Escea DX1000 User manual

Installation / Service Guide
For the latest documentation, visit www.escea.com 630228_5
DX1000 / DX1500
Gas Fireplaces

Important:
The appliance shall be installed in accordance with;
• Thisinstallationinstructionbooklet
• Localgasttingregulations
• Municipalbuildingcodes
• Electricalwiringregulations
• Anyotherrelevantstatutoryregulations.
• AS/NZS5601:2010GasInstallations
Thisapplianceisnotintendedforusebyyoungchildrenorinrmpersonsunlessthey
havebeenadequatelysupervisedbyaresponsiblepersontoensurethattheycanusethe
appliancesafely.
Youngchildrenshouldbesupervisedtoensurethattheydonotplaywiththeappliance.
Manufacturedby:EsceaLtd,POBox5277DunedinNZ,Ph:+6434788220
ForcontactdetailsofyourlocalEsceadistributorordealerpleasevisit:
www.escea.com inf[email protected]
WARNING:
Failure to follow these instructions could cause a malfunction of this appliance, which
couldresultindeath,seriousbodilyinjury,and/orpropertydamage.Failuretofollow
theseinstructionsmayalsovoidyourreinsuranceand/orwarranty.
Thisappliancemustnotbemodied.
THIS APPLIANCE MUST BE FITTED WITH AN ESCEA REMOTE ROOM AIR FAN
AND SUITABLE RETURN AIR VENTILATION
THIS APPLIANCE MUST BE FITTED WITH AN ESCEA REMOTE FLUE FAN
THE TERMINAL MUST ALWAYS VENT DIRECTLY OUTDOORS
Who can install this product:
Installationmustbecarriedoutbyaqualiedandregisteredinstallerwho,oncompletion
oftheinstallation,mustissuea:
AUS:CerticateofCompliance
NZ:EnergyWorkCerticate
inaccordancewithnationaland/orlocalcodes.IfthesearenotissuedthentheEsceawar-
rantymaybevoid.

Warranty Repair and Annual Servicing:
WarrantyrepairworkmustbecarriedoutbyarecognisedEsceagasreplacetechnician.
ItisrecommendedthatrecognisedEsceaGasFireplaceTechniciansarealsousedtocarry
outannualservicingrequirements(particularlyduringthewarrantyperiod).Forcontact
detailsofauthorisedEsceaGasFireplaceTechniciansinyourarea,pleasecontactthe
retailer from whom the appliance was purchased.
General installation information:
Thisappliancemustbeinstalledaccordingtotheseinstructionsandincompliancewith
allrelevantbuilding,gastting,electricalandotherstatutoryregulations(eg.AS/NZS
5601).Anyshortcomingsintheapplianceandueinstallationwillbetheresponsibility
oftheinstaller,andEsceawillnotbeaccountableforanysuchfailingsortheirconse-
quences.
Oncethisapplianceisinstalleditcannotberemovedwithoutdisturbingthewalllining.
ThisDXSeriesreplaceshasbeendispatchedfromthefactorysetasasinglesidedver-
sion.ThiscanbeconvertedintoadoublesidedappliancebyusingtheDoubleSided
ConversionKitavailablefromyourEsceadistributor.Conversiondetailsareshownin
SectionE.
Anelectricianisrequiredtoinstalla3pinpowersocket–SectionC

Contents
A Installation Process and Product Description 6
A1 RecommendedInstallationProcess: 6
A2 ProductDescription 6
A3 ProductDimensions 7
B Creating the Cavity 8
B1 CavityShape 8
B2 DesigningtheCavity 8
B3 FlueConguration 9
B4 FramingDimensions 10
B5 CavityBase 10
B6 Hearth 10
B7 WallLinings 10
B8 Fascia 11
B9 MantleClearance 11
B10 TelevisionClearances 11
B11 Ducting 12
B12 DuctFanmounting 13
C Installing the Electricity and Gas to the Appliance 14
C1 PowerSupply 14
C2 NetworkCable 14
C3 GasPipeSizing 15
C4 GasPipePosition 15
C5 GasIsolatingValve 15
D Installing the Flue 16
D1 InstallingtheHorizontalPowerueWallTerminaloption 16
D2 InstallingtheVerticalPowerueRoofTerminaloption 17
D3 InstallingtheHorizontalPowerueoption 18
D4 InstallinginAccordancewithRelevantCodes 18
D5 CreatingtheHoleintheOutsideWall 19
D6 HowtoashtheHorizontalPowerue 20
D7 HowtoashtheVerticalPowerue 20
D8 RunningtheFlue 21
D9 RunningthePowerueElectricalCable 21

