Eureka Jindara Duet SRS2/Duplicity User manual

Hole cutting dimensions
Duet SRS2/Duplicity Through Wall Kit
(Part No. 214813)
Installation Instructions
1015mm
1015mm
Hearth
Internal wall 120mm
220mm
500mm
See
Note 1
• The installation of this appliance must be carried out as per this manual and the manufacturer’s
We recommend that you use a installer to carry out the installation.
• If in doubt do not hesitate to contact your local Jindara or Eureka dealer.
• This appliance weighs in excess of 230 kilograms. Extreme care should be taken when handling the appliance.
Read and follow these instructions (in conjunction with the Duet
SRS2/Duplicity Freestanding manual) carefully before installing this appliance.
SAVE THESE INSTRUCTIONS
A minimum 1000mm
wide x 1800mm
deep x 12mm thick
protector should
be used under and in
front of the appliance
when installing. The
protector should
extend 500mm in
front of the appliance
base on both doors.
Note 1: A combustible mantle must be no lower
than 500mm from top plate of heater.
Note 2: Internal wall noggin must not be lower
than 500mm above top plate of heater (a steel
noggin is permitted lower than 500mm).
If cutting hole through
a plasterboard wall
ensure wall width is
within 100mm
minimum to 115mm
maximum in thickness.
If constructed in brick
ensure wall width is
within 100mm
minimum to 145mm
maximum in thickness.
Sheet 1 of 4 GPN 214835
F:\Docs\Manuals\Heaters\GPN 214835 Thru Wall
mm005mm005
1800mm
1000mm
Minimum requirements
This Heater has been tested to AS2918:2001 Appendix B.
Test Report No. HCMG/14/069A using an Australian Standard
kit. For the through wall installation additional
8˝ stainless is to be over the 7˝ stainless active
then a 9˝ mesh shield and a 10˝ stainless steel
shield are to be installed, both to ceiling height.
(See diagram opposite)
9˝ solid back
mesh
8˝ stainless
7˝ stainless
!
10˝ stainless steel
shield up to
drop box height
NB: First height 4600 mm (+/– 300mm) from protector
Internal wall
120mm
min.
These must be used to make the installation conform.
Clearances to combustibles
400mm
1015mm
(cutout)
1015mm
(cutout)
See
Note 2
150mm
drop box
Triple skin from
ceiling upwards

Step 2
1. Slide the Inbuilt Fascia Assembly (Part 1) over the front of the
heater, so that pre-drilled screw holes (A) and (B) are aligned.
2. Insert screw (supplied) and tighten.
3. Do this on each side of the heater.
(B)(A)
Step 1
1. Remove screws from the heater pedestal fascia panel
(opposite fan switch end)
2. Position lower fascia panels (Parts 3 & 4) as shown (one on each side
of heater)
3. Reattach screws
Fan switch
Pedestal fascia panel
goes on top of the
lower fascia panels
Lower
fascia panel Panels should be flush
with side of base
1. Fascia Assembly - Inbuilt side
2. Fascia Assembly - Freestanding side
3. Panel fascia - lower left hand
4. Panel fascia - lower right hand
5. Spray can
6. 10 off 1/2” x 8G self tapping screws
7. 4 springs
8. Panel heat deflector
Parts
12
3 4
56
8
7
Sheet 2 of 4 GPN 214835
F:\Docs\Manuals\Heaters\HM214835\Duet In Wall Inst
(through Windows NT Explorer)

Step 3
1. Use a square to ensure the Inbuilt Fascia Assembly is perfectly
vertical.
2. Using a 3mm dia drill bit, drill holes (C) and (D) through the
Inbuilt Fascia Assembly and into the side of the heater. Insert
screws (Part 7) and tighten. Do this on the other side of the
heater as well.
Step 5
1. Slide the Freestanding Fascia Assembly (Part 2) over the
freestanding side of the heater. To allow the assembly to easily
pass over the flue spigot, raise the top of the heater until it is
flush with the top edge of the flue spigot.
2. When the Freestanding Fascia Assembly has crossed the flue
spigot, lower the top of the heater and continue to slide the
Freestanding Fascia Assembly until it meets the Inbuilt Fascia
Assembly.
Step 6
1. Overlap the flanges as shown
2. Attach the springs between Inbuilt Fascia Assembly and
Freestanding Fascia Assembly on both sides of the heater.
3. Attach heat deflector to
freestanding fascia assembly
with self tapping screws.
(C)
(D)
Square
Flue Spigot
Raise Top of Heater
Springs
Heat shield
Screw
Step 4
Position heater into wall opening. Ensure it is centrally located and
Inbuilt Fascia Assembly is hard up against wall.
Sheet 3 of 4 GPN 214835
F:\Docs\Manuals\Heaters\HM214835\Duet In Wall Inst
(through Windows NT Explorer)
Step 7
1. If required use spray can (Part 5) to touch up if required. Follow
directions on spray can.

Phone [phone]
Fax [phone]
Sheet 4 of 4 GPN 214835
