EunSung 3-MAX User manual

User Guide
Ultrasonic Cavitation and RF with Vacuum System

Operating Manual
www.esglobal.co.kr 2
Ⅰ. Structure of 3-MAX
Ⅰ-1. General Structure
Ⅰ-2. Description of Applicator
Ⅰ-3. Operating Board
Ⅰ-4. Operation
Ⅰ-5. Filter Cleaning
Ⅱ. Operation
Ⅱ-1. Operation LED screen
Ⅱ-2. Cavitation (Body)
Ⅱ-3. RF & Vacuum (Body)-1Mhz
Ⅱ-4. RF & Vacuum (Face)-3Mhz
Ⅲ. Practical Application
Ⅲ-1. Abdomen/ Waist Side line
Ⅲ-2. Front & Back Thigh/ Hip/ Calf
Ⅲ-3. Back/ Arm
Ⅲ-4. Face
Ⅳ. Cautions
Ⅳ-1. Contraindication
Ⅳ-2. Cautions
Ⅳ-3. Maintenance
Ⅳ-4. Solution
Ⅴ. Warranty
Ⅴ-1. Warranty Coverage
Ⅴ-2. Exclusions
Ⅵ. Specification
Ⅶ. Manufacturer information
Ⅶ-1 Contact information
3~6
…………………………………… 3
…………………………………… 4
…………………………………… 5
…………………………………… 6
…………………………………… 7
8~15
…………………………………… 8
…………………………………… 9~11
…………………………………… 12~13
…………………………………… 13~15
16~23
…………………………………… 16~17
…………………………………… 18~20
…………………………………… 21~22
…………………………………… 23
24~26
…………………………………… 24
…………………………………… 24
…………………………………… 25
…………………………………… 26
27
…………………………………… 27
…………………………………… 27
…………………………………… 28
…………………………………… 29
Contents
Operating Manual
Appendix

Operating Manual
www.esglobal.co.kr 3
Ⅰ. Structure of 3-MAX
Ⅰ-1. General Structure
Body
LCD
Hand-piece
Start Key
Wheels
Hand-piece Holder
Hand-piece Hose Holder

Operating Manual
www.esglobal.co.kr 4
Ⅰ. Structure of 3-MAX
Ⅰ-2. Description of Applicator
• Treaded on abdomen, leg, back and waist
• Simultaneously operate RF and Vacuum.
• Dynamic pulse function
• Developed Muti-Polar RF Technology
• Include RED LED
•Treated on face, eye and neck for lifting
• Lymph drainage technology
• Simultaneously operate RF and Vacuum
• Dynamic vibration
• Negative pressure with 4 types of pulse
Body(RF& Vacuum )
RF : 1MHz
Face(RF& Vacuum)
RF : 2MHz
• Treatment of fat and cellulite area
• 80ΦHand-piece
• Safe BLT mode
• 4 types of pulse function
•Light signal function
Body (Cavitation)

Operating Manual
www.esglobal.co.kr 5
Ⅰ-3 : Installation
1.Put and turn the accessory holder into the machine
4. Put connector of Cavitation, Face, Body
Ⅰ. Structure of 3-MAX
* If the accessory holder doesn’t parallel the machine,
release 3 screws on the top and set the direction
correctly.
2. Hold hand-pieces to the accessory holder
3. Put in the hand-piece connector to the machine tightly
*Put the connector to the hole correctly.
It may cause serious problem to the pin inside of
the connector.

Operating Manual
www.esglobal.co.kr 6
Press
2.Turn the power switch key.
•The blue LED will be lightened
on the side of head
Ⅰ. Structure of 3-MAX
Ⅰ-4 . Operation
1. Press the power switch

Operating Manual
www.esglobal.co.kr 7
Ⅰ-5 : Filter Cleaning
Ⅰ. Structure of 3-MAX
1.Open the hexagonal screw on the back side of machine
with wrench.
2. Empty the filter container when the oil filled till
red line.
3. Open the lid of filter container as arrow direction.
* Empty the filter container.
4. After cleaning, put the container as arrow direction.

Operating Manual
www.esglobal.co.kr 8
Ⅱ -1. Operation LCD screen
RF& Vacuum (Face)
RF& Vacuum (Body)
Cavitation (Body)
Ⅱ. Operation
* Select and press the handpiece from LCD screen
Choose Cavitation / RF & Vacuum for body treatment.
Choose RF & Vacuum for face treatment.

