Eraser L Series User manual

MODEL L (SERIES) WIRE STRIPPERS & LEAD CLEANERS
Please Read Before Operating Unit
Operating Manual
Please Call for Service or Spare Parts
The Eraser Company, Inc.
PO Box 4961
Syracuse, NY 13221, USA
Phone: [phone]
Fax: [phone]
Website: www.eraser.com
E-mail: [e-mail]

p 2
Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • [e-mail] • www.eraser.com • Fax [phone]
MODEL L4
MODEL PL3S
SPECIFICATIONS
WIRE STRIPPING
Wire Size:
L2S & L4 .................................. 29-8 AWG (0.28-3.25mmø)
PL3S ...................................... 29-14 AWG (0.28-1.63mmø)
L2AS .......................................... 8-4 AWG (3.25-5.18mmø)
Maximum Strip Length:
L2S .... 3-1/2” (89mm); 1-5/16” (33.3mm) with strip length stop
L2AS ....1-1/2” (38mm); 1-5/16” (33.3mm) with strip length stop
PL3S .............1-3/8” (34.9mm) no strip length stop available
L4 ........................ 3” (76.2mm) no strip length stop available
COMPONENT LEAD CLEANING
Lead Diameter....................0.0112”-0.114” (0.28-2.90mmø)
Cleaning length ................................ Up to 2-1/2” (63.5mm)
Close-up cleaning ................Flush with component body or
length stop permits precise cleaning of only part of lead
ALL APPLICATIONS
Decibel rating
L2S, L2AS, PL3S ...................................................58 dB(A)
L4 .........................................................................100 dB(A)
Power
L2AS .........................................1/15 HP motor, 120V 60Hz
L2S, PL3S...................................1/7 HP motor, 120V 60Hz
L4 .............Clean lubricated air up to 90 P.S.I. at 32 C.F.M.
Size
L2S, L2AS, PL3S ........................................11” x 6” x 7-1/4”
(114mm x 203mm x 178mm)
L4 ........................................... 1-3/4” diameter x 8-1/4” long
(44mmø x 210mm)
Weight
L2S, L2AS, PL3S ............................................11 lbs. (5 Kg)
L4 .....................................................................2 lbs. (910g)
ORDERING INFORMATION
BENCH Rotary Insert Wire Stripper
AR2051 (L2S)....................................................... 120V 60Hz
AR2071 (L2AS) ....................................................120V 60Hz
PORTABLE Rotary Insert Wire Stripper
AR2061 (PL3S) ....................................................120V 60Hz
AR0180 (L4) ........... Air operated; up to 90 P.S.I. at 32 C.F.M.
IR0104............................. Chuck assembly for 3/8” (9.5mmø)
diameter inserts for use on L2S, PL3S & L4
IR0106........................... Chuck assembly for 1/2” (12.7mmø)
diameter inserts for use on L2AS & L4A
INSERTS ........................................ see insert selection guide
REPLACEMENT PARTS
TR0630........................ Collet nut for chuck assembly IR0104
TR5086........................ Collet nut for chuck assembly IR0106
PR3878.........Double angle collet for chuck assembly IR0104
IR7823.......................... Sheath and shaft assembly for PL3S
PR0253......................................................... Sheath for PL3S
PR0254............................................................ Shaft for PL3S
TR8329.........................................................Length Stop Rod
PG2508 ......................L1, L2S, PL3, L4 Wrench (2) Required
PR3742................................ L2AS, L4A Wrench (2) Required
ROTARY INSERT WIRE
STRIPPERS & LEAD CLEANERS
MODEL L2AS
MODEL L2S

p 3
Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • [e-mail] • www.eraser.com • Fax [phone]
INSERT SELECTION GUIDE
Most inserts are available in two grades of material - Heavy Duty and Tungsten Carbide tipped. Under normal use in a cost
basis, the most expensive grade will give the best cost versus insert life (i.e. carbide is better than standard). Concave face
permits easy wire entry, at face permits stripping ush to the coil body and bullet nose permits stripping in conned areas.
