Ergotron Glide LD User manual

1 of 15
888-45-305-W-00 rev. G • 06/19
Table of Contents
TV/Display Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Hazard Symbol Review. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Determine mounting location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Mount Glide to wall:
Option A: wood stud walls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Option B: solid concrete walls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Attach TV/Display to Glide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Option A: no VESA adapter needed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Option B, C, D: with VESA adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Quick Release . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Route Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Test Range of Motion . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjust according to applied load and desired user force . . . . . . . . . . . . . . . . . . . . . 14
Screen Capacity Lift Tilt Pan VESA
27”- 40” 10 - 30 lbs
(4.5 - 13.6 kg) ≥10” (25.4mm)
TV/Display
10°
TV/Display
95°
Extension
180°
100 x 100
100 x 200
200 x 200
200 x 100
300 x 300
400 x 400
www.ergotron.com | USA: 1-800-888-8458 | Europe: [phone] | China: 400-120-3051 | Japan: [email protected]
Glide LD
User's Guide
For the latest User Installation Guide please visit: www.ergotron.com

2 of 15
888-45-305-W-00 rev. G • 06/19
Components
M4 x 15mm
M6 x 15mm
M5x 15mm
M8x 15mm
M4 x 30mm
M6 x 30mm
M5 x 30mm
M8 x 30mm
4x
4x
4x
4x
4x
4x
4x
4x
4x
1x 1x
M6-M8
x 5mm
spacer
M6-M8
x 10mm
spacer
M4-M5
washer
M6-M8
washer
4x 4x 4x 4x
M8M5 kit
4x
M8M5 Converter
Conversor M8M5
Convertisseur M8M5
M8M5-Konverter
M8M5 Convertor
Convertitore M8M5
M8M5 konverterare
M8M5サイズ変換ネジ
M8M5 转接件
M5 x 20mm
4x
8x M4 x 6mm
2x 2x
M8 anchorM6 x 70mm
These symbols alert users of a safety condition that
demands attention. All users should be able to
recognize and understand the signicance of the fol-
lowing Safety Hazards if encountered on the product
or within the documentation. Children who are not
able to recognize and respond appropriately to Safety
Alerts should not use this product without adult
supervision!
Hazard Symbols Review Symbol SignalWord Level of Hazard
NOTE A NOTE indicates important information that helps you
make better use of this product.
CAUTION A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
WARNING AWARNING indicates either potential for property dam-
age, personal injury, or death.
ELECTRICAL An Electrical indicates an impending electrical hazard which, if not avoided, may result in personal injury, re
and/or death.

3 of 15
888-45-305-W-00 rev. G • 06/19
TOOLS NEEDED
3/8”1/8”
3/8” 9.5-10mm
1/8” 3.2mm
80mm 80mm
10 mm

4 of 15
888-45-305-W-00 rev. G • 06/19
Determine mounting location.
1
CAUTION: Before proceeding with this installation consult your TV/large display product guide for
manufacturer recommendations on choosing a mounting location that will ensure optimum TV/large
display performance. Location considerations might include: TV/large display height and viewing
angle - based on height and distance of seating, room dimensions and size of TV/large display; access
to power outlets; cable connections for speakers and other devices; protection from glare and heat,
(windows, lamps, replace, air ducts) and vibration.
Locate the wall mount bracket on the wall using the dimensions below, as a guide.
5.1”
(130mm)
7.9”
(200mm)
2.2”
(57mm)
6.5”
(165mm)
Glide range of motion
upper, right position
Wall mount bracket
Glide range of
motion
lower, left position

5 of 15
888-45-305-W-00 rev. G • 06/19
2
a
d
fg
b
e
c
M6 x70mm
2x
1/8”
1/8” 3.2mm
80mm
3-1/8”
10mm
NOTE: make sure extension bracket is
level before tightening bolts. Refer to
Step 3 on the page 7.
Mount extension bracket
Option A: wood stud walls

6 of 15
888-45-305-W-00 rev. G • 06/19
abc
d
e
10mm
WARNING:
Anchors that are not fully set in solid concrete will not support the applied
load resulting in an unstable, unsafe condition which could lead to personal
injury and/or property damage. Consult a construction professional if you
have any doubt about what this means in regard to your particular situation.
123
WARNING:
Mounting holes must be at least 3-1/8”
(80mm) deep and must be located within
solid concrete, not mortar or covering ma-
terial. If you drill into an area of concrete
that is not solid, reposition mounting holes
until both anchors can be fully inserted
into solid concrete!
3/8”
3/8” 9.5-10mm
3-1/8”
80mm
M6 x70mm
2x 2x
NOTE: make sure extension bracket is level
before tightening bolts. Refer to Step 3 on the
next page!
M8 anchor
2Mount extension bracket
Option B: solid concrete walls