Operating Manual
www.esglobal.co.kr 9
Ⅱ. Operation
II -2. Cavitation (Body)
⑧Start Button
①Type of
Handpiece
⑨Select Handpiece Type
⑦Select
Hapdpiece Type
②Cavitation
③Control
Time Button
⑤Preset Timer
①Type of handpiece: Displays the current operation handpiece.
②Cavitation : Cavitation operating button (Level : 1~10 step)
③Control Time Button: Adjusts operation time button (1~30 min)
④Pulse Program Button: Selects the pulse program. (4 mode: C , P1 ,P2 ,P3)
⑤Preset Timer : Shows total treatment time
⑥Display Power Level: Shows the current power level of cavitation.
⑦Select Handpiece Type
⑧Start Button : Start/Stop Button
⑨Select Handpeiece Type
⑥Display Power Level
15:00
④Pulse Program Button < C , P1 ,P2 ,P3 >

Operating Manual
www.esglobal.co.kr 10
15:00
Set
Cavitation
the level
Control time
Preset time
Choose the program
* Selecting the Cavitation Mode, it has a preset function.
level Program Time
5 C 15 min
II -2-1. Cavitation Operation (Body)
1. Use to the preset program and change to mode, level and time as your convenient
2.Apply gel to the treatment area
Press
3.Press the Power button on the handpiece to start operation
Ⅱ. Operation
* The preset function is basically set up to each mode for users. If the level of
preset is not suitable for user, then the user can adjust to level to use

Operating Manual
www.esglobal.co.kr 11
※ Foot switch can e used as start/stop button.
II -2-2. Cavitation Operation (Body)
*User can use the foot switch all operation modes, the Cavitation and RF & Vacuum
1.When finishes the treatment, press“Power”on the LCD board.
(Basically, it will be finished the function after finishing the time set)
2.Keep the power on 2~3 min before off the power, more to cool down
the inside heat.
3.Turn off the power Key.
4.Turn off the power switch backside of the machine.
5.Clean the accessories after treatment and keep them in order
II-2-3. Finish the Cavitation (Body)
•Finish mode is same as Cavitation and RF & Vacuum operation
Ⅱ. Operation

Operating Manual
www.esglobal.co.kr 12
II-3. RF & Vacuum (Body)-1Mhz
⑨Start Button
①Type of
handpiece
④Vacuum Pulse < C , P1 , P2 , P3 >
⑩Select Handpiece Type
②Set Vacuum
level
⑥Bipolar RF
⑤Preset Timer
①Type of Handpiece : Displays the current handpiece type.
②Vacuum : Operating Vacuum/Control the button (Level : 1~ 5 step)
③Control Time Button : Operation time control button (1~30 Min)
④Vacuum Pulse : Choose the pulse (5 modes).
* Pulse type < C:Continous P1:Slow Pulse P2:Midium Pulse P3:Fast Pulse >
⑤Preset Timer : Shows total treatment time
⑥Bipolar RF : RF operating button (Level : 1~10 step)
⑦Select Handpiece Type
⑧Display Power Level: Shows the current power level of Vacuum and RF
⑨Start Button : Start/Stop Button
③Control
Time Button
⑧Display Power Level
20:00
⑦Select Handpiece Type
Ⅱ. Operation

Operating Manual
www.esglobal.co.kr 13
Ⅱ -3-1. RF & Vacuum Operation(Body)-1Mhz
Press
Ⅱ. Operation
Vacuum level RF level Vacuum Pulse
3 5 P3
Time: Body 20min
Set Vacuum
level
Vacuum Pulse
Set RF level
20:00 Preset Timer
Control Time
Button
4. Finish is same as Cavitation (Refer to Cavitation finish mode)
1. Use to the preset program and change to mode, level and time as your convenient
* Selecting the RF & Vacuum Mode, it has a preset function.
* The preset function is basically set up to each mode for users. If the preset of
level is not suitable for user, then the user can adjust to level to use
2.Apply the RF Lotion to the treatment area
3.Press the Power button on the handpiece to start operation

Operating Manual
www.esglobal.co.kr 14
Ⅱ -4. RF & Vacuum (Face)-2Mhz
Ⅱ. Operation
⑨Start Button
①Type of
handpiece
④Vacuum Pulse < C , P1 , P2 , P3 >
⑩Select Handpiece Type
②Set Vacuum
level
⑥Set Bipolar RF
level
⑤Preset Timer
③Control
Time Button
⑧Display Power Level
20:00
⑦Select Handpiece
Type
①Type of Handpiece : Displays the current handpiece type.
②Vacuum : Operating Vacuum/Control the button (Level : 1~ 5step)
③Control Time Button : Operation time control button (1~30 Min)
④Vacuum Pulse : Choose the pulse (5 modes).
* Pulse type < C:Continous P1:Slow Pulse P2:Midium Pulse P3:Fast Pulse >
⑤Preset Timer : Shows total treatment time
⑥Bipolar RF : RF operating button (Level : 1~10 step)
⑦Select Handpiece Type
⑧Display Power Level: Shows the current power level of Vacuum and RF
⑨Start Button : Start/Stop Button

Operating Manual
www.esglobal.co.kr
Vacuum level RF level Vacuum Pulse
3 5 P3
Time: Face 15min
15
Ⅱ -4-1. RF & Vacuum Operation(Face) -2Mhz
Ⅱ. Operation
Set Vacuum
level
Vacuum Pulse
Set RF level
20:00 Preset Timer
Control Time
Button
* Selecting the RF & Vacuum Mode, it has a preset function.
1. Use to the preset program and change to mode, level and time as your convenient
4. Finish is same as Cavitation (Refer to Cavitation finish mode)
* The preset function is basically set up to each mode for users. If the preset of
level is not suitable for user, then the user can adjust to level to use
2.Apply the RF Lotion to the treatment area
3.Press the Power button on the handpiece to start operation
Press