ROTARY INSERT WIRE
STRIPPERS & LEAD CLEANERS
WIRE SIZE HEAVY DUTY GRADE INSERTS MACHINE
USED ON
Concave Face Flat Face Bullet Nose
29-24 AWG (0.28-0.51mmø) L30HC-IR1951 L30HF-IR1961 L30HB-IR1981
L1, L2S,
PL3S, L4
24-20 AWG (0.51-0.81mmø) L35HC-IR1952 L35HF-IR1962 L35HB-IR1982
20-16 AWG (081-1.30mmø) L31HC-IR1953 L31HF-IR1963 L31HB-IR1983
15-13 AWG (1.45-1.83mmø) L33HC-IR1954 L33HF-IR1964 L33HB-IR1984
13-11 AWG (1.83-2.31mmø) L38HC-IR1955 L38HF-IR1965 L38HB-IR1985
L2S, L411-9 AWG (2.31-2.90mmø) L34HC-IR1956 L34HF-IR1966 L34HB-IR1986
9-8 AWG (2.90-3.25mmø) L37HC-IR1957 L37HF-IR1967 N/A
8-6 AWG (3.25-4.11mmø) L39HC-IR1958 L39HF-IR1968 N/A L2AS, L4A
IR0106
5-4 AWG (4.62-5.18mmø) L40HC-IR1959 L40HF-IR1969 N/A
WIRE SIZE CARBIDE TIPPED INSERTS MACHINE
USED ON
Concave Face Flat Face Bullet Nose
29-24 AWG (0.28-0.51mmø) L30CC-IR9007 L30CF-IR9008 L30CB-IR9009
L1, L2S,
PL3S
24-20 AWG (0.51-0.81mmø) L35CC-IR9017 L35CF-IR9018 L35CB-IR9019
20-16 AWG (081-1.30mmø) L31CC-IR9027 L31CF-IR9028 L31CB-IR9029
15-13 AWG (1.45-1.83mmø) L33CC-IR9037 L33CF-IR9038 L33CB-IR9039
13-11 AWG (1.83-2.31mmø) L38CC-IR9047 L38CF-IR9048 L38CB-IR9049 L2S IR0104
L4
11-9 AWG (2.31-2.90mmø) L34CC-IR9057 L34CF-IR9058 N/A
FLAT FACE BULLET NOSE
S* S* S*
1 1/4”
(32mm) 1 1/4”
(32mm)
1/32”
(0.79mm)
3/8”
(9.5mm)
CONCAVE
3/8”
(9.5mm)
3/8”
(9.5mm)
1/2”
(12.7mm)
3/4”
(19 mm)
3/16”
(4.8mm)
L2S, PL3S & L4 L2S, PL3S & L4
*“S” dimensions are determined by wire size to be stripped.
L2S, PL3S & L4

p 4
Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • [e-mail] • www.eraser.com • Fax [phone]
IMPORTANT! DO NOT OPERATE MACHINE UNTIL
YOU HAVE READ THOROUGHLY, AND UNDERSTAND
COMPLETELY, ALL PRECAUTIONS, INSTRUCTIONS
AND INFORMATION ON THESE PAGES. THIS
MANUAL CONTAINS IMPORTANT SAFETY AND
OPERATING INSTRUCTIONS. IT SHOULD BE
RETAINED WITH THE MACHINE FOR FUTURE
REFERENCE.
SAFETY PRECAUTIONS - MECHANICAL
! DO NOT OPERATE UNIT WITHOUT GUARDS IN
PLACE OR WITH DAMAGED GUARDS.
! DO NOT DEFEAT ANY OF THE SAFETY FEATURES.
! DO NOT PLACE FINGERS OR APPENDAGES NEAR
MOVING PARTS OR IN OR NEAR OPENINGS IN
GUARDS.
SAFETY PRECAUTIONS - ELECTRICAL
! ALWAYS UNPLUG UNIT FROM POWER SUPPLY
PRIOR TO ANY MAINTENANCE.
! DO NOT RUN UNIT WITH INCORRECT LINE
VOLTAGE.
! NEVER RUN MACHINE WITH DAMAGED OR WORN
POWER CORD.
