Escea DL850 Installation and maintenance instructions

630203_4
Installation / Service Guide
For the latest documentation, visit www.escea.com 630241_1
DL850 / DL1100
Gas Fireplaces

630203_4
Important:
The appliance shall be installed in accordance with;
• Thisinstallationinstructionbooklet
• Localgasttingregulations
• Municipalbuildingcodes
• Electricalwiringregulations
• Anyotherrelevantstatutoryregulations.
• AS/NZS5601:2010GasInstallations
WARNING:
Thisappliancemustbeinstalledbyaqualiedperson.
Donotmodifythisappliance.
Thisapplianceisnotintendedforusebyyoungchildrenorinrmpersonsunlessthey
havebeenadequatelysupervisedbyaresponsiblepersontoensurethattheycanusethe
appliancesafely.
Youngchildrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Failure to follow these instructions could cause a malfunction of the heater, which could
resultindeath,seriousbodilyinjury,and/orpropertydamage.Failuretofollowthese
instructionsmayalsovoidyourreinsuranceand/orwarranty.
Who can install this product:
Installationmustbecarriedoutbyaregisteredinstallerwho,oncompletionoftheinstal-
lation,mustissuea:
AUS:CerticateofCompliance
NZ:EnergyWorkCerticate
inaccordancewithnationaland/orlocalcodes.IfthesearenotissuedthentheEsceawar-
rantymaybevoid.
Warranty Repair and Annual Servicing:
WarrantyrepairworkmustbecarriedoutbyarecognisedEsceaGasFireTechnician.Itis
recommendedthatrecognisedEsceaGasFireTechniciansarealsousedtocarryoutan-
nualservicingrequirements(particularlyduringthewarrantyperiod).Forcontactdetails
ofauthorisedEsceaGasFireTechniciansinyourarea,pleasecontacttheretailerfrom
whom the appliance was purchased.
Theheatermustbeinstalledaccordingtotheseinstructionsandincompliancewithall
relevantbuilding,gastting,electricalandotherstatutoryregulations(eg.AS/NZS5601).
Anyshortcomingsintheapplianceandueinstallationwillbetheresponsibilityofthe
installer,andEsceawillnotbeaccountableforanysuchfailingsortheirconsequences.
Manufacturedby:EsceaLtd,POBox5277DunedinNZ,Ph:+6434788220
Forcontactdetailsofyourlocalesceadistributorordealerpleasevisit:
www.escea.com inf[email protected]

630203_4
Contents
A Installation Process and Product Description 6
A1 RecommendedInstallationProcess: 6
A2 ProductDescription: 6
A3 ProductDimensions: 7
B Creating the Cavity 7
B1 CavityShape: 7
B2 FlueConguration(Iflessthan4muelength): 8
B3 Fascia: 10
B4 CavityBase: 10
B5 Hearth: 11
B6 WallLinings: 11
B7 MantleClearance: 11
B8 TelevisionClearances: 12
B9 CornerInstallations: 12
B10 DistancefromFireplacebasetoFasciabase: 12
C Installing the Electricity and Gas to the Appliance 13
C1 PowerSupply: 13
C2 NetworkCable: 13
C3 GasPipeSizing: 14
C4 GasPipePosition: 14
C5 GasIsolatingValve: 14
C6 PressureTestPoint: 14
D Installing the ue 15
D1 HorizontalPowerueDescription 15
D2 InstallinginAccordancewithRelevantCodes: 16
D3 CreatingtheHoleintheOutsideWall 17
D4 InstallingtheHorizontalPowerueWallTerminal 17
D5 VerticalPowerFlue 18
D6 Installationtherestrictorplate(VerticalPowerFlueOnly) 19
D7 RunningtheFlue 19
D8 RunningthePowerueElectricalCable 19
E Installing the Appliance 20
E1 Installation 20
E2 ConnectingtheNetworkCable 20
E3 ConnectingtheFlue 21