Operating Manual
16
www.esglobal.co.kr
Treatment
program
Application Level Mode Time Hand-
piece
1 Only for
Cavitation
(15 min)
Excessive edema, fat
and cellulite 5 C 15min
2 Only for RF
& Vacuum
(20min)
Large fat and
contouring body line
RF: 5 P3
-> C
P3 15min
C 5min
Vaccum: 3
3 Cavitation +
RF&Vacuum
(35min)
Total remodeling fat,
cellulite and
contouring body line
Cavitation: 5 C Cavitation
15min
RF: 5 P3
-> C
RF&Vacuum
P3 15min
C 5min
Vacuum: 3
Ⅲ. Practical Applications
Ⅲ-1: Abdomen
※Basically, P3 mode and C mode are same action
①②③
①Action is an exception to use mode to P1~3
①②③
Cavitation
Practice
RF & Vacuum
Practice

Operating Manual
17
www.esglobal.co.kr
Treatment
program
Application Level Mode Time Hand-
piece
1 Only for
Cavitaion
(10min)
Excessive edema, fat
and cellulite 5 C 10min
2 Only for RF
& Vacuum
(10min)
Large fat and
contouring body line
RF: 5 P3
-> C
P3 7min
C 3min
Vacuum: 3
3 Cavitation +
RF&Vacuum
(20min)
Total remodeling fat,
cellulite and
contouring body line
Cavitation: 5 C Cavitation
10min
RF: 5 P3
-> C
RF & Vacuum
P3 7min
C 3min
Vacuum: 3
Ⅲ. Practical Applications
Ⅲ-1: Waist Side Line
※Basically, P3 mode and C mode are same action
Cavitation
Practice
RF & Vaccum
Practice
①②③
①②

Operating Manual
18
www.esglobal.co.kr
Ⅲ. Practical Applications
RF &Vaccum Practice
Ⅲ-2 : Front & Back Thigh
①②③
①②
①②③
①②
Front
Back
Front
Back
Treatment
program
Application Level Mode Time Hand-
piece
1 Only for
Cavitation
(30min)
Excessive edema, fat
and cellulite 5 C
Back : 10min each
Front : 5min each
2 Only for RF
& Vacuum
(30min)
Large fat and
contouring body line
RF: 5 P3
-> C
Back: P3 7min each
C 3min each
Vacuum
: 3->1 Front:P3 7min each
C 3min each
3 Cavitation
+
RF&Vacuum
(60min)
Total remodeling fat,
cellulite and
contouring body line
Cavitation:
5
C Back:
Cavitation 10min each
RF & V P3 3min C 2min
RF: 5 P3
-> C
Front:
Cavitation 10min each
RF & V P3 3min/C 2min
Vacuum:
3->1
※Basically, P3 mode and C mode are same action
Cavitation Practice * Same practice for both legs.
※ Treat with vacuum level 1 for thigh 안쪽 during RF&Vaccum C mode .

Operating Manual
19
www.esglobal.co.kr
Treatment
program
Application Level Mode Time Hand-piece
1 Only for
Cavitation
(10min)
Excessive edema, fat
and cellulite 5 C
10min
2 Only for RF
& Vacuum
(10min)
Large fat and
contouring body line
RF: 5 P3
-> C
P3 7min
Vacuum: 3 C3min
3 Cavitation +
RF&Vacuum
(20min)
Total remodeling fat,
cellulite and
contouring body line
Cavitation: 5 C Cavitation
10min
RF: 5 P3
-> C
RF&Vacuum
P3 7min
C 3min
Vaccum: 3
Ⅲ-2: Hip
Cavitation
Practice
RF &Vaccum
Practice
①②
①②③
※Basically, P3 mode and C mode are same action
Ⅲ. Practical Applications

Operating Manual
20
www.esglobal.co.kr
Treatment
program
Application Level Mode Time Hand-piece
1 Only for
Cavitation
(10min)
Excessive edema, fat
and cellulite 5 C
5min each
2 Only for RF
& Vacuum
(10min)
Large fat and
contouring body line
RF: 5 P3
-> C
P3 3min each
Vacuum: 3 C 2min
3 Cavitation +
RF&Vacuum
(20min)
Total remodeling fat,
cellulite and
contouring body line
Cavitation: 5 C Cavitation 5min
each
RF: 5 P3
-> C
RF&Vacuum
P3 3min
C2min
Vacuum: 3
Ⅲ. Practical Applications
Cavitation
Practice RF & Vacuum
Practice
Ⅲ-2 : Calf
* Same practice for both calves
①②①
※Basically, P3 mode and C mode are same action
