Euromatic BT2000 User manual

Model Number BT2000
INSTRUCTION MANUAL
AFTER SALES SUPPORT
(AU) 1300 886 649 (NZ) 0800 836 761
Wall-Mounted Bathroom Fan Heater

2After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Contents
Important Safety Instructions 3
Product Overview 6
Getting Started 7
Instructions 9
Other Useful Information 10

3
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Important Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with this
type of product. The safety precautions enclosed herein reduce the risk of fire,
electric shock and injury when correctly adhered to. Make sure you understand
all instructions and warnings. Keep the manual in a safe place for future
reference, along with any warranty information, your purchase receipt and the
packaging carton. If you sell or transfer ownership of this product, please pass
on these instructions to the new owner.
Always follow basic safety precautions and accident prevention measures
when using an electrical appliance, including the following:
Electrical safety and cord handling
• Voltage: Make sure your outlet voltage and circuit frequency correspond to
the voltage stated on the rating label. If this is not the case, do not use the
fan heater.
• Electrical circuit: To prevent overloading a circuit, do not plug the heater into
a circuit that already has other appliances working.
• Water: To protect against fire and electric shock, do not immerse the cord,
plug or the heater in water or other liquid, or allow water to come into contact
with the plug or control device.
• Ingress protection: The appliance is protected against exposure to vertically
or nearly vertically dripping water, and against insertion of objects up to
12mm, such as a finger (IP22).
• Damage: Check the power cord regularly for visible damage. If the cord is
damaged, it must be replaced by the manufacturer, its authorised service
centres or appropriately qualified personnel in order to avoid any hazards.
WARNING! Do not pick up or operate the appliance if the power supply cord,
plug or housing is damaged, or after it malfunctions or has been dropped or
damaged in any manner. In case of damage, contact our after sales support
centre for advice.
• Protect the power cord:
- Do not operate the fan heater with the cord coiled up; always fully unwind.
- Do not twist or kink the cord or let it touch heated surfaces.
- Do not put any stress on the cord where it connects to the product.
- Never carry the fan heater by the cord.
- Arrange the cord away from any traffic area so no one will trip over it.
- Ensure the cord is placed at the back, away from the heater’s front panel.
- Do not run the cord under carpeting or cover it with rugs or runners.

4After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Important Safety Instructions (Cont.)
• Connection: To insert the plug, grasp it firmly and guide it into the outlet.
• Disconnection: Unplug the appliance from the power outlet when it is
not in use and before wall-mounting, cleaning, moving or servicing the fan
heater. Grasp the plug and remove it from the outlet, do not pull the cord to
disconnect.
• WARNING! Do not leave unattended during use! Always switch off the
appliance and unplug it when it is not in use, if left unattended, and before
cleaning and storing.
• RCD: Unless your home is already fitted with a residual current device
(safety switch), we recommend installing an RCD with a rated residual
operating current not exceeding 30mA to provide additional safety
protection when using electrical appliances. See your electrician for
professional advice.
• WARNING! No extension cord, no timer: Do not use this heater with
an extension cord, plug adaptor, external timer or separate speed control
device.
Usage conditions and restrictions
• Domestic use only: This fan heater is intended for indoor household use
only. It is not suitable for commercial, industrial or outdoor use. It is only
suitable for well insulated spaces or occasional use.
• Space heating only: Do not use this appliance for anything other than its
intended purpose, and only use it as described in this manual. Any other
use is not recommended and may cause fire, electric shock or injury.
• Attachments: The use of accessory attachments not recommended in this
manual may cause injury or hazards.
• Usage restriction: This fan heater is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for
their safety.
• Children: This fan heater is not a toy. Supervise children to ensure they do
not play with it. Close supervision is necessary when any appliance is used
by or near children.
• Wall-mounting: Only use the fan heater fully assembled and mounted
to a suitable, flat wall that is strong enough to support the weight of the
appliance.