! NEVER MODIFY THE PLUG PROVIDED. IF IT WILL
NOT FIT INTO THE OUTLET, HAVE THE PROPER
OUTLET INSTALLED BY A QUALIFIED ELECTRICIAN.
GROUNDING INSTRUCTIONS. Grounding provides a
common return path for electric current to reduce the
risk of electric shock. This machine is supplied with an
electric cord with an equipment-grounding conductor
and a grounding plug. The plug must be plugged into a
matching outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Check
with a licensed electrician if in doubt as to whether the
machine is properly grounded.
SAFETY FIRST - USE BEST PRACTICES
ALWAYS USE SAFETY GLASSES. Everyday
eyeglasses only have impact resistant lenses; they are
NOT safety glasses. Also use face or dust mask if cutting
operation
is dusty.
REMOVE ADJUSTING KEYS AND WRENCHES. Form a
habit of checking to see that keys and adjusting wrenches
are removed from machine before turning it on.
KEEP WORK AREA CLEAN. Cluttered areas and
benches invite accidents. Always leave at least 12” (305
mm) of space around all sides and top of unit.
DON’T USE IN DANGEROUS ENVIRONMENTS. Do not
use or locate machine in high-humidity environments, or
expose to rain. Keep work areas well lighted.
WEAR PROPER APPAREL. Do not wear loose clothing,
such as gloves, neckties, rings, bracelets, necklaces
or any other clothing or jewelry that might get caught
in moving parts. This is not an all-inclusive list. Wear
protective hair covering to contain long hair. Non-slip
footwear is recommended.
DON’T OVERREACH. Maintain proper footing and
balance at all times.
MAINTAIN BLADES WITH CARE. Keep blades sharp
and clean for optimal performance. Follow instructions for
lubricating and changing blades and all accessories.
DISCONNECT MACHINE FROM POWER SUPPLY.
Unplug the unit before servicing and when changing
accessories.
DO NOT EXCEED THE UNIT’S MAXIMUM MATERIAL
SPECIFICATIONS. Eraser’s warranty will be null and void
if machine has been used in any manner that is contrary
to these instructions.
CHECK FOR DAMAGED PARTS. Before continued use
of the machine, the guard and all moving parts should be
carefully inspected to ensure that nothing is damaged.
Ensure proper alignment of moving parts. Check for any
binding of moving parts, breakage of parts, and any other
condition(s) that may a󰀨ect operation. Any damaged
part(s) should be properly repaired or replaced prior to
any continued use of the machine.
ONLY ALLOW TRAINED AND QUALIFIED
PERSONNEL TO OPERATE UNIT. Always keep these
instructions within reach of the machine.
USE RECOMMENDED ACCESSORIES ONLY. Consult
this operating manual for recommended accessories. Use
only parts supplied by The Eraser Company, Inc. Use of
improper accessories will void Eraser’s warranty and may
increase risk of injury.
ALL REPAIRS SHOULD BE PERFORMED BY AN
ERASER COMPANY REPRESENTATIVE ONLY.
Unauthorized disassembly of machines will void Eraser’s
warranty.
WHEN USING MACHINERY, ALL SAFETY
PRECAUTIONS – INCLUDING, BUT NOT LIMITED TO,
THOSE LISTED ABOVE - SHOULD BE FOLLOWED
TO REDUCE THE RISKS OF FIRE, ELECTRIC SHOCK,
AND PERSONAL INJURY, AND DEATH.
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS

p 5
Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • [e-mail] • www.eraser.com • Fax [phone]
L SERIES MODEL WIRE STRIPPERS & LEAD CLEANERS
OPERATING MANUAL
AIR SUPPLY:
Model L4 only
The L4 requires a clean, lubricated air supply which
can deliver 3 C.F.M. at 90 PSI. Attach an air tting of
the proper style to the end of the air hose to enable
it to be connected to the air supply. If the optional
PR0003 combination air/lter/lubricator is being used,
the air hose of the L4 should be connected to the
output side of this and the air supply connected to the
other side.
! CAUTION: Never operate the L4 at an air pressure
higher than 90psi.
OPERATION:
NOTE: Safety glasses or other suitable eye protection
should be worn when using these units.
