Mixpro 100
User manual
Edition of 29/05/2020

User manual - Mixpro 100 202005-434-ENGP2
You just acquired one of our
machines and all the team
of Europe Projection thanks
you for the condence
you have granted us.
Manufacturer of professional
equipments for paint and
llers, we have put our
know-how for 25 years
at the service of the
users of our machines.
Our technical & commercial
team is at your disposal
for any further information
you may need about the
machine you just acquired.
EUROPE PROJECTION
228, avenue Olivier Perroy
13790 ROUSSET
Tél : [phone]
Fax : [phone]
SUMMARY
1. USER MANUAL............................................................. p. 3
1.1. Importance of the manual .........................................p. 3
1.2. Receivers of the manual............................................p. 3
2. WARNING .................................................................... p. 4
2.1. Safety .....................................................................p. 4
2.2. Electric connection ...................................................p. 6
2.3. End-of-life of the product ..........................................p. 6
3. YOUR MACHINE ........................................................... p. 7
3.1. Description..............................................................p. 7
3.2. Technical characteristics ...........................................p. 7
3.3. Identication of the components ................................p. 8
4. USE OF THE MACHINE ................................................. p.10
4.1. Prerequisites............................................................p.10
4.2. Starting up ..............................................................p.11
4.3. Error codes..............................................................p.11
5. MAINTENANCE............................................................. p.12
5.1. Cleaning procedure...................................................p.12
5.2. Check-up ................................................................p.12
6. DECLARATION OF CONFORMITY ................................... p.13
7. WARRANTY CONDITIONS.............................................. p.15

202005-434-ENG User manual - Mixpro 100 P3
1. USER MANUAL
1.1. IMPORTANCE OF THE MANUAL
This manual is a key part for the use of your machine. It summarizes the procedures of starting-up, cleaning
and maintenance of the device and also the safety instructions you need to observe.
Read carefully all the working and safety instructions and the warnings included in this manual before
starting your machine.
Most of the accidents are caused by the non-compliance of the safety standards and rules.
This manual must be kept near the machine, within reach of the user and held in good condition until the
nal destruction of the machine.
In case of loss or deterioration of the manual, you can ask the machine manufacturer mentioned on page
4 for a copy at any moment.
1.2. RECEIVERS OF THE MANUAL
This manual is intended to any staff which will manipulate the machine :
- people in charge of the transport of the machine
- people in charge of the use of the machine
- people in charge of the cleaning and maintenance of the machine
- people in charge of the nal destruction of the machine

User manual - Mixpro 100 202005-434-ENGP4
2. WARNING
2.1. SAFETY
Using the machine in an incorrect way or in non-compliance of the safety instructions indicated in
this manual can cause death or serious injuries.
Read carefully all the working and safety instructions and the warnings contained in this manual
before starting your machine.
• Respect all the safety standards before running the equipment.
• Use the equipment only for the applications specied in the manual.
• Always remain alert when using the equipment.
• Transport the machine using the handles or the appropriate grips.
• During the breaks, disconnect electrically the machine.
• Run the equipment to its nominal voltage.
• Let at least 50 cm of free space between the equipment and any obstacle so that the air ow
is not blocked.
• Know how to quickly stop the equipment in case of necessity.
• Never use the equipment while it is running abnormally or it is defective.
• Do not direct a water jet or ammable liquid on the machine.
• Never direct an air jet or product jet on a person or an animal.
• Do not touch warm surfaces of the equipment.
• Always wear adequate body protections (glasses, gloves, overall and mask) and pay attention
to long hair.
• Never touch moving parts.
• Do not insert any object or the hands inside the protection grids to avoid any accident or
damage to the machine.
• For any outside job, only use appropriate extension cords.
• Maintain the equipment carefully and clean it properly after every use.
• Disconnect the equipment before any intervention.
• Avoid absolutely to unscrew any connection while the machine is under pressure.
• Check the damaged parts.
• Do not clean the plastic parts with solvant.
• In case of damage of the electric cable or the plug, do not run the machine and contact a
licensed After-Sale Service to put genuine parts instead of the defective ones.
• In case of needed After-Sale Service, always specify the machine model and its serial number.
• For any replacement of parts, only use genuine parts.
• Do not modify the machine.
• Do not cut or dismantle the protection grids.
• Do not open the electric box.