630203_4
E4 FixingtheAppliancetotheBaseandWall: 21
E5 FixingAppliancetoBase: 21
E6 FixingAppliancetoWall: 21
E7 RemovingtheGlass 22
E8 ConvertingtheApplianceGasType 22
E9 CheckingthePilotIgnition 23
E10 LogFuelBedInstallation 24
E11 RiverStoneorCoal(Pebbles)FuelBedInstallation 25
E12 CrystalightFuelBedInstallation 25
E13 CrystalightandDriftwoodFuelBedInstallation 26
E14 CheckingtheOperatingPressure 26
E15 HomeAutomationSetup 27
F Fitting the Fascia and Finishing Installation 29
F1 FittingtheFasciaPanels: 29
F2 FittingtheVeloFourSidedFasciaPanels 30
F3 FittingtheQuadratoFasciaPanels 32
F4 FittingtheRadoFasciaPanels 34
F5 LocatingWallMountCradleforWirelessControl: 37
F6 OperatingtheAppliancefortheFirstTime: 37
F7 NormalOperatingSoundsandSmells: 38
F8 Cleaningtheglass 38
G Installation Checklist 39
S Service Manual 40
S1 ErrorCodes: 40
S2 SerialNumber: 42
S3 CheckingOperatingPressure: 42
S4 CleaningtheLogSetandGlass: 42
S5 ServicingtheHorizontalPowerueWallTerminal 43
S6 RemovingorCleaningFan 44
S7 ReplacingElectronicDrawer 46
S8 ReplacingaWirelessControl: 46
S9 Annualserviceprocedure: 47
S10 WiringDiagram: 48
S11 Warranty 49

B
ACDEF G SERVICE
6
A Installation Process and Product Description
A1 Recommended Installation Process:
Thefollowingdiagramillustratesthestepsrequiredtoinstallyourgasre..
Thesequenceinwhichyouchoosetodothesetaskswillvarydependingonyourindi-
vidualscenario.Pleasereadtheseinstructionsfullybeforeproceedingwiththeinstalla-
tion.Leavetheinstallationofthefasciapanelsuntiltheveryendoftheinstallationand
commissioningtoavoiddamagetothefasciapanels.
Create the Cavity Install electrical / gas
connections and ue
system
Install appliance and
nish cavity
Finish installation,
t fascia and test
appliance
SectionB SectionC,D SectionE Section F
A2 Product Description:
TheEsceaDLseriesgasreisaroomsealedgasappliancedesignedtobebuiltintoa
cavity.Theseappliancesareuedusingco-linearexiblealuminiumueconnectedtoa
powerueterminal.
TheuserwillcontroltheirrewiththeRadioFrequency(RF)remotethatwillnormally
beleftinitswallmountcradle.InadditiontotheRFremotetheappliancehasasingle
auxiliaryOn/Obuttonontheunit.Whennotinoperationitisinastandbymodeunless
itisphysicallyisolatedfromthemainssupply.

BACDEFGSERVICE
7
A3 Product Dimensions:
B Creating the Cavity
B1 Cavity Shape:
TheDL850/DL1100issuitableforbothtimberframedandmasonrycavities.
Foramasonrycavitytheinsidewidthofthecavitymustbeatleast960mm(DL850)or
1260mm(DL1100)tottheapplianceandmustbeatleast600mmdeeptoaccommo-
datetheueconnections.
Atimberframedcavitycanbeshapedtosuit.Thecavityshapewillbedependentontwo
things:
-theueconguration(sectionB2)
-thefascia(sectionB3)

B
A C DEF G SERVICE
8
B2 Flue Conguration (If less than 4m ue length is required):
Ifyouruesystemislessthan4mlong(asshownindiagramsbelow),thenasimpleex-
ibleueisrequired.Ifyouwishtoinstallalongeruerun,upto12m,seesectionB3.
Horizontally Terminated: (utilises the escea horizontal power ue enclosure kit)
Thehorizontalosetoftheterminalcanbeanyamountuptothetotaluelengthlisted
below.PleaseconsultwithEscea’stechnicalstaifyourintendeduecongurationsteps
outsideoftheboundsoftheuecongurationsshownbelow.
X
Y
X+ YMaximum=4m
YMaximum=1.5m
YMinimum=0m
XMaximum=4m
XMinimum=0m
X
Y
X+ YMaximum=4m
YMaximum=4m
YMinimum=0m
XMaximum=4m
XMinimum=0m