Models L2S, L2AS, PL3S:
The L2S, L2AS, and PL3S may be operated with
either clockwise or counter-clockwise motor rotation.
This feature facilitates longer insert life. When an
insert begins to wear, reverse the rotation to utilize the
opposite stripping edges of the insert. To change the
direction of motor rotation, turn o󰀨 power to the unit, and
then press the switch located on the rear of the unit.
Turn the unit on. Insert the wire into the stripping insert.
The wire will strip while being pushed in, not while
being withdrawn. If the wire does not strip, turn the
unit o󰀨, remove the guard and use the collet adjusting
wrenches to tighten the insert further. Replace the
guard and try the wire again. Repeat this procedure as
often as necessary until a satisfactory strip is achieved.
If using the strip length stop (models L2S or L2AS
only) insert the wire until it butts against the stop, then
withdraw. Once set, the unit may be used continuously.
OPERATION (PL3S Only):
! CAUTION: Do not bend the exible shaft
assembly tighter than a 4” radius. Permanent
damage will result.
Keep the unit clean and free of insulation dust, and
replace inserts when worn. No other maintenance is
required.
Replace the collet assembly with stripping insert and
the plastic guard.
After replacing the collet assembly and guards on the
unit, connect the unit to the power supply.
SET-UP:
INSERT INSTALLATION:
Installation of the stripping insert into the collet is the
same for all models except where specied.
Remove the guard. Models L2S and L2AS have a
plastic guard. Models PL3S, and L4 have a metal
guard.
The collet has two parts. The rst holds the stripping
insert and is mounted on the motor shaft by use of
a set screw. The second part screws onto the rst
part and varies the pressure on the insert to allow
adjustability for di󰀨erent wire sizes. It is not necessary
to remove the collet assembly from the motor shaft to
install the stripping insert. Unscrew the front part of the
collet from the insert holder. Slide the insert into the
holder, aligning the slots in the insert with the slots in
the holder.
On Models L2S, PL3S and L4, the insert should
protrude 1/8” - 3/16” (3.1 - 4.8mm) from the front of the
collet. Screw the front part of the collet back on and
nger tighten. Slide a sample of the wire to be stripped
into the insert. Use the collet adjusting wrenches in
the ats on the collet to tighten the collet down until
the sample wire is tight in the insert. Remove the wire.
Replace the guard.
On the L2AS, push the insert all the way in until it
stops. There is a small at on the rear of all 1/2” inserts
used on these units. This feature will prevent the insert
from slipping in the collet during stripping. The insert
should be oriented so that the at is aligned with the
small set screw located on the outside of the collet.
Push the insert into the collet until it seats on the inside
shoulder of the collet, then tighten the set screw down
on the at using the Allen wrench provided with the
unit. For proper operation, ensure that the stripping
insert is seated on the shoulder inside the collet and
the set screw engages the at on the stripping insert.
STRIP LENGTH STOP:
Models L2S and L2AS only
Models L2S and L2AS have a strip length stop rod that
protrudes from the motor shaft and is held in place by
a small set screw on the motor shaft. Using the larger
of the 3 Allen wrenches provided, loosen the set screw
holding the collet assembly to the motor shaft, and
slide the assembly o󰀨 the shaft. Adjust the strip length
rod to the desired position using the smaller of the
Allen wrenches provided.

p 6
Eraser Company Inc. • Syracuse, NY USA • Ph: 315-454-3237 • [e-mail] • www.eraser.com • Fax [phone]
GROUND LOCATION
This protective Earth ground label is
located inside the housing beside the
ground wire. This wire is connected to
the Power Supply Cable and is wired
back through the Mains supply to
ground.
CAUTION LABEL
Refer to the operating instructions
before using this unit. High voltage
is inside this unit and power must be
disconnected before servicing.
ON/OFF LABEL
This is the ON/OFF switch. Press I
for on and press O for o󰀨. This switch
is also the anti-start switch. In case
of power outage, this switch must be
reset for the unit to operate.
ROTATION DIRECTION
Rotation of the head may be reversed
by pressing this rotation switch.