5
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
• Clearances: The heater must be installed in a position where the outlet
grille is a minimum distance of:
- 1800mm from the floor
- 350mm from the nearest side to an adjacent wall
- 500mm from the ceiling to the top face of the heater
- 90mm from any combustible material such as furniture, curtains, bedding,
clothes or papers, etc.
• Installation requirements: The heater is to be installed so that switches
and other controls cannot be touched by a person in the bath or shower.
The plug must not be positioned below the heater.
• Keep the top clear: Do not place anything on top of fan heater.
• No overnight use: Do not leave the heater on overnight.
• WARNING! DO NOT use the fan heater in the following areas or
circumstances:
- Near an open flame, a hot burner, oven or other source of high heat
- Outdoors or in areas of high humidity without suitable ventilation
- Near a swimming pool or other source of water, where it may get splashed
or fall into the water
- In a window or near curtains
- Above a socket outlet
- In areas where paint, petrol, etc. is stored and there is a risk of explosion
or fire from flammable gases, or in areas where substances are being
sprayed.
• CAUTION! Personal safety: Avoid contact with moving parts. Never insert
fingers, pencils or any other objects through the grilles when the fan heater
is running. Keep hair and loose clothing well away from the fan heater when
it is in use.
• Free airflow: Ensure nothing is blocking the airflow grilles. Do not insert
foreign objects into any opening as this may cause electric shock and/or a
fire hazard.
• Moving: When moving the appliance, do not touch the outlet grilles.
• Cleaning: When cleaning the appliance, do not use water or a wet cloth on
any part of the unit, as this may cause a short circuit or electric shock.
• Misuse: We accept no liability for any damages or personal injury caused by
misuse of the product and/or failure to follow these instructions.
Important Safety Instructions (Cont.)

6After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Product Overview
1
2
3
NOTE: Due to continued product improvement, images and illustrations in this
manual may vary slightly from the product purchased. All images in this manual
are for reference only and are not necessarily depicted to scale.
Scope of delivery
(A) Wall fan heater
1 Front panel
2 Air outlet grille
3 Pull cord
(B) Installation hardware (not pictured)
3 wall plugs and 3 screws
1 metal wall plate and 2 screws
(C) Documentation (not pictured)
Instruction manual
Warranty certificate

7
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Unpacking
• This product has been packaged to protect it against transportation
damage. Unpack the appliance and keep the original packaging carton
and materials in a safe place. It will help prevent any damage if the product
needs to be transported in the future, and you can use it to store the
appliance when it is not in use. In the event that it is to be disposed of,
please recycle all packaging materials where possible.
• Plastic wrapping can be a suffocation hazard for babies and young
children, so ensure all packaging materials are out of their reach and
disposed of safely.
• Unwind the cord to its full length and inspect it for damage. Do not use the
appliance if the appliance or its cord have been damaged or are not working
properly. In case of damage, contact our after sales support centre for
advice on examination, repair or return of the damaged product.
• Make sure you have read and understood all instructions and warnings in
this manual. Refer to the Product Overview, opposite, to familiarise yourself
with the product and identify all parts. Pay particular attention to the safety
instructions on the previous pages.
• Assembly: Your new fan heater comes fully assembled, ready for wall-
mounting to a suitable wall. Wall-mounting instructions are provided on the
following page.
Getting Started

8After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Getting Started (Cont.)
Wall-mounting instructions
IMPORTANT!
• Your wall must be structurally sound and sturdy enough to support the
weight of the heater. If in doubt about the suitability of your wall, please
consult a builder. If mounting the heater to a plasterboard wall, make
sure you mount it onto a wall stud.
• A power point must be in easy reach, but not directly below the heater.
• Ensure you are mounting the fan heater in a safe location on the wall; do
not mount it directly above a bed, cot or similar location.
• In accordance with the safety instructions, determine the place on the wall
where you want to mount the fan heater. Mark two holes for the screws
165mm apart and at a minimum distance of 1.8m above the floor (Fig. 1).
• If you are mounting the heater above a shelf or other wall-mounted object,
then there must be a minimum clearance of 700mm between the shelf and
the air outlet.
• Using the two small screws provided, affix
the small metal plate to the back of the
heater, as illustrated (Fig. 2: a).
• Drill two holes in the wall where you have
marked the spots – their diameter should be
wide enough so they just tightly contain the
plastic wall plugs. Insert two of the plugs into
the holes, then screw in two screws, keeping
the tips protruding approximately 5mm.
• When the wall plugs and screws are secured
in the wall, hang the heater with the holes at the
back (Fig. 2: b) over the protruding screw tips.
Ensure that the heater is hanging straight, then
mark the spot for the third wall plug through the
hole in the metal plate (Fig. 2: c). Take the heater
off the wall, drill a hole where you marked the
spot and insert the third wall plug.
• Hang the heater back on the wall (over the two
protruding screw tips) and fasten it with the third
screw into the wall plug at the bottom.
• To check that the heater is securely mounted,
try to gently slide the heater upwards. It should
not move.
Fig. 1
Fig. 2
(a)
(b)
(c)

