General information
3
1 General information
Support for cleaning and maintenance
This document provides support for cleaning and
maintaining the product. The required steps are listed
in detail here.
Take note of the date of the cleaning or maintenance
and any faults that may have occurred. This facilitates
troubleshooting for the expert (system operator,
heating technician...).
For services (such as commissioning, mainte-
nance, fault fixing) provided by ETA customer
service, the service reports are provided in digital form.
For clarity, you should staple these reports to this
document or enclose them.
Commissioning data
Enter the manufacturing number of the product
(printed on the type plate), the date of commissioning
as well as the heating technician who commissioned
the system.
Software Description
The software version described in this documentation
corresponds to the version valid at the time of publica-
tion. The software version installed on your product
may differ from that described in this documentation.
A software update to a more recent version can
always be performed. With the appropriate au-
thorisation, the required files can be found at
"www.eta.co.at".
Copyright
All contents of this document are property of ETA
Heiztechnik GmbH and are protected by copyright.
Any reproduction, transfer to third parties or use for
other purposes is prohibited without written permission
from the owner.
Subject to technical changes
We reserve the right to make technical modifications
without notice. Printing and typesetting errors or
changes of any kind made in the interim are not cause
for claims. Individual configurations depicted or
described here are only available optionally. In the
event of contradictions between individual documents
regarding delivery scope, the informationin our current
price list applies.
Explanation of symbols
Instructions and information
Layout of safety instructions
SIGNAL WORD!
Type and source of danger
Possible effects
• Measures for avoiding the danger
Types of safety instruction
CAUTION!
On non-compliance with this safety instruction, there is
a risk of material damage.
WARNING!
On non-compliance with this safety instruction, there is
a risk of physical injury.
DANGER!
On non-compliance with this safety instruction, there is
a risk of major physical injury.
Commissioning data
Manufacturing number:
________________________________________
Commissioned on:
_________________________________________
Commissioned by (company):
_________________________________________
_________________________________________
_________________________________________

4 www.eta.co.at
Maintenance notes Cleaning and maintenance
2 Cleaning and maintenance
2.1 Maintenance notes
Performing regular cleaning and maintenance
To ensure satisfactory functionality, cleaning and
maintenance must be performed at regular intervals.
You will receive a timely reminder about this from the
ETAtouch control system.
Cleaning of the boiler must be carried out at least
once a year, or when requested by the control
system. Maintenance is necessary at least every
3 years, or when requested by the control system. We
recommend that you perform maintenance annually.
You can also enter into a service agreement for your
heating system. Find out more from your heating
contractor or customer service.
All tasks where the maintenance table reads
"Customer" or "Customer or expert" in the column
"To be carried out by" can be carried out by any trained
adult. Instruction may be provided by the heating
technician or our customer service.
Steps that are marked with "Expert" only can only be
carried out by the heating technician or our customer
service.
Operation only by trained personnel
The product may be operated by trained adults only.
Training may be provided by the heating technician or
our customer service. Please read the associated doc-
umentation carefully in order to avoid errors during
operation and maintenance.
Persons who lack experience and knowledge as well
as children may not operate, clean, or maintain the
product.
Clean and maintain the precipitator together with
the boiler
The intervals for cleaning and maintaining the precipi-
tator correspond to those for the boiler. Therefore,
clean and upkeep the precipitator in the course of
cleaning and upkeeping the boiler.
Clean the precipitator before the emission
measurement
We recommend cleaning the precipitator before an
emission measurement is made. Therefore, empty the
precipitator ash box and clean the piping between
boiler and precipitator. Also clean the flue gas recircu-
lator if one is installed.
Explanation of pictograms
Switch the boiler on/off with the mains
switch.
Perform a visual check of the components.
Clean the components with a soft cloth, for
example.
Remove deposits with a vacuum cleaner or
an ash vacuum.
Remove deposits with the poker.
Remove deposits with the cleaning brush.
Replacethewearparts(e.g.,seals)withnew
items.
Lubricate the components. The lubricant to
use is listed in the respective step.
Mountthecomponents(e.g.,screwsor nuts)
by hand only, without tools.
Installthecomponentswithsomeforce(e.g.,
the retaining tube or the Lambda probe).
Handle the components carefully, since they
break very easily.
Measure or check dimensions or clearances
on the components.
Mark the components so that the correct
position can be found, for example, when
mounting.
Wear a protective mask to avoid injuries to
the airways.
Seal the components. The sealant to use is
listed in the respective step.
Use glue to adhere the seals, for example.
Do not use compressed air to clean the
components.

