Ericsson Base Station F800 Quick start guide

COPYRIGHT 1996  Ericsson Mobile Communications AB
EN/LZB 115 681 R1
Base Station F800
Field Service Manual

RUBRIKFÖRTECKNING
LIST OF HEADINGS
Document maintenance 1
Dokumentnr - Document No
EN/LZB 115 681
Safety instructions
Datum -Date
96-06-06
Rev
A 2
FIELD SERVICE MANUAL
F800
Overview
3
Technical specifications
4
Installation
5
Operations instructions
6
Spare parts list
7
Service tools
8
Service information
9
This manual is provided by Ericsson Mobile
Communications without any kind of warranty.
Improvements and changes in this manual due to
typographical errors, inaccuracies in current information, or
improvements to programs and/or equipment may be
made by Ericsson Mobile Communications at any
Cabinet
10
time and without notice. These changes will, however, be
incorporated into new editions of this manual. Transceiver unit
11
All right reserved.
COPYRIGHT 1996 
Ericsson Mobile Communications AB Applications
12

DOCUMENT LIST 1 (3)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ESE Rune Tapper ECS/S/LT-96:1036
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ESE (Rune Tapper) 1999-05-25 D
F800 Field Service Manual
Document list
Chapt Document name Document number Rev
1. Document maintenance
Distribution list 031 51-LZB 115 681 B
Revision journal 109 21-LZB 115 681 A
Document list (this document) ECS/S/LT-96:1036 D
2. Safety instructions
Warning, health risk! ECS/S/LT-96:5031 A
Warning, health risk! ECS/S/LT-96:5032 A
Handling MOS devices ECS/S/LT-96:5033 A
Warning, high voltage! ECS/S/LT-96:5034 A
Information about ESD LZT 109 170 Ue -
3. Overview
Product structure 1315-KRD 103 10 Ux B
Mechanical structure ECS/S/LT-96:5035 A
Manufacturing instruction 1510-KRD 103 10 ux A
Coding scheme 1518-KRD 102 01 usv C
4. Technical specifications
Ericsson F800 Technical data EN/LZT 123 593 R3
F800 Product sheet EN/LZT 123 841 A
5. Installation
Installation ECS/S/LT-96:5036 A
Installation instruction 1531-SXK 107 2274/1 UX B
Installation instruction 1531-SXK 107 2274/4 UX A
Lightning protection for masts ECS/S/LT-96:5037 A
F800 Commissioning ECS/S/LT-96:1042 A
6. Operating Instructions
Operating Instructions F800 ECSTAP 97:1055 A

DOCUMENT LIST 2 (3)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ESE Rune Tapper ECS/S/LT-96:1036
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ESE (Rune Tapper) 1999-05-25 D
7. Spare parts list
Spare parts list ECS/S/LT-96:5042 A
8. Service tools
LPC 102 213 F800 Test Handset KTR97:2444 A
Fault tracing F800 KTR97:2486 A
Special service tools for F800 15/EN/LZB 115 681 R1 Uen A
Service unit F800 15188-LPC 102 81 UX A
F800 personality programming ECS/S/LT:96-1014 A
9. Service information
Service information SI95-011 A
Service information SI96-003 A
Service information SI96-004 A
10. Cabinet
F800 Radio base station concept 109 21-KRD 103 10 - 1 Uen A
Cable 151 88-RPM 113 669 Ux B
Cable 151 88-RPM 113 671 Ux A
Cable 151 88-RPM 113 670 Ux A
Cable terminal info F800 193 12-SXK 107 2274/4 Uen A
Cable terminal info F800 193 12-SXK 107 2274/4 Uen B
Connection cable 151 88-RPM 113 1511 Ux A
Connection cable 151 88-RPM 113 1511 Ux B
Connection cable 151 88-RPM 113 1512 Ux A
Connection cable 151 88-RPM 113 1512 Ux B
Connection cable 151 88-RPM 113 1513Ux A
Fan kit 151 88-BKV 301 203 Ux A
Connection cable 151 88-RPM 113 1703 Ux A
Wiring diagram F800 MRS3000 107 31-SXK 107 2274/1 Ux E
Wiring diagram F800 MRS5000 107 31-SXK 107 2274/2 Ux D
Circuit board 1911-ROA 117 2010 Ux A
Printed board 1078-ROA 117 2010 Ux A
Station unit C700 151 88-NTM 201 57 Ux E
Assembly drawing F800 151 88-SXK 107 2274/1 Ux C
Wiring diagram transceiver unit F800 107 31-KRD 103 10 Ux A
Assembly drawing F800 151 88-SXK 107 2274/4 Ux C
11. Transceiver unit
Logic unit 3/EN/LZB 115 681 R1 Uen A
F800 Circuit description ECS/S/LT-96:5044 A
Logic board F800, circuit diagram 1911-ROA 119 8736 UEN C
Logic board F800, mounting drawing 1078-ROA 119 8736 Ux B