SYMBOLS:
Models L4
The L4 will only operate with counter-clockwise
rotation. Depress the handle to start the unit and insert
the wire into the insert. The wire will strip as it is being
inserted, not as it is being withdrawn. If the wire does
not strip, release the handle, remove the metal guard
and use the collet adjusting wrenches to tighten the
insert. Replace the guard and strip the wire again.
Repeat this procedure as often as necessary until a
satisfactory strip is achieved.
The L4 model has a slotted motor adjusting screw
located on the bottom of the unit near the air intake
end. The speed of the motor may be adjusted slightly
by turning the screw.
MAINTENANCE:
Models L2S, L2AS, PL3S
Keep the unit clean and free of insulation dust, and
replace inserts when worn. No other maintenance is
required.
Model PL3S only
It may be necessary to replace the exible shaft
assembly periodically.
To replace the assembly unsnap the handpiece
assembly from the exible shaft assembly by pulling
apart. Unscrew the motor coupling from the motor
ange and remove the casing from the core of the
exible shaft. Remove the 4 screws attaching the
motor ange to the motor and slide the ange ahead of
the brass coupling.
NOTE: Be careful not to lose the spacers behind the
ange washer.
Remove the brass coupling from the motor shaft by
unscrewing the locking screw and sliding it o󰀨. Replace
the new exible core and casing and reverse the
operations. When reinstalling the motor ange, be sure
the ange washer and spacers are relocated correctly
within the motor housing and the screw holes are
properly aligned.
NOTE: When reinstalling the handpiece onto the
exible shaft assembly, the key on the core must align
with the groove in the handpiece. It may be necessary
to rotate the collet assembly to properly align the
handpiece.
Model L4
The L4 unit should be lubricated DAILY with a turbine
or spindle grade oil containing a rust inhibitor with a
viscosity of 100 to 150 S.U.S. at 100° F. To lubricate,
unscrew the air hose from the back of the unit and
pour 2-3 drops of oil directly into the intake port of the
unit. The handle hinge pin should also be lubricated
periodically, using a drop of lightweight oil. Replace
inserts when worn, and keep unit clean and free of
insulation dust.
IMPORTANT: NO LIABILITY WILL BE INCURRED
BY THE ERASER CO. FOR INJURY, DEATH, OR
PROPERTY DAMAGE CAUSED BY A PRODUCT
WHICH HAS BEEN SET UP, OPERATED, AND/OR
INSTALLED CONTRARY TO ERASER’S WRITTEN
INSTRUCTION MANUAL, OR WHICH AS BEEN
SUBJECTED TO MISUSE, NEGLIGENCE, OR
ACCIDENT, OR WHICH HAS BEEN REPAIRED OR
ALTERED BY ANYONE OTHER THAN THE ERASER
COMPANY, OR WHICH HAS BEEN USED IN A
MANNER OR FOR A PURPOSE FOR WHICH THE
PRODUCT WAS NOT DESIGNED.
L SERIES MODEL WIRE STRIPPERS & LEAD CLEANERS
OPERATING MANUAL

TROUBLE SHOOTING:
PROBLEM: Wire does not strip
SOLUTIONS:
1) Check that insert size is correct for wire being
stripped.
2) Tighten collet on insert.
3) Check that slots of insert are aligned with slots of
collet.
4) Check that insert is pushed back far enough into the
collet.
5) Check if insert is worn, and replace.
PROBLEM: Wire breaks when inserted
SOLUTIONS:
1) Loosen collet on insert.
2) Check that insert size is correct for wire being
stripped.
3) Check that there are no kinks or bends in the wire.
Wire must be straight going into the insert.
PROBLEM: Motor does not run (Model L4 only)
SOLUTIONS:
1) Check that air supply is adequate, 90 PSI, 3 C.F.M.
2) Check the motor adjusting screw on underside of unit
to ensure it is open. This screw orients an internal air
port.
IR5322
REV 10/21
p 7
L SERIES MODEL WIRE STRIPPERS & LEAD CLEANERS
OPERATING MANUAL
Phone: [phone]
Fax: [phone]
Website: www.eraser.com
E-mail: [e-mail]
The Eraser Company, Inc.
PO Box 4961
Syracuse, NY 13221, USA