BACDEFGSERVICE
9
Vertically Terminated:
(utilises the escea vertical power ue enclosure kit)
400mm Min.
4m Max.
Overallfluelength:
1.2m Co-axialflue:
X
Y
X+ YMax=4m
YMax=4m
XMax=4m
Vertical Powerflue
Enclosure

B
A C DEF G SERVICE
10
B3 Flue Conguration (If more than 4m ue length is required):
fyouruesystemisgreaterthan4mlong(asshownindiagramsbelow),thenaexible
uewithcondensatetrapandrigidPPtubeuelengthsisrequired.Ifyouwishtoinstalla
longeruerun,upto12m,seesectionB3
4m
Ø80mm / Ø100mm
Flexible Flue
1.2m Co-axial Flue
Vertical Powerflue
12m MAX
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
PP Tube
4m
ESCEAWALL
TERMINAL
12m MAX
Ø80mm / Ø100mm
PP Tube
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
Flexible Flue

BACDEFGSERVICE
11
B3 Flue Conguration (If more than 4m ue length is required):
fyouruesystemisgreaterthan4mlong(asshownindiagramsbelow),thenaexible
uewithcondensatetrapandrigidPPtubeuelengthsisrequired.Ifyouwishtoinstalla
longeruerun,upto12m,seesectionB3
4m
Ø80mm / Ø100mm
Flexible Flue
1.2m Co-axial Flue
Vertical Powerflue
12m MAX
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
PP Tube
4m
ESCEAWALL
TERMINAL
12m MAX
Ø80mm / Ø100mm
PP Tube
Ø100mm
Condensate Trap
Ø80mm / Ø100mm
Flexible Flue
B4 Installing a Condensation Trap (If more than 4m ue length)
Internalcondensatedrainagepipeworkmustbeaminimumof19mmID(typically22mmOD)plastic
pipeandthisshould“fall”atleast45mmpermetreawayfromthecondensatecollector,takingthe
shortest practicable route to the termination point.
Thefirstcomponentofthecondensatedischargesystemshouldbea‘U’traporsyphonwithamini-
mumtrapheightof75mm.Theuseofasyphonwouldbethepreferredmethodwhendischarging
toanexternalterminationpoint.Howevercaremustbetakenwheninstallingthesyphontoensure
thatitismountedtomanufacturer’sinstructions.
Inordertominimisetheriskoffreezingduringprolongedperiodsofverycoldweather,oneofthe
followingmethodsofterminatingcondensatedrainagepipeshouldbeadopted:
1: INTERNAL TERMINATION:
Whereverpossible,thecondensatedrainagepipeshouldbeterminatedatasuitableinternal
foulwaterdischargepointsuchas(a)aninternalsoilandventstackor(b)aninternalkitchenor
bathroomwastepipe,washingmachinewastepipeetc.Asuitablepermanentconnectiontothe
foulwastepipeshouldbeused.Ifconnectingintothewasteofasinkorbasinthe‘U’traporsyphon
shouldbeatleast100mmabovetheheightofthesinkorbasin.
Thepossibilityofwastepipesfreezingdownstreamoftheconnectionpointshouldbeconsidered
whendeterminingasuitableconnectionpoint-e.g.aslightlylongerpiperuntoaninternalsoil
stackmaybepreferabletoashorterrunconnectingintoakitchenwastepipedischargingdirectly
throughthewalltoanexternaldrain.
Where“gravitydischarge”toaninternalterminationisnotphysicallypossible(e.g.thedischarge
pointisabovetheappliancelocation,oraccessisobstructedbyadoorway),orwhereverylong
internalpiperunswouldberequiredtoreachasuitabledischargepoint,thefollowingmeasures
maybeadopted-
2: USE OF A CONDENSATE PUMP (TO AN INTERNAL TERMINATION):
Condensatecanberemovedusingaproprietarycondensatepump.
Thepumpoutletshoulddischargetoasuitableinternalfoulwaterdischargepoint,suchas(a)anin-
ternalsoilandventstackor(b)aninternalkitchenorbathroomwastepipe,washingmachinewaste
pipeetc.Asuitablepermanentconnectiontothefoulwastepipeshouldbeusedandthemanufac-
turer’sdetailedinstallationinstructionsforthepumpshouldbefollowed.
3: EXTERNAL TERMINATION:
Theuseofanexternally-runcondensatedrainagepipe,terminatingatasuitablefoulwaterdis-
chargepointorpurpose-designedsoak-away,maybealsobeconsidered;howeverifthistermina-
tionmethodischosenthenthefollowingmeasuresshouldbeadopted-
Thepipeshouldberuninternallyasfaraspossiblebeforegoingexternallyandthepipediameter
shouldbeincreasedtoaminimumof30mmID(typically32mmOD)beforeitpassesthroughthe
wall(thisistoreducethepossibilityoffreezinginextendedperiodsofcoldweather).
Theexternalrunshouldbekeptasshortaspossible,takingthemostdirectand“mostvertical”route
possibletothedischargepoint,withnohorizontalsectionsinwhichcondensatemightcollect.
Theexternalpipeshouldbeinsulatedusingsuitablewaterproofandweatherproofinsulation.
Additional Important notes:
A) Internalcondensatedrainagepipesruninunheatedareassuchasroofspaces,
 basementsandgaragesshouldbetreatedasexternalpipework(seemethod3 
 above).
B)Ifthecondensatedrainagepipeworkisconnecteddirectlytoaninternalsoilstackorrainwater
 downpipeavisibleairbreak(suchasatundish)shouldbeplacedinthecondensatelinetopre
 vent‘reverseflow’andfoulwaterenteringtheappliance,followedbyanotherUtrap.
C)Whenarainwaterdownpipeisusedastheterminationanairbreakmustbeinstalledbetween
 thecondensatedrainagepipeandthedownpipetoavoidreverseflowofrainwaterintothefire
 shouldthedownpipeitselfbecomefloodedorfrozen
D)Considerationshouldbegiventowindchillandallexternalpipesthatterminateatgroundlevel
 shouldpassintothegrate.