E Installing the Appliance 22
E1 DoubleSidedconversion 22
E2 InstallingtheAppliance 23
E3 ConnectingtheFlue 23
E4 ConnectingtheNetworkCable 23
E5 RemovingtheGlass 24
E6 RemovetheFuelbedTray&Burners 24
E7 GasTypeConversion 25
E8 CheckingtheGasOperatingPressure 27
E9 OperatingtheAppliance 27
E10 AuxillaryOn/Obutton 28
E11 Reinsertingfuelbedandceramicglass 28
F Finishing the Installation 29
F1 CrystalliteFuelBedInstallation 29
F2 Walllining 29
F3 FittingtheFasciaPanels 30
F4 LocatingWallMountCradleforWirelessControl 31
F5 OperatingtheAppliance 31
F6 Finalchecklist 32
F7 NormalOperatingSoundsandSmells 33
G Installation Checklist 34
S Service Manual 35
S1 Annualserviceprocedure 35
S2 ErrorCodes 36
S3 CleaningtheFuelbedandGlass 38
S4 CheckingOperatingPressure 39
S5 ReplacingaRemoteControl 40
S6 Replacingtheburners 41
S7 Accessingthecontroltray 42
S8 RemovingtheCircuitBoard 42
S9 ServicingtheHorizontal/VerticalPowerue 44
S10 WiringDiagram 45
S11 Esceaproductwarranty 46
S12 DX1000StarRatingLabels 49
S13 DX1500StarRatingLabels 50

B
ACDEF G SERVICE
6
A Installation Process and Product Description
A1 Recommended Installation Process:
Thefollowingdiagramillustratesthestepsrequiredtoinstallyourgasre,andthetrades
requiredateachstage.
Thesequenceinwhichyouchoosetodothesetaskswillvarydependingonyourindi-
vidualinstallation.Pleasereadtheseinstructionscarefullybeforeproceedingwiththe
installation.Leavetheinstallationoftheoptionalfasciapanelsuntiltheveryendofthe
installationandcommissioningtoavoiddamagetothefasciapanels.
Create the Cavity Install electrical / gas
connections, ue system, and
replace
Finish installation and t
fascia
SectionB SectionC,D Section F
A2 Product Description
TheEsceaDX1500/DX1000gasreisadirectvent(fandraughtbalancedue),room
sealedgasappliancedesignedtobebuiltintoacavity.Thisapplianceisuedusingaco-
linearexiblealuminiumueconnectedtoapowerueterminal.
Thehotairfromthegasreistransferredtotheroomviaducting.
TheuserwillcontroltheirrewiththeRadioFrequency(RF)remotethatwillnormallybe
leftinitswallmountcradle.InadditiontotheRFremoteithasasingleauxiliaryOn/O
buttonontheunit.Whennotinoperationitisinastandbymodeunlessitisphysically
isolatedfromthemainssupply.

BACDEFGSERVICE
7
A3 Product Dimensions
NOTTOBEMISTAKENFORCAVITYDIMENSIONS
Alldimensionsareinmm
61
183
A
744
B
382
70
372
DX1000 DX1500
A664mm 914mm
B1328mm 1828mm

B
A C DEF G SERVICE
8
B Creating the Cavity
B1 Cavity Shape
The DX1500 / DX1000 is suitable for timber framed cavities.
Mostexistingmasonrycavitieswillnotbesuitable.
Thecavitydesign&shapewillbedependentonanumberofthings:
B2 Designing the Cavity
Thefollowingaspectsmustbeconsideredwhendesigningthisinstallation:
• Appliancephysicalsize
• SinglesidedorDoublesided
• Wallnishingandinteractionwithappliance
• Positioningofapplianceinregardstowalllining(depthintowall)
• IsaFasciatobeused?onesideortwosides?
• Exhaustcowlaspect–horizontal/verticalandueconguration
• Flueexhaustfannoise
• Exhaustcowlaccessformaintenance
• Ductlayoutandcavityspacestorunducting
• Ductfanposition
• Accesstoductfanformaintenance
• Gaspipelayout
• Gasisolationvalve/pressuretestpointposition
• Electricalisolationswitch
• Homeautomationnetworkconnections-Ethernetcablelayout
□
Thecavityandwallliningsmaybeconstructedfromstandardtimberframingmaterials
and do not need to be non-combustible.
Donotlinethetopofthecavity.
Itisnotnecessarytolinethesides,orbackofthecavity.
This DX1500 / DX1000 re is to be installed prior to any wall lining.
The wall lining is the very last task to be completed in this installation.

