Sunbeam 2356 User manual

Instruction Manual
DELUXE MIXMASTER®MIXER
Mode d'Emploi
BATTEUR DELUXE MIXMASTER®
Manual de Iinstrucciones
BATIDORA MIXMASTER® DELUXE
Instruzioni per l'Uso
DELUXE MIXMASTER®MIXER
Gebrauchsanleitung
DELUXE MIXMASTER®MIXER
Anvandarhandledning
DELUXE MIXMASTER®MIXERN
■
■
■
■
2356, 2358, 2359 &2360
2356, 2358, 2359 &2360

2
When using electrical appliances, basic safety precautions should always
be followed including the following:
1. Read all instructions before using the Mixer.
2. To protect against risk of electrical shock, do not put Mixer in water or
other liquid. This may cause personal injury or damage to the product.
3. Close supervision is necessary when Mixer is used by or near children,
or incapacitated persons.
4. Unplug from outlet while not in use, before putting on or taking off parts
and before cleaning.
5. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas
and other utensils away from beaters during operation to reduce the risk
of injury to persons and/or damage to the Mixer.
6. If the power supply cord of this appliance is damaged, it must only be
replaced in a repair shop appointed by the manufacturer, because
special tools are required.
7. The use of attachments not recommended or sold by Sunbeam may cause fire,
electrical shock or injury.
8. Do not use outdoors or for commercial purposes.
9. Do not let cord hang over edge of table or counter or touch hot surfaces,
including the stove.
10. Remove beaters from Mixer before washing.
IMPORTANT SAFEGUARDS

11, Do not place Mixer or bowls on or near a hot gas or
electric burner, or in a heated oven.
12. Do not use Mixer for other than intended use.
13. Do not leave Mixer unattended while it is operating
THIS UNIT FOR HOUSEHOLD USE ONLY
When your Mixmaster” Mixer is first used, you may experience
an odor and possibly a slight wisp of smoke from your mixer motor.
This is caused by the heat curing of the insulation which protects the
motor and is normal. After the first few uses, this effect will disappear.
FOR PROOUCTS PURCHASEO IN U.S & CANADA ONLY:
T O reduce the risk of electrical shock, this appliance
has a polarized plug (one blade is wider than the other). As a
safety feature, this plug will fit in a polarized plug only one way.
If the plug does not fit fully in the outlet: reverse the plug.
If it still does not fit, contact a qualified electrician.
00 NOT ATTEMPT TO OEFEAT THIS SAFETY FEATURE.

3
1. Beater Ejector
2. Large Mixing Bowl
3. Small Mixing Bowl
4. Bowl-Fit Beaters
5. Turntable
6. Dough Hooks
7. Stand
8. Worklight*
9. Mixer-Release Trigger
10. Mix-Finder®Dial
11. Mixing Guide
*Some models do not have
the worklight feature.
F EATURES
Thank you for choosing the Sunbeam®
Deluxe Mixmaster
®
Mixer. For generations we
have been helping cooks prepare moist
cakes, light and fluffy meringue, and chewy
cookies. You can even make bread with your
Sunbeam®Deluxe Mixmaster®Mixer.
The Sunbeam®Deluxe Mixmaster®
Mixer offers you a choice of 12 different
mixing speeds. The bowl-fit beaters
and bowls have been designed to mix
ingredients thoroughly and evenly.
The Mix-Finder
®
dial tells you at a glance
which mixing speed to use. No problem
ejecting the beaters either – just push
the ejector button beside the handle.
When making bread, the Sunbeam®
Deluxe Mixmaster®electronically
controls the speed of the dough hooks
to deliver just the right power for proper
kneading action.
You’ll love being able to make so many
things with your mixer!
1
2
3
4
5
6
7
8
9
10
11

4
A SSEMBLING THE S TAND M IXER
Before assembling the mixer, be
sure the Mix-Finder®dial is in the
ZERO position and the electric cord
is unplugged.
A TTACHING THE T URNTABLE
Place the revolving turntable into
the base of the stand using the socket
corresponding to the size of the bowl.
A TTACHING THE M IXER H EAD
Press in on the mixer-release trigger,
located at the rear of the stand.
For models equipped with a head lock
feature – While pressing in on the
mixer-release trigger, press in on the
head-lock latch. This is best
accomplished by using the thumb and
forefinger of the same hand and
pressing inward.
This will open the top of the stand to
receive the mixer head. Place the mixer
head on the top of the stand so that the
metal pivot, located on the bottom of
the mixer head, goes into the open
groove on the top of the stand.
As you release the mixer-release trigger,
the top of the top of the trigger should
clamp around the metal pivot.
For models equipped with a head-lock
feature–To lower the mixer-head for
normal operation, support the mixer
head with one hand. Then press in on
the head-lock latch. Gently lower the
mixer head until the mixer head is in a
normal operating position.
Be sure the mixer head is securely
attached to the stand before using.
NOTE: This mixer is NOT intended
for use away from the stand.
A DDING THE M IXING B OWL
Place the desired mixing bowl onto
the turntable so that the groove in the
bottom of the bowl fits into the correct
groove in the turntable.
Mixing bowls should NEVER be used in
a conventional oven, microwave oven,
on top of the range, or on any other
heated surface.
NOTE: If mixing bowls are scratched
or chipped, do not use mixer. Mixer
bowl should not be used to blend in
hot liquids.
Mixer-Release
Trigger
Latched Opening
Ball Bearing
Extension
Small
Bowl Large
Bowl
Mixer
Head
Mixer-Release
Trigger
Metal
Pivot
Stand

