Eureka! Tents 10'x10' Owner's manual

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc. Rev. H - May 2014
Instruction Manual
www.eurekapartytents.com
TRADITIONAL PARTY CANOPY
10'x10'
15'x15'
20'x20'
20'x30'
20'x40'
30'x40' Oval
30'x60' Oval

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
Prior to installing any tent, always make sure you check for overhead and underground obstructions!
For safe assembly, we recommend:
  •SteelToeSafetyShoes •HardHats/Helmets  •SafetyGloves
  •UtilityAprons  •StepLadders  •DropCloths
  •CleaningSupplies  •SledgeHammer 
ALWAYS READ THE TECHNICAL INSTRUCTION MANUAL COMPLETELY BEFORE BEGINNING.
IF YOU HAVE ANY QUESTIONS, PLEASE CONTACT YOUR SALES REPRESENTATIVE OR THE
MANUFACTURER BEFORE YOU BEGIN.
Whetheryouareplanningtodoityourselfor
hireaprofessionaltentinstallationcompany,
alwaysknowwhat'sunderground.Call811
priortoinstallingyourtentandmakesure
your underground utility lines are marked. It's
FREEandhelpspreventaccidentsand/or
injury.
STOP
CAUTION
Whenever you install a tent with hardware at -
or above - the shoulders, always wear a hard
hat.
CAUTION
Properstakingisrequiredonalltents.Soil
conditions can vary from site to site and within a
setupsite.Additionalstakesmayberequiredin
softsoilconditionsorwheneverstakespullup
fromtheground.TraditionalPartyCanopiesare
NOTengineeredorwind-rated.
CAUTION

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
1.Inspectthesiteandmakesuretheareaislevel,freeof
undergroundutilitiesandanyoverheadobstructions.Unloadpolesand
tent bundles.
2.Laythecanopyout,onagroundcloth,withthetopsideup.Stretch
andsquarethefabrictoremoveslack.Pulltheguyropesoutfromthe
canopy.
3.Ifthisisthersttimeusingyourtent,youmayneedtoputthe
slidersoneachrope.Todoso,threadaguyropethroughoneholein
theropeslider.Then,threadtheropethroughtheremainingholein
theropeslider.Fortheslidertoworkproperly,theguyropemustenter
thesliderfromthesamedirection/sideeachtime-asillustratedinthe
picture.Tieaknotintheendoftherope.Repeatwithremainingguy
ropesandsliders.
**Can'tndthesliders?Checkinsidethevinyltenttopbag.
4.Drivethestakes4'outandataslightangleawayfromthecanopy.
Stakethecornersrst,usingtwostakesplacedat90˚fromeach
corner.Continuestakinguntilallguyropesareat4'.Besuretoleave
enoughslackintheguyropestoraisethepoles.
Assembly (20'x20' Shown)
UP
FROM SAME DIRECTION

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
5.Ifusingsectionalaluminumpoles,assemblethemandmakesure
eachsnapbuttonissecured.
NOTE:Sidepolesaretwoequallengthpieces.Thetoppiecehasthe
pinandthebottompiecehasablackendcap.Centerpoleswillhave
atop(pin)piece,middlepiecesthatareopenontopandbottomanda
bottompiecewithablackendcap.
6.Next,installthesidepolesfromtheundersideofthecanopy.Insert
polepinsupthroughboththegrommetandD-ring.
7.Standthepolesupata60˚anglewiththeirbasetowardthecenter
ofthetent.Setthecornerpolesrst,thenthesidepoles.
8.Withtheallofthesidepolesset,walkunderthetentandinsert
centerpolepinintothegrommetatthetopofthecanopy.Withthispin
inplace,liftandpushthepinendskywardandthecenterpolebase
towardcenteroftenttoraisethepoleandcanopy.

