Eurotech LAU1 User manual

LAU1
ASSEMBLY INSTRUCTIONS
OPERATING INSTRUCTIONS
WARRANTY
CUSTOMER SERVICE: [email protected]
CUSTOMER SERVICE: 1-800-637-0005
www.eurotechseating.com

A 5 pcs
1 pcs
1 pcs
1 pcs
1 pcs
1 pcs
2 pcs
2 pcs
Key Description
Caster
Star Base
Cylinder
Mechanism & Seat Cushion
Backrest & Lumbar Support
Hand wheel for back
Armrests - 1 Left & 1 Right
Hand wheel for arm
Part Qity.
B
C
D
E
F
G
H
ASSEMBLY INSTRUCTIONS
LAU1
Remove all items from the carton. Verify all pieces before assembly.
PARTS LIST
including washer and spring washer)
(M10*45,yellow

E
D
Attach the Backrest (E) to the mechanism and
due to special construction of this connection,
you might need to push in the backrest into
mech hardly.
D
H
G
ASSEMBLY INSTRUCTIONS
LAU1
Remove all items from the carton. Verify all pieces before assembly.
STEP 1 STEP 2 STEP 3
STEP 4 STEP 5 STEP 6
Press the casters (A) into the holes at the end
of each leg of the Base(B).
Insert the bottom end of the cylinder (C) into
the center hole of the Base (B).
You will hear a“clip sound”and see clip is in
the position of hole. Tighten the hand wheel
(F) securely with hand.
Now turn the assembled chair upright and
locate the center hole of mechanism over the
cylinder. Push down firmly until the connec-
tion is secured.
Before using your chair, ensure that all hand
wheels are tighten fully for safety. You can
now enjoy the comfort of your new chair.
Note: please check all hand wheels every
month to secure they are remained tightly and
fasten.
Please be careful to use the correct armrest
(G) which are marked Left and Right.
For easy assembly, place the Seat Cushion
(D) face down on a flat surface. Attach each
Armrest (G) to the Seat Cushion (D) using 2
hand wheels (H) for each arm. Tighten the
hand wheel by hand.
A
B
C
Clip!
F
F

While seated, pull the lever on the right side
of the mechanism up and hold it while raising
or lowering the seat to change the seat
height. When the lever is released, the seat
height is locked. The seat height adjustment
range is approximately 110mm / 4.3″.
While seated, turn the knob on the left side
of the mechanism to lock and unlock the tilt
function. To adjust force of tilt, turn the knob
on the right side of the mechanism to
increase and decrease the force. The range
of motion is approximately 21°.
While seated, to adjust the seat depth, there
is a lever on the left side of the seat and you
can pull up the lever to adjust the depth of
seat and release lever to lock the seat. The
range of adjustment is approximately
50mm / 2″.
There is a button at front / underside of arm
pad, you can press in to release the locking
for height adjustment. The range of
adjustment is approximately 100mm / 4″. Your chair can rotate around 360°.
To adjust the lumbar support, you
need to put your hands behind the
chair and search for a lever and
then you can adjust upward /
downward to the desired position.
OPERATING INSTRUCTIONS
LAU1
Remove all items from the carton. Verify all pieces before assembly.
A SEAT HEIGHT ADJUSTMENT. B BACK TILT ADJUSTMENT.
D ARMREST HEIGHT ADJUSTMENT. E ARM WIDTH ADJUSTMENT. F 360 SWIVEL.
C SEAT DEPTH ADJUSTMENT.
There are hand wheel at underside of arm
upright, you can turn to release the lock and
adjust outward / inward and tighten the hand
wheel when arm is adjusted to desired
position. The range of adjustment is
approximately 60mm / 2.4″.
LOCK UNLOCK
