Epson PowerLite 505c User manual

Eleven hundred lumens in a convenient 6 lb package—
when you size it all up, the EPSON®PowerLite®505c is the perfect
solution for highly effective mobile presentations. Bright enough to
deliver brilliant performances, even in the most challenging lighting
conditions, this remarkable SVGA projector consistently delivers sharp,
vivid images. Take it across the hall or around the world. Its award-
winning 3-LCD design and exceptional video processing make it the
ideal partner for business professionals. Its innovative EPSON EasyMP™
technology facilitates PC-free presentations so you can leave your laptop
and cables behind without sacrificing advanced features. This technology
also delivers lightning-fast image renderings plus fifteen transitional
effects. And, with its “power-on-and-go” operation, even novice users
can be up and running in no time. Having contributed over 50 years of
engineering excellence to the business world, Epson continues to
provide technologically-advanced, user-friendly solutions like the
EPSON PowerLite 505c—the perfect combination of portability and
performance.
Ultra bright 1100 lumens
• Projects brilliant images, even in the most challenging lighting
conditions
Superior detail and razor-sharp contrast
• 3 LCD technology offers three 0.9" high aperture LCDs for
evenly distributed color
• SVGA (800 x 600) resolution delivers sharp, vivid detail
• 400:1 contrast ratio for blacker blacks and whiter whites
Compact and lightweight
• Only 6 lb, allowing travel flexibility for presentations of any size,
in any environment
PC-free presenting with EPSON EasyMP
• Auto-run capability—just power on the projector and begin
• Unique editing capability:
- Rearrange the order of projected images,
individually or as a group
- Select and hide individual images
- Customize your presentation to your audience
• Easy to use—drag and drop your entire
presentation using EPSON conversion software
• Smooth picture transitions—jpeg or bitmap
images advance as fast as 40 milliseconds,
either automatically or with a mouse click
• 15 PowerPoint®-type transitions—includes wipes,
dissolves, etc. for smooth, professional presentations
• Annotations—make notes and annotations directly on the image
and capture them for future reference
• Memory card slot—multicard capability including
PCMCIA Flash Memory, Compact Flash*, SmartMedia,*
and Memory Stick* cards
Component video input
• Great for movie viewing; the best video quality of any
superportable available
Easy installation, setup and operation
• Zoom lens adds versatility
• 15º digital keystone correction adjusts the angle, aspect ratio
and shape of projected images
• EPSON SizeWise™resizing technology supports virtually any
computer (Mac or PC) up to SXGA (1280 x 1024)
• Cool and quiet operation translates into longer lamp life and
lower total cost of ownership, and eliminates excessive sound
during presentations
Renowned Epson service and support
• Comprehensive 2-year warranty
• 90-day bulb warranty for added dependability
• EPSON PrivateLineSM dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday – Friday. This program is free
for the duration of the warranty
• EPSON Road Service Program provides a replacement projector,
typically within 24 hours. This program is free for the duration of
the warranty
• International warranty in over 45 countries, offered exclusively
by Epson
*PCMCIA adapter required, not included
EPSON®
CYAN
MAGENTA
YELLOW
BLACK
PMS 519
PMS 5483
EPSON PowerLite®505c
Powerful presentations made easy
Front View
Back View
high
performance,
low profile
audio L/R
full-featured
IR remote control
zoom lens
stylish metallic
silver finish
component video
s-video
audio in/out
EasyMP PC
card slot
PL 505c Cat Sheet c11600 2/5/01 4:53 PM Page 1 (2,1)

EPSON PowerLite 505c Specifications
Projection System EPSON original LCD prism technology
Projection Method Front/rear/ceiling mount
LCD
Size 0.9"
Driving method EPSON Poly-Silicon TFT Active Matrix
Pixel number 480,000 dots (800 x 600) x 3
Native resolution SVGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom/focus
F-number 2.0 to 2.2
f-number 35 to 42mm
Zoom ratio 1:1.2
Lamp
Type 150W UHE
Life (typical) 1000 hours
Screen Width Ratio: (Distance/Width) 1.83 to 2.23:1
Screen Size (Projected Distance) 26" to 300" (1.1m to 13.8m)
Keystone Correction ±15 degrees
Brightness (typical) 1100 ANSI lumens
Contrast Ratio 400:1
Brightness Uniformity (typical) 85%
Color Reproduction 24 bit; 16.7 mil
Sound Output 1W Monaural
Operating Temperature 5°C to 35°C (41°F to 95°F)
Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC
Power Consumption 230W (5W at standby mode)
Dimension (including lens and feet) 10.5"D x 8.4"W x 3.4"H
Weight 6.0 lb/2.7kg
Fan Noise 42db
Effective Scanning Frequency Range
Pixel clock 13.5MHz to 160MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control Features
Keystone, picture in picture, special effects, source selection, power, resize,
right/left mouse click, volume, presets
RGB Analog RGB I/O
Display performance
Native 800 x 600
Resize 1280 x 1024
1024 x 768
640 x 480
Input terminal
Video Mini D-sub 15pin
Audio Stereo mini jack
Output terminal
Audio Stereo mini jack
(Common video audio output)
(plug-in, then speaker-off)
Video I/O
Display performance 600 TV Line
Input signal NTSC/NTSC4.43/NTSC50/
PAL/M-PAL/N-PAL/PAL60/SECAM
Input terminal
Video RCA x 1
S-Video x 1
Mini D-sub 15pin
Audio RCA x 2
Output signal 0 - 500m Vrms / 600ohm
Output terminal Stereo mini jack
(common analog RGB audio output)
(plug-in, then speaker-off)
Control I/O
Mouse/serial I/O
I/O terminal Din 9pin x 1 / USB type B x 1
Mouse compatibility PS/2, ADB, USB
Security
Kensington-style lock provision
Warranty
Standard two year limited warranty, international warranty, 90-day lamp
warranty, EPSON Road Service Program and EPSON PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cord, RCA video/audio cable, remote control, 2 batteries, computer
cable HD15/HD15, PS/2 mouse cable, USB mouse cable, soft case, memory
card set (8MB Compact Flash memory card), application software CD-ROM
(slidemaker for EasyMP), Start Here Kit
Product/Accessory Part Numbers
EPSON PowerLite 505c Projector EMP-505
Replacement lamp ELPLP14
Component video cable ELPKC19
Samsonite wheeled soft case ELPKS35
Slimline soft shoulder bag ELPKS31
Notebook/projector soft shoulder bag ELPKS32
ATA molded hardshell case ELPKS30
Screens
50" portable screen ELPSC06
60" insta-theatre screen ELPSC07
80" insta-theatre screen ELPSC08
Mac adapter set ELPAP01
Kensington security lock ELPSL01
Ceiling mount ELPMB32
Suspension adapter for ceiling mount, 11/2" pipe ELPMBAST
Suspension adapter for ceiling mount, 1" pipe ELPMBAPS
Presentation audio system ELPPAS1
Wireless microphone system ELPCVS1
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
550 McNicoll, Willowdale, Ontario M2H 2E1
Epson Latin America
6303 Blue Lagoon Drive, Miami, FL 33126
Specifications and terms are subject to change without notice. EPSON is a registered trademark and EasyMP is a trademark of Seiko Epson Corporation. PowerLite is a registered trademark, SizeWise is a trademark
and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks of their respective
companies. Epson disclaims any and all rights in these marks. © Copyright 2001 Epson America, Inc. CPD-11600 50K 2/01 LG Printed on Recycled Paper
