Epson PowerLite 503c User manual

Convenient video connectivity
•Composite and S-video compatibility
•Picture-in-picture capability for simultaneous display of video
and computer presentations
Renowned Epson service and support
•Comprehensive two-year warranty
•90-day bulb warranty for added dependability
•EPSON PrivateLine®dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday – Friday. (calls are typically
answered live within 1 minute. This program is free for the
duration of the warranty.)
•EPSON Road Service Program provides a replacement projector,
typically within 24 hours. (this program is free for the duration
of the warranty.)
•International 2 year warranty in over 45 countries, offered
exclusively by Epson
Eleven hundred lumens and SVGA resolution in a
lightweight 5.8 lb package—when you size it all up, it’s the
perfect solution for highly effective mobile presentations. The EPSON
PowerLite 503c consistently delivers sharp, vivid computer and video
images, even in the most challenging lighting conditions. Take it across
the hall or around the world. Its award-winning EPSON 3-LCD design
and exceptional video processing make it the ideal partner for business
professionals. You get brilliant power and portability, without sacrificing
advanced features. And, with its easy setup and operation, even novice
users can be up and running in no time. Epson continues to contribute
technologically-advanced, user-friendly solutions and unquestionable
reliability. The EPSON PowerLite 503c—the perfect combination of
power and portability.
Ultra bright 1100 lumens
•Projects brilliant images, even in the most challenging lighting
conditions
Superior detail and razor-sharp contrast
•3-LCD technology offers three EPSON 0.9" high aperture LCDs
for evenly distributed color
•SVGA (800 x 600) resolution delivers sharp, vivid images and
astounding detail
•400:1 contrast ratio for blacker blacks and whiter whites
Compact and lightweight
•Only 5.8 lb, allowing travel flexibility for presentations of any
size, in any environment
•Compact size (10.5" x 2.8" x 8.4") designed to fit in your
computer bag
Easy installation, setup and operation
•15˚ digital keystone correction adjusts the angle, aspect ratio
and shape of projected images
•Zoom lens adds versatility
•EPSON SizeWiseTM resizing technology supports virtually any
computer from VGA to SXGA (1280 x 1024)
•Full-featured remote control
•USB mouse connection
•Auto setup tunes and optimizes your computer input
•Cable lock feature for security conscious environments
•Start Here Kit gets first-time users projecting in just minutes
CYAN
MAGENTA
YELLOW
BLACK
PMS 519C
PMS 5483C
EPSON®
EPSON PowerLite®503c
A brilliant combination of power and portability
full-featured
IR remote control
zoom lens
stylish metallic
silver finish
Front View
Back View
composite video
audio in/out
S-video
high performance,
low profile
audio left/right
HD15 computer input
PL503 cat sht 12809.qxd 9/18/01 9:38 AM Page 1

Video I/O
Display performance 600 TV line
Input signal
Video standard NTSC/NTSC4.43/NTSC50/
PAL/M-PAL/N-PAL/PAL60/SECAM
Video signal Composite video/S-video/video-RGB
Input terminal
Video RCA x 1/S-video x 1/Mini D-sub 15pin
Audio RCA x 2
Control I/O
Mouse/USB I/O Din 9pin x 1/USB type B x 1
Mouse compatibility PS/2, ADB, USB
Security
Kensington-style lock provision
Warranty
Standard two year limited warranty, 2 year international warranty, 90-day
lamp warranty, EPSON Road Service Program and EPSON PrivateLine
dedicated toll-free support (U.S. and Canada only)
Supply Accessories
Power cord, RCA video/audio cable, remote control, 2 batteries,
computer cable HD15/HD15, PS/2 mouse cable, USB mouse cable,
soft case, Start Here Kit
Product/Accessory Part Numbers
EPSON PowerLite 503c projector V11H058020
Replacement lamp ELPLP14
Soft shoulder bag ELPKS31
Notebook/projector soft shoulder bag ELPKS32
ATA molded hardshell case ELPKS30
Samsonite wheeled soft case (22" x 15" x 9") ELPKS35
Samsonite wheeled soft case (16.75" x 15" x 9") ELPKS24
(available November 2001)
Ceiling mount ELPMB32
Mac adapter set ELPAP01
Distribution amplifier ELPDA01
Screens
50" portable screen ELPSC06
60" insta-theatre screen ELPSC07
80" insta-theatre screen ELPSC08
Wireless microphone system ELPCVSII
Presentation audio system ELPPAS1
Kensington security lock ELPSL01
High resolution document imager ELPDC02
Motion presentation camera ELPDC03
Support-The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
SM
EPSON PowerLite 503c Specifications
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.9 inches
Driving method EPSON Poly-Silicon TFT Active Matrix
Pixel number 480,000 dots (800 x 600) x 3
Native resolution SVGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 2.0 to 2.2
f-number 35mm to 42mm
Zoom ratio 1.2
Lamp
Type 150W UHE
Life (typical) 1000 hours
Screen Width Ratio 1.83 to 2.23:1
Screen Size (Projected Distance) 26" to 300" (1.1m to 13.8m)
Keystone Correction Vertical: ±15 degrees
Brightness (Typical) 1100 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (Typical) 85%
Color Reproduction 24 bit; 16.7 mil
Sound Output 1W monaural
Operating Temperature 5º C to 35º C (41º F to 95º F)
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption 230W (5W at standby mode)
Maximum Dimensions
Including lens and feet 8.4"D x 10.5"W x 3.4"H
Excluding lens and feet 8.4"D x 10.5"W x 2.8"H
Weight 5.8 lb/2.6 kg
Fan Noise 42db
Effective Scanning Frequency Range
Pixel clock 13.5MHz to 162MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control Features
Keystone, picture in picture, special effects, source selection, power, resize,
right/left mouse click, volume, presets
RGB Analog RGB I/O
Display performance
Native 800 x 600
Resize 1280 x 1024
800 x 600
640 x 480
Input terminal
Video Mini D-sub 15pin
Audio Stereo mini jack
Output terminal
Audio Stereo mini jack
(common video/audio output)
(plug in, then speaker off)
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
