Eureka Forbes Aquaguard Pro Universa 80SC User manual

Read this manual carefully before using the water purifier

- 2 -- 2 -
Dear Valued Customer
Congratulations!
You are now the proud owner of the new Aquaguard®Universa 80SC Storage Cooler
Cum Water Purifier - The only product of its kind that assures you of Safe drinking water
by converting chemically and micro biologically unpotable water to potable water.
Welcome to Eureka Forbes (the marketers of Aquaguard®) family of health and hygiene
brand.
This manual will help you know your Aquaguard®Universa 80SC RO+UV Storage Cooler
Cum Water Purifier better. In case you need any information or help, please get in touch
only with our Qualified service personnel or your nearest Eureka Forbes Customer Care
Centre. Please avoid dealing with any unauthorized service mechanics as this could
severely damage your valued Aquaguard®Universa 80SC RO+UV Storage Cooler Cum
Water Purifier.
Introducing the new Aquaguard®Universa 80SC RO+UV Storage Cooler Cum Water Purifier.
Advantage of the Aquaguard®Universa 80SC RO+UV Storage Cooler Cum Purifier:
Aquaguard®Universa 80SC is a 7 stage online Reverse Osmosis and Ultra Violet based
water purifier with Storage Tank. The Product has a Storage Capacity of 80 Ltr. And the
refrigeration system capacity of 60 Ltr. At 17°C ± 1°C water dispensing
It has 3 advanced operating modes - RO+UV / UV / Auto Mode.
In Auto Mode, It automatically switches between RO+UV or UV technologies, based on
output TDS.
The Aquaguard®Universa 80SC has Self-cleaning system that ensures superior and
effective membrane performance by auto-flushing in every four hour.
The Aquaguard®Universa 80SC Water Purifier makes the water both chemically and
micro-biologically potable by reducing hardness, TDS, heavy metals contaminants like
Arsenic, Lead & Mercury and by removing Pathogenic Micro-organisms. Consequently,
it revives the original taste of water. Its unique 7 stage purification process also
reduces pesticides in the water and reduces the scale formation, when water is heated.
1. Particulate Filter
2. Pre Carbon Filter
3. Anti-Scalant Filter
4. Sediment Filter
5. Reverse Osmosis Membrane Filter
6. Post Carbon Filter
7. UV Filter

- 3 -
Particulate Cartridge: Purification stage 1: Using polypropylene yarn candle to remove
physical impurities from the input water.
Pre Carbon Block Filter: Purification stage 2: Specially treated carbon block is used for
adsorbing colour, odour, organic impurities and chlorine. The special treatment given to
carbon provides higher surface area for adsorption and prevents microbial growth on
activated carbon block. Activated carbon block also removes chlorination by-products
from water.
Anti-Scalant Filter: Purification stage 3: This prevents the reverse osmosis membrane
from scaling deposits as the complex molecules will not get settled and gets flushed away
along with concentrate (reject) water flow. Thus it enhances the service life of membrane.
Sediment Filter: Purification stage 4: Sediment filter traps all the fine sediments present in
the input water.
Reverse Osmosis Membrane Filter: Purification stage 5: Reverse Osmosis Membrane
filter has a porosity of 0.0001 micron and strains the micro-organism, TDS (Total Dissolved
Solids) from the input water. This stage rejects around 90% of the input TDS and the
permeate water (purified good water) flows towards the next stage.
Post Carbon Cartridge: Purification stage 6: This process enhances the taste of the pure
water.
UV Filter: Purification stage 7: The UV filter fitted at the point of use ensures that the
water that you consume is safe and free from disease causing microbes.
Product Construction: The outer body and Storage Tank is made of Stainless Steel 304 grade.
The refrigeration system is mounted just below the storage tank and purification section is
mounted on the bottom compartment. Thus the electrical and electronic components of
the product are protected from water entry and related issues.
The refrigeration system and the components are accessed from front and rear side of the
product for any service related issues.