BACDEFGSERVICE
9
B3 Flue Conguration
Therearetwobasictypesofueconguration,usingaverticalpoweruecowl,orahori-
zontalpoweruecowl.Thehorizontalosetoftheterminalcanbeanyamountuptothe
totaluelengthlistedbelow.
10m MAX
X
Y
X + Y = 12m MAX
= 0.6m MIN
Note: You must provide sucient access to the powerue to enable it to be serviced in the
future. This means that the fan unit must have sucient access to allow it to be replaced if
necessary.
Theuemustbesecurelyxedandadequatelysupportedbybracketsfastenedtothe
buildingstructureatsuitablepointstoensurethestabilityoftheuesystem.
Anyjointswithintheuesystemmustbesealedadequately,withasealingagentused
ifnecessary.TheuesystemfortheDX1500/DX1000iszerorated,sonospacesare
requiredbetweentheueandanytimberframing.
HorizontalFlueoption
Minimum:600mmuelength
Maximum:Totaluelength12m
□
VerticalFlueoption
Minimum:600mmuelength
Maximum:Totaluelength10m
For ue installation, see section D
ONLY USE ESCEA APPROVED FLUE COMPONENTS
Note: All sections of horizontal ue must be sloped back toward the re at a rate
of no less than 20mm per metre, to allow any condensation to run back into the
appliance.

B
A C DEF G SERVICE
10
B4 Framing Dimensions
DX1000: MIN
800
MIN
450
MIN
381
Front Side
Single Sided
Side
Double Sided
1400
DX1500: MIN
1900
Framing Dimensions - Bench top / Hutch style
150 MIN
1150 MIN
400 MIN
B5 Cavity Base
ThisapplianceMUSTbefullysupportedonitsbase,overtheentireareaoftheunderside
oftheappliance.Thebasemustalsobelevelandstrongenoughtosupportthetotal
productweight,whichisapproximately100kg(DX1000)or120kg(DX1500).
B6 Hearth
Nohearthisrequired
B7 Wall Linings
Theappliancemustbeinstalledpriortoandbehindthenishedwallsurface.Takeinto
accountanyplasterboard,tilesoranyothernishingsurfacethatmaybeintendedfor
thenishedwallsurface.Wallnishingmaterialsmustnotencroachupontheminimum
cavityclearancesgiveninprevioussections.Thewallboardthatlinestheoutsideofthe
openingcanbenormalplasterboardanddoesnotneedtobenon-combustible.
Note:Thenalwallliningmustnotencroachwithinthespecieddimensionsinthissec-
tionorsectionB8.Thesedimensionsindicatetheopeningrequiredinanywalllining.
ThesedimensionsareforDX1500/DX1000withoutfascia,ifusingafasciathenplease
checkthefollowingsectionofthismanualforseparatewallliningdimensions.