202005-434-ENG User manual - Mixpro 100 P5
IN CASE OF NECESSITY, WE SAVE OURSELVES THE RIGHT TO MAKE ANY USEFUL
MODIFICATION WITHOUT ADVANCED NOTICE.
2. WARNING (continued)
2.1. SAFETY (continued)
WORKSPACE
• Maintain the workspace clean and clear.
• Ambient operating temperature must be from 5°C and 35°C.
• Do not use the equipment in a potentially explosive area.
• Do not place any potentially inammable objects in close proximity to the machine.
• Take away every not qualied person from the working area of the machine, as well as children and
animals.
• In case of installation of the machine on scaffolding or a plan above ground level, attach the machine
to avoid any fall while operating.
• Do not install the equipment on an inclined surface to avoid the risks of unexpected moves or falls.
HOSES
• Always use hoses and connections adapted to the used product (genuine parts), do not try to x it.
• Do not walk on the hoses, do not bend them.
• Do not use the hoses to pull the machine.
STORAGE
• Keep the equipment in a clean and clear area in which the temperature does not exceed +35°C.
• After every use, necessarily grease the pump with a mixture of water + storage liquid to avoid it blocking
up. The storage of a not greased pump can damage it seriously.

User manual - Mixpro 100 202005-434-ENGP6
2. WARNING (continued)
2.2. ELECTRIC CONNECTION
The electric connection of the machine must be on a 16A - 230V plug with a differential circuit
breaker.
Before any intervention on the machine, make sure that every energy supply is cut (air and
electricity).
GROUND CONNECTOR
All the machines must be connected to the ground when they work to protect the operator from electric
shocks. Our machines are all equipped with standardized connection plugs.
Electric connection must be made by a qualied technician. It is fobidden to modify or dismantle the
machine, especially the electric box.
Repairs must be made by an authorized center or our After-sale Service.
During any intervention on the machine, make sure that the ground is well reconnected.
EXTENSION CORDS
During the use of an extension cord, make sure that it is not crushed or damaged and that it contains a
ground. Check that the section of the used extension cord is sufcient to support the machine when it is
working. A too thin extension cord can cause voltage drops or overheating of the machine.
In case of use of a cable reel, it is imperative to unwind it entirely, otherwise, the equipment can be
damaged. The section must be proportional to the length of the cord.
2.3. END OF LIFE OF THE PRODUCT
At its end-of-life, the machine must not be eliminated with the other household waste. The
uncontrolled elimination of waste can harm the environment or human health. Individuals are
invited to contact the distributor which sold them the product or to inquire with their city hall
to know where and how to get rid of the product so it can be recycled while respecting the
environment.
Under the regulation of Waste of Electrical and Electronic Equipments (WEEE), we undertake to
process the used EEEs according to the following provisions: applicable only to products on the
market since 08/13/05, under the brands EUROPE PROJECTION or VOLUMAIR, products of other
brands sold by our company (upon presentation of the corresponding invoices), products that
operate using electrical energy (for example, thermal washers or compressors do not fall into this
category).
Treatment modality
WEEE returns collected by our clients/distributors at their own expense to our collection points in
Antony (92) or Rousset sur Arc (13). Upon receipt, the products are sorted by our employees and
directed to the most appropriate processing channels.
For any further information, please contact our hotline [phone] or [e-mail].