- 4 -
Aquaguard®Universa 80SC RO+UV Storage Cooler cum Purifier
Aquaguard®Universa 80SC RO+UV Water Purifier is equipped with Thin Film Composite (TFC)
RO Membranes having 0.0001 microns pore size. The output water is better tasting, crystal
clear and free from micro-organism and with reduced TDS, which is safe to drink.
Advantages of thin film membrane are
1. High resistant to bacteria
2. Wide PH range of tolerance
3. Good salt rejection
4. Good temperature resistance
5. Good pressure withstanding capacity
GUIDE CHART FOR MINERALS IN WATER
Chemical
Constituents
(in water)
Total Hardness
as CaCO3
mg/lit (max)
Total Dissolved
Solids mg/lit
(max)
Iron as Fe
mg/lit (max)
Chloride as Cl
mg/lit (max)
Nitrate as NO3
mg/lit (max)
Fluoride as F
mg/lit (max)
Mercury as Hg
mg/lit (max)
Arsenic as As
mg/lit (max)
Lead as Pb
mg/lit (max)
Pesticides
mg/lit (max)
Requirement
(Desirable Limits)
IS:10500, 1991
300
500
0.3
250
45
1
0.001
0.05
0.05
0.001
Harmful Effects Produced When Chemical
Constituents Exceed Desirable Limits
Formation of a white layer on the surface of
water supply structures and adverse effects on
water usage for domestic purposes.
Beyond this limit, palatability decreases and
may cause gastrointestinal irritation.
Beyond this limit, taste and appearance are
affected. It also has adverse effects on cooking,
washing and other domestic purposes. It also
promotes iron bacteria.
Beyond this limit taste and palatability are
affected. It leads to corrosion.
Beyond this Methaemoglobinaemia (Blue Baby
Syndrome) takes place. Methaemoglobinaemia
is an enzyme in the human body, which gets
affected.
Fluoride should be kept as low as possible. High
Fluoride concentration may cause Fluorosis.
Beyond this limit, the water becomes toxic.
Beyond this limit, the water becomes toxic.
Beyond this limit, the water becomes toxic.
Beyond this limit, the water becomes toxic.

- 5 -
TECHNICAL SPECIFICATIONS of Universa 80SC
Approximate External Dimensions (WxDxH) 640 X 450 X 1350
Operating Power Supply 170-260V AC,1ph
Running Current in Amps. (Max) 4.5 ±10%
Power in Watts (Max) 700 ± 10%
Water Storage Tank Capacity 080 Ltr.
Capacity with Comfort Level 060 Ltr.
Water Outlet Temperature at 17°C±1°C
Compressor Make Emerson KCE 444/Equivalent
Refrigerant HFC R 134 a
Thermal Insulation for Storage Tank PUF
No of Faucets 2
No of Cold Water Faucets 2
No of Stages for Filter cum Purifier 7
Mode RO+UV
UV
Auto (TDS will be maintain 100±20)
Stages Details 1)Particulate Filter 2)Pre Carbon Block
3)Anti-Scalant Cartridge 4)Sediment Filter
5)RO Membrane 6)Post Carbon Filter 7)UV Filter
RO Membrane Rating 4 X 80 GPD
Permeate (Purified Water)Production Capacity 50 LPH*
% of Purified Water Recovery 25%
% Rejection of TDS 90% (Approx.) Eg: if Input Water Contains
1000mg/Ltr. The Output Water Contains TDS
up to 100mg/Ltr.
Storage Tank Material SS 304
Outer Body Material SS 304
Type of Product Construction Concealed
Type of Installation Indoor
Weight 86 Kg
Input Water Conditions:
Minimum Input Water Pressure 1 Kg/Sq.cm
Recommended Total Dissolved Solids in 2000 ppm.(Max)
Input Water
Recommended Hardness in Input Water 300 ppm(Max)
Recommended pH of Input Water 6.5 to 8.5
Recommended Chlorine Input Water 0.2 ppm (Max)
Recommended Iron in Input Water 0.3 ppm (Max)
Turbidity 5 NTU (Max)
SDI (Silt Density Index) Less than 5
Description Aquaguard Universa 80SC
*Under standard test condition 1000ppm NaCl & input pressure of 1bar..
Note:
ØSpecifications, features and colours are subject to change without prior notice due to
continuous product improvements.

