Eurolux FS252 User manual

LED Floodlights with Sensors
FS252: 1 x 10W Integrated LED 220 - 240V
FS253: 1 x 20W Integrated LED 220 - 240V
FS254: 1 x 30W Integrated LED 220 - 240V
ILLUSTRATIONS
ENVIRONMENTAL PROTECTION
Waste electrical & Electronic equipment regulations requires that any of our products
showing this marking must not be disposed of with other household or commercial
waste. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate any such products from other waste types and recycle it
responsibly at your local facilities.
FS252 / FS253 / FS254
PRODUCT CODE
Cape Town - 9 Racecourse Road, Milnerton, 7441
Johannesburg - 10 Milkyway Avenue, Linbro Business Park, Sandton, 2065
web: www.eurolux.co.za
Please read instructions before commencing installation and retain for future reference.
FS252 FS253 FS254

• Fitting: Die cast aluminium with clear tempered glass lens.
• Class: Class1. Requires earth connection.
• IP Rating: IP 44
• Voltage: 220V - 240V ~ 50Hz
• Dimensions: FS252 - (H)131mm x (W)89mm x (D)30mm
FS253 - (H)175mm x (W)162mm x (D)26mm
FS254 - (H)225mm x (W)241mm x (D)31mm
• Weight: FS252 - 0.3kg
FS253 - 0.509kg
FS254 - 0.904kg
• Lamp Type: FS252 - 1 x 10W Integrated LED 230V
FS253 - 1 x 20W Integrated LED 230V
FS254 - 1 x 30W Integrated LED 230V
• Maximum Projected Area: FS252 - 0.00385m2
FS253 - 0.01008m2
FS254 - 0.02080m2
• Commercial/domesticuse
• Suitableforoutdoorusewhenusedcorrectly.
• Thisxturemustbemountedinthehorizontalposition.
• Thelightsourceofthisluminaireisnotreplaceable.Whenthelightsourcereachesitsendoflifethe
whole luminaire should be replaced, or the light source should only be replaced by the manufacturer.
SPECIFICATIONS
CLEANING
Sensor Controls
• Beforecleaningalwaysensurethepowersupplyisturnedoff.
• Donotimmersetheluminaireinwater.
• Noabrasiveproducts,solvents,detergentmaybeusedtocleanthisluminaire.
• Ensurethattheluminairedoesnotcomeincontactwithcorrosivechemicals,etc.
• Coastalareasensurethattheluminaireiscleanedfortnightly.
• TIME: the length of time the unit remains switched on after activation can be adjusted from approx.
10±3seconds to 8±2minutes.
• LUX:turningcontrolto“Sun”symbolmeansthettingissettoworkdayandnight.Turning controlto
“Moon”symbolmeansthettingonlyworksatnight.
• SENS:theMaximumdistancethePIRsensordetectsmotion(maximumis10m).
FS252 / FS253 / FS254 - attachments:
Iftheexternalexiblecableorcordofthisluminaireisdamaged,itshouldbeexclusivelyreplacedby
themanufacturerorhisserviceagentorasimilarqualiedpersoninordertoavoidahazard.
To ensure that you get maximum longevity and maximum use out of your luminaire, please
observe the following safety instructions.
 Electricalproductscancausedeath,injury,ordamagetoproperty.Installationoftheluminairemust
 becarriedoutbyaqualiedelectrician,inaccordancewithSANS10142.Oncompletionof
 installation,ensurethattheCerticateofComplianceisupdated.
• Beforeconnectingthisluminaire,ensurethatvoltageindicatedontheratinglabelcorrespondswiththe
mains voltage in your home.
• Whenchangingthelamp,ensurethatthepoweristurnedoff.
• Thisluminaireischeckedinfullforconformitytothequalitystandardsandsafetyrequirements.
• Themanufacturer/supplierisnotresponsibleforanydamageofpropertiesandpersons,causedby
the incorrect use or installation of the luminaire.
• Shouldyoubeunsureofhowtoinstallthisluminairecorrectly,pleaseconsultaprofessionalelectrician
or your supplier for assistance.
• Ensureallitems/components,threadsandscrewsaretightlysecured.
IMPORTANT:
• Tamperingwiththisluminaire,IE.Usingsiliconsealersorincorrectcabling,willinvalidate
your warranty.
• Whentheprotectionglassisdamaged,itshouldbereplacedimmediately.Theluminaire
must not be used without the protection glass.
• Pleasecheckwhethertheconnectionofthepowercordissafeandreliablebeforeinstallation.
• Alwaysensurethatthemainssupplyvoltageiscorrect.
• Alwaysreplacethelampwithoneofanidenticalrating.
• Ensurethatyoudonotplacetheluminairenearanycombustiblematerialsand/orsurfaces.
• Chokinghazard:Maycontainsmallparts.Keepawayfromchildren.
• Donotinsertyourngersoranypartofyourbodyintotheelectricalcontactandsocketsofthisproduct
whilst it is connected to the electricity supply.
• Itemmayvaryslightlyfromthepictureonthecarton.
• Coastalhumiditymayeffectthelongevityoftheluminaire.
• Outdoorluminairesmustbecleanedtopreventrustoccurring.
• Useacoppergreaseonallscrewsorstrings.
IMPORTANT SAFEGUARDS
