Essilor Eye-Ruler 2 User manual

INSTALLATION MANUAL

Your package includes:
›1 Eye-Ruler 2 device (1)
›1 jig for iPad 3 (2)
›1 jig for iPad (Air 1, Air 2, new iPad and iPad Pro 9.7”) (3)
›1 magnetic charging cable (4)
›1 power supply (5)
›2 measurements clips (6)
›1 adapter for iPad 3 (7)
›2 magnets (8)
1. DESCRIPTION
14 5
7
8
6
2
3

Take the iPad on which you wish to install Eye-Ruler 2:
›Get the correct jig for your iPad and position it (1).
›Align the notch on the back with the iPad’s front-facing camera (2).
›Peel off the sticker’s top layer of the magnet.
›Stick the magnet to the designated jig’s spot then remove the jig (3).
Once the magnet has been
placed, wait for 12 hours.
This is how long it takes the
sticker to dry.
The iPad must be
perfectly clean to place
the magnet properly.
›Position the device as it corresponds to the magnet portion (4).
2. DEVICE PREPARATION
12
43

Once the device is installed on the iPad, turn
on Eye-Ruler 2.
A blue light should appear on the side of the
device (1).
›Go to the iPad’s Bluetooth settings (2).
›Switch On Bluetooth, and connect to:
IVS device/pad.
Once this connection has been made the first
time, Eye-Ruler 2 will automatically connect to
the device (even if Bluetooth has been turned
off).
3. BLUETOOTH PAIRING
2
1

•SCENARIO 1
The device is detected by the app but the led cannot be turned on.
›Please contact your distributor.
•SCENARIO 2
The device is not detected by the app.
›Check that the device is charged. Green means the device is charged and
yellow means it needs to be recharged soon. If there is no light, there is no
charge left. If charging doesn’t work, the power supply needs to be replaced.
›Restart the iPad.
›Restart the iPad’s Bluetooth.
›If it still does not work properly, please contact your distributor.
•USING YOUR DEVICE
›Do not charge the device with another power supply than the one provided.
›Do not try to open the device, warranty will immediately be voided.
4. TROOBLESHOOTING
5. RECOMMENDATIONS
