Epson Powerlite 713c User manual

Convenient video connectivity

•Composite and S-video compatibility

•Picture-in-picture capability for simultaneous display of video

and computer presentations

Renowned Epson service and support

•Comprehensive two-year warranty

•90-day bulb warranty for added dependability

•EPSON PrivateLine®dedicated toll-free support line available

from 6 a.m. to 6 p.m. PST Monday – Friday (calls are typically

answered live within 1 minute. This program is free for the

duration of the warranty.)

•EPSON Road Service Program provides a replacement projector,

typically within 24 hours (this program is free for the duration

of the warranty.)

•International 2 year warranty in over 45 countries, offered

exclusively by Epson

Twelve hundred lumens and XGA resolution in a

lightweight 5.8 lb package—when you size it all up, it’s the

perfect solution for highly effective mobile presentations. The EPSON

PowerLite 713c consistently delivers sharp, vivid computer and video

images, even in the most challenging lighting conditions. Take it across

the hall or around the world. Its award-winning EPSON 3-LCD design

and exceptional video processing make it the ideal partner for business

professionals. You get brilliant power and portability, without sacrificing

advanced features. And, with its easy setup and operation, even novice

users can be up and running in no time. Epson continues to contribute

technologically-advanced, user-friendly solutions and unquestionable

reliability. The EPSON PowerLite 713c—the perfect combination of

portability and performance.

Ultra bright 1200 lumens

•Projects brilliant images, even in the most challenging lighting

conditions

Superior detail and razor-sharp contrast

•3-LCD technology offers three EPSON 0.9" high aperture LCDs

for evenly distributed color

•XGA (1024 x 768) resolution delivers sharp, vivid images and

astounding detail

•400:1 contrast ratio for blacker blacks and whiter whites

Compact and lightweight

•Only 5.8 lb, allowing travel flexibility for presentations of any

size, in any environment

•Compact size (10.5" x 2.8" x 8.4") designed to fit in your

computer bag

Easy installation, setup and operation

•15˚ digital keystone correction adjusts the angle, aspect ratio

and shape of projected images

•Zoom lens adds versatility

•EPSON SizeWiseTM resizing technology supports virtually any

computer from VGA to UXGA (1600 x 1200)

•Full-featured remote control

•USB mouse connection

•Auto setup tunes and optimizes your computer input

•Cable lock feature for security conscious environments

•Start Here Kit gets first-time users projecting in just minutes

CYAN

MAGENTA

YELLOW

BLACK

PMS 519C

PMS 5483C

EPSON®

EPSON PowerLite®713c

Bright, light, and built to last

full-featured

IR remote control

zoom lens

stylish metallic

silver finish

Front View

Back View

composite video

audio in/out

S-video

high performance,

low profile

audio left/right

HD15 computer input

PL713 cat sht 12808.qxd 9/18/01 9:37 AM Page 1

Video I/O

Display performance 750 TV line

Input signal

Video standard NTSC/NTSC4.43/NTSC50/

PAL/M-PAL/N-PAL/PAL60/SECAM

Video signal Composite video/S-video/video-RGB

Input terminal

Video RCA x 1/S-video x 1/Mini D-sub 15pin

Audio RCA x 2

Control I/O

Mouse/USB I/O Din 9pin x 1/USB type B x 1

Mouse compatibility PS/2, ADB, USB

Security

Kensington-style lock provision

Warranty

Standard two year limited warranty, 2 year international warranty, 90-day

lamp warranty, EPSON Road Service Program and EPSON PrivateLine

dedicated toll-free support (U.S. and Canada only)

Supply Accessories

Power cord, RCA video/audio cable, remote control, 2 batteries,

computer cable HD15/HD15, PS/2 mouse cable, USB mouse cable,

soft case, Start Here Kit

Product/Accessory Part Numbers

EPSON PowerLite 713c projector V11H057020

Replacement lamp ELPLP14

Soft shoulder bag ELPKS31

Notebook/projector soft shoulder bag ELPKS32

ATA molded hardshell case ELPKS30

Samsonite wheeled soft case (22" x 15" x 9") ELPKS35

Samsonite wheeled soft case (16.75" x 15" x 9") ELPKS24

(available November 2001)

Ceiling mount ELPMB32

Mac adapter set ELPAP01

Distribution amplifier ELPDA01

Screens

50" portable screen ELPSC06

60" insta-theatre screen ELPSC07

80" insta-theatre screen ELPSC08

Wireless microphone system ELPCVSII

Presentation audio system ELPPAS1

Kensington security lock ELPSL01

High resolution document imager ELPDC02

Motion presentation camera ELPDC03

Support-The Epson ConnectionSM

Pre-Sales Support U.S. and Canada 800-463-7766

Automated Technical Support 800-922-8911

Internet Web Site www.epson.com

EPSON PowerLite 713c Specifications

Projection System EPSON original LCD prism technology

Projection Method Front/rear/ceiling mount

LCD

Size 0.9 inches

Driving method EPSON Poly-Silicon TFT Active Matrix

Pixel number 786,432 dots (1024 x 768) x 3

Native resolution XGA

Aspect ratio 4:3 (supports 16:9, 5:4)

Pixel arrangement Stripe

Projection Lens

Type Manual: zoom/focus

F-number 2.0 to 2.2

f-number 35mm to 42mm

Zoom ratio 1.2

Lamp

Type 150W UHE

Life (typical) 1000H

Screen Width Ratio 1.83 to 2.23:1

Screen Size (Projected Distance) 26" to 300" (1.1m to 13.8m)

Keystone Correction Vertical: ±15 degrees

Brightness (Typical) 1200 ANSI lumens

Contrast Ratio 400:1

Brightness Uniformity (Typical) 85%

Color Reproduction 24 bit; 16.7 mil

Sound Output 1W monaural

Operating Temperature 5º C to 35º C (41º F to 95º F)

Power Supply Voltage 100-120V, 200-240V ±10%, 50/60Hz AC

Power Consumption 230W (5W at standby mode)

Maximum Dimensions

Including lens and feet 8.4"D x 10.5"W x 3.4"H

Excluding lens and feet 8.4"D x 10.5"W x 2.8"H

Weight 5.8 lb/2.6 kg

Fan Noise 42db

Effective Scanning Frequency Range

Pixel clock 13.5MHz to 162MHz

Horizontal 15KHz to 92KHz

Vertical 50Hz to 85Hz

Remote Control Features

Keystone, picture in picture, special effects, source selection, power, resize,

right/left mouse click, volume, presets

RGB Analog RGB I/O

Display performance

Native 1024 x 768

Resize 1600 x 1200

1280 x 1024

800 x 600

640 x 480

Input terminal

Video Mini D-sub 15pin

Audio Stereo mini jack

Output terminal

Audio Stereo mini jack

(common video/audio output)

(plug in, then speaker off)

Epson America, Inc.

3840 Kilroy Airport Way, Long Beach, CA 90806

Epson Canada, Ltd.

550 McNicoll, Willowdale, Ontario M2H 2E1

Epson Latin America

6303 Blue Lagoon Drive, Miami, FL 33126
