Equinox Systems Explo Strobe EX-2500 User manual

User manual
www.prolight.co.uk
EX-2500
(Order code: STRO14)

WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
CAUTION!
Keep this equipment away from rain,
moisture and liquids.
SAFETY INSTRUCTIONS
Every person involved with the installation, operation & maintenance of this
equipment should:
- Be competent
- Follow the instructions of this manual
CAUTION! TAKE CARE USING THIS EQUIPMENT!
HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!
Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the
equipment.
To maintain the equipment in good working condition and to ensure safe operation, it is necessary
for the user to follow the safety instructions and warning notes written in this manual.
Please note that damages caused by user modifications to this equipment are not
subject to warranty.
Equinox EX-2500 Safety

Equinox EX-2500 Safety
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused
by the non-observance of this manual or any unauthorised modification to the
equipment.
• Never let the power-cable come into contact with other cables. Handle the
power-cable and all mains voltage connections with particular caution!
• Never remove warning or informative labels from the equipment.
• Do not open the equipment and do not modify the equipment.
• Do not connect this equipment to a dimmer-pack.
• Do not switch the equipment on and off in short intervals, as this will reduce the
system’s life.
• Only use the equipment indoors.
• Do not expose to flammable sources, liquids or gases.
• Always disconnect the power from the mains when equipment is not in use or before
cleaning! Only handle the power-cable by the plug. Never pull out the plug by pulling
the power-cable.
• Make sure that the available voltage is between 220v/240v.
• Make sure that the power-cable is never crimped or damaged. Check the equipment
and the power-cable periodically.
• If the equipment is dropped or damaged, disconnect the mains power supply
immediately. Have a qualified engineer inspect the equipment before operating again.
• If the equipment has been exposed to drastic temperature fluctuation (e.g. after
transportation), do not switch it on immediately. The arising condensation might
damage the equipment. Leave the equipment switched off until it has reached room
temperature.
• If your product fails to function correctly, discontinue use immediately. Pack the unit
securely (preferably in the original packing material), and return it to your Prolight
dealer for service.
• Only use fuses of same type and rating.
• Repairs, servicing and power connection must only be carried out by a qualified
technician. THIS UNIT CONTAINS NO USER SERVICEABLE PARTS.
• WARRANTY; One year from date of purchase.
OPERATING DETERMINATIONS
If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.
Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.
Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property.
Please note: When used as a blinder effect, the unit can not be used with a 13A plug and
must be wired directly to the mains power supply. Please consult a qualified electrician for
connection advice.

Equinox EX-2500 Operations
Remote control operation:
To operate the EX-2500 strobe using the remote control, first plug the EC-3 remote controllers 1/4”
stereo jack cable (signal) into the “INPUT” Jack socket on the underside of the unit. Finally plug
the unit into an appropriate mains power supply.
Please be sure to set all of the manual control knobs to the off position and refer to the strobe
controller user manual for operation.
If you wish to connect a second strobe, first plug the 1/4” stereo jack signal cable into the “OUT-
PUT” socket on the first (master) unit. Now plug the opposite end of the 1/4” stereo jack signal
cable to the “INPUT” socket on the second (slave) unit.
To link further units together in a daisy chain fashion, repeat the above steps.
Note: For the best results only use the EC-3 remote controller. Always follow the controller
user manual specifications regarding the maximum number of strobes that can be linked to
one controller.
Daisy chain linking:

Equinox EX-2500 Operations
EX-2500 Overview:
Identification:
1, Power Supply
2, Fuse
3, 1/4” Stereo Jack Output
4, 1/4” Stereo Jack Input
EC-3 Overview
Identification:
1, Blinder control knob
2, Flash control knob
3, Intensity control knob
4, Cycle mode button
5, Fade/Wink button
6, Normality/Blinder button
TOP VIEW BOTTOM VIEW
5M Remote Cable

Equinox EX-2500 Operations
EC-3 Operations:
For normal strobe operation:
Make sure all three switches and indicators are OFF, you can now adjust the “INTENSITY” and
“FLASH SPEED” controls to your desired setting. The strobe will now function as normal, the
speed can be adjusted from 1 to 25 flashes per second.
For use as a blinder:
Blinder mode 1:
Press the “BLINDER” button and the “WINK” button, you can now adjust the intensity and
the blinder rate (timer). The blinder will now wink ON and OFF at regular intervals set by the
“BLINDER RATE” control.
Blinder mode 2:
If you press the “BLINDER” button but not the “WINK” button, the strobe will now fade down
during the blinder operation.
You can also use the “CYCLE” button in both blinder modes. With the “CYCLE” button pressed
when you press the “BLINDER” button it will only activate the blinder once for each time you
press the “BLINDER” button.
The “BLINDER RATE” button adjusts the length of time the blinder is illuminated from 0.2 to a
maximum of 1 second.

EX-2500 Specifications:
EC-3 Specifications:
Equinox EX-2500 Specifications
Lamp
Blinding Rate
Flash speed
Dimming
Signal Connector
Control mode
Fuse
Power Consumption
Power Supply
Dimensions
Weight
ST-2500
0.2 - 1 second
1-25fps
0-100%
1/4” stereo jack
EC-3 remote
NFB 20A
3000W (12A) Strobe, 4000W (16A) Blinder effect
240V
442 x 114 x 242mm
3.5Kgs
Output signal
Maximum load
Signal Connector
Fuse
Power Consumption
Power Supply
Dimensions
Weight
DC 10V
10 Strobes
1/4” stereo jack
N/A
0.5W
DC 12V
120 x 65 x 35mm
0.6Kgs
