Performance Recessed CFL Downlighting 1101FRD
Page 1 of 2 6 ¾" Aperture, 1 Light, Compact Fluorescent, Non-IC, Dimming, Remodeler, Frame-In Kit
Complete Fixture consists of Frame-In Kit and Reflector Trim. Select each separately.
Uniframe™
Frame-In Kit
Uniframe™Compact Fluorescent Performance Series Reflector Trims
Vertical Open Vertical Wall
Wash - Single
Vertical Wall
Wash - Double
Horizontal
Open
Horizontal Wall
Wash - Single
Horizontal Wet Location
Lensed / Diffused
Horizontal
Cross Blade
1101FR264MX1
(Advance Mark X- 120V)
26W Quad/ Triple, GX24q-3
120V- 0.26amp max
32W Triple, GX24q-3
120V- 0.32amp max
42W Triple, GX24q-4
120V- 0.41amp max
1101FR264MX2
(Advance Mark X- 277V)
26W Quad/ Triple, GX24q-3
120V- 0.11amp max
32W Triple, GX24q-3
120V- 0.14amp max
42W Triple, GX24q-3
120V- 0.18amp max
1101CL
1101CD
1101WH
1101CLSW
1101CDSW
1101WHSW
1101CLDW
1101CDDW
1101WHDW
1101HCL
1101HCD
1101HWH
1101HCLSW
1101HCDSW
1101HWHSW
Clear Lens Fresnel
1101HCLC 1101HCLF
1101HCDC 1101HCDF
1101HWHC 1101HWHF
Opal Lens
1101HCLO
1101HCDO
1101HWHO
1101HACB
1101HWHCB
Universal Series Reflector Trims (Reference Trim Spec Sheet for Recommended Lamping)
Performance Cone Cone Satin Cone Bafe Wall Wash Wet Location
1113CFL
1113CDCFL
1112*
1113*
1113BK*
1113WH
1113CD*
1145
1146
1146CD
1143
1144
1144CD
1108*
1110*
1105*
1105BNM
1105WH
1176
1176WH
1135
1135WH
1195
1196
1196CD
1121
1124
1134
1177SH
1178SH
*Add NM sufx to catalog number for Natural Metal ange and nish.
3/4"
FOR O.A HEIGHT SEE
TRIM SPECIFICATION 3 3/4"
4
3
6
5 INSIDE
2
1
13 9/32"
7 1/8"
CEILING
CUTOUT
Labels cULus Listed. Suitable for Damp Locations.Features
1. Uniframe™Mounting Ring: .032" (#22ga.) thick Galvanized Steel.
Accommodates existing ceilings up to 2" thick. Attaches securely to any type
of ceiling material without tools using (3) mounting straps provided. Includes
adhesive backed aperture template.
2. Trim Clips: “Push In / Twist Out” clips hold reflector flush to ceiling.
3. Junction Box: 2" x 4" x 3-1/2" (22cu.in.) .032" (#22ga.) galvanized steel. UL
Listed for 90˚ C supply wire. Attaches to mounting ring without tools.
4. Ballast: 120V or 277V UL listed Electronic Dimming Ballast, 100% to 5% full
range continuous dimming. End of lamp life protection, class "P" thermally
protected, class "A" sound rating.
5. Socket: Four-pin base, molded thermoplastic socket, prewired with No. 18
AWM leads to ballast.
6. Socket Housing: .036" (#20ga.) Galvanized Steel housing attaches to
reflector trim by spring clip for precise optic alignment.