Cleaning and maintenance Maintenance notes
5
Do not use cleaning brushes to clean the
components.

6 www.eta.co.at
Maintenance openings Cleaning and maintenance
2.2 Maintenance openings
Maintenance openings and components
The illustration shows a precipitator for a boiler
with the fuel discharge on the left side.
1 Maintenance cover
2 Position switch for the electrode dedusting
3 Drive chain for the electrode dedusting
4 Position switch for the sliding rake
5 Drive chain for the sliding rake and ash screw
6 Draught fan
7 Ash box seal
8 Ash box position switch

Cleaning and maintenance Maintenance openings
7
1 Maintenance cover for optional flue gas recircula-
tion
2 Flue gas temperature sensor
3 Maintenance cover for the piping between boiler
and precipitator
4 Maintenance cover for optional flue gas recircula-
tion

8 www.eta.co.at
Maintenance table Cleaning and maintenance
2.3 Maintenance table
Cleaning must be carried out at least once a year or when requested by the control system. Maintenance is
necessary at least every 3 years or when requested by the control system. We recommend you perform
maintenance annually.
Tasks Regular
ly Cleaning
annually
Maintenan
ce
at least
every 3
years
to be
performed by
Empty the ash box
• Empty the ash box
• Check the seals X X X Customer
Clean the piping
• Clean the piping between boiler and precipitator
• Clean the flue tube from the precipitator to the chimney X X Customer or
specialist
Clean flue gas recirculation (if installed) X X Customer or
specialist
Clean the precipitator
• Check and remove ash accumulations
• Clean the flushing air opening
• Clean and inspect the electrode holder
• Check the alignment of the electrodes
• Check maintenance cover seal
X X Customer or
specialist
Check idle position
• Check idle position of the electrode dedusting
• Check the idle position of the sliding rake XSpecialist
Check de-ashing
• Check the drive chains and position switches of the
electrode dedusting
• Check the drive chainand the slidingrake position switch
XSpecialist
Clean the draught fan XSpecialist
Clean the temperature sensor XSpecialist
Check the ash box position switch XSpecialist
Check the safety switch for the maintenance cover XSpecialist

Cleaning and maintenance Regular maintenance
9
2.4 Regular maintenance
2.4.1 Empty the ash box
End heating mode
End the boiler's heating mode with the On/Off switch in
the boiler overview window. The boiler performs an
ember burnout and then changes to the [Switched off]
operating mode. Then start de-ashing, so that the
boiler can perform a final de-ashing.
Empty the ash box, inspect the seals
If the boiler ash box is already empty, also empty
the precipitator ash box. This prevents an
additional boiler switch-off.
Open both side fasteners by pressing their locks in the
direction of the arrow.
Fig. 2-1: Ash box
Remove the ash box from the precipitator. Remove the
cover by opening the fasteners and empty the ash box.
Fig. 2-2: Cover
Inspect the seal on the ash box cover to ensure it is in
good order, and replace it if necessary.
Fig. 2-3: Seal
Inspect the ash box seals on the precipitator to ensure
they are in good order and replace if necessary.
Fig. 2-4: Seal
After emptying the ash box, replace the cover on the
ash box and attach the ash box to the precipitator with
the two fasteners.
Fig. 2-5: Ash box
Once the ash box is attached, precipitator de-
ashing starts automatically in order to transport
the remaining ash to the ash box.

10 www.eta.co.at
Regular maintenance Cleaning and maintenance
Switch the boiler on via the mains switch and start
de-ashing
Restore the boiler's power supply from the mains
switch. Start de-ashing, so that the boiler can perform
de-ashing. Switch the boiler back on with the On/Off
switch.

