Eurotech ELV2-BLK-FS User manual

ELV2-BLK-FS/ELV2-WHT-FS
ASSEMBLY
OPERATING INSTRUCTIONS
WWW.EUROTECHSEATING.COM
CUSTOMER SERVICE 1-800-637-0005
INSTRUCTIONS
WARRANTY

Key
Spare
Description
M
3
· Please tighten your chairs hardware every six months.
N
3
4
Part List
Part Qty.
ASSEMBLY INSTRUCTIONS
CHAIR NAME AND SKU OR MODEL
ELV2-BLK-FS/ELV2-WHT-FS
Remove all items from the carton. Verify all components before assembly.
Spring Washers for
Washers for Back Bolts
Washers for Arm Bolts
(Ø6*16*2.0mm)
Back Bolts
(Ø8*20*2.0mm)
(Ø8*13*2.0mm)
L
1
1
1

Seat must slide into the slot on back.
STEP 2
STEP 2
PREVENTIVE MAINTENANCE AND WARNING!
• USE THIS PRODUCT ONLY FOR SEATING ONE PERSON AT A TIME.
• DO NOT USE THIS CHAIR AS A STEP STOOL / LADDER.
• DO NOT SIT ON ANY PART OF THE CHAIR EXCEPT THE SEAT.
• DO NOT USE CHAIR ON UNEVEN FLOOR SURFACES.
• DO NOT USE CHAIR UNLESS ALL BOLTS, SCREWS AND KNOBS ARE TIGHTENED.
• EVERY SIX MONTHS, PLEASE MAKE SURE ALL BOLTS, SCREWS AND KNOBS ARE
FULLY TIGHTENED TO ENSURE STABILITY.
• IF ANY PARTS ARE MISSING, BROKEN, DAMAGED OR WORN, STOP USE OF THE
PRODUCT UNTIL REPAIRS ARE MADE USING FACTORY AUTHORIZED PARTS.
• DISPOSE OF PACKAGING PROPERLY. PLASTIC BAG IS NOT A TOY. DO NOT USE
PLASTIC BAG AS HEAD COVERING – IT MAY CAUSE SUFFOCATION.
• FAILURE TO FOLLOW THESE WARNINGS COULD RESULT IN SERIOUS INJURY.
• NOTE: SOME SCREWS MAY BE PREASSEMBLED. IF PREASSEMBLED, IGNORE
ASSEMBLY INSTRUCTIONS.
STEP 4
STEP 3
STEP 2
STEP 1
Press the Casters (F) into the holes at the end of each
leg of the Base (D).
Insert Seat Post (E) into the center hole of the base (D).
ASSEMBLY INSTRUCTIONS
ELV2-BLK-FS/ELV2-WHT-FS
Remove all items from the carton. Verify all components before assembly.
Tighten the bolts securely with the enclosed Allen
Wrench (K).
Please be careful to use the correct Back Bolts (H).
E
D
F
Now turn the assembled seat upright and locate the
center hole of the Mechanism over the Seat Post.
Push down firmly until the connection is secure.
H
K
L
A
B
M
N
J
I
C
Attach ea ch Ar mrest (C)to th e Se at Cu shion (B)
using Ar mrest Bo lts (I)an d Wa shers (N ) fo r ea ch ar m.
Tighten se curely wi th th e en closed Al len Wr ench (J).
Assemble th e Ba ckrest (A)to th e Se at Cu shion (B) using
3 Back Bo lts (H)
and
with 3 Spring Washers for Back screws (L)
3 Washers for Back Bolts (M).

OPERATING INSTRUCTIONS
B1 BACKREST HEIGHT ADJUSTMENT B2 ARMREST HEIGHT ADJUSTMENT
B5 SEAT HEIGHT ADJUSTMENT B6 BACKREST TILT ANGLE ADJUSTMENT
B1 BACKREST HEIGHT ADJUSTMENT
B2 ARMREST HEIGHT ADJUSTMENT
ADJUSTMENT
forward or backward to a desired position.
B4 ARM PAD ANGLE ADJUSTMENT
ELV2-BLK-FS/ELV2-WHT-FS
ADJUSTMENT
The height of the lumbar support can
be adjusted by lifting or lowering the
backrest height.
While seated, grasp each armrest and
The range of movement is approximately 2”.
While seated, a 15º range of movement
desired height.
The arm height adjustment range is 2.75”
.
raise to your desired height. In order to
lowest height. Then repeat toget to your
B3 ARMPAD FORWARD AND BACKWARD
can be achieved by swiveling the armpads
inward or outward.
While seated, push the armpads
lower the arm, lift the armrest to its highest
position and it will go back down to the
B3 ARMPAD FORWARD AND BACKWARD B4 ARMPAD ANGLE ADJUSTMENT

B5 SEAT HEIGHT ADJUSTMENT
B6 BACKREST TILT ANGLE ADJUSTMENT
that provide 21º of range.
B5 SEAT HEIGHT ADJUSTMENT B6 BACKREST TILT ANGLE ADJUSTMENT B5 SEAT HEIGHT ADJUSTMENT
OPERATING INSTRUCTIONS
ELV2-BLK-FS/ELV2-WHT-FS
D2 SEAT DEPTH ADJUSTMENT
B6 BACKREST TILT ANGLE ADJUSTMENT
The seat height adjustment range is
approximately 3.54”.
While seated, pull the single control lever
upward and hold it while raising or lowering
the seat to reach your desired seat height.
angle is achieved, return the lever to the
original middle position to lock your tilt
angle into place. There are 4 positions
against the back. When your desired
When the lever is released to its original
position, the seat height is locked.
While seated, pull the single control
lever completely backward and lean

• For all products except for 24/7 chairs (see below), Eurotech warrants to the original
purchaser all components for the life of the product with the exception of upholstery
and foam, which will be warranted for five years.
• For 24/7 chairs, Eurotech warrants to the original purchaser of all 24/7 chairs all components
for 10 years with the exception of upholstery and foam which will be warranted for 2 years.
• Eurotech warrants to the original purchaser that all parts will be free from material defects.
• Eurotech does not warrant any aftermarket hardware that is installed on the product.
• Eurotech does not w arrant customer’s own material.
This warranty is made as of 9/15/16. Please see http://www.eurotechseating.com/warranty-
information for any updates and/or revisions to this warranty.
those specifically described.
Eurotech will repair or replace, at its option, any unaltered components.
• Eurotech’s warranty is limited to the normal use of the product in a forty hour work week
and a 275lb. weight limit unless otherwise noted.
• Eurotech shall NOT be liable for consequential or incidental damage arising from any
product defect.
• Eurotech’s warranty is limited to replacement or repair and does not cover cost of
transportation and labor. There are no other warranties expressed or implied other than
OUR PROMISE.
design are essential ingredients in delivering real value for our customers. All
these years later, those three simple pillars still stand behind our promise of
exceptional seating with every chair we sell.
DESIGN CRAFTSMANSHIP VALUE
Eurotech. Sit Smarter.
THE EUROTECH WARRANTY
They say with age comes wisdom. And while we’ ve learned a lot since we sold
our first office chair in 1979, even then we knew that superior craftsmanship and
