Eterna PIR Series Setup guide

Ifyou experience problems:
If your lightisdefectiveor developsafault, pleasereturn ittothe placewhere you boughtit. You can call
our Helpline for advice.TheHelpline will gladlygiveadviceon anyaspectofanyEterna Lighting product
but may notbe able togivespecific instructions regarding individual installations.
Ifindoubt,consultaqualified electrician.
Helpline:
Tel:[phone]Fax: [phone]Email: [e-mail]
For answers tofrequently asked questions (FAQs)and other information visit our web-site
www.eterna-lighting.co.uk
Lampreplacement:
>Switchoff the electricityatthe mains.
>Removethe diffuser fromthe frontofthe fitting by inserting awide bladed screwdriver intoeachofthe
slots atthe side of the diffuser in turn, and twisting gentlytorelease.
>Removeand replacelamp.
>Press the diffuser intoplaceensuring that all of the retaining clipshavesnapped intoposition
correctly and thatthe diffuser issecure.
>Restore the power and switchon.
Replacementlamptype:
Wattage: 60 W
Supply Voltage:230 V
Type:BC GLS
Cleaning:
>Disconnect the power and clean the exterior only ofthisfitting withamoist(notwet)cloth.
>Donot useanychemical or abrasivecleaners.
Eventually, you may wanttoreplace thislightfitting:
When your lightfitting comes tothe end ofit’slifeor you choosetoupdateor upgrade it
byreplacing it, pleasedo notdisposeofitwithyour normal household waste,please
recycle where facilitiesexist.When you need todisposeofthisfitting,checkwithyour
retailer or local authority for suitable options. Newregulationswill encourage the
recycling ofWastefromElectrical and ElectronicEquipment(European “WEEE
Directive”effectiveAugust 2005 ).
PLEASE READ THESE INSTRUCTIONSBEFORE
INSTALLING YOUR NEWFITTING
--
PLEASE RETAINFORFUTUREREFERENCE
PIR Bulkhead
Model(s)
PIR80BK
Pack contents:
Bulkhead light withintegral PIR 1

Safetymarkings:
Read thisfirst:
>Thislightfittingmust beinstalledin
accordance withtheBuildingRegulations.
Thesemaybe obtained fromHMSO or viewed
and downloaded from www.odpm.gov.uk
following the link for Building Regulations.
>Ifin anydoubt,consultaqualified
electrician.
>Switchoff the mainsbefore commencing
installation and removethe appropriatecircuit
fuse.
>Donotusethe fittingwithoutthesafetyshield
fitted.
>Replacethe safetyshield ifitiscrackedor
broken.
>When replacing the lamp,do nottouchwith
bare fingers, grip the lampwithatissueor
clean soft cloth.
>Donotconnect toacircuitwhichalsohas
inductiveloadsconnected as spikesgenerated
switching inductiveloadsmaydamage
electroniccomponents within your PIR
detector and may causefalsetriggering.
>Suitable for outdoor use.
>Thisproduct issuitable for installation on
surfaceswithnormal flammability (indicated
bythe "F"in atriangle )e.g.wood,
plasterboard,masonry.Itisnotsuitable for
useon highlyflammable surfaces(e.g.
polystyrene, textiles ).
>Before making fixinghole(s),check thatthere
are no obstructionshidden beneaththe
mounting surfacesuchaspipes or cables.
>The chosen location ofyour newfitting should
allowfor the producttobesecurelymounted
and safelyconnected tothe mainssupply
(lighting circuit ).
>If the location ofyour newfitting requiresthe
provision ofanewelectrical supply, the supply
must conformwiththe requirements ofthe
Building Regulations.
>Thisproduct isdesigned for permanent
connection tofixedwiring:thisshould beeither
asuitable lighting circuit(protected witha5or
6AmpMCBorfuse)or afused spur(witha3
Ampfuse)via afused connection unit. We
recommend thatthe supplyincorporatesa
switchfor easeofoperation.
