Eurotech IOO-BLK User manual

IOO-BLK/IOO-WHT

Key
Spare
Description Part Qty.
Arm Bolts
Back Bolts
Backrest
Seat
Armrests
Star Base
Caster
Seat Post(Cylinder)
G
F
1
1
1
1
1
1
2
2
4
5
E
D
C
B
A
H
I
J
(M8 X 22mm)
(M8 X 15mm)
(1 left & 1 right armrest)
1
r
Allen Wrench
Washers for Arm Bolts
(Ø6.5*10.5*1.5mm)
2
1
1
Part List
IOO-BLK/IOO-WHT
ASSEMBLY INSTRUCTIONS

G
G
C
C
I
I
B J
Press the Casters (F) into the holes at the end of each leg of
the Base (E).
Insert Seat Post (D) into the center hole of the Base (E).
Please be careful to use the correct Arm Bolts (G), Washers (I)
and Armrests (C) which are marked Left and Right.
For easy assembly, place the Seat Cushion (B) face down on a
flat surface. Attach Armrest (C) to the Seat Cushion (B) as
shown using 1 Arm Bolt (G) with 1 Washer (I) on each arm .
Tighten the bolts securely with the enclosed Allen Wrench (J).
Please be careful to use the correct Back Bolts (H).
Attach the Backrest (A) to the Seat Cushion (B) using 4
Back Bolts (H) .
Tighten the bolts securely with the enclosed Allen
Wrench (J).
IOO-BLK/IOO-WHT
Now turn the assembled seat upright and locate the
center hole of the Mechanism over the Seat Post.
Push down firmly until the connection is secure.
rr
F
E
D
B
A
H
H
J
J
Seat must slide into the slot on back.

IOO-BLK/IOO-WHT
A1 BACKREST TILT ANGLE ADJUSTMENT
B1 BACKREST HEIGHT ADJUSTMENT
C1 ARMREST HEIGHT ADJUSTMENT C2 ARMREST PAD ANGLE ADJUSTMENT
B2 LUMBER SUPPORT HEIGHT ADJUSTMENT
A2 BACKREST TENSION ADJUSTMENT
A1 BACKREST TILT ANGLE ADJUSTMENT
A2 BACKREST TENSION ADJUSTMENT
B1 BACKREST HEIGHT ADJUSTMENT
B2 LUMBER SUPPORT HEIGHT ADJUSTMENT
C1 ARMREST HEIGHT ADJUSTMENT
While seated, pull the single rod control
lever completely backward and lean
against the back. When your desired angle
is achieved, return the lever to the original
middle position to lock your tilt angle into
place. There are 4 positions that provide
25º of range.
While seated, turn the Backrest Tilt
Tension Adjustment handle clockwise or
counterclockwise to adjust the tilt tension
to your preferred level of resistance.
While seated, hold the sides of the
backrest handle and move up or down.
There is a 1.57” range of adjustment.
A.The height of the lumbar support can be
adjusted by lifting or lowering the backrest
height.
B.Suitable height of the lumbar support
provides optimum comfort.
While seated, push the button on the
outside of each arm and move the armrests
up or down. Release the button when you
have reached your desired height.
There are eight positions where the arm
height can be locked. The arm height
adjustment range is 3.15”.
C2 ARM PAD ANGLE ADJUSTMENT
While seated, a 9º range of movement
can be achieved by swiveling the arm pads
inward or outward.

IOO-BLK/IOO-WHT
C3 ARM PAD WIDTH ADJUSTMENT
D1 SEAT HEIGHT ADJUSTMENT D2 SEAT DEPTH ADJUSTMENT
C4 ARM PAD FORWAR D A ND BACKWARD ADJUSTMENT
C3 ARM PAD WIDTH ADJUSTMENT
C4 ARM PAD FORWARD AND BACKWARD
ADJUSTMENT
D1 SEAT HEIGHT ADJUSTMENT
D2 SEAT DEPTH ADJUSTMENT
While seated, push the arm pads
outward or inward to a desired width.
The range of movement is approximately 1.57".
While seated, push the arm pads forward
or backward to a desired position.
The range of movement is approximately 1.57".
While seated, pull the single rod control lever
upward and hold it while raising or lowering
the seat to reach your desired seat height.
When the lever is released to its original
position, the seat height is locked.
The seat height adjustment range is
approximately 3.5".
While seated, push the single rod control
lever forward to adjust the seat depth.
The range of movement for the seat is
approximately 1.97". When your desired
seat position is achieved, return the lever
to the original middle position to lock your
seat position into place.

• For all products except for 24/7 chairs (see below), Eurotech warrants to the original
purchaser all components for the life of the product with the exception of upholstery
and foam, which will be warranted for five years.
• For 24/7 chairs, Eurotech warrants to the original purchaser of all 24/7 chairs all components
for 10 years with the exception of upholstery and foam which will be warranted for 2 years.
• Eurotech warrants to the original purchaser that all parts will be free from material defects.
• Eurotech does not warrant any aftermarket hardware that is installed on the product.
• Eurotech does not warrant customer’s own material.
This warranty is made as of 9/15/16. Please see http://www.eurotechseating.com/warranty-
information for any updates and/or revisions to this warranty.
those specifically described.
Eurotech will repair or replace, at its option, any unaltered components.
• Eurotech’s warranty is limited to the normal use of the product in a forty hour work week
and a 250lb. weight limit unless otherwise noted.
• Eurotech shall NOT be liable for consequential or incidental damage arising from any
product defect.
• Eurotech’s warranty is limited to replacement or repair and does not cover cost of
transportation and labor. There are no other warranties expressed or implied other than
OUR PROMISE.