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
9.Ifyourtenthasmultiplecenterpoles,therstpolebaseshouldbe
angledat45˚tocenter.Raisetheremainingcenterpoles.Whenyou
havereachedthe45˚angles,youcanputastakeatthebaseofthe
polesothatitdoesnotslip.Onceallcenterpolesareinplace,returnto
therstcenterpoleandadjusttoalmostvertical.Adjusttheotherpoles
toalmostverticaluntilallcenterpolesareraisedandadjusted.
10.Withallcenterpolesalmostvertical,bringthemintoline.Have
someonestandatoneendofthetent.Aligneachcenterpoleas
directedbythatperson.Thenaligneachcenterpolefromthesidesof
thetent.Afterallcenterpolesarealigned,goaroundandstraightenall
sidepoles.
**Ifthecenterorsidepolessinkintosoftground,tryusingsmall
wooden"coasters"undereachpoletohelppreventitfromsinking.
11.Ifthetopofthecenterpoleappearstobeleaningtowardoneend,trythesehelpfulhints:
•Tightenguyropesandstraightensidepoles,attheendoppositeofthelean,topullthetop
ofthecenterpolebacktovertical.
•Straightenandadjusttheguyropesattheotherend.Becarefulnottopullthecenterpole
out of alignment.
•Whencenterpolesappearvertical,adjustopposingendsidepolessimultaneouslyto
avoiddrawingtheentiretenttowardoneside.Afterendsareadjustedandguyropesare
secure,repeatdownlengthofthetent.Again,avoidpullingordrawingentiretenttoone
side or the other.
12.Onceallpolesareverticallyaligned,securethecenterpoleby
drivingastakeintothegroundnearthebase.Tieajumpropearound
thecenterpoleandtothestake.Ifusingsidewalls,clipthesidewalls
tothesidewallropeontheinsideofthevalance.Sidewallsoverlap
approximately2'.Buckletheendstoinsurecompleteenclosure.
NOTE:Severeweathercandamagetents.Ifsevereweatheris
expected,takedownthetentandstoreinasafearea.
HELPFUL
HINT

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
Note: Plan shows suggested staking.
Additional stakes will be necessary
in soft soil conditions or whenever
stakes pull up from the ground. END/ SIDE
PLAN W/STAKES
10'
10'
7'
2'6"
10'
10'x10'
4'

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
END/ SIDE
PLAN W/STAKES
15'
15'
7'
3'6"
7'6"
Note: Plan shows suggested staking.
Additional stakes will be necessary
in soft soil conditions or whenever
stakes pull up from the ground.
15'x15'
4'

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
END/ SIDE
PLAN W/STAKES
20'
20'
7'
5'6"
10'
4'
Note: Plan shows suggested staking.
Additional stakes will be necessary
in soft soil conditions or whenever
stakes pull up from the ground.
20'x20'
END/ SIDE
PLAN W/STAKES
15'
15'
7'
3'6"
7'6"
20'
5' 6"
4'

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
END
SIDE
PLAN W/STAKES
4'
30'
20'
7'
5'6"
10'
30'
12'6"
Note: Plan shows suggested staking.
Additional stakes will be necessary
in soft soil conditions or whenever
stakes pull up from the ground.
20'x30'
4'
END
SIDE
20'
7'
5'6"
30'
12'6"

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
END
SIDE
PLANW/STAKES
40'
20'
7'
5'6"
10'
40'
12'6"
Note: Plan shows
suggested staking.
Additional stakes will be
necessary in soft soil
conditions or whenever
stakes pull up from the
ground.
20'x40'
4'

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
Note: Plan shows
suggested staking.
Additional stakes will be
necessary in soft soil
conditions or whenever
stakes pull up from the
ground.
30'x40' OVAL
4'
END
SIDE
PLANW/STAKES
40'
30'
7'
7'
30'
40'
10'
9'3"
14'

TECHNICAL INSTRUCTION MANUAL: TRADITIONAL PARTY CANOPIES
©2014 Johnson Outdoors Gear, Inc.
www.eurekapartytents.com
Rev. H - May 2014
END
SIDE
PLANW/STAKES
60'
30'
7'
7'
30'
60'
7'6"
9'3"
14'
Note: Plan shows
suggested staking.
Additional stakes will be
necessary in soft soil
conditions or whenever
stakes pull up from the
ground.
30'x60' OVAL
4'
