Operation Manual
For
Sodir
½ Size Convection Oven– FC-60, FC-60G
765 Westminster Street Providence, Rhode Island 02903 U.S.A.
Tel: [phone] Fax: [phone]
www.equipex.com e-mail: [e-mail]

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed, including the
following:
1. Read all the instructions before use.
2. Do not touch hot surfaces; use handles or knobs.
3. To avoid electric shock, do not immerse the power cord, or any part of the unit, in any liquid.
4. Close supervision is necessary when any appliance is used, especially around children.
5. Unplug appliance from the electrical outlet when not in use, and before cleaning. Allow appliance
to cool before installing or removing any parts or accessories, and before cleaning.
6. Do not operate any appliance with a damaged cord or plug, or if appliance should sustain
damage, or malfunction in any way. In this event, return appliance to the nearest authorized
service facility for examination, repair or adjustment.
7. The use of accessories and/or attachments not recommended by the appliance manufacturer
may cause injury or damage to the appliance, and may void your warranty.
8. Do not use outdoors.
9. Do not allow the power cord to hang over the edge of a table or counter, or to be exposed to hot
surfaces, as damage may occur.
10. Do not place appliance on or near a burner, or in a heated oven.
11. To disconnect an appliance, first turn all controls to the ‘off’ position; then unplug the power cord
from the wall outlet.
12. Do not use appliance other than for its intended use.
13. SAVE THESE INSTRUCTIONS FOR LATER USE!

INTRODUCTION
The SODIR model FC-60 and FC-60 G convection ovens are designed to offer quality
baking, cooking and reheating. The ovens are constructed of food service quality
stainless steel, and are equipped with a rear-mounted blower fan and heating
element, and, in the case of the FC-60 G, top mounted infrared quartz heating
elements for salamander style finishing. The units are thermostatically controlled up
to 480 F, with a 120-minute timer and constant on position. Two indicator lights, green and
orange, (three for FC-60 G) add convenience for the operator. Units include four wire-
baking racks. All models will accommodate up to four 1/2-size sheet pans or two 1/3-size
cafeteria pans.
Specifications:
Model Electrical Plug
Configuration
FC-60 208/240V, 1 PH, 3.3KW, 13/15A NEMA-6-20P
FC-60/1 120V, 1PH, 1.7KW, 14A NEMA-5-15P
FC-60 G 208/240V, 1PH, 3.3KW, 13/15A NEMA-6-20P
FC-60 G/1 120V, 1PH, 1.7KW, 14A NEMA-5-15P
INSTALLATION
The SODIR convection oven needs to be connected to a grounded outlet of proper
voltage, 208/240V or 120V, depending on the model. DO NOT place the unit in a
damp area or near steam sources. Make sure that the exterior rear ventilation panel
is not blocked. Maintain 4” clearance at each side, rear and top of the oven.
ASSEMBLY
The SODIR convection comes from the factory assembled, but with the 4”
adjustable legs removed for shipping. It is shipped with plastic exterior protective
film, which must be removed before operation. DO NOT operate the oven prior to
installing the 4” legs and protective film completely.

OPERATION
Preheating
To preheat the convection oven, select the desired temperature by rotating the thermostat knob
clockwise to the desired temperature setting and then turn the timer knob, that also acts as
an ON/OFF switch, clockwise to the maximum setting (120 minutes), or counterclockwise to
the constant on position. The FC-60 G has a third knob for mode selection, convection mode
for normal cooking, quartz infrared top heaters for salamander type operations or fan only for
cool-down mode. Both indicator lights (green and orange) will be lit. The orange light will stay
on until the oven reaches the desired temperature, and then cycle on and off. The green light
will stay on until the timer expires. Allow about 20 minutes for the preheating process.
Cooking
After the preheat process is completed, select the desired temperature (unless it is already
set) and turn the timer knob to select the time setting. When the set time is elapsed, the
heating element and the blower fan will be switched off and the indicator lights will go out.
The timer bell will chime repetitively, announcing the end of the cycle, until the timer button is
pressed in to silence it. To use the oven in continuous mode, turn the timer knob
counterclockwise to the position marked by the hand pictograph.
The SODIR convection ovens can be used for a wide variety of foods. Cooking times will vary
depending on food products, temperature settings and desired results.
Cleaning
WARNING: Disconnect (unplug) electrical power supply before cleaning
Cleaning is very important in maintaining a safe and well working machine. Allow the oven to
cool before cleaning. Remove the baking racks and clean them separately using a damp
cloth or sponge and mild liquid soap. Use a cloth dampened slightly with a soap and water
mixture to clean all exterior and interior stainless steel surfaces. Use a clean lint-free cloth to
remove the excess water or soap. Make sure no water enters the unit through ventilation
holes.
DO NOT use an abrasive sponge on exterior or interior surfaces
DO NOT wash the oven under running water
DO NOT spray the exterior motor housing with any liquid
DO NOT allow water to drip into the motor housing or onto electrical
components