- 6 -
WATER FLOW DIAGRAM
ØNeed to maintain a minimum of 18 inches of gap on all sides for better air circulation
ØSuggest using appropriate capacity voltage stabalizer for better performance and
compressor service life.
ØRecommend to use online booster pump of ¼ HP Capacity, if the input water pressure is
below 0.6 kg /Sq. cm. for better product performance
RAW WATER
INLET
10" PRE FILTER 10" PRE CARBON
SOLENOID
VALVE
10" SEDIMENT FILTER 10" MEMBRANE LIFE ENHANCER
CHECK VALVE
FLOW SENSOR
CHECK VALVE 3/8"
LOW PRESSURE
SWITCH
AQUAGUARD UNIVERSA 80SC
POST CARBON
11 W REFLECTOR
HOUSING
CHECK VALVE PL-8
HIGH PRESSURE
SWITCH
Tap1 Tap2
UV LAMP
QG TUBE 1
QG TUBE 2
PUMP - 1
PUMP - 2
75 GPD RO MEMBEANE - 1
TEE 3/8"
"4/1EET"4/1x"4/1x"8/3EET
TEE 1/4"x1/4"x3/8"
"8/3EET"4/1x"8/3x"8/3EET
TEE 3/8"
TANK 80 Lts
BLENDING
SV PL-3/8"
TDS
SENSOR
INPUT
OUTPUT TDS
BOWL
TDS
SENSOR
OUTPUT
75 GPD RO MEMBEANE - 2
75 GPD RO MEMBEANE - 3
"4/1EET"4/1x"4/1x"8/3EET
75 GPD RO MEMBEANE - 4
SOLENOID
VALVE
AUTO FLUSH
800 ml
REJECT VALVE
800 ml
REJECT VALVE
REJECT
WATER OUTLET

- 7 -
WIRING DIAGRAM
UNIVERSA 80SC WIRING DIAGRAM

- 8 -
FEATURE BENEFITS:
Ø3 advanced operating modes - RO+UV / UV / Auto Mode.
ØAuto Mode - Automatically switches between RO+UV or UV technologies, based on
output TDS.
Ø2” LCD Screen on Front Panel - Shows Running Mode.
ØLarger Membrane: Aquaguard®Universa 80SC has the dual advantage of high
capacity.
ØPurification and storage. It is built with special membrane elements, which produce
higher quantity of treated water faster and continuous. Also, a large stainless steel
tank of 80 litres to store the same.
ØMicrobiologically potable with UV filter RO system makes the water both chemically
and microbiologically potable by reducing hardness and water borne
micro-organisms during the process.
ØSafe drinking water is assured at the outlet using the advanced internationally proven
UV technology, leaving no chance for re-contamination.
ØNo need for bottled water.
ØSelf-Cleaning System: This ensures superior and effective membrane performance
by auto flushing every 4 hour.
ØTough, Hygienic and Durable Body: Aquaguard®Universa 80SC is unique in terms of
its construction. The entire body is corrosion resistant which prevents rusting and
helps maintain hygiene standards.
ØInternationally acclaimed product quality: Aquaguard®stringent international quality
standard has been awarded the ISO 9001 & 14001 certification by Standards
Australia. Aquaguard®manufacturing facility is deemed as world’s largest
manufacturer of Ultraviolet Technology based water purification systems.

- 9 -
Do’s Don’ts
Demand service your unit once in Don’t spill water on the panel. This may
four months. lead to electric shock and short circuit.
When the unit is not in use for more Don’t connect extra tubes to the outlet spout
than two days switch off the power to collect water This may recontaminate the
and water supply to the unit. purified water.
Use genuine spares for replacement. Don’t repair the unit by yourself. This may
lead to total system failure and even death.
If the unit is not working inform the Do not install the unit in direct and diffused
nearest customer response center. sun light.
Connect the unit to duly grounded Do not keep any objects above the unit.
230VAC 15A power supply.
Ensure replacing the filters as per Do not keep the unit open.
the frequency mentioned in the
replacements.
Ensure flushing of the filters Do not install the unit near to
whenever they are replaced. heating devices.
Ensure Membrane Life Enhancer
Filter is topped up during every
routine service by our technician.