BACDEFGSERVICE
11
ThePlasterboardistoprotrudebeyondframeworkasshowninthefollowingdiagram.
362
SideFront
362
192
DX1000: MIN
1062
DX1500:
MIN
1562
Note:Thewallliningdirectlyabovetheappliancewillgetwarmandhencemaydiscolour
paintnishesthataresusceptibletotemperaturedamageordistortvinylwallcoverings.
Fordurabilityofnishesandsurfacesyoushouldcontacttherelevantmanufacturerfor
theirspecicationandavoidmaterialswithtemperatureratingslessthan80degC.
B8 Fascia
Ifusinga(velo)fascia,thecutoutrequiredinthenishedplasterboarddimensionsare:
410
DX1000: MIN
1100
DX1500: MIN
1600 10
FASCIA
Notethat10mm(orless)wallliningmustbeusedwheninstallingaDX-seriesreplace
withafascia,asthisisthedistancethefasciasitsothefrontfaceofthereasshown.
B9 Mantle Clearance
Pleaserefertothediagram.Mantlesorprotrudingledgesabove
the heater must not be installed lower than the dimension shown.
Notedimensionfrombaseofappliance.
B10 Television Clearances
Thefollowingaretherecommendedminimumclearancesforthe
locationofanyelectricalequipment(suchasaPlasmaTV,LCDTV
orhometheatresystem)aboveanEsceaDXSeriesgasre.
Note:Theabovetelevisionclearancerecommendationsaretobe
treatedasasuggestionofasuitableinstallationonly.Itisthere-
sponsibilityoftheendusertochecktheinstallationinstructionsof
their electrical appliances to ensure that the location in relation to
thegasreissuitable.Esceainnowayguaranteesortakesrespon-
sibilitythattheaboveinstallationsuggestionwillbesuitableforall
electrical or home entertainment appliances.
800
MIN
800
MIN
WALL OPENING
(WITHOUT FASCIA)
WALL OPENING
(WITH FASCIA)

B
A C DEF G SERVICE
12
B11 Ducting
Thisgasrerequiresasmallnetworkofductingsituatedeitherintheceilingorunderthe
oortodistributetheheatgeneratedbythisreplace.
TheDX1500/DX1000hasbeensuppliedwithaninlinecentrifugalroomairfanthat
drawsairfromtheroom,throughthegasreappliancethenpushesthewarmedairback
intothesameroomthroughatleast2ductoutletsandanoptionaloneintoahallway.
When placing outlets in rooms other than the room the appliance is installed, it is
important to allow for back ow to equalise pressure between the rooms, and to
allow for temperature regulation.
Caution: Neglecting to allow backow of return air to the replace can
result in a risk to personal safety to infants or inrm persons.
WARNING: OVERHEATED ROOMS ARE NOT SAFE FOR INFANTS
Theoneotherductcanbeinstalledintoanadjoininghallwayonly.Failuretofollowthese
instructions could cause serious harm to persons or appliance.
This fan is powered via a connection to the main appliance. This appliance has been sup-
pliedwithastandardductkitthatwillallow3x150mmoutlets-Youcanuseyourown
ductworkandoutlets,butyoumustensuretheyareratedtotemperaturesofatleast90
degreesCelsius.ThemaximumnumberofoutletsfortheDX1500is8,andDX1000is5.
Ductworkmustbeadequatelysizedtoavoidexcessbackpressures.Inadequateductsizes
willcauseunnecessaryfannoiseandprematurefanfailure.
Werecommendremovingthecloseapsfromallbutoneoftheductoutletstoprevent
unnecessarybackpressure.
Aminimumnumberof2outletsmustremainfullyopenatalltimesduringoperation.
Fannoisewillincreaseasbackpressureincreaseswithfeweroutletsopen.
□
Becausetheseductswillactassoundtubesthatamplifythesoundofthefan,youmay
considerinstallingairductsilencers.Avarietyoftheseproductsareavailablefromyour
localbuildingsupplierandcaneasilybeinstalledwiththissystem.Wealsorecommend
usingsoundabsorbingmaterialsforliningyourwalls,ductsandfan.Insulatingtheduct
systemwillalsohelpwithtotaleciency.
• CheckwithyourlocalcounciltochoosethecorrectR-valueduct.
• Ductworkshouldbeasshortaspossiblewhilemaintainingsmoothowingbends.
• Ductworkandoutletregistersmustbeadequatelysupported
• Alloutletregistersmustbefullyopenandfreefromobstruction.
• Ductworkmustnotbecrushedorexposedtoheatsources.
• Ensureductinganduepipesareseparatedandtiedback,sotonevertouch.
• Failuretofollowthismaycausefailureofductwork,andvoidthewarranty.
Note: If duct backpressure is too great, the appliance will shut down due to overheating.
This ducting fan will generate mechanical noise. It must be installed in a position where noise
will not interfere with daily activities. We recommend installing the fan within a garage roof
space for example. All air ducts will make noise no matter how well the system is designed.
Increasing the diameter and number of outlets is the best strategy to reduce this noise.

