Eurolux FS220 User manual

LED Floodlights with Sensors
FS220: 1 x 100W Integrated LED 220 - 240V
FS221: 1 x 150W Integrated LED 220 - 240V
FS222: 1 x 200W Integrated LED 220 - 240V
FS272: 1 x 300W Integrated LED 220 - 240V
ENVIRONMENTAL PROTECTION
ILLUSTRATION
Waste electrical & Electronic equipment regulations requires that any of our products
showing this marking must not be disposed of with other household or commercial
waste. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate any such products from other waste types and recycle it
responsibly at your local facilities.
FS220 /FS221 / FS222 / FS272
PRODUCT CODE
Cape Town - 9 Racecourse Road, Milnerton, 7441
Johannesburg - 10 Milkyway Avenue, Linbro Business Park, Sandton, 2065
www.eurolux.co.za
Please read instructions before commencing installation and retain for future reference.
FS221FS220 FS222 FS272
Min: 200mm
To set the Floodlight’s beam angle
Loosen the screws on the sides and
adjust the oodlights angle and
tighten screws again.
2m - 3m (Install out of arms reach)

• Fitting: Die cast aluminium with clear tempered glass lens.
• Class: Class1. Requires earth connection.
• IP Rating: IP 65
• Voltage: 220V - 240V ~ 50Hz
• Dimensions: FS220 - (H)345mm x (W)300mm x (D)60mm
FS221 - (H)380mm x (W)345mm x (D)75mm
FS222 - (H)420mm x (W)380mm x (D)26mm
FS272 - (H)475mm x (W)420mm x (D)31mm
• Weight: FS220 - 3.1kg
FS221 - 4.2kg
FS222 - 5.6kg
FS272 - 8.2kg
• Lamp Type: FS220 - 1 x 100W Integrated LED 230V
FS221 - 1 x 150W Integrated LED 230V
FS222 - 1 x 200W Integrated LED 230V
FS272 - 1 x 300W Integrated LED 230V
• Maximum Projected Area: FS220 - 0.045761m2
FS221 - 0.076101m2
FS222 - 0.076101m2
FS272 - 0.104779m2
• Commercial / domestic use
• Suitable for outdoor use when used correctly.
• Thisxturemustbemountedinthehorizontalposition.
• The light source of this luminaire is not replaceable. When the light source reaches its end of life the
whole luminaire should be replaced, or the light source should only be replaced by the manufacturer.
SPECIFICATIONS
CLEANING
• Beforecleaningalwaysensurethepowersupplyisturnedo󰀨.
• Do not immerse the luminaire in water.
• No abrasive products, solvents, detergent may be used to clean this luminaire.
• Ensure that the luminaire does not come in contact with corrosive chemicals, etc.
• Coastal areas ensure that the luminaire is cleaned fortnightly.
FS220 / FS221 / FS222 / FS272 - attachments:
Iftheexternalexiblecableorcordofthisluminaireisdamaged,itshouldbeexclusivelyreplacedby
themanufacturerorhisserviceagentorasimilarqualiedpersoninordertoavoidahazard.
To ensure that you get maximum longevity and maximum use out of your luminaire, please
observe the following safety instructions.
Electrical products can cause death, injury, or damage to property. Installation of the luminaire must
 becarriedoutbyaqualiedelectrician,inaccordancewithSANS10142.Oncompletionof
 installation,ensurethattheCerticateofComplianceisupdated.
• Before connecting this luminaire, ensure that voltage indicated on the rating label corresponds with the
mains voltage in your home.
• Whenchangingthelamp,ensurethatthepoweristurnedo󰀨.
• This luminaire is checked in full for conformity to the quality standards and safety requirements.
• The manufacturer / supplier is not responsible for any damage of properties and persons, caused by
the incorrect use or installation of the luminaire.
• Should you be unsure of how to install this luminaire correctly, please consult a professional electrician
or your supplier for assistance.
• Ensure all items/ components, threads and screws are tightly secured.
IMPORTANT:
• Tampering with this luminaire, i.e.using silicon sealers or incorrect cabling, will invalidate
your warranty.
• When the protection glass is damaged, it should be replaced immediately. The luminaire
must not be used without the protection glass.
• Please check whether the connection of the power cord is safe and reliable before installation.
• Always ensure that the mains supply voltage is correct.
• Always replace the lamp with one of an identical rating.
• Ensure that you do not place the luminaire near any combustible materials and / or surfaces.
• Choking hazard: May contain small parts. Keep away from children.
• Donotinsertyourngersoranypartofyourbodyintotheelectricalcontactandsocketsofthisproduct
whilst it is connected to the electricity supply.
• Item may vary slightly from the picture on the carton.
• Coastalhumiditymaye󰀨ectthelongevityoftheluminaire.
• Outdoor luminaires must be cleaned to prevent rust occurring.
• Use a copper grease on all screws or strings.
IMPORTANT SAFEGUARDS
