][ ][ ][ ]
buttons
•Press to adjust focus, zoom, and lens shift.
s"Adjusting the Position of the Projected Image
(Lens shift)" p.35
s"Adjusting the Zoom" p.37
s"Adjusting the Focus" p.37
•If pressed when the Configuration menu or the Help
screen is displayed, menu items and setting values are
selected.
s"Using the Configuration Menu" p.114
L[Esc] button •Press to stop the current function.
•If pressed when the Configuration menu is displayed, it
returns to the previous menu level.
s"Using the Configuration Menu" p.114
M[] button Press to turn on or off the buttons on the control panel and
the status monitor.
Name Function
N[] button Press to display the Control Panel Lock screen allowing
you to make settings to lock the control panel buttons.
s"Restricting Operation" p.110
O[][ ][ ][ ]
buttons
Press to select the menu items and setting values for status
monitor to monitor the projector's status.
PStatus monitor Displays the projector's status by character information.
s"Reading Status Monitor" p.150
Q[Menu] button Press to display and close the Configuration menu.
s"Using the Configuration Menu" p.114
Part Names and Functions
19

Remote Control Name Function
A[] button Press to turn the projector on.
B[t] button Press to turn the projector off.
CChange input buttons Press to change to signals from each input port.
s"Switching to the Target Image" p.59
The [SDI] button is only available for EB-Z10005U/EB-
Z10000U/EB-Z9875U/EB-Z9870U.
D[Aspect] button Each time the button is pressed, the aspect mode changes.
s"Changing the Aspect Ratio of the Projected Image"
p.72
E[Auto] button If pressed while projecting analog RGB signals from the
Computer input port or the BNC input port, you can
automatically optimize Tracking, Sync., and Position.
F[Freeze] button Press to pause or unpause the images.
s"Freezing the Image (Freeze)" p.95
G[Test Pattern] button Displays a test pattern.
s"Displaying a Test Pattern" p.34
H[Lens Shift] button Press to adjust the lens shift.
s"Adjusting the Position of the Projected Image (Lens
shift)" p.35
If pressed for more than five seconds, the lens position
returns to the center.
I[Zoom] button Press to adjust the zoom.
s"Adjusting the Zoom" p.37
J[Menu] button Press to display and close the Configuration menu.
s"Using the Configuration Menu" p.114
Part Names and Functions
20