B
A C DEF G SERVICE
12
B5 Fascia:
Thecavityshapeisdependentonthefasciatype.Therearethreefasciatypesavailable
withtheDL850andDL1100:
Velo (4 Sided) QuadratoRado
The Velo and Quadratofasciassitproudofthenishedwallsurfaceandhaveasimple
cavityshape.Thecavitymaybeconstructedfromcombustiblematerials.
The Radofasciasitsushwith,orinsetfrom,thenishedwallsurfaceandhasamore
complexcavityshape.Thecavityframingandwallfacingforaminimumof300mm
directlyabovetheRadofasciamustbeconstructedfromnon-combustiblematerials.
Pleasecheckthestyleoffasciabeforecommencingthebuildingofthecavitytothe
dimensionsshownbelow.ThecavityforVeloandQuadratofasciasmaybeconstructed
fromcombustibletimberframingmaterials.Note:Itisnotnecessarytolinethesides,top
orbackofthecavity.
Cavity for Velo or Quadrato Fascia Cavity for Rado Fascia
Ideal Cavity Dimensions (mm):
DL850: A B (min) B (max) C D E (min) E (max)
Velo/Quadrato 965 560 610 560 - - -
Rado 965 585 590 560 995 30 130
DL1100:
Velo/Quadrato 1265 560 610 560 - - -
Rado 1265 585 590 560 1295 30 130
B6 Cavity Base:
ThisapplianceMUSTbefullysupportedonitsbase.Thebasemustextendoverthe
entire area of the underside of the appliance. The base must also be levelled to prevent
vibrationfrompossiblefanimbalance.Thebaseofthecavitymustbestrongenoughto
supportthetotalproductweight,whichisapproximately65kg,dependingonfuelbed.