- 10 -
Installation Procedure of
Model : Aquaguard®Universa 80SC
The Universa 80SC is a standalone with floor installation, Discuss with the customer and
finalizes the place for install the unit. The preferable place is to position the product is
somewhere near to the drain point and closure to the electrical socket. Then follow the
below procedure for installation:
Diverter valve fixing:
1. Close the input source valve for the water pipe line where the purifier is planned to
be installed.
2. Remove the existing tap from location where the unit is planned to be installed.
3. Connect the Diverter valve to the point and fix the existing tap to the Diverter valve.
4. Check for water leakage from the joints.
Flushing the unit:
1. Make the product to standalone on the platform with the help of leg bush.
2. Connect the other end of the PL8 tube white (connected to the diverter valve) to the
inlet of the product & Remove the Flush port dummy plug from the bottom.
3. Connect the PL4 tube blue to the Flush port of the product and leave the other end
into drain.
CAUTION: Sediment Filter & Carbon Cartridge should be flush for minimum of 5 to 10
minutes before connection to the unit.
4. After flushing close the DV & remove the all the tubes form the inlet & flush port, the
replace the dummy plug in the flush port.
Ø Connect the PL8 white color tube to the quick connector which is fixed on the
diverter valve.
Ø Connect the other end of the PL8 tube to the inlet port of the purifier.
Ø Connect the blue colour tube to the drain port and place the other end of the tube in
to the drain point where draining facility is available. Ensure that the tube does not
come out from the drain point.

- 11 -
TROUBLESHOOTING
Problem Possible Cause Remedial Action / Recommendation
Check for the power Wait for the power supply
availability
Low voltage Wait till voltage stabilize
Unit Not Switching Check for the power Insert properly
ON cord insertion
Power switch not Switch ON the power switch
switched ON
Chocked Filters Clean/replace filter
No water supply Ensure continuous water supply
Diverter valve not Open the diverter valve
Water Not Coming opened
No water supply Ensure continuous water supply
Blockage in the Clear the blockage
water line
Back flush the sediment filter candle.
Sediment filter candle If it is still blocked contact nearest
is blocked customer Response centre for
replacement
Carbon filter is blocked Inform the nearest customer
response centre
Water Flow Rate is SV malfunctioning Inform the nearest customer
Less response centre
Input flow rate is less Ensure continuous water supply
Blockage in nozzles Inform the nearest customer
response centre
Partially chocked Inform the nearest customer
membrane filter response centre

- 12 -
TERMS OF WARRANTY
Your Aquaguard®Universa 80SC Water Purifier is warranted against defects arising from
faulty design, workmanship and materials, for a period of 15 Months from date of invoice
or 12 Months from the date of installation (whichever is earlier), subject to the following
condition:
1. The customer will notify the Company promptly about any defects and give the
Company or it Authorised Distributor adequate opportunity to inspect, test and
remedy them, for which the customer will deposit the goods if necessary, with the
Company’s office/service centre along with the original invoice, in the city where
they are sold.
2. Inspection and Test Report of the Company’s office/service centre will be treated as
final and binding under the Warranty for determining defects, repairs/alterations
required or carried out, or certifying working of goods thereafter.
3. The Company or it Authorised Distributor will be entitled to retain any defective part
replaced under the warranty.
4. The Company’s liability under the Warranty will be limited only to defects which
occur under the conditions of normal operations and under proper use. It excludes
defects occurring because of abuse, faulty care or maintenance, repairs/alterations
to goods or partly by others.
5. Consumables such as Sediment Filter, Reverse Osmosis Membrane & Activated
Carbon which are subject to normal wear & tear in the course of use are not covered
by this Warranty.
6. The customer will have no claim under this Warranty in respect of any personal
injury, damage to property or consequential damages; for utilization of the goods
not in accordance with the user manual.
Note:
ØThe undernoted expression should have the following meaning.
ØThe ‘Goods’ shall mean the goods described in the Purchase Agreement.
ØThe ‘Customer’ shall mean the original purchaser under the Purchase Agreement.
ØThe ‘Company’ shall mean ‘Eureka Forbes Limited’.

