Eraser BTS1 User manual

BTS1 Thermal Wire Stripper
The Eraser Company, Inc.
PO Box 4961/ Oliva Drive
Syracuse, NY 13221, USA
Pho e: [phone] / Fax: [phone]
Website: www.eraser.com
E-mail: i [e-mail]
Service and All Spare Parts Available
Operating Manual
Please Read Before Operating Unit
Always Moving Forward
Eraser International Ltd.
U it M, Hu ti g Gate
A dover SP10 3SJ, E gla d
Pho e: [phone] / Fax: [phone]
Website: www.eraser-i ter atio al.com
Email: sales@eraser-i ter atio al.com

Ordering Information:
AR0111...Thermal Wire Stripper, 115V 60Hz
AR0112......Thermal Wire Stripper,
220/240V 50Hz Europea plug
AR0113Thermal Wire Stripper
220/240V 50Hz UK plug
Optional Parts/Accessories:
IR1474.....O e Pair Small Die Eleme t Set
(.050, .080, a d .102 Diameters)
IR1475........O e Pair Large Die Eleme t Set
(.120, .140, a d .160 Diameters)
IR1479.........Right A gle Adaptor Kit
IR1491.........Foot Pedal Assembly
AA0004.........Brass Eraser Brush to Clea Eleme ts
Replacement Parts:
IR1473.........O e Pair Sta dard
Replaceme t Eleme t Set
PG0920.........Replaceme t Fuse
U it may be fitted with a timer if eeded.
Service a d all spare parts available.
BTS1 THERMAL
WIRE STRIPPER
Eraser Company Inc.  Syracuse, NY USA  Ph: 315-454-3 37  [email protected]  www.eraser.com  Fax [phone]
Eraser International Ltd.  England  Ph:(01 64)351347  [email protected]  www.eraser-international.com  Fax [phone]
Specifications:
Wire Size:
36 AWG - 1 AWG (0.013mmø - 7.34mmø)
or up 1/2 OD (12.7mmø) over i sulatio
Strip Le gth:
0 To 1½ (38.1mmø) or u limited with optio al
90° Eleme t Adaptors
Operatio :
By ha d or with optio al electric footswitch
Power:
I put via fused IEC Co ector, variable
temperature co trol,
115V 60Hz or 220/240V 50Hz
Size:
7-9/16H x 5-5/16W x 14-1/8D
(192mm x 135mm x 359 mm)
Weight:
2.2 lbs. (5.5 Kg)
PRODUCT WARRANTY
Eraser warra ts all of its machi es to be free from
defects of materials or workma ship, u der mor al
a d proper use a d service. The warra ty is for 1 year
from the date of delivery to the buyer.
PURC ASE DATE
(TO BE FILLED IN BY BUYER)