Cleaning and maintenance Cleaning (customer)
11
2.5 Cleaning (customer)
2.5.1 Preparation
End heating mode
End the boiler's heating mode with the On/Off switch in
the boiler overview window. The boiler performs an
ember burnout and then changes to the [Switched off]
operating mode. Then start de-ashing, so that the
boiler can perform a final de-ashing.
WARNING!
Switch off the electricity to the boiler via the mains
switch
Switch off the electricity to the boiler via the mains
switch. This prevents injuries caused by switching
the boiler on inadvertently.
2.5.2 Clean piping
Clean the piping between boiler and precipitator
Open the maintenance cover in the piping.
Fig. 2-6: Maintenance cover
Only clean out the piping with an ash vacuum.
Fig. 2-7: Vacuum piping
To clean the top pipe, the heat exchanger cover
can also be removed from the boiler. Then the
pipe from the boiler can be cleaned out with the ash
vacuum.
WARNING!
Never brush ash into the precipitator
Only clean out the piping with an ash vacuum.
Never sweep ash into the precipitator as this can
block the precipitator's exhaust path. As a result,
the boiler can no longer ignite and this can lead to
deflagrations.

12 www.eta.co.at
Cleaning (customer) Cleaning and maintenance
Re-attach the maintenance cover to the piping.
Fig. 2-8: Maintenance cover
Clean the flue tube from the precipitator to the
chimney
Sweep the flue tube from the precipitator to the
chimney and remove flue ash from the chimney using
a vacuum cleaner.
Fig. 2-9: Flue tube
Brush the ash into the chimney and not the pre-
cipitator.
2.5.3 Clean flue gas recirculator (optional)
Clean flue gas recirculation (if installed)
Remove the two maintenance covers for the flue gas
recirculation from the back side.
Fig. 2-10: Maintenance cover
Also remove the maintenance cover from the bottom.
Fig. 2-11: Maintenance cover
Brush out the pipes with a cleaning brush and remove
the ash with a vacuum.
Fig. 2-12: Clean pipes

Cleaning and maintenance Cleaning (customer)
13
Fig. 2-13: Clean pipes
Then re-install all maintenance covers and the seals.
2.5.4 Clean precipitator
Remove maintenance cover and panels
Remove the panel from the top and remove the
insulating cover.
Fig. 2-14: Panels and insulating cover
Remove the maintenance cover.
Fig. 2-15: Maintenance cover

14 www.eta.co.at
Cleaning (customer) Cleaning and maintenance
Check and remove ash accumulations
Inspect the inner walls of the precipitator for ash accu-
mulations. Cleaning is not functioning correctly if there
is too much ash on the inner walls or on the electrodes.
The cause must be found and eliminated.
Fig. 2-16: Ash accumulations
Use the cleaning brush to carefully scrape the ash ac-
cumulations from the inner walls. Especially the area
above the sliding rake.
Fig. 2-17: Clean the inner walls
Do not damage or bend the electrode during
cleaning.
Fig. 2-18: Electrode
Also clean the narrow duct in the precipitator flue gas
inlet. The ash can fall down. Then remove this with an
ash vacuum.
Fig. 2-19: Clean the inner walls

Cleaning and maintenance Cleaning (customer)
15
Inspect the ash accumulations in the lower area of the
precipitator through the opening on the top. The ash in
particular must be removed with an ash vacuum from
the transitions at the bottom.
Fig. 2-20: Remove ash from transition
Clean flushing air opening
Vacuum out the opening for the electrode flushing air
on the isolator on the inside of the precipitator.
Fig. 2-21: Flushing air opening on the isolator
Do not clean the opening with compressed air,
because this will stir up the ash,which can end up
in the precipitator control system and cause damage.
Clean and inspect the electrode holder
Clean the electrode holder with a soft cloth.
Fig. 2-22: Electrode holder
Then inspect the status of the electrode holders.
The best way to do this is to check the electrode
holder manually, especially the area around the
flushing air openings. If cracks or small holes can be
"felt" there is damage. In this case, contact ETA
Customer Support.
Check the alignment of the electrodes
The electrode must be in the centre of the precipitator
so that the flue gas can be optimally cleaned.
Therefore, check the clearance of the electrodes to the
inner walls.
Fig. 2-23: Electrode
If the distance is uneven, check the electrodes.
They may have been bent during cleaning.