DOCUMENT LIST 3 (3)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ESE Rune Tapper ECS/S/LT-96:1036
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ESE (Rune Tapper) 1999-05-25 D
12. Applications
F800 as radio link S/XT 95:7049 A
F800 as repeater station ECS/S/LT-96:1013 A
F800 as OEM station ECS/S/LT-96:1018 A
Enclosure
F800 Personality Programming Tool EN/LZY 213 633 1.47

Öppen Open
INFORMATION 1 (1)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ESE Magnus Lindahl ESE-9902150
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KL/ESE (Rune Tapper) 1999-10-27 A
This manual is an
unregistered copy
and will not be
updated!
This manual is provided by Ericsson Sverige AB without any kind of
warranty. Improvements and changes in this manual due to typographical
errors, inaccuracies in current information, or improvements to programs
and/or equipment may be made by Ericsson Sverige AB at any time and
without notice. These changes will, however, be incorporated into new
editions of this manual.
COPYRIGHT1999 Ericsson Sverige AB
All rights reserved.

SAFETY PRECAUTIONS 1 (4)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5031
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965031.doc
WARNING, HEALTH RISK!
Beryllium oxide
The transistors in the power amplifier’s driver stage and in the power amplifier contain
beryllium oxide ceramics (BeO). Dust particles of this substance may be dangerous to
your health if you inhale or get them on your skin.
Therefore, DO NOT IN ANY WAY INTERFERE WITH THE TRANSISTORS. It is, vital
that you comply with the directions given in the appended “Beryllia safety precautions”.
BERYLLIA SAFETY PRECAUTIONS
Introduction
This appendix details the safety precautions when handling components containing
Beryllium oxide. Dust from this material can present a health hazard unless adequate
precautions are taken.
The hazard
The material is highly dangerous in a dust form when it might be inhaled or enter a cut
or skin irritation area.
If dust is caused as a result of chafing, filing or breakage and is inhaled, a single
exposure lasting minutes or seconds can cause injury to skin or mucous membranes
severe enough to endanger life or cause permanent injury. Particles penetrating the
skin through wounds or abrasions are liable to cause chronic ulceration’s.
Symptoms of poisoning indicated by respiratory troubles or cyanosis (grey blue
discoloration of the skin), may develop within a week, or after a period extending to
several years.

SAFETY PRECAUTIONS 2 (4)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5031
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965031.doc
COMPONENTS
Power transistors, diodes and thyristors
Power transistors, diodes and thyristors, as received in the manufacturers packing, are
clearly identified by attached information. They should be stored in the original packing
and not mixed with other items. The Beryllia is encapsulated and components are safe
to handle for replacement purposes. Care should be exercised in removing defective
items to ensure that they do not become physically damaged.
They MUST NOT:
 be carried loosely in a pocket, bag or container with other components where they
may rub together or break and disintegrate into dust
 be heated excessively (normal soldering is quite safe)
 be broken open for inspection or in any way abrased by tools.
Heat sink washers
Some of the heat sink washers contain Beryllia. When new these are packed
individually.
They MUST NOT:
 be stored loosely
 be filed, drilled or any way tooled
 heated other than when clamped in heat sink application.
They are best handled with gloves or cloth when being removed from equipment.
Cathode ray tubes and ceramic applications
Some products of cathode ray tube are coated on the inside with a ceramic beryllium
oxide mixture. The tube is safe unless the glass is broken but should this occur.
DO NOT:
 handle the broken glass with bare fingers
 blow on the exposed surface (because of the danger of inhalation).
Ceramic cylinders or formers, identified by blue coloration or black lines, are safe to
handle provided they are not damaged. In the latter event take precautions as with
other components.

SAFETY PRECAUTIONS 3 (4)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5031
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965031.doc
Disposal
Defective and broken components MUST NOT be disposed of in containers used for
general refuse.
Defective components should be individually wrapped, clearly identified as
“DEFECTIVE BERYLLIA COMPONENTS” and returned for subsequent disposal. Such
components securely packed and with inside identification, may also be returned
directly to the manufacturer.
Broken components should be individually wrapped and identified as “BROKEN
BERYLLIA COMPONENTS”. They MUST NOT be sent through the post and should
be returned to a depot by hand.
Medical precautions
If Beryllia is believed to be on, or have entered the skin through cuts or abrasions, the
area should be thoroughly washed and treated by normal first aid methods followed by
subsequent medical inspection.
Suspected inhalation should be treated as soon as possible by a doctor, preferably at
a hospital.