7 of 15
888-45-305-W-00 rev. G • 06/19
3
4Determine TV/large display mount fasteners
Ø
NOTE: If a stand is already attached to your TV/large display, remove it according to TV/large display manu-
facturer directions. Place the display on a clean, flat, padded surface or, if you prefer, lean the TV/large display against a
stable, vertical surface.
Several sizes of screws and spacers have been provided for mounting the Glide brackets to your TV/large display-
choose those that best match the depth and diameter of the mounting holes on the back of your TV/large display, along
with the design of the area surrounding the mounting holes (Flat, Curved or Inset).
TV/Display Style
If your TV/large display has a curved or inset mounting hole configuration, you may need to use the provided spacers or
washers with the screws.
Hole Depth and Diameter
Four sets of display bracket screws have been provided, each of a different diameter: 4mm, 5mm, 6mm, and 8mm.
Compare the screws with the diameter of the mounting holes at the back of your TV/large display to find the same size.
NOTE: Washer A is provided for use with the 4mm and 5mm screws while Washer B works with 6mm and 8mm screws.
Test screw diameters and lengths until you find the right match to your TV/large
display.
abc
Ensure the extension bracket is level.

8 of 15
888-45-305-W-00 rev. G • 06/19
5Determine if VESA adapters are needed between TV/display and Glide LD
Check the shape and size of your TV/large display mounting hole configuration against the VESA con-
figurations shown below. Choose VESA option that matches and continue to Step 6 on the next page.
100mm
100mm
100 x 100
100 x 200
200 x 200
300 x 300
400 x 400
200 x 100
400mm
200mm
300mm
100mm
200mm
100mm
200mm
400mm
200mm
300mm
Option A
Option B
Option C
Option D
VESA Mounting Hole ConfigurationsTV/large display Mounting Hole Configurations

9 of 15
888-45-305-W-00 rev. G • 06/19
6
6
Option A: Attach TV/large display to the Glide LD
using fasteners determined in step 4.
Continue to
Step 7 on
page 12.
6mm
6mm
6mm
1x
Penta wrench
8x
M4 x 6mm penta
Options B, C, and D
Attach VESAAdapters to Glide using 8 M4x6mm penta screws.
Step 6 details
continued on the
next page.

10 of 15
888-45-305-W-00 rev. G • 06/19
a
b
VESA Mounting Hole
Configurations
Option B Option C Option D
Rotate VESA plate to access mounting holes.
Step 6
continued
on the
next
page.
8x M4 x 6mm

11 of 15
888-45-305-W-00 rev. G • 06/19
6mm
6mm
6mm
6
7Mount the Glide LD (with attached TV/large display) to extension bracket
on wall.
Options B, C, and D (cont.)
Attach TV/large display to VESAAdapters on Glide LD.
c

12 of 15
888-45-305-W-00 rev. G • 06/19
8
Quick-release instructions: to remove the Glide LD from
the wall, pull down on the strap below the extension.
ab

13 of 15
888-45-305-W-00 rev. G • 06/19
9Test for smooth operation throughout full range of motion.
If movements are too easy or difficult or if the Glide LD does not stay
in desired positions, follow the Adjustment instructions on the following
pages to create smooth and easy movements.
Lift
Pan (TV/display motion)
Tilt
Pan (TV/display side-
to-side with extension)
ab
cd

14 of 15
888-45-305-W-00 rev. G • 06/19
ADJUSTMENT
Increase Lift Strength
If the mounted weight is too heavy or this product does not stay
up when raised, then you'll need to increase Lift Strength:
Decrease Lift Strength
If the mounted weight is too light or this product does not stay
down when lowered, then you'll need to decrease Lift Strength:
Important! You will need to adjust your Glide LD after installation is complete.
Make sure all your equipment is properly installed on the product before
attempting adjustments. This product should move smoothly and easily through
the full range of motion and stay where you set it. If movements are too easy
or difficult or if product does not stay in desired positions, follow the adjustment
instructions to create smooth and easy movements. Depending on your product
and the adjustment, it may take many turns to notice a difference. Any time
equipment is added or removed from this product, resulting in a change in
the weight of the mounted load, you should repeat these adjustment steps to
ensure safe and optimum operation.
aAdjust lift up and down.
10mm

15 of 15
888-45-305-W-00 rev. G • 06/19
bAdjust tilt To change tilt angle, loosen knob,
adjust and tighten knob.
© 2019 Ergotron, Inc. All rights reserved.
www.ergotron.com | USA: 1-800-888-8458 | Europe: [phone] | China: 400-120-3051 | Japan: [email protected]
For local customer care phone numbers visit: http://contact.ergotron.com
For Service visit: www.ergotron.com
For Warranty visit: www.ergotron.com/warranty