5
Attaching the Beaters
Be sure the Mix-Finder®dial is in the
ZERO position and unplug electric cord
from the electrical outlet.
Lift mixer head up and back to pull it
out of the way of the bowl, while
holding in an upright position.
NOTE: It is important that the beaters go
into the correct sockets. Otherwise the
mixer will not give you the proper
mixing action. Do not risk ruining a
recipe or damaging your mixer. Read
the following instructions carefully.
One of the beaters is conical in shape
and has a nylon button on the bottom.
It goes into the socket on the side of
the mixer nearest the side of the bowl.
The other beater is square-shaped and
goes into the socket nearest the center
of the bowl. See beater symbols located
on the front of the mixer head.
Insert the beaters, one at a time,
using a combination pressing and
twisting motion, until the beaters
snap into position.
If a beater should not properly snap
into place, pull it out of the socket
and rotate it one quarter turn.
Reinsert the beater into the socket
until it snaps into position.
Attaching the Dough Hooks
Set the Mix-Finder®dial in the OFF
position and unplug the electric cord
from the electrical outlet.
Lift mixer head up and back to tilt it out
of the way of the bowl, while holding in
an upright position.
NOTE: The dough hooks must go into
the correct sockets. The mixer will
operate with the dough hooks in the
wrong position. However, you will not
get proper kneading action and you
could risk ruining a recipe or damaging
your mixer. Read the following
instructions carefully.
Nylon
Button
Square
Beater
Conical-Shaped
Beater
Side of
Bowl
Conical
Beater Square
Beater

6
The dough hook with the small washer
and foot goes into the socket on the
side of the mixer nearest the side of
the bowl. The other dough hook with
the large washer goes into the socket
nearest the center of the bowl. See the
dough hook symbols located on the
front of the mixer head.
Beater-Bowl Drive Adjustment
Automatic bowl rotation is factory set.
Occasionally, a simple adjustment
may be necessary when the bowl
fails to rotate.
To make this adjustment, tilt the mixer
head back. Hold the mixer head in an
upright position and locate the
adjustment screw on the underside
of the mixer head. Loosen the locking
nut and turn the adjustment screw on
the underside of the mixer head.
Loosen the locking nut and turn the
adjustment screw clockwise, to lower
the mixer head; or counter clockwise,
to raise the mixer head. Retighten the
locking nut. The beater with the nylon
button should lightly touch the bottom
of the mixing bowl.
About the Worklight Feature
Some of our models have a
worklight that lights the area
inside the mixing bowl.
As soon as the electric cord is
plugged in, the worklight will glow.
It will continue to glow until the
electric cord is unplugged from
the electrical outlet.
Operating Instructions
About the Mix-Finder® Dial
The Mix-Finder®dial is used for turning
the mixer ON and OFF and for selecting
its 12 mixing speeds.
Rotate the Mix-Finder
®
dial in a clockwise
direction, to increase mixing speed;
and in a counterclockwise direction,
to decrease mixing speed.
As you rotate the Mix-Finder®dial,
notice that a numbered speed
is aligned with the indicator on top
of the mixer head. This numbered
speed indicates the speed at which
the mixer is operating.
Rotate the Mix-Finder®dial until the
indicator is opposite the numbered
speed you wish to use.
Adjustment
Screw Locking
Nut
Worklight
Speed
Indicator
Mixing
Guide
Mix-Finder®
Dial