SAFETY PRECAUTIONS 4 (4)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5031
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965031.doc
HANDLING THE BERYLLIUM OXIDE COMPONENT
In the radio station one or more components contains beryllium oxide. Dust from this
material is highly toxic and can present a health hazard.
These components must not be incinerated or damaged in any way. Exercise care
when removing or installing this component to prevent physical damage.
The component which contains beryllium oxide is
the RF-amplifier. It is located on the radio board
inside the radio station.
The components have the beryllium oxide encapsulated and the component is safe to
handle for replacement purpose.
Defective components or complete radio stations must not be disposed in containers
used for general refuse.
Therefore, return defective components or radio stations that contain beryllium
oxide, individually wrapped, clearly identified as “Defective beryllia
components” to your local Ericsson dealer or service facility.

SAFETY PRECAUTIONS 1 (1)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5032
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965032.doc
WARNING, HEALTH RISK!
Radio frequency radiation
Exposure to the antenna RF field may be dangerous to your health. Therefore,
SWITCH OFF THE TRANSMITTERS if you work with or near the antennas.

SAFETY PRECAUTIONS 1 (2)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5033
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965033.doc
HANDLING MOS DEVICES
Though all MOS integrated circuits incorporate some protection against electrostatic
discharge, they can nevertheless be damaged by accidental over-voltages. In storing
and handling them, the following precautions are recommended.
Caution
Handling and mounting call for special attention to personal safety. Personnel
handling MOS devices should normally be connected to ground via a 1 M resistor.
Storage and transport
Store and transport the circuits in their original packing. Alternatively, use a
conductive material or special IC carrier that either short-circuits all leads or insulates
them from external contact.
Testing or handling
Work on a conductive surface (e.g. metal table top) when testing the circuits or
transferring them from one carrier to another. Electrically connect the person doing
the testing or handling to the conductive surface, for example by a metal bracelet and
a conductive cord or chain. Connect all testing and handling equipment to the same
surface. Signals should not be applied to the inputs while the device power supply is
off. All unused input leads should be connected to either the supply voltage or
ground.
OBSERVE: USE ONLY SPECIAL DESIGNED, ORIGINAL SAFETY DEVICES!
Mounting
Mount MOS integrated circuits on printed circuit boards after all other components
has been mounted. Take care that the circuits themselves, metal parts of the board,
mounting tools, and the person doing the mounting are kept at the same electric
(ground) potential. If it is impossible to ground the printed-circuit board the person
mounting the circuits should touch the board before bringing MOS circuits into
contact with it.
Soldering
Soldering iron tips, including those of low-voltage irons, or soldering baths should
also be kept at the same potential as the MOS circuits and the board.

SAFETY PRECAUTIONS 2 (2)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5033
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965033.doc
Static charges
Clothing of non-electrostatic material should be worn. Clothes made of material like
wool, silk or synthetic fibres can give very high static voltages and should therefore
NOT be worn.
After the MOS circuits have been mounted on the board proper handling precautions
should still be observed. Until the sub-assemblies are inserted into a complete
system in which the proper voltages are supplied, the board is no more than an
extension of the leads of the devices mounted on the board. To prevent static
charges from being transmitted through the board wiring to the device it is
recommended that conductive clip or conductive tape is put on the circuit board
terminals.
Transient voltages
To prevent permanent damage due to transient voltages, do not insert or remove
MOS devices, or printed-circuit boards with MOS devices, from test sockets or
systems with power on.
Voltage surges
Beware of voltage surges due to switching electrical equipment on or off, relays and
D.C. lines.

SAFETY PRECAUTIONS 1 (1)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5034
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC (Ulf Brömster) 1996-06-03 A
965034.doc
WARNING, HIGH VOLTAGE!
High voltage warning (over 200 v)
Is used in the operation of this equipment.
Death on contact
May result if personnel fail to observe safety precautions.
Never work on electronic equipment unless there is another person nearby who is
familiar with the operation and the hazards of the equipment, and who is competent
in administering first aid. When the technician is aided by operators, he must warn
them about dangerous areas.
Whenever possible, the power supply to the equipment must be shut off before
beginning work on the equipment. Be careful not to contact high-voltage connections
when installing or operating this equipment.
Whenever the nature of the maintenance permits, keep one hand away from the
equipment to reduce the hazard of current flowing through vital organs of the body.
OBSERVE! Do not be misled by the term “low voltage”. Potentials as low as 50 volts
may cause death under adverse conditions.

MECHANICAL STRUCTURE 1 (1)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
KL/ECS/S/LT Magnus Lindahl ECS/S/LT-96:5035
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC 1996-06-05 A
Error! Unknown switch argument.

