PRO SERIES AIR HOSE REEL

Operating Instructions

Model 10970

65 ft. | 20 m Hose Included

1

4

8

7

2

3

6

5

The ESCO PRO SERIES Hose Reel with a

precision machined solid brass internal

spindle for strength and reliability, combined

with the unique HELIX Ultra-Coil self layering

system, sets a high standard of hose reel

performance.

The ESCO PRO SERIES Hose Reel has been

manufactured using the highest quality

materials. This multi-purpose hose reel is

suitable for standard water applications and

is ideal for use around the home, automotive

workshop or industrial site.

FEATURES

•Precision machined solid brass internal

spindle for strength and reliability.

• Unique HELIX Ultra-Coil self layering hose

system provides tangle free operation.

• Fully enclosed outer case protects hose and

inner drum against dirt and other

contaminants.

•High impact and weather resistant

UV stabilized polypropylene case.

• Auto lock and auto rewind mechanism

provides positive hose latching every

full revolution ofthe hose inner drum.

• Extreme Ultraflex Reinforced Hose with an

additional 6.5 ft. | 2 m leader hose.

• Quality brass hose connectors and tap

fittings

•Heavy duty mounting bracket, locking plate

and pivot pin for fixed in-line or optional 180°

swivel mount.

• Suitable for both wall or overhead mounting.

• Convenient carry handle located on top of

the case allows easy removal and refitting of

the hose reel tothe mounting bracket.

PRODUCT IDENTIFICATION

1. Mounting Bracket

2. Optional Fixed In-line Locking Plate

3. Pivot Pin

4. Fully Enclosed Case

5. Carry Handle

6. Solid Brass Internal Spindle

7. 6.5 ft. | 2 m Leader Hose

8. Hose with Adjustable Stopper

INSTALLATION

The ESCO PRO SERIES Hose Reel can be

mounted in a horizontal or vertical position.

1. Chose a location that is near to the water

source or compressed air source.

2. For large areas, place the hose reel at the

centre of the work area.

3. When mounting the hose reel vertically,

ensure there is adequate clearance under

the reel to prevent injury or damage.

4. Mounting bracket must be installed on

a at surface.

Note: It is recommended to install the

mounting bracket 2.6 ft. | 0.8 m (minimum)

above the floor level.

5. Drill 4 x M8 holes to

match the holes located

in the Mounting Bracket.

(Fig. 1)

6. Connect the hose reel

to the Mounting Bracket

with the Pivot Pin.

(Fig. 2)

Note: For xed in-line

position, t the locking

plate onto the Mounting

Bracket prior to inserting

the pivot pin. (Fig. 3)

7. Connect the inlet

leader hose to the

source using the

ttings supplied.

Note: Apply thread sealing

tape to all air line and air

hose ttings.

OPE R ATION

1. Slowly pull out the hose to the required

length. A ‘clicking’ noise will be heard every

revolution of the inner drum. To lock the reel,

allow the hose to retract slowly after hearing

the second or third ‘click’.

2. To release the hose, pull out the hose until

the ‘clicking’ noise stops, and then allow the

hose to slowly retract while guiding the hose

back into the hose reel. The self layering

mechanism will coil the hose back onto the

inner drum.

3. To avoid injury and damage, always hold

the hose while it is retracting.

IMPORTANT:

If the hose becomes tangled and will not

retract - slowly pull out the hose past the

tangled section and then allow the hose to

slowly retract while guiding the hose back

into the hose reel.

Always ensure the hose is clean and

not twisted.

2.6 ft. / 0.8 m min.

Fig. 1 Mounting Bracket

Fig. 2 Pivot Pin

Fig. 3 Locking Plate

SPECIFICATIONS

Model

No.

Hose

Length

Hose

Material

Working

Pressure

Hose

I.D.

Hose

O.D.

Leader

Hose

Inlet

Size

10970 65 ft.

20 m

Extreme Ultraex

Reinforced

Max. 300 p.s.i.

(2068 kPa)

3/8 in.

9.2 mm

1/2 in.

15.2 mm

6.5 ft.

2 m

1/4” NBT

Male

MAINTENANCE

• Always keep the hose clean.

• If the hose becomes dirty, clean it with

a damp cloth while retracting.

• DO NOT twist the hose while in use.

• Mount the hose reel in a sheltered area to

assist and protect the performance of the

hose and hose reel.

•DO NOT allow the hose to contact any

corrosive chemicals orfluids.

•Always retract the hose when not in use.

•The ESCO PRO SERIES Hose Reel

contains a pre-tensioned spring inside the

inner drum assembly.

Do not attempt to open the inner drum

assembly.

ADJUSTING THE STOP-BALL

The location of the hose stopper can be

adjusted to allow more hose or less hose to

be exposed when fully rewound.

1. Pull out the desired length of hose, ensuring

the hose reel is in the lock position.

2. Open the latch on the hose stopper and

move it to the desired position on the hose.

3. Re-latch the hose stopper at desired

position

CAUTION:

Always make sure the hose reel is in the

locked position before removing the hose

stopper and make sure the hose stopper is

securely fastened before unlocking the reel.

WARRANTY

&CLAIM PROCEDURE

The ESCO PRO SERIES Hose Reel

is covered against defects in material and

workmanship.

In the instance of a warranty claim, the owner

will be entitled to a replacement unit or a

sufcient repair of the defective part/s and

or component/s to ensure normal operating

condition of the hose reel.

WARRANTYEXCLUSIONS

The hose, rubber o-rings and hose stopper

are deemed normal wear items and are not

covered under warranty.

The warranty does not extend to parts or

components affected or damaged by

accident, normal wear, misuse, neglect or

faulty installation.

Toregister a warranty claim contact:

ESCO - Equipment Supply Co.

Phone: 1-800-352-9852

Fax: 352-754-4508

E-mail: [email protected]

NOTES

________________________________________________________________________________

NOTES

________________________________________________________________________________

www.esco.net

Distributed by

ESCO - Equipment Supply Co.

15270 Flight Path Drive, Brooksville FL, 34604

[email protected]

For more information contact Customer Service on

1-800-352-9852