16 www.eta.co.at
Cleaning (customer) Cleaning and maintenance
Check maintenance cover seal
Clean the maintenance cover. Inspect the seal on the
maintenance cover to ensure it is in good order and
replace if necessary.
Fig. 2-24: Maintenance cover
CAUTION!
Avoid operation with damaged seals
Never operate the precipitator with damaged seals.
Otherwise, leak air is sucked in, disturbing the
combustion process and causing increased wear.
Always replace seals immediately when they are
damaged.
Re-attach maintenance cover and panels
Place the maintenance cover and tighten the screws
evenly and cross-wise.
Fig. 2-25: Maintenance cover
Finally, place the insulating cover and re-attach the
panels.
Fig. 2-26: Panels and insulating cover

Cleaning and maintenance Cleaning (customer)
17
2.5.5 Establish operational readiness
Switch the boiler on via the mains switch and start
de-ashing
Restore the boiler's power supply from the mains
switch. Start de-ashing, so that the boiler can perform
de-ashing. Switch the boiler back on with the On/Off
switch.

18 www.eta.co.at
Maintenance (expert) Cleaning and maintenance
2.6 Maintenance (expert)
2.6.1 Preparation
Before this maintenance, perform all steps for the
preceding maintenance intervals
Before this maintenance, all steps for the
preceding maintenance intervals must be
performed.
WARNING!
The following activities may only be performed by
qualified specialist personnel.
If you carry out these activities without the correspond-
ing specialist training, and above all without the
required experience, safe operation is no longer
guaranteed. The resulting defects and consequential
damage are excluded from the guarantee and
warranty.
Equally an incorrect performance of these activities
can lead to serious injuries.
End heating mode
End the boiler's heating mode with the On/Off switch in
the boiler overview window. The boiler performs an
ember burnout and then changes to the [Switched off]
operating mode. Then start de-ashing, so that the
boiler can perform a final de-ashing.
WARNING!
Switch off the electricity to the boiler via the mains
switch
Switch off the electricity to the boiler via the mains
switch. This prevents injuries caused by switching
the boiler on inadvertently.
DANGER!
Caution high voltage!
The electrode inside the precipitator can
still have residual voltage even after
switching off the power supply.
Therefore, switch off the boiler at the
mains switch and ensure that it cannot be switched
back on before starting work. Then establish
additional earthing between the electrode on the
inside and the housing of the precipitator.
2.6.2 Check idle position
Remove maintenance cover and panels
Remove the panel from the top and remove the
insulating cover.
Fig. 2-27: Panels and insulating cover
Remove the maintenance cover.
Fig. 2-28: Maintenance cover

Cleaning and maintenance Maintenance (expert)
19
Removing the side panel
Remove the side panel from the precipitator.
Fig. 2-29: Side panel
Check idle position of the electrode dedusting
There is a mark on the washer on the electrode
dedusting drive wheel which marks the idle position of
the electrode dedusting.
Fig. 2-30: Idle position mark
Through the maintenance opening on the top,
inspect whether the lever gear teeth can support
the striking weight in idle position. The gap must be 3
mm. If not, the delay time (= parameter [Electrode
dedusting delay]) must be adjusted in the control
system.
Fig. 2-31: Idle position
Check the idle position of the sliding rake
There is a mark on the drive wheel which marks the
idle position of the sliding rake. In idle position, this
mark must point directly to the position switch.
Fig. 2-32: Idle position mark

20 www.eta.co.at
Maintenance (expert) Cleaning and maintenance
Through the maintenance opening on the top
inspect whether the sliding rake is still holding the
crank straight in the idle position.
Fig. 2-33: Idle position
2.6.3 Check de-ashing
Check the drive chains and position switches of
the electrode dedusting
Check the chain tension. The chain may sag by 1 -
2 cm without effort. Tension the chain by shifting the
motor. Lubricate the drive chain with chain spray.
Fig. 2-34: Electrode dedusting drive chain
Check whether the position switch is actuated.
Fig. 2-35: Position switch