Oven Door Removal
The SODIR Models FC-60, FC-60/1, FC-60 G and FC-60 G/1 are equipped with a double glass
door which is easily removable for cleaning.
For cleaning, remove the door following the steps
below:
• Open the door completely
• Move each hinge lock to “UP” position, engaging the “J” hook of the long arm (one lock per
hinge)
• Tilt the door up at 45 – 60 degree angle (hinge lever arm will be released)
• Pull the door out of the hinge slots
Upon removal, the door can be washed or cleaned, both on the inside and on the outside. To
install the door, reverse the procedure. Insure that the bottom of the hinge cutout fits into the
notch on the bottom of the hinge. Move the hinge lock to the “down” position to restore
proper hinge operation. DO NOT leave the hinge lock in “UP” position at the end of
installation.
Maintenance
You should inspect all parts on a regular basis to ensure that all is in proper working order. If a
part is damaged, have the unit repaired by an authorized service agency prior to returning the
unit to operation. If you have trouble locating a service agency in your area, please consult our
website at http://www.equipex.com/, or call us at 1-800-649-7885 and ask for customer service.

Spare Parts FC-60 and FC60/1

DWG # Part # QTY Description
1 15124|308 1 Top casing
2 15111|108 1 Ventilation Cover
3 15016|308DR 1 Right side panel
4 A18022 1 Lamp with fixture 220V
4 A18021 1 Lamp with fixture 120V
5 H03005 1 Door Gasket
6 F01039 2 Shelf Rail
7 B09005 2 Door Hinge
8 A02028 1 120min timer with bell
9 A14078 2 Knob
10 H01012 1 Interior Glass
11 H01011 1 Exterior Glass
12 A15010 1 Handle
13 F01035 4 Wire Shelf
14 A13005 4 Leg
15 15017G010 1 Bottom Panel
16 A08009 1 Green Pilot Light 220 V
16 A08007 1 Green Pilot Light 120 V
17 A08003 1 Orange Pilot Light 220 V
17 A08004 1 Orange Pilot Light 120 V
18 A06042 1 RegulatingThermostat
19 B09007 2 Hinge support
20 A06035/1 1 Hi-limit thermostat
21 15016|308GA 1 Left Side Panel
22 D02034 1 Heating element 220V
22 D02041 1 Heating element 120V
23 A03001 1 Motor 220V
23 A03003 1 Motor 120V
24 15018G010 1 Back Cover
Light Cover 1 Light Cover
OEM60L1 1 120V Lamp
OEM60L2 1 220V Lamp
H0FC60DC 1 Door Complete
A16013 1 Terminal Block, 3 Position
90021 4 BakingPan (25 7/8" x17 7/8")

