Electric Standing Desk
Instruction Manual
Technical Support:
(US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST)
(UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC)
Other Info: [e-mail]
Website: https://ergear.com
EGESD11B / EGESD11W
Rev01(A)

Specifications
Height Adjustment Range
27.9”–46.4” (71–118cm)
Power Input
100V–240V Max Speed 25mm/s Operating Noise <50dB Max Load 132 lbs / 60kg
RATED
Step 1
Supplied Parts
and Hardware
01 x 1
Desktop
02 x 2
Desk Leg
Bolt
M6 x 14mm
Ax 8
Bolt
M6 x 14mm
Ax 8
Bolt
M5 x 10mm
Cx 4
B1 x 1
Large Allen Wrench
5/32” (4mm)
B1 x 1
Large Allen Wrench
5/32” (4mm)
B2 x 1
Small Allen Wrench
1/8” (3mm)
Step 2
Supplied Parts
and Hardware
Leg Base
03 x 2
Step 3
Supplied Parts
and Hardware
Step 4
Supplied Parts
and Hardware
Motor Connection Cable
05 x 1
Power Cable
06 x 1
Power Connection Box
07 x 1
Storage Hook
04 x 2
08 x 4
Cable Clip
01 02 03 04 05 07 08 09 10
06

Step 1 Attaching the Legs to the Desktop
Soft Cloth
(not included)
B1
A
02
02
01
01 02 03 04 05 07 08 09 10
06

Step 2 Attaching the Leg Bases
B1
A
03
03
01 02 03 04 05 07 08 09 10
06

Step 3 Attaching the Storage Hooks
B2
C
04
04
01 02 03 04 05 07 08 09 10
06

Step 4 Connecting the Cables
Motor CableMotor Cable
Motor CableMotor Cable
Motor CableMotor Cable
05
05
05
08
06
07
05
Motor
Cable
06 07
01 02 03 04 05 07 08 09 10
06

07
07
01 02 03 04 05 07 08 09 10
06

Using the Controller
Raise the Desk
Press the button to raise the desk continuously until it reaches the
highest position of 46.4”(118cm) or the button is released.
Lower the Desk
Press the button to lower the desk continuously until it reaches the
lowest position of 27.9”(71cm) or the button is released.
USB Output
(5V 1A)
USB-C Output
(9V 2A)
Tip: Reset before first use.
Save Current Height Setting
Press the button and the screen will display ‘S-.’ Then press the , ,
, or button to save the current height to that button. When you press
, , , or button, the desk will move to the height that was previously
set for that button.
M
4
4
Set Highest Height Limit
1. Press the button, and the screen will display ‘S-.’
2. Press and hold the button until ‘S-’ flashes once, and then release the
button.
3. Quickly press and hold button again for 2 seconds, and ‘999’ will be
displayed on the screen. Setting the highest limit is complete.
M
M
Set Lowest Height Limit
1. Press the button, and the screen will display ‘S-.’
2. Press and hold the button until ‘S-’ flashes once, and then release the
button.
3. Quickly press and hold button again for 2 seconds, and ‘00.0’ will be
displayed on the screen. Setting the lowest limit is complete.
M
M
Main Settings
01 02 03 04 05 07 08 09 10
06

Clear Highest/Lowest Height Limit
1. Press the button, and the screen will display ‘S-.’
2. Press and hold button again for 2 seconds, and ‘555’ will be displayed
on the screen. Clearing the highest/lowest limit is complete.
M
M
Lock/Unlock
1. To turn the lock on, press and hold the button, and the screen will
display ‘S-,’ the current height, and then ‘LOC.’ The buttons will be disabled.
2. To turn the lock off, press and hold button for 8 seconds, and the
screen will display current height. The buttons will be operable again.
Reset
1. Press and hold the button until the desk goes down to its lowest level,
and then release the button.
2. Press and hold button for 5 seconds until the screen displays ‘RST,’ and
then release the button with ‘RST’ flashing.
3. Press and hold button again until the desk goes down to its lowest
level and comes back up slightly. Reset is complete.
M
M
01 02 03 04 05 07 08 09 10
06

Change Display Height Units
Press and hold the button for 5 seconds to switch the display height
units.
10.3: Metric (cm)
10.4: Imperial (inch)
Change Collision Detection Sensitivity
Press and hold the button for 5 seconds to switch sensitivity level.
10.5: High Sensitivity
10.6: Medium Sensitivity
10.7: Low Sensitivity
Change Displayed Minimum Height
If you attach a different desktop or add other things that change the desk
surface level, you can adjust the displayed height to match. Press and
hold the button for 5 seconds, and current minimum height will flash on
the screen. Press the or button to adjust the minimum height, and
then release the button to save. After 5 seconds, the screen will show ‘RST’
again. Saving is successful.
M
To adjust the settings below, follow the reset instructions until the
screen displays ‘RST.’ Next, follow the instructions for adjusting individual
settings. Afterward, the screen will display ‘RST’ again. To exit, press and
hold the button until the desk goes down to its lowest level and
comes back up slightly or goes up to its highest level and comes back
down slightly. The screen will display the current height.
Change Height Settings Operation
Press and hold the button for 5 seconds to switch the mode.
10.1: One-Press Mode. Short-press the , , , or button, and the desk
will move to the height set for that button. Press any button to stop the
desk.
10.2: Press & Hold Mode. Long-press the , , , or button, and the
desk will move toward the height set for that button while the button is
held down.
4
4
Other Settings
01 02 03 04 05 07 08 09 10
06

Please try resetting the desk if you have any issues like the
following:
• Abnormal operation.
• The controller screen displays an error message.
Protection Mode Error Codes
E01/E02
E12
E07/E08
H01
Overcurrent Protection: Input current too high. If the correct
AC adapter is being used, reset the desk.
Undervoltage Protection: Input voltage too low. If the correct
AC adapter is being used, reset the desk.
Sensor Malfunction Warning: Motor safety sensor can’t be
detected. Power off, check the connection between the
motor and controller, power back on again, and reset.
Overheating Protection: When the motor has been working
continuously for too long (total 2.5 minutes in 20 minutes),
it will stop operating to prevent damage from overheating.
Wait for the motor to cool down before making any further
height adjustment.
01 02 03 04 05 07 08 09 10
06

Thank you for choosing this product. We strive to provide you with the
best quality products and service in the industry. Should you have
any issues, please don't hesitate to contact us.
Technical Support
(US/CA) 1-800-651-9525 Mon–Fri, 8am–8pm (CST)
(UK) 44-808-196-3875 Mon–Fri, 2pm–10pm (UTC)
Other Info
[email protected]
Website
https://ergear.com
860-00645-00 Rev01