7
NOTE: Due to variations in ingredient temperatures and quantities, the Mixing Guide
speeds are only suggested. If necessary, adjust speeds as needed to achieve
desired results.
Mixing Guide
The mixing guide on your mixer has been designed to help you take the guess work
out of preparing foods.
Next to each of the numbered speeds on the Mix-Finder®dial are descriptions
of the mixing task best suited to that mixing speed. Use those descriptions as
a mixing guide when preparing your favorite recipes.
Speed Mixing
Setting Guide Example
1 Fold-Kneaded Use when mixing dry ingredients or when folding
two portions of a recipe together, such as a beaten
egg white into a batter or when directions call for
LOW speed. Use for kneading bread.
2 Stir Use when stirring liquid ingredients or when gentle action
is needed to moisten dry ingredients.
3 Blend Use when quick breads require a brisk action,
just enough to blend ingredients but not enough
to develop a smooth batter.
4 Mix Use when mixing dry ingredients and liquid ingredients
together alternately in a recipe.
5 Combine Use when recipe calls for combining ingredients together.
6 Cake Mixes Use when preparing packaged cake mixes or
when directions call for MEDIUM speed.
7 Cream Use when creaming sugar and butter together.
8 Whip Use to whip potatoes or to develop a smooth batter.
9 Whip/Cream Use to whip whipping cream or to develop a light,
fluffy texture.
10 Desserts Use to beat air into whipped desserts.
11 Frostings Use when preparing light, fluffy frostings and candies.
12 Egg Whites Use when aerating eggs and egg whites.
Use when directions call for HIGH speed.

8
CARING FOR YOUR MIXER
E JECTING THE B EATERS OR D OUGH H OOKS
After you’ve finished mixing, turn the
Mix-Finder®dial to OFF and unplug the
electric cord from the electrical outlet.
Push the ejector button located near
the handle to remove beaters or
dough hooks.
Scrape excess batter off the beaters
using a rubber or plastic spatula. Do not
strike beaters on the rim of the bowl.
C LEANING Y OUR M IXER
To clean the mixer, wipe the mixer head,
stand, and turntable with a damp cloth,
then dry. DO NOT IMMERSE THE
MIXER HEAD OR STAND IN WATER.
Avoid the use of abrasive cleaners, as
they may mar the finish of the mixer.
Wash the beaters and bowls in hot,
soapy water after each use. Rinse
thoroughly and dry. Beaters and
bowls may also be washed in an
automatic dishwasher.
C ARE AND C LEANING OF THE W ORKLIGHT
(For models with worklight feature only.).
The worklight bulb should be replaced
as soon as it burns out. You may also
wish to remove the worklight lens
periodically for cleaning.
To remove the worklight lens, place
the Mix-Finder®dial in the ZERO position
and unplug mixer from electrical outlet.
Remove beaters or dough hooks
from mixer sockets and remove
bowl from turntable.
Holding the mixer head in an upright
position, use a small screwdriver to
remove the screw holding the
worklight lens in place.
Squeeze the worklight lens, as shown,
until the tabs on the lens clear the
housing. Tilt the worklight lens down
and out of the housing.
To clean the worklight lens, wash in
warm, soapy water. Rinse and dry
thoroughly.
To replace the worklight bulb, unscrew
from socket. Replace with new bulb.

9
NOTE: Replacement bulbs may be
purchased from local hardware or
department stores or from your
nearest authorized Sunbeam Service
Center (6 watt maximum bulb
can be used.)
To replace the worklight lens,
repeat the steps described in
“To remove the worklight lens”
in reverse order.
S TORING Y OUR M IXER
Store the mixer in a dry location,
such as on a counter top or table top,
or in a closet or cupboard.
Place the small mixing bowl inside
the large mixing bowl with the beaters
inserted into the proper sockets.
Place the dough hooks in the
small mixing bowl. Store the bowls
on the turntable. The beaters will help
hold the bowls in position. Wind the
electric cord into a coil, secure it
with a twist fastener.
M AINTENANCE
The motor of your stand mixer has
been carefully lubricated at the
factory and does not require
any additional lubricant.
Other than the recommended
cleaning and worklight replacement,
no further user maintenance
should be necessary.
Return the mixer to the nearest
Sunbeam Service Center for
servicing or repairs.
MIXING AND BAKING SUGGESTIONS
• Ingredients should be added to the
mixing bowl as they are specified in
the recipe. When combining dry
and wet ingredients, you may wish
to moisten ingredients on Speed 1
or 2, then turn to the desired
mixing speed.
• Use the mixing speed that is
recommended in the recipe. When
using a recipe that is not in this book,
use the handy mixing guide on the
Mix-Finder®dial of the mixer to help
you find the correct speed to use.
• If times are specified in the recipe,
use them! BE CAREFUL NOT TO
OVERMIX. Overmixing can cause a
mixture to become very tough.
• Should an object, such as a spatula,
fall into the bowl while the mixer is
operating, turn the mixer off
immediately. Then, remove the object.
• Remove beaters and place in sink
for easy clean-up.
• When preparing your favorite
recipe, DO NOT exceed 3-1/2 cups
of flour grain in a recipe.