BACDEFGSERVICE
13
B12 Duct Fan mounting
Usingthe2xspringmountssupplied,theductfanshouldbeinstalledinahangingposi-
tionasperthedrawingbelow.Youmustusethespringmountsasthiswillhelpdecrease
noisebynottransferringvibrationintothewalls.
Wesuggestusingthelikesof“buildersstrapping”orsimilarasshowntohangthesprings
from.
Runtheelectricalcablefromtheductfantothecavitywheretheappliancewillbein-
stalled.Ensurethecableisnotdrapedoverorincontactwiththeoutershelloftheappli-
anceoreitheroftheexiuetubesandkeptclearfromanyotherpossibleheatsources.
Fixitappropriatelyandallowenoughcablelooptopreventtensiononthecableplugs.
END OF SECTION B
Bytheendofthissection,youshouldhave:
□Aframed,butun-lined,cavitysizedtosuityourfasciaandueconguration
□Provisionforsucientaccesstothepowerueforfutureservicing

B
ACDEF G SERVICE
14
C Installing the Electricity and Gas to the Appliance
C1 Power Supply
Whilethecavityisbeingcreated
considerationshouldbegivento
appropriate location of a standard 3 pin,
EARTHED230/240Vpoweroutlet.This
mustbewithin1.0mofthebottomright
of the appliance.
IMPORTANT:Locatingthepoweroutletwithinthecavitymakestheinstallationveryneat
butprovisionMUSTbemadetobeabletoswitchthepowersupplyoandon(electri-
calisolationswitch)andMUSTbeaccessibleaftertheheaterhasbeeninstalled.Thisis
normallydonebymeansofaseparateswitchlocatedoutsideofthecavityandwiredto
theplug.Thiswillallowtechnicianstoisolatethepowersupplybeforeservicingtheap-
pliance.
Thisappliancemustnotbelocatedimmediatelybelowasocketoutlet.
Thisappliancewilldrawamaximumof2Ampsfroma230/240Vsupply.
Noadditionalpowersupplyisrequiredforthepowerue.
C2 Network Cable
A5meterlengthofnetwork(Ethernet)cablehasbeensuppliedandiscoiledinsidethe
lowerrightofthereplace.Accessthisviatheremovableaccesspanel,andconnectitto
thebuildingsmodem.
If you do not wish to connect the replace to the modem, the Network /
Ethernet cable should be run to somewhere accessible by a service
technician, such as a cupboard.
1m

BACDEFGSERVICE
15
C3 Gas Pipe Sizing
GaspipeshouldbesizedaspertherequirementsofAS/NZS5601.Thepipesizingmust
besucienttodeliverthefollowingvolumeofgastotheheaterwithallothergasappli-
ancesinthehomerunningatthesametime:
DX1500 Gas Consumption = 42MJ/hr
DX1000 Gas Consumption = 33MJ/hr
C4 Gas Pipe Position
Thegasconnectionisinsidetheapplianceandis½”maleBSPonthelowerrightofthe
applianceasshown.Accessisthroughthebottomoftherebox.
C5 Gas Isolating Valve
Agasisolatingvalvemustbeinstalledinthegaslineasclosetotheapplianceaspossible.
Fixitinaconvenientpositiontoallowittobeclosedoquicklyandeasilyduringnormal
operation.Takeintoconsiderationaccesstothisvalveoncethewallliningsareon.This
willalsoallowforeasierservicinginthefuture.
END OF SECTION C
Bytheendofthissection,youshouldhave:
□Anunlinedcavitywith230/240VACsupplythattheappliancecanbepluggedinto
□Anelectricalisolatingswitchthatisaccessibleoncetheapplianceisinstalled
□Asuitablysizedgassupplytotherighthandsideoftheappliancewithapressure
testpoint,readytobeconnectedonceinstalled
□Networkcableinstalled,readyforpluggingintoappliance,regardlessofbeing
connectedtointernetrouter/networkornot

B
A C DEF G SERVICE
16
D Installing the Flue
Note:Theapplianceisdesignedtooperateusingtheapprovedexibleuesuppliedby
Escea.Usingotherbrandsofuemayaecttheappliancewarranty.
D1 Installing the Horizontal Powerue Wall Terminal option
TheHorizontalPowerueWallTerminalmustbeinstalledin
the correct orientation. This allows for the correct operation
oftheuesystemandpreventstheingressofwater.
TheHorizontalPowerueWallTerminalmustbeweather-
tightwheninstallationiscompletetopreventdamageto
thedwelling.Itmustbeinstalledbyasuitablyqualied
person.
FittheHorizontalPowerueWallTerminalintotheholeandxinplace,makingsurethe
installationissealedappropriatelytopreventtheingressofwaterfromoutsidethewall
cladding.Takenoticeofthelabelontheterminationwhichshowsthecorrectorientation
thattheterminalshouldbetted.
NOTE:ItistheresponsibilityoftheinstallertoensuretheHorizontalPowerueWallTermi-
nalisinstalledtoallrelevantbuildingcodestoensureweathertightness.