Warranty Certificate
Dist. Name and Address
Customer Name: ........................................... Product: ........................................... Serial No.: ........................................... Invoice No. & Date: ........................................... Eureka Forbes Ltd. (hereinafter the Company warrants that the goods (hereinafter the Goods)are free from defects arising from faulty design workmanship and materials that would substantially affect the functioning of the Goods under normal use for a period of 12 months from the date of sale. The Company will repair or replace free of charge any part or parts of the Goods if it is fully satisfied, in its sole discretion, that the defects is / are due to faulty material or workmanship only, provided it is used in normal working condition and in accordance with the operating Manual. The warranty will be governed by the following clauses:
1. The Customer will notify the Company in writing promptly of any defects noticed and give the
Company or its authorized agent adequate opportunity to inspect test and remedy them for
which the Customer will deposit the Goods if so required by the Company with the Company’s office / service centre along with original Invoice in the city where they are sold.
2. Inspection, and Test Report of the Company’s office / service centre will be final and binding
under the Warranty for determining defects, repairs, alterations required or carried out or certifying working of Goods thereafter.
3. The Company or its authorized agent will be entitled to retain any defective part replaced under
the Warranty.
4. Notwithstanding anything to the contrary contained in or implied by this Warranty. a) The Company’s liability under this Warranty shall be limited to the first sale of the Goods by the
Company to Customer and will not apply or extend to any secondary or subsequent sale of the Goods by the Customer.
b) The Company’s liability under this Warranty shall be limited only to defects in the Goods, which
occur under conditions of normal operation of the Goods, their proper and prescribed use. Consumables like brushes, gears, bearings, belts, fuel, batteries, detergents, filters, activated carbon, body parts and any components made of rubber, paper, cloth etc. will not be covered under the warranty. This Warranty does not cover or extend to defects which are determined by the Company or its authorized agents as abuse, misuse, faulty care, operation or maintenance or repairs, alterations to the Goods or any part thereof by others or the use of the Goods on electrical supply for which they are not designed or damage caused by lighting or other electrical disturbances or interruptions.
c) The Company’s liability under this Warranty shall remain valid only if the Goods are duly
installed by the Company or its authorized agent at the location specified in the Invoice or where the installation is at a place other than specified in the Invoice. Such installation is undertaken by the Company or its authorized agent or franchisee Shifting of the Goods to any other location will be Customer’s responsibility. Any damage caused during shifting will be repaired on chargeable basis.
d) The Customer will have no claim against the Company, its employees and its authorized
agents or franchisees, under or pursuant to this Warranty in respect of death or injury to the Customer or any other person or loss or damage to any property caused by or due to equipment failure, breakdown or accident, fire or operation or utilization of the Goods
otherwise than in accordance with User’s Manual or by or due to any other cause external or circumstances beyond the control of the Company.
e) The Company’s liability under this Warranty shall in no event and under no circumstances
exceed the price paid by the Customer to the Company / distributor for the Goods stated in the Invoice.
This Warranty shall not be valid in case of accidental damage, theft or loss of items, or natural
calamities.
5) The Company reserves its right to transfer or assign the obligation under this warranty to any of
its subsidiaries or associate companies or competent nominee.
General:
For the purpose of this warranty, the following expressions shall have the meaning respectively. 1 The Goods shall mean the goods described in the purchase agreement. 2. The Customer shall mean the original purchaser of the Goods from the Company or its
authorized agent who is party to the purchase agreement.
3. The Company shall mean ‘Eureka Forbes Limited’
4. The purchase agreement shall mean the general terms conditions of sale agreed upon by the
customer and the company as printed in the invoice.
5. The invoice shall mean the invoice issued by the company or its agent to the customer.
Post warranty:
The customer may be offered a yearly service contract with the company, renewable on expiry of th contract.
Address SEAL AND SIGNATURE

B1/B2, Marathon Innova, Off Ganpatrao Kadam Marg,
Lower Parel, Mumbai 400 013.
Tel No: 022-30449700 ; Fax No: 30434970