BACDEFGSERVICE
13
B7 Hearth:
Thebaseoftheappliancemustbeinstalledaminimumof100mmotheoor,unlessthe
applianceisbeinginstalledatoorlevelinwhichcaseahearthisrequired,madefrom
non-combustiblematerialandmustextendnolessthan300mmfromthefrontofthere.
Thishearthshouldbeatleastaswideasthere’souterfasciaandnolessthan10mm
thick.Raisedhearthscanbeanysizebutmustalsobeconstructedfromnon-combustible
materials.
Theoorinfrontofthishearthwillstillgetwarmsoiftheoorcoveringisvinyl,nylon
carpetoranotherheatsensitivematerialthenwerecommendextendingthehearthto
450mmfromthere.Araisedhearthcanbeofanysizebutmustbeconstructedfrom
non-combustible materials. NOTE: If the hearth is to be covered with tiles or some other ve-
neer then the re must be installed so that the base of the appliance is level with the nished
top surface of the hearth.
B8 Wall Linings:
Thefrontmountingangesoftheappliancemust
beontopofthenishedwallsurfaceinorderforthe
fasciapanelstomountproperly.Takeintoaccount
anyplasterboard,tilesoranyothernishingsurface
thatmaybeintendedforthenishedwallsurface.
Wallnishingmaterialsmustnotencroachuponthe
minimumcavityclearancesgiveninsection2.2.The
wallboardthatlinestheoutsideofthisopeningcan
benormaldrywall(plasterboard)anddoesnotneed
to be non-combustible.
Note:Thetemperatureofthewallliningdirectlyabove
theheaterdoesgetwarmandhencemaydiscolour
paintnishesthataresusceptibletotemperature
damageordistortvinylwallcoverings.Fordurabilityof
nishesandsurfacesyoushouldcontacttherelevant
manufacturerfortheirspecication.
For more detail on cavity construction, view the
“Drawings for Architects” in the technical section of the Escea website.
B9 Mantle Clearance:
Pleaserefertothediagramtotheright.Man-
tlesorprotrudingledgesmountedabove
the heater that are made from combustible
materials,mustnotextendoutsideofthe
dimensions shown.
ExceptforRadofascias,maintaina30mm
clearance around the fascia to ensure ease of
fasciaremoval.NB:Noclearanceisneeded
underneathVeloThreeSidedorRadoFascias
QUADRATO FASCIA ONLY: TheQuadratofasciamustnotbeinstalledushagainstahearthas
thereplacedrawsairfromthelowersurfaceofthefascia.Assuchthefasciamustberaiseda
minimum of 25mm from a hearth.
RADO
VELO / QUADRATO
TOP DOWN VIEW
Cavity
Framework
Gibbing
FIREPLACE
Wall Finish
Cavity
Framework
Gibbing
Wall Finish
FIREPLACE
min
min
min max
max

B
ACDEF G SERVICE
14
B10 Television Clearances:
Thefollowingaretherecommendedmini-
mumclearancesforthelocationofany
electricalequipment(suchasPlasmaTV,
LCDTVorhometheatre)aboveanEscea
DLSeriesgasre.Useeitherashelfor
mantlebelowyourTVscreenoralterna-
tivelyyoucanconstructarecesstomount
yourTVscreeninto.
Note:Theabovetelevisionclearance
recommendations are to be treated as a
suggestionofasuitableinstallationonly.
Itistheresponsibilityoftheenduserto
checktheinstallationinstructionsoftheir
electricalappliancestoensurethatthelocationinrelationtothegasreissuitable.Escea
innowayguaranteesortakesresponsibilitythattheaboveinstallationsuggestionwillbe
suitable for all electrical or home entertainment appliances.
B11 Corner Installations:
Ifacavityistobecreatedinacorner,thefollowingdraw-
inggivestheminimumsizedinteriorwalldimensions.
Minimum corner install dimensions (mm):
DL850 DL1100
A 970 1145
B 960 1260
C510 510
B12 Distance from Fireplace base to Fascia base:
Thefollowingside-onviewsshowthemeasurementfromthebaseofthereplacetothe
base of the Fascia.
FIRE
BASE
18mm
VELO
FASCIA FIRE
BASE
34mm
QUADRATO
FASCIA FIRE
BASE
0mm
RADO
FASCIA
45º
C
B
A
END OF SECTION B
Bytheendofthissection,youshouldhave:
□Aframed,butun-lined,cavitysizedtosuityourfasciaandueconguration
□Provisionforsucientaccesstothepowerueforfutureservicing