BACDEFGSERVICE
17
D2 Installing the Vertical Powerue Roof Terminal option
Theverticalueoptionisdesignedtohavetheboxcontain-
ingthefanandelectricalsmountedwithintheroofspaceof
thehouse,andthevertical200mmdiametertwinwallue
penetratethroughtheroof.Thestandardkitcomeswith1.2m
oftwinwallue(postfan),butyoucanaddasmuchasyou
requiretoachievethedesiredinstallation.Notetotalcombined
maximumverticaluemustbelessthan10metres.
Usestandardmethodstoashtheroofpenetration,theinstal-
lation must be weather proof and conform to all local council
standardsincludingpoweredueroofterminationrules.
Thecowlsurroundshouldbexedinplaceasshown
Mountthefanassemblyboxtoroofframingusingtimberor
buildersstrapping,ensuringtheueisverticalandrigidly
mounted.
Aimtohavethefanboxmountedashighaspossible,mainlyto
allowsucientfallforcondensationdrainageiftheexi-ueis
torunhorizontally.
Ensurethereissucientspacebelowfanboxtohaveaccessto
ttheexi-uetubesandtoallowowingbendsifrequired.

B
A C DEF G SERVICE
18
D3 Installing the Horizontal Powerue option
ThelocationoftheHorizontalPowerueWallTerminalmustbeinstalledinaccordance
withAS/NZS5601andanyotherrelevantbuildingcodes.AvoidinstallingtheHorizontal
PowerueWallTerminalinareasexposedtohighwindsandextremeweather,ifpossible.
D4 Installing in Accordance with Relevant Codes
Some of those minimum clearances for a fan assisted wall terminal are listed below;
pleaserefertoAS/NZS5601Gasinstallationstandardforfullguidanceonthedesignof
theuesystem.Wherepossibleallowagreaterclearance.
A Beloweaves,balconiesandotherprojections 200mm
B Fromtheground,aboveabalconyorothersurface 300mm
C Fromareturnwallorexternalcorner 300mm
DFromagasmeterorregulatorvent 1000mm
E Fromelectricitymeterorfusebox 500mm
F From a drain pipe or soil pipe 75mm
GHorizontallyfromanybuildingstructureorobstruction 500mm
H Fromanyotherueterminalorcombustionairintake 300mm
JHorizontallyfromanyopenablewindow,door,non-mechanicalair
inlet,oranyotheropeningintoabuildingwiththeexceptionofsub
oorventilation (or 1500mm in direction of discharge)
300mm
KFrom a mechanical air inlet or spa blower 1000mm
N Verticallybelowanyopenablewindow,door,non-mechanicalair
inlet,oranyotheropeningintoabuildingwiththeexceptionofsub
oorventilation
150mm
6.2

BACDEFGSERVICE
19
D5 Creating the Hole in the Outside Wall
Whencuttingtheholeintheoutsidewall,bemindfulofhowtheinstallationHorizontal
PowerueWallTerminalwillbenished,theinstallationmustbeweatherproof.
Idealhole/cavitysizeforHorizontalPowerue
X298mm
Y298mm
Z 175mmExcludingallowance
foruewhichexitshere
TheHorizontalPowerueWallTerminalcanbeattachedto
thewallintwoways,
A)Fromthefrontoftheterminal:
B)ByattachingtheoptionalWallTerminalInstallationBracketstothesidesofthecavity
andattachingtheHorizontalPowerueWallTerminaltothese,fromthefront:

B
A C DEF G SERVICE
20
D6 How to ash the Horizontal Powerue
Thefollowingdiagramsareexcerptsfromtheesceaarchitectdrawings,andareavailable
infullonourwebsite.Thesediagramsarerecommendations,andyourinstallationmust
complywithanylocalornationalbuildingcodes.
D7 How to ash the Vertical Powerue