9
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Connection
• Insert the power plug into an appropriate electrical outlet nearby and switch
on the power at the outlet. Always use a separate socket that has no other
high wattage appliances connected at the same time – do not plug it into a
power board or socket adaptor; do not use an extension cord.
Operation
This wall fan heater is equipped with a pull cord for easy operation.
• Pull the cord once, gently, to switch on the fan heater. The pilot light will
illuminate and the fan heater will start with low (1000W) heat output.
• Pull the cord a second time to select high (2000W) heat output.
• Pull the cord a third time to switch off the heater.
WARNING: Do not pull the cord too hard, otherwise it may break.
Overheat protection
This heater is equipped with an overheat protection device, which will turn the
heater off in the event of overheating. The heater will automatically reset when
it has cooled down.
When the overheat protection device has been triggered and the appliance
stops working, turn the heater off, disconnect it and let it cool down. Inspect
the air outlet and intake grilles at the front and back of the unit and remove any
obstructions and blockages. Wait at least 10 minutes for the protection system
to reset before attempting to restart the heater.
If the overheat protection device keeps switching the heater off and you cannot
restart it, please contact our after sales support centre for advice.
Instructions
IMPORTANT!
• A common cause of overheating is deposits of dust and fluff entering
the heater. Ensure these deposits are removed regularly by unplugging
the heater, allowing it to cool and cleaning it (see page 10).
• Also make sure that the appliance can sufficiently dissipate the heat
generated. This is particularly important in case the overheat protection
has been triggered. Ensure there is sufficient room all around the heater,
and nothing is covering or obstructing the air outlet at the front or air
intake grille at the back of the unit.

10 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information
Cleaning and maintenance
Disconnect the fan heater from the power supply and take it off the wall for
cleaning and maintenance.
• Dusting: Clean your fan heater periodically by lightly running a vacuum
cleaner nozzle (soft brush) over the front and rear grilles to remove any
dust or dirt that may have accumulated inside or on the unit. Alternatively,
use a soft, dry cloth or feather duster for dusting.
• Stubborn stains: Use a slightly damp, soapy cloth for stubborn stains but
be sure the cloth is not too wet. Dry thoroughly.
Storage
• To store the fan heater when it is not in use, take it off the wall and store it in a
safe, dry location, protected from dust.
• We recommend using the original carton for storage. Alternatively, place it in a
plastic bag or wrap it in a piece of material for dust protection.
Service/repair
• The appliance requires no maintenance and contains no user-serviceable
parts. Do not attempt to take it apart, or to repair or modify the appliance.
• Do not operate the fan heater if its power cord or plug is damaged, or
when it is working abnormally. In case of damage or malfunction, or if
the cord is damaged, have the unit repaired by appropriately qualified
personnel only, or contact our after sales support centre for advice on
repair or replacement.
WARNING!
• Before cleaning, maintenance or moving the fan heater, and before
removing the air outlet grille, switch off the fan heater and unplug it from
the wall outlet.
• Do not immerse the fan heater in water or other liquids.
• Never use petrol, solvents, harsh detergents, or abrasive or alkaline
cleaners on the fan heater.

11
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Other Useful Information (Cont.)
Technical specifications
Power 1800–2000W, 220-240V ~, 50Hz
Fan heater speeds 2 (1000W, 2000W)
Ingress protection IP22
Dimensions approx. (L)265 x (D)125 x (H)315 mm
Weight approx. 1.55kg
Responsible disposal
• At the end of its working life, make the appliance unserviceable by
unplugging it from the power outlet and cutting the power cord.
• Do not throw this appliance out with your household rubbish. Electrical
and electronic products contain substances that can have a detrimental
effect on the environment and human health if disposed of inappropriately.
Observe any local regulations regarding the disposal of electrical consumer
goods and dispose of it appropriately for recycling. Contact your local
authorities for advice on recycling facilities in your area.
Compliance
This appliance has been fully tested and meets all requirements as set out by
standards AS/NZS 60335.1 and AS/NZS 60335.2.30.
CLASS II - DOUBLE INSULATED APPLIANCE
This symbol indicates that the appliance has been designed in such a way
that it does not require a safety connection to electrical earth (ground).
Troubleshooting
If your heater fails to operate, or you experience any other problem with the
appliance, contact our after sales centre for advice or to arrange a service.
But before phoning for a service, please ensure that the heater is properly
plugged in and the outlet and circuit breaker or fuse are working properly.
The RCM Mark (Regulatory Compliance Mark) indicates that the product
complies with the relevant guidelines of the ACMA as well as corresponding
government requirements for the safety of electrical devices.
E209

12 After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
After Sales Support
(AU) 1300 886 649 (NZ) 0800 836 761 | [e-mail]
Warranty returns
Should you for any reason need to return this product for a warranty
claim, make sure to include all accessories with the product.
Product does not work?
If you encounter problems with this product, or if it fails to perform
to your expectations, make sure to contact our After Sales Support
Centre on (AU) 1300 886 649 or (NZ) 0800 836 761 for advice.
Distributed by Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Australia NSW 2086
Customer Helpline:
(AU) 1300 886 649 (NZ) 0800 836 761
Email: [email protected]
For an electronic copy of this manual, please contact our after sales support centre.
IM Version No: V1.0 Issue: November 2019