BACDEFGSERVICE
15
C Installing the Electricity and Gas to the Appliance
C1 Power Supply:
Whilstthecavityisbeingcreatedconsiderationshouldbegiventoappropriatelocation
ofastandard3pin,EARTHED230/240Vpoweroutlet.Thismustbewithin1.0moftherear
bottom left hand corner of the appliance.
IMPORTANT:Locatingthepoweroutlet
withinthecavitymakestheinstallation
veryneatbuttheprovisionMUST be
made to be able to switch the power
supplyoandon(electricalisolation
switch)andMUSTbeaccessibleafterthe
heater has been installed. This is normal-
lydonebymeansofaseparateswitch
whichmustbelocatedadjacenttothe
applianceasperAS/NZS5601.1.2010.
This will allow service technicians to iso-
latethepowersupplybeforeperforming
serviceworkontheappliance.
Thisappliancemustnotbelocateddirectlybelowasocketoutlet.
Thisappliancewilldrawamaximumof2Ampsfroma230/240Vsupply.Noadditional
powersupplyisrequiredforthepowerue.
Anelectricalwiringdiagramislocatedunderneaththeelectronictray,andalsointherear
ofthismanual(Servicesection)
C2 Network Cable:
Iftheapplianceistobewiredtoahomeautomationsystemorinternetrouter/networkis
beinginstalledthenprovisionmustbemadeforthenetworkcabletogettothecontrol
tray.Aknockoutisprovidedontherearleftoftheapplianceforanetworkcabletopass
throughthechassisandreachthecontroltray.Allowenoughslackinthenetworkcable
toensuretheelectronictraycanstillberemovedfromtheappliance.SeeSectionE2for
nalconnectionofthenetworkcable.
Networkcable
positions
Appliance
Mains Cord

B
A C DEF G SERVICE
16
C3 Gas Pipe Sizing:
GaspipeshouldbesizedaspertherequirementsofAS/NZS5601.Thepipesizingmust
besucienttodeliverthefollowingvolumeofgastotheheaterwithallothergasappli-
ancesinthehomerunningatthesametime:
DL850 Gas Consumption = 38MJ/hr
DL1100 Gas Consumption = 43Mj/hr
C4 Gas Pipe Position:
TheDL850/DL1100has2possibleentrypointsforgaspipe,ontherearrightcornerand
thefrontright.Eachissealedbya‘knock-out’.Removeonlytheknock-outwhichyoure-
quire,andplacethesuppliedrubberplugintothehole.Youwillneedtomakeasmallcut
intotherubberplugtoallowthegaspipetopassthrough,keepingtheplugasair-tight
as possible.
Thegasconnectionontheapplianceisa½”femaleBSPattheveryfrontrightoftheap-
pliance.Thissectionofthepipingwillneedtobeexibletoallowforpipedisconnection
andreboxremoval.
C5 Gas Isolating Valve:
Itisrecommendedthatagasisolatingvalvebeinstalledasclosetotheregulatoronthe
gasinletsideaspossiblewitheasyaccessifthefasciaisremoved.Thiswillallowforeasier
servicinginthefuture.
C6 Pressure Test Point:
AsperAS/NZS5601,apressuretestpointshallbeprovidedbytheinstallerattheinletof
the appliance
Gas pipe entrypositions
Regulator
Inletgas connection
END OF SECTION C
Bytheendofthissection,youshouldhave:
□Anunlinedcavitywithastandardthreepin230/240VACsupplythattheappliance
canbepluggedinto
□Anelectricalisolatingswitchthatisaccessibleoncetheapplianceisinstalled
□Asuitablysizedgassupplytotherighthandsideoftheappliancewithapressure
testpoint,readytobeconnectedonceinstalled
□Networkcableinstalled,readyforpluggingintoappliance(ifbeingconnectedto
internetrouter/network)

BACDEFGSERVICE
17
D Installing the ue
ForHorizontallyterminatedue,seesectionD1.ForVerticallyterminatedue,seesection
D5.
D1 Horizontal Powerue Description
Note:Theapplianceisdesignedonlyto
operateusingtheapprovedexibleue
suppliedbyEscea.Otherbrandsofuemay
nott,andthiswillaecttheappliance
warranty.
TheHorizontalPowerueWallTerminalmust
be installed in the correct orientation. This
allowsforthecorrectoperationoftheue
systemandpreventstheingressofrain.
TheHorizontalPowerueWallTerminalmust
beweather-tightwheninstallationiscom-
pletetopreventdamagetothedwelling.
Itmustbeinstalledbyasuitablyqualied
person.
Accesstothepoweruefromtheoutsidemustbeprovidedforservicing,andthisshould
betakenintoconsiderationwheninstallingintallbuildings.