Spare Parts FC-60 G and FC60 G/1

DWG # Part # QTY Description
115124|308 1Top casing
215111|108 1Ventilation Cover
315016|308DR 1Right side panel
4A18022 1Lamp with fixture 220V
4A18021 1Lamp with fixture 120V
5H03005 1Door Gasket
6F01039 2Shelf Rail
7B09005 2Door Hinge
8A02028 1120min timer with bell
9A01014 1Mode Switch
10 A14078 2Knob
11 H01012 1Interior Glass
12 H01011 1Exterior Glass
13 A15010 1Handle
14 F01035 4Wire Shelf
15 A13005 4Leg
16 15017G010 1Bottom Panel
17 A08009 1Green Pilot Light 220 V
17 A08007 1Green Pilot Light 120 V
18/19 A08003 1Orange Pilot Light 220 V
18/19 A08004 1Orange Pilot Light 120 V
20 A06042 1Regulating Thermostat
21 B09007 2Hinge support
22 A06035/1 1Hi-limit thermostat
23 15016|308GA 1Left Side Panel
24 D04016 3Quartz Tube
25 D02034 1Heating element 220V
25 D02041 1Heating element 120V
26 A03001 1Motor 220V
26 A03003 1Motor 120V
27 15018G010 1Back Cover
28 D04028 3IR Quartz with Element 220V
28 D01031 3IR Heating Element 120V
A09001 6Ceramic Insulator for IR
OEM60L1 1120V Lamp
OEM60L2 1220V Lamp
A16013 1Terminal Block, 3 Position
H0FC60DC 1Door Complete
90021 4Baking Pan (25 7/8" x 17 7/8")

LIMITED WARRANTY
Your new EQUIPEX product is warranted to the original purchaser for a period of one year from the date of purchase.
This limited warranty is against defects from original factory imperfections in material and/or workmanship
and includes labor for replacement of defective parts, provided repairs are performed by an authorized service
agency. Our obligation under this warranty is limited to repairing or replacing any part or parts thereof. The
CUSTOMER must inform the Service Agency of warranty coverage and provide a copy of the dated sales or
delivery receipt BEFORE WARRANTY REPAIRS BEGIN. Replacement parts and accessories are warranted for
ninety (90) days from the date of purchase when purchased separately and will be verified by dated sales receipt or
packing slip for that item. All parts or accessories replaced under warranty must be returned to the Service Agency.
This warranty applies only to equipment under normal use and service in the U.S.A. and Canada. It does not
apply to any item which has been repaired or altered in any way so as, in the judgment of EQUIPEX, to affect its
reliability.
THE FOLLOWING ARE NOT COVERED UNDER WARRANTY:
1. Damage caused by abuse, misuse or dropping or other similar incidental damage caused by, or as a
result of, customer failure to follow assembly, operation, cleaning, user maintenance or storage
instructions.
2. Labor to replace inoperative parts such as bulbs, plugs or racks due to normal wear and tear or abuse.
3. Materials or labor to repair scratched, stained, chipped, pitted, dented or discolored surfaces, attachments or
accessories.
4. Transportation charges to or from a service agency for repair of your machine. If you should have
questions relating to this issue, please call Equipex at 1-800-649-7885.
5. Labor charges to install or test attachments or accessories, which are replaced for any reason.
6. SHIPPING DAMAGES. Visible and hidden damages are the responsibility of the freight carrier.
The consignee must file the claim promptly against the carrier. KEEP ALL ORIGINAL
CONTAINERS AND PACKAGING MATERIAL FOR CARRIER INSPECTION.
7. Products placed or stored in the equipment are not subject to this warranty and no responsibility is
assumed thereof.
THIS WARRANTY IS GIVEN EXPRESSLY AND IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED
OR IMPLIED, FOR MERCHANTABILITY AND FOR FITNESS TOWARD A PARTICULAR PURPOSE AND
CONSTITUTES THE ONLY WARRANTY MADE BY EQUIPEX, LLC. IT NEITHER ASSUMES, NOR AUTHORIZES
ANY PERSON TO ASSUME FOR US, ANY OTHER LIABILI TY IN CONNECTION WITH THE SALE OF THE
SUBJECT EQUIPMENT.
For service, please call EQUIPEX at 1-800-649-7885, menu option # 3
765 Westminster Street Providence, Rhode Island 02903 U.S.A.
Tel: [phone] Fax: [phone]
www.equipex.com e-mail: [e-mail]