202005-434-ENG User manual - Mixpro 100 P7
3. YOUR MACHINE
3.1. DESCRIPTION
The mixer MIXPRO 100 is equipped with a double helical paddle on a horizontal arm ensuring a rapid &
homogeneous mixing of all types of powder products.
Mixer equipped with a speed control, reversing function and water doser.
Equipped with a digital control panel, allowing simplied adjustment of rotation speed, water dosage and
display of the network voltage.
Its folding feet allow the MIXPRO 100 to be placed above a spraying machine.
TO USE WITH
• All types of powder products
• All bi-component products
• Sand or lime to mix with water
3.2. TECHNICAL CHARACTERISTICS
Machine compatible with CP Joint 10, CP 10, 15, 20, 25, 30, 35, 40,
45 & 50
Mixing type sequential
Motor 2,2 kW
Forward / reverse rotation speed 36 to 84 RPM
Power supply 230 V - 10 A - 50 & 60 Hz
Tank capacity 100 L
Water meter integrated
Mixing paddle double helical paddle
Loading height 126 cm
Dimensions (L x w x h) 129 x 74 x 84 cm
Dimensions high position (L x w x h) 129 x 74 x 126 cm
Weight 107 kg
Do not use corrosive, acid or other types of products susceptible to damage the tank or the
blade.
The water distribution circuit is expected to be used only with water. The use of another
product, whatever it might be, can seriously damage the machine.

C ED
A
B
G
F
H
User manual - Mixpro 100 202005-434-ENGP8
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS
ASafety grid
BEmptying trapdoor
CFolding feet
DWater inlet quick-connect
EGeared motor
FCommand panel (see details on the next page)
GShaft bearing
HLubricator

1L1 L3 3 72 6
L2 L4
AU J4 85 9 K
202005-434-ENG User manual - Mixpro 100 P9
3. YOUR MACHINE (continued)
3.3. IDENTIFICATION OF THE COMPONENTS (continued)
JMotor speed display in % KWater volume display in litres
1Start / Stop 8Increase of the preset water volume
2Start / Stop of the mixing 9Decrease of the preset water volume
3Start / Stop of the tank emptying L1 Power on light
4Increase the motor speed L2 Mixing process light
5Decrease the motor speed L3 Tank emptying process light
6Start / Stop of the water dosage L4 Water dosage process light
7Ajout d’eau par impulsion AU Emergency stop

User manual - Mixpro 100 202005-434-ENGP10
4. USE OF THE MACHINE
4.1. PREREQUISITES
• The electric connection has to be 230 V - 16 A - 50 or 60 Hz with a 3 x 2,5 mm cable reel of 40m
maximum, completely unreeled.
• The mixer is equipped with a security grid (A). If the grid is open, the display (J) shows SEC and the
mixer will not start. Close the grid to activate the mixer.
START / STOP
• Once the machine has been connected, the machine is in the stop mode, the display (J) shows OFF.
• One push of the ON/OFF button (1), the display (J) shows the set value of the speed in %, the warning
light (L1) lights up, the machine is ready.
• When the machine is working (warning light (L1) is on), one push of the button ON/OFF (1) will switch
the machine off. The display (J) will show OFF and the warning light (L1) will switch off.
MIXING
• One push of the button MIXING (2) will provoke the start-up of the mixing (alternate rotation) and the
warning light (L2) lights up.
• The button (4) and (5) allow you to increase or to reduce the speed of rotation.
• One push on the button EMPTYING (3) provokes the rotation of the mixer in emptying mode (backwards
rotation) and the light (L4) lights up.
WATER DOSAGE
• Set the wanted water quantity with the buttons (8) and (9). The display (K) will show the set value in
liters. Once you have set the water quantity, the display (K) will once again show the last injected water
quantity
• One push of the button DOSAGE (6) starts the dosing of the water, the warning light (L4) lights up
during the duration of the dosing and the display (K) increments the injected water quantity. Once the
set amount has been reached, the water dosage stops automatically and the warning light (L4) switches
off.
• During the automatic cycle, one push of the button DOSAGE will pause the dosing. Another push will
re-start the cycle.
• One push of the button +WATER provokes a water ow as long as the button is kept pressed. The
display (K) will add the water quantity to the one previously shown. This function is only possible
outside of the automatic water dosing seen above.
In case of a dysfunction of the machine, one 3 second push on the ON/OFF (1) will allow
you to verify that the power supply is over 210 V.