Model BTS1 Thermal Wire Stripper
OPERATING INSTRUCTIONS
Eraser Company Inc.  Syracuse, NY USA  Ph: 315-454-3 37  [email protected]  www.eraser.com  Fax [phone]
Eraser International Ltd.  England  Ph:(01 64)351347  [email protected]  www.eraser-international.com  Fax [phone]
Setup:
Place the BTS1 on a surface at a comfortable work height.
Set the temperature control to zero and the on/off switch to
off on front panel then plug the power cord into the I.E.C.
outlet in the rear of the unit and the other end into an
appropriate power outlet. For optional foot control operation
place the footswitch on the floor then plug it into the appliance
outlet in the rear of the unit. Switch the unit on using the on/
off switch on the front panel.
Strip Length Setting
Set strip length by rotating the black knurled knob located
along the left side of the lower element assembly (see
Figure 1). Move the length stop plate in or out as required by
rotating the knurled knob.
Temperature Setting
With the temperature control setting on the control panel at
0 slowly turn the knob up until the elements soften and cut
the insulation. Excessive temperature causes greater oxida-
tion of the elements and can create fumes from burning
insulation. Ideally the temperature control should be set at
the minimum temperature required to removes the slug from
the conductor. As a rough guide Teflon insulation strips at
approximately an 80% setting where as PVC insulation might
strip with as low as a 30% setting. Once the temperature is
set for a given insulation the temperature setting will have the
same effect for all similar insulation materials.
Element Depth Setting
Set the element depth with the element depth control knob
located in the center of the upper element assembly (see
Figure 1). The element depth should be set so the element
cuts through the insulation but clears the conductor. Once
the element depth is determined lock the elements by
tightening the set screw located on the front of the upper
element assembly block. For elements with precut notches
(optional factory die elements) simply adjust the element
depth knob so that the upper and lower elements meet. Once
the element depth setting is adjusted to a given wire diameter
it shouldnt require further adjustment until a new wire
diameter is introduced.
Operation:
After determining the best stripping temperature insert wire
between elements to the length stop plate press down on a
ball knob located on either side of the upper element assem-
bly (optionally depress footswitch). Rotate the wire in the
elements to cut the entire circumference of insulation then
pull steadily on the wire with the elements still closed. The
insulation slug will fall away and the wire will have the set
stripped length removed. Dont tug or yank sharply on the wire
as it may damage the conductor or bend the elements. If the
insulation slug doesnt come off the conductor cleanly adjust
the element depth knob (located in the center of the upper
element assembly) or adjust the temperature until you
achieve the desired results.
Maintenance:
IMPORTANT NOTE: Always turn the unit off disconnect the
power cord and wait until the elements have cool down before
servicing the unit. Clean insulation build-up from stripping
elements periodically with an AA0004 Brass Eraser Brush.
Ensure the element retaining screws are always tight to
ensure good electrical contact with the electrode bars. Also
periodically clean the contact area of the electrode bars and
the elements of any oxidation build-up with the Brass Eraser
Brush.
Installing the optional 90 degree adaptors:
Turn the unit off and disconnect the power cord. (Always wait
until the elements have cooled down before servicing the
unit). Remove the elements from the ends of the electrode
bars by removing the four retaining screws. Remove the clear
guard by first removing the element depth control knob
remove the knob by loosening the set screw located on the
collar of the knob then pulling it off the threaded shaft. Remove
the three button head screws securing the clear guard. Adjust
the length stop so that its position is as far back as it will go.
All the adaptors pieces are identical fasten the adaptors to
the elements creating two adaptor assemblies (see Figure 2).
Fasten the adaptor assemblies to the vertically tapped holes
near the ends of the electrode bars using the screws and
washers provided. Fasten one assembly to the top of the
upper element electrodes and one to the bottom of the lower
element electrodes.
Troubleshooting:
PRO LEM: Unequal heating of elements.
1. Remove elements and clean oxide from contact points.
2. Retighten screws tightly.
PRO LEM: Poor stripping results.
1. Check element for wear or corrosion.
2. Clean or replace as needed.
PRO LEM: Unit does not operate.
1. Ensure unit is plugged into appropriate power source.
2. Check fuse. Replace if blown. Unplug power while
verifying.
IMPORTANT: No liability will be incurred by The Eraser
Company for injury death or property damage caused by a
product which has been set up operated and/or installed
contrary to Erasers written instruction manual or which has
been subjected to misuse negligence or accident or which
has been repaired or altered by anyone other than Eraser or
which has been used in a manner or for a purpose for which
the product was not designed.

Eraser International Ltd.
U it M, Hu ti g Gate
A dover SP10 3SJ, E gla d
Pho e: [phone] / Fax: [phone]
Website: www.eraser-i ter atio al.com
Email: sales@eraser-i ter atio al.com
The Eraser Company, Inc.
PO Box 4961/ Oliva Drive
Syracuse, NY 13221, USA
Pho e: [phone] / Fax: [phone]
Website: www.eraser.com
E-mail: i [e-mail]
IR1477
REV8/02
LENGTH
STOP
WIRE TO E
STRIPPED
STRIP LENGTH
ADJUSTMENT
ELEMENT DEPTH
ADJUSTMENT
FIGURE 1
FIGURE 2
90° ELEMENT ADAPTORS FOR
UNLIMITED STRIP LENGTH
CLOSE UP OF 90° ELEMENT ADAPTORS