B
A C DEF G SERVICE
18
D2 Installing in Accordance with Relevant Codes:
ThelocationoftheHorizontalPowerueWallTerminalmustbeinstalledinaccordance
withAS/NZS5601andanyotherrelevantbuildingcodes.Ifpossible,avoidinstallingthe
HorizontalPowerueWallTerminalinareasexposedtohighwindsandextremeweather.
Some of the minimum clearances for a fan assisted wall terminal are listed below; please
refertoAS/NZS5601Gasinstallationstandardforfullguidanceonthedesignoftheue
system.Wherepossibleallowagreaterclearance.
A Beloweaves,balconiesandotherprojections 200mm
B Fromtheground,aboveabalconyorothersurface 300mm
C Fromareturnwallorexternalcorner 300mm
DFromagasmeterorregulatorvent 1000mm
E Fromelectricitymeterorfusebox 500mm
F From a drain pipe or soil pipe 75mm
GHorizontallyfromanybuildingstructureorobstruction 500mm
H Fromanyotherueterminalorcombustionairintake 300mm
JHorizontallyfromanyopenablewindow,door,non-mechanicalair
inlet,oranyotheropeningintoabuildingwiththeexceptionofsub
oorventilation
300mm
K From a mechanical air inlet or spa blower 1000mm
N Verticallybelowanyopenablewindow,door,non-mechanicalair
inlet,oranyotheropeningintoabuildingwiththeexceptionofsub
oorventilation
300mm
6.2

BACDEFGSERVICE
19
D3 Creating the Hole in the Outside Wall
Whencuttingtheholeintheoutsidewall,bemindfulofhowthe
installationHorizontalPowerueWallTerminalwillbenished,the
installation must be weatherproof.
Idealhole/cavitysizeforHorizontalPowerue
WithoutSideBrackets WithSideBrackets
X298mm 360mm
Y298mm 298mm
Z 175mmExcludingallowanceforuewhichexitshere
TheHorizontalPowerueWallTerminalcanbeattachedtothewallintwoways,
A)Fromthefrontoftheterminal:
B)ByattachingtheoptionalWallTerminalInstallationBracketstothesidesofthecavity
andattachingtheHorizontalPowerueWallTerminaltothese,fromthefront:
D4 Installing the Horizontal Powerue Wall Terminal
AttachtheØ100mmandØ75mmexiblealuminiumuestothespigotsontherearof
theHorizontalPowerueWallTerminalusingthehosebandclampssupplied.Plugthe
powerueelectricalcableintothebackoftheHorizontalPowerueWallTerminal.
Ensurethattheelectricalcableisrmlysecuredtothewallterminalorbuildingtopre-
ventdamageordisconnectionifpulled

B
A C DEF G SERVICE
20
FittheHorizontalPowerueWallTerminalintotheholeandxinplace,makingsurethe
installationissealedappropriatelytopreventtheingressofwaterfromoutsidethewall
cladding.
NOTE:ItistheresponsibilityoftheinstallertoensuretheHorizontalPowerueWall
Terminalisinstalledtoallrelevantbuildingcodestoensureweathertightness.Thismay
nesesitatetheuseofappropriateashingmaterialwhereappropriate.
IMPORTANT:Ensurethatashingsdonotrestricttheairintakeslotaroundtheperiphery
of the cowl
D5 Vertical Power Flue
TheVerticallyterminateduekitisintendedforusewithinanaccesableroofspaceor
accesable‘chimney’construction. Service access must be provided.
To appliance
Typical Installation Vertical High Wind Terminal
‘Decktite’orsimilarflashing
Ø203mm/8”Co-axial Flue
Hosebandclamps
Ø75mmØ100mm
Ensure Power Flue unit
is securelybracedusing
integral brackets.
Roof Space
Power cord to
appliance