>Makeconnectionstothe electrical supplyin
accordancewiththe following code:
Live-Brownor Red
Neutral -Blue or Black
Earth-Green and Yellow
>Additional red wiresmaybe presentthatare
connected tothe ring livecircuit.Donot
connect yourfitting tothesewires. Ifthese
wiresare notseparatelyterminated,join them
together in aseparateterminal block (not
supplied ),ensure thatthere are no strandsof
wire protruding fromthe terminalsand wrap
well withinsulating tape.
>This product must be connected toEarth.
>You are advised ateverystageofyour
installation todouble-check anyelectrical
connectionsyou havemade.After you have
completed your installation there are electrical
tests that should be carried out: thesetests are
specified in the Wiring Regulations(BS7671 )
referred toin the Building Regulations. If in
doubt, consult aqualified electrician.
Installation:
Choosethe location ofyounewlightfitting giving
consideration tothe following points:
a) Avoid positioning the unit closetotreesor
shrubsthatmaycausefalsetriggering during
wet or windyweather.
b) Avoid positioning the unitclosetoheat
sourcessuchasboiler flueswhichmaycause
falsetriggering,
c)Avoid positioning the unitclosetobright
artificial lightsourceswhichwill preventthe
unitfromoperating when the luxcontrolisset
for operation in dark conditions.
d) PIR detectorsare most sensitiveto
movement acrossthe field ofdetection.
1) Removethe diffuser fromthefrontofthefitting
byinserting awide bladed screwdriver into
eachofthe slotsatthesideofthe diffuserin
turn, and twisting gentlytorelease.
2) Removethe translucentcover infrontofthe
lampholder by first removing the small screw in
the top lefthand corner.
3) Using the fitting asatemplate,markthe
position ofthe fixing holeson your mounting
surface,taking intoaccountthe position of
IP44
your emerging supplycable and the cable
entry point in the fitting.
4) Piercethe rubber grommetin the cable entry
and thread your supplycable through the
grommet. The grommetshould be atightfiton
the cable tomaintain agood water-tightseal.
5) Secure your fitting in placeusing suitable
fixings (notsupplied ).
6) Replacethe translucentcover infrontofthe
lampholder andsecure using the screw
removed earlier.
7) Fit alight bulb observing the maximumwattage
marked on the side ofthe fitting and listed on
the back ofthis leaflet.
8) Press the diffuser intoplaceensuring that all of
the retaining clipshavesnapped intoposition
correctly and thatthe diffuser issecure.
9) Adjust the position ofthe PIRdetector tocover
the desired area.
10)You can checktheoperation ofthe PIR
detector byperforming a“walktest”,see
below.
11)Restore the power and switchon.
Timeon adjustment.
(TIMEcontrol )
Turning the timecontrol clockwisereduces the time
thatthe lightstays on after activation.Turning it
anti-clockwiseincreasesthe timethe lightstayson
after activation.
Lux level adjustment
(LUX control )
Turning the luxcontrol anti-clockwise(towardsthe
sun symbol )increasesthe ambientlightlevel in
whichthe PIRwilloperate.Turning itclockwise
(towardsthe moon symbol )will decreasethe
ambient light level in whichthe PIR will operate.
Walktest
Turn the Luxadjustmentcontrol fulyanti-clockwise
(towardsthesun symbol)andthe timecontrol fully
clockwise.The fitting will now operatein full daylight
and stayon for between 5and 15 secondsafter
eachdetection.
Adjust the position ofthe PIR detector sothatitis
triggered bymovementin the desired area.Further
adjustment can be made by blanking out sections of
the PIR window withopaque tape (notsupplied ).
After satisfactorycompletion of the walk test, the lux
adjustment needs tobe set toallow operation of the
light in darkness. At atimewhen the ambient light is
atthe levelyou wantyour lighttoturn on,turn the
luxcontrolclockwise(towardsthe moonsymbol)
until the lightceasestooperateand then back
slightly.Repeatadjustmentsover following nights
until the operation of the light is as desired.
Adjust the timesetting sothatthe lightremains
illuminated for the desired lengthof time.
PIR150&500-110 Halogen Floodlight 050324-2
Technical information
Operating Voltage:230Vac
Detection angle:120°
Maximum detection range:12m
Timeon:adjustable between 5-15 seconds and 8-10 minutes
Lux level adjustable