202005-434-ENG User manual - Mixpro 100 P11
4. USE OF THE MACHINE (continued)
4.2. STARTING UP
1. Once the machine is plugged in, the display (J) shows AU (emergency stop). Turn the red button (AU)
to deactivate it.
2. The display (J) shows OFF, push the button ON/OFF (1) to switch on the machine.
3. The display (J) corresponds to the mixing speed from 0 to 100%, the display (K) shows the water
dosage in litres.
4. Verify on the bag of the product to be mixed the water quantity and the necessary mixing time.
5. Using the arrows +/- (8) and (9), set the water quantity to the inferior value given by the product
manufacturer.
6. Press the button DOSAGE (6). The water starts to run into the tank.
7. Using the arrows +/- (4) and (5), set the mixing speed to 80% and activate the mixing by pressing
on the button MIXING (2).
8. Once the desired water quantity is in the tank (after the automatic stoppage of the water dosing),
break the bag of powder and empty it.
9. Mix the product for the time indicated by the product manufacturer.
10. If the product is too dry, use the +WATER button to add some water. The display (K) increments the
value of the injected water quantity.
11. If you had to add some water, correct the initially set quantity with help of the arrows +/- (8) and (9).
12. Press the EMPTYING button (3) and open the trapdoor (B).
13. Once the product has been emptied, close the trapdoor (B).
14. Press the button DOSAGE (6) to once again pour water into the tank, then press the button MIXING (2).
15. Once the automatic water dosing has stopped, break the bag of powder and empty it.
16. Mix the product for the amount of time indicated by the product manufacturer.
17. Repeat from step 12 as frequently as necessary.
4.3. ERROR CODES
The different error codes show up on the display (J).
CODES DEFINITION TO DO
No display. Plug the machine into the power supply, assure the power supply is
230 V, verify the fuse in the electric box.
Emergency stop is
on. Unlock the emergency stop button (AU).
Machine is in the
stop mode. Switch the machine on by pressing on the button (1).
Default control
engine. Set the machine to OFF for one minute and then switch it back on.
Default security
sensor. Verify that the security grid is closed.
If the problem persists or if in doubt on the good running of the machine, do not try to repair
it by yourself or to dismantle it.
Contact an authorized After-Sale Service or our hotline : [phone].

User manual - Mixpro 100 202005-434-ENGP12
5. MAINTENANCE
5.1. CLEANING PROCEDURE
After every utilization of the machine :
Clean the tank with help of a water jet or high pressure washer, then tip it over to empty it.
Open the emptying trapdoor (B) to let the product ow.
For an optimal cleaning of the mixing blades, think of turning them during the procedure.
Also clean the security grid (A).
Once the operation is nished, close the security grid.
Then clean the emptying trapdoor (B).
5.2. SERVICING
Once a week, lubricate the lubricator (D) with help of a grease pump (ref. 12566) as well as the engine
lubricator.
The direct projection of water under pressure onto the control panel has to be stopped at
the risk of water inltration into the electric box. Proceed by simply cleaning with a humid
sponge.