Base Station F800 - Technical Data
TYPE OF STATION
F802
F804
F805
GENERAL
Operating mode Simplex or Duplex
Frequency range 68 - 88 MHz 146 - 174 MHz 370 - 415 MHz
378 - 415 MHz
400 - 443 MHz
430 - 470 MHz
No of channels 15 (255 as option)
Channel separation 25 kHz 25 or 12.5 kHz
Frequency stability ±1.35 kHz ±2 kHz ±2.5 kHz
Signal/noise ratio, SINAD CCITT >40 dB 25 kHz >40dB
12.5 kHz >37 dB
AF in and output level -10dBm at 600 ohm
Antenna impedance 50 ohm
Supply voltage 13.8 VDC (10.8-15.6 V)
Voltage to interface 13.2 VDC max. 1 A
Power consumption
-transmission <7 A at 13.8 V DC and 20 W incl. Interface
-reception <0.8A at 13.8 V DC (<1.5A incl. Interface)
-stand by <0.8A at 13.8 V DC (<1.5A incl. Interface)
Weight < 15 kg
Dimensions (WxHxD) Approx. 439 x 177 x 325 mm, equipped with brackets for 19” rack mount, 3HE
Operating temperature range -25°C to +55°C
Storage temperature range -40°C to +85°C
Standards Meets or exceeds ETS 300 086, ETS 300279
TRANSMITTER
Output power, High 20 W ±1 dB 6 W ±1 dB for 370 -
415 MHz
Output power, Low 2 W ±1 dB 0.6 W ±1 dB for 370 -
415 MHz
Adjacent channel power > 70 dBc or 0.2µW
Spurious emissions at operation < -36 dBm ( 9 kHz - 1 GHz )
Spurious emissions at standby < -57 dBm ( 9 kHz - 1 GHz )
RECEIVER
Sensitivity 20 dB SINAD CCITT ≤-116 dBm ≤-116 dBm 25 kHz = ≤-115 dBm
12.5 kHz = ≤-113 dBm
Adjacent channel selectivity >70 dB
Intermodulation attenuation >70 dB
Spurious response rejection >70 dB
Telenor products are under continuos development. We therefore reserve the right to change technical data or to modify the equipment without prior notice.
Telenor Radio Systems AB
P.O. Box 903
SE-692 29 KUMLA, Sweden
Tel [phone]. Fax [phone] EN/LZT 123 593 R7

Error! Unknown switch argument. 1 (4)
Uppgjord (även faktaansvarig om annan) - Prepared (also subject responsible if other) Nr - No.
Error! Unknown switch argument. Error! Unknown switch argument.
Dokansv/Godk - Doc respons/Approved Kontr - Checked Datum - Date Rev File
KI/ECS/S/LTC Error!
Uk
Error!
Uk
Error! Unknown switch argument.
F800 Commissioning
Contents:
INTRODUCTION 1
SITE INFORMATION FORM 2
F800 BASE STATION INFORMATION 3
INSTALLATION CHECK 4
SITE COMPLETED 4
Introduction
The intent of this form is to make sure that the installation is performed and
tested in such way, that the customers and our requirements will be fulfilled.

Error! Unknown switch argument. 2 (4)
Datum - Date Rev Nr - No.
Error!
Uk
Error!
Uk
Error! Unknown
ih
Error! Unknown switch argument.
Site Information Form
On completion of installation of a station unit, please place a completed form
of this information including F800 Base Station Information and Installation
Check in the Site Documentation that is prepared for the site (customer). One
copy must be filed at the local workshop.
Site identification: .....................................................................................
..................................................................................................................
Owner: ......................................................................................................
..................................................................................................................
The key is available at: ..............................................................................
Telephone no, main operator: ..................................................................
Telephone no at site: ................................................................................
Number or name for the control line: ........................................................
Servicing organised by: ............................................................................
Local workshop: .......................................................................................
Telephone no: ..........................................................................................
Other important names, telephone numbers etc.: ....................................
..................................................................................................................
..................................................................................................................
..................................................................................................................
..................................................................................................................
..................................................................................................................
Prepared by Place Date
..................................... .................................. ...............................

Error! Unknown switch argument. 3 (4)
Datum - Date Rev Nr - No.
Error!
Uk
Error!
Uk
Error! Unknown
ih
Error! Unknown switch argument.
F800 Base Station Information
Station unit number: .................................................................................
F80X transceiver unit type: KRD 103 10/ ..................................................
 Serial number: .....................................................................................
Line panel type: ........................................................................................
 Serial number: .....................................................................................
Frequencies: TX= ................................... RX= .......................................
Traffic mode simplex/duplex: ....................................................................
Power supply:
 Mains power unit type: .........................................................................
 Type of batteries: .................................................................................
 Others: .................................................................................................
 ..............................................................................................................
Antenna installation etc.: ..........................................................................
..................................................................................................................
..................................................................................................................
..................................................................................................................
..................................................................................................................
If necessary please make up separate sketches and/or drawings.
