Projection System
High-aperture Epson 3-chip 3LCD technology
Projection Method
Front/rear/ceiling mount
LCD
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
786,432 pixel x 3 LCDs (1024 x 768)
Native Resolution
XGA
Aspect Ratio
Supports 4:3, 16:9, 16:10
Pixel Arrangement
Cross stripe
Projection Lens
Type
Manual focus/zoom
F-number
1.64 – 2.5
Focal Length
21.27 mm – 37.93 mm
Zoom Ratio
Optical zoom 1.0 – 1.8
Screen
White Light Output*
4000 lumens (ISO 21118 Standard)
Color Light Output*
4000 lumens
Contrast Ratio (High Brightness, Game Mode)
Up to 1000:1
Brightness Uniformity (typical)
86%
Color Reproduction
16.7 million colors
Throw Ratio Range
1.64" – 2.5"
Size (projected distance)
30" – 300"
Lens Shift
Vertical: ±50 degrees
Horizontal: ±10 degrees
Keystone Correction
Vertical: -40 degrees to +40 degrees
Horizontal: -20 degrees to +20 degrees
Lamp
Type
210 W UHE
Lamp Life**
2000 hours (High Brightness Mode)
3000 hours (Low Brightness Mode)
Dimensions (W x D x H)
Including Feet (with standard lens)
18.5" x 13.26" x 5.94"
Excluding Feet, Lens
18.5" x 12.27" x 5.31"
Weight
14.55 lb
Effective Scanning Frequency Range
Pixel Clock
13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 KHz – 99 KHz
Vertical
50 Hz – 120 Hz
Remote Control
Features
Source search selection, power, aspect resize, color
mode, volume, e-zoom, A/V mute, freeze, menu,
page up and down, help, auto, mouse functions, ID
Operating Angle
Right/left ± 60 degrees
Upper/lower ± 20 degrees
Rear ± 30 degrees
Operating Distance
40 ft (6 m)
Display Performance
Native
1024 x 768
Resize
640 x 480
800 x 600
1280 x 1024
1400 x 1050
1600 x 1200
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line
(depends on observation of the multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/
SECAM
SDTV: 480i, 480p; HDTV: 720p, 1080i
Pixel works: video chip
3D Y/C separation, noise reduction motion
compensated
Interlace-Progressive conversion (2 – 2,
3 – 2 film detection)
Interfaces
Computer/component video: mini D-sub HD 15 pin x 2
S-video: mini DIN x 1
Composite video: RCA x 1, composite x 1 BNC
Audio in (RCA (L & R) x 1, mini stereo x 1)
Variable audio out: mini stereo x 1
LAN networking: RJ-45 x 1, 10/100MB
Serial: RS-232c x 1
Other Features
Operating Temperature
32 ˚ to 104 ˚F (0 ˚ to 40 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
0.6 W standby (343 W)
Fan Noise
35 dB (High Brightness Mode)
29 dB (Low Brightness Mode)
Security
Kensington®-style lock provision, anchor (metal) bar
for security lock or cable
Support — Epson ConnectionSM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Projector resources available at presentersonline.com
Service Programs
Two-year limited warranty, 90-day lamp warranty,
Epson Road Service Program and Epson PrivateLine®
dedicated toll-free support (U.S. and Canada only)
Contents
Power cable, computer cable, projector remote
control, batteries, user manual CD, Quick Setup Sheet,
PrivateLine support card, password protection sticker,
lens included
Accessory Part Numbers
Replacement lamp V13H010L47
Wireless mouse receiver for
Air filter V13H134A17
Replacement remote control 1485872
Advanced projector ceiling mount
with precision gear ELPMBPRG
Adjustable suspended ceiling channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column (pipe) 8” – 11” ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen (4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Distribution amplifier ELPDA01
Remote control (ELPST16) V12H007T16
Image presentation camera (ELPDC05) V12H162020
Projector Part Number
PowerLite G5000 V11H299020
(lens included)
Epson PowerLite G5000 Specifications
Packaging Specifications
PowerLite G5000
Dimensions 16.1" x 25.3" x 12.2" (W x D x H)
Weight 22.3 lb
Replacement Lamp
Dimensions 6.3" x 5.6" x 5.6" (W x D x H)
Weight 0.97 lb
Master Carton
Dimensions 28.4" x 13.1" x 6.8" (W x D x H)
Weight 11.7 lb
Units Per Master Carton 10
Replacement Air Filter
Dimensions 11.14" x 3.59" x 1.73" (W x D x H)
Weight 0.21 lb
Master Carton
Dimensions 19.17" x 11.78" x 4.84" (W x D x H)
Weight 3.09 lb
Units Per Master Carton 10
Specifications and terms are subject to change without notice. Epson and Quick Corner are registered trademarks and Epson Exceed Your Vision is a registered logomark of Seiko Epson Corporation. PowerLite and
PrivateLine are registered trademarks, Duet is a trademark and Epson Connection is a service mark of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their
respective companies. Epson disclaims any and all rights in these marks. Copyright 2008 Epson America, Inc. CPD-27029 11/08 PDF
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
** Light output varies depending upon modes (color and brightness) selected.
** Lamp life results will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