202005-434-ENG User manual - Mixpro 100 P13
6. DECLARATION OF CONFORMITY
THE MANUFACTURER : EUROPE PROJECTION
228, avenue Olivier Perroy
13790 ROUSSET
DECLARES THAT THE EQUIPMENT DESIGNATED BELOW :
Trademark : EUROPE PROJECTION
Type : Mixer
Model : Mixpro 100
COMPLIES WITH THE ARTICLE:
• the R.233-73 article of the Labour Code
THE DIRECTIVES :
• Machines 2006/42/CE
• Low voltage 2014/35/UE
• CEM 2014/30/UE
• ROHS 2011/65/UE
• Noise emissions 2005/88/CE
AND WITH THE STANDARDS:
• NF EN ISO 12100
• NF EN 60204-1
• NF EN ISO 13857
ROUSSET, JANUARY 20th 2020
Patrick BOREL
President
EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET
Tél : [phone] – Fax : [phone]
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510

User manual - Mixpro 100 202005-434-ENGP14

202005-434-ENG User manual - Mixpro 100 P15
7. WARRANTY CONDITIONS
Each product is delivered inspected and tested.
We exclude any warranty for visible defects for which the customer did not claim within 48 hours.
The equipments sold are covered by the warranty during the period dened by the manufacturer from
the date of purchase, the date on the original proof of purchase being authentic and under the conditions
dened by the manufacturer.
This warranty covers any equipment against any manufacturing or material defect of for normal use and
service. Insofar as the customer is presumed to be a professional of the same specialty, the guarantee
covers only the lack of realization of the equipment rendering it unt for its use not likely to be detected by
a professional buyer.
The defects or deteriorations caused by natural wear, external accident or a modication, use, storage or
treatment of equipments not planned by the manufacturer, nor specied by ourselves, are excluded from
any warranty.
Are expressly excluded from the warranty the defects coming from: a bad use, the application of abrasive
or corrosive products, an inappropriate installation, the negligence, an insufcient maintenance or cleaning
chemical, electrochemical or electric inuences, any change in the normal process of use.
The following wearing parts are not covered by the warranty: rotors, stators, driving shafts, connecting rods,
seals, cleaning balls, spray guns, lance, nozzle, hose, needle kits, cylinders, piston rods, prime/spray valve
assy, seal kits, membranes, suction and delivery valves, carding machine vanes, lters, oils.
The warranty also excludes the equipments: on which the serial number was erased or made illegible, on
which unauthorized people made attempts of repair which were totally or partially dismantled.
Defective equipment will be removed by us. Any shipment of equipment by the customer will be at its own
expense. The guarantee will be subject to the presentation of the purchase invoice. We will then be able to
perform an equipment analysis to determine if the defect is covered by the warranty.
If the defective equipment is covered by the warranty, it will be repaired or replaced free of charge. Repaired
equipment (under warranty) will be delivered to the customer free of charge.
If the defective equipment is not covered by the warranty, we will issue a quote for the repair that we will
submit to the customer’s agreement. The costs of removal and shipping of equipment not covered by the
warranty will be charged to the customer, whether or not the latter accepts the repair estimate.
Except as otherwise required by law, this warranty is exclusive of all other warranties, including the statutory
warranty of hidden defects.
In case of intervention of our services on a breakdown caused by the customer or an outage excluded in the
conditions referred to above, the costs of repair and transport will be billed to the customer.
We exclude all liability for indirect damages suffered by the customer, such as, but not limited to, loss of
income, turnover, loss of prots, loss of image, of any kind whatever.
In all cases, our liability shall be limited to the amount paid by the customer for non-compliant equipment.
Any action of the customer against us relating to the guarantee of the equipments will be prescribed within
the period of 1 year as from the day of the discovery of the defect. It is up to the customer to prove the day
of this discovery.
Our equipments are covered by a warranty (parts and labour) of 12 months following the purchase.
The duration of this warranty can be extended by 6 months by completing the warranty extension
form within 4 weeks after purchasing on our website www.euromair.com (section Warranty).

EUROPE PROJECTION - 228, avenue Olivier Perroy 13790 ROUSSET - Tél : [phone] – Fax : [phone]
SAS au capital de 400 000 € - RCS Aix-en-Provence B 394 961 510 - NAF 2892 Z - Intracom : FR 54 394 961 510
User manual - Mixpro 100 202005-434-ENGP16
