Eurotech BT-400 User manual

BT-400
ASSEMBLY INSTRUCTIONS
CUSTOMER SERVICE: [email protected]
CUSTOMER SERVICE: 1-800-637-0005
www.eurotechseating.com
OPERATING INSTRUCTIONS
WARRANTY

BT-400
ASSEMBLY INSTRUCTIONS
Remove all items from the carton.Verify all components before assembly.
Backrest
Seat Cushion
Armrests
Seat Post (cylinder)
Star Base
Casters
Back Cover
Armrest Knobs
G
H
I
J
1
2
5
1
2
3
Part List
Key
Description Part Qty. Spare
Plesse tighten your chairs hardward every six months.
Allen Wrench
1
L-Bar Screws (5/8x1") with Washers

STEP 1
STEP 4
STEP 2
STEP 5
STEP 3
STEP 6
Turn the Star Base (E) upside down. Press the
Casters (F) into holes at the end of each leg.
Turn the Star Base (E) upright and insert Gas
Lift (D) into the center hole of Star Base (E).
For easy assembly, place Seat Cushion (B) face
down on a raised flat surface. Attach Armrests
(C) to the Seat Cushion (B) as show using 2
Armrest Knobs (H) .
Assemble Backrest (A) to Seat Cushion (B) and
secure in place using 3 Bolts (I) with washers as
shown. Tighten the bolts fully with Allen Wrench
(J).
A
G
Assemble Back Cover (G) to Backrest (A) as
shown putting the Back Cover (G) with inside
arrow upright.
Turn assembled seat upright and locate central
hole below Seat Cushion (B) cover Gas Lift (D).
Push down firmly until connection is secure.
PREVENTIVE MAINTENANCE AND WARNING!
USE THIS PRODUCT ONLY FOR SEATING ONE PERSON AT A TIME.
DO NOT USE THIS CHAIR AS A STEP STOOL / LADDER.
DO NOT SIT ON ANY PART OF THE CHAIR EXCEPT THE SEAT.
DO NOT USE CHAIR ON UNEVEN FLOOR SURFACES.
DO NOT USE CHAIR UNLESS ALL BOLTS, SCREWS AND KNOBS ARE TIGHTENED.
IF ANY PARTS ARE MISSING, BROKEN, DAMAGED OR WORN, STOP USE OF THE
PRODUCT UNTIL REPAIRS ARE MADE USING FACTORY AUTHORIZED PARTS.
DISPOSE OF PACKAGING PROPERLY. PLASTIC BAG IS NOT A TOY. DO NOT USE
PLASTIC BAG AS HEAD COVERING - IT MAY CAUSE SUFFOCATION.
FAILURE TO FOLLOW THESE WARNING COULD RESULT IN SERIOUS INJURY.
NOTE: SOME SCREWS MAY BE PREASSEMBLED. IF PREASSEMBLED, IGNORE
ASSEMBLY INSTRUCTIONS.
EVERY SIX MONTHS, PLEASE MAKE SURE ALL BOLTS, SCREWS AND KNOBS ARE
FULLY TIGHTENED TO ENSURE STABILITY.
F
EE
D
C
C
B
H
H
B
A
I
I
I
D
J
B
BT-400
ASSEMBLY INSTRUCTIONS
Remove all items from the carton.Verify all components before assembly.

Lock Unlock
Lock Unlock
OPERATING INSTRUCTIONS
A. TO ADJUST SEAT HEIGHT
C. TO OPERATE BACK CUSHION
TILT LOCKOUT
B. TO ADJUST BACKREST HEIGHT
D. TO OPERATE SEAT CUSHION
TILT LOCKOUT
A TO ADJUST SEAT HEIGHT
While seated, lean forward, lifting your
body weight from the seat. Reach
underneath the right side of chair and
locate the front lever. Pull the lever back
slowly to allow the chair to rise to the
desired height. To lower seat height,
lift the lever slowly while seated.
B TO ADJUST BACKREST HEIGHT
To raise backrest, hold the backrest and
pull upward. The backrest can be returned
back to the lowest level after the highest
point has been reached.
C TO OPERATE BACK CUSHION
TILT LOCKOUT
Reach underneath the right side of chair
and locate the convex-surfaced handle.
Push the handle downward. When the
handle is in this position, leaning back
will cause the chair back to tilt backwards.
To lock the chair back in the upright or
vertical position, sit upright and push the
handle upward
D TO OPERATE SEAT CUSHION
TILT LOCKOUT
Reach underneath the right side of chair
and locate the middle convex-surfaced
handle. Push the handle downward. When
the handle is in this position, leaning back
will cause the chair seat to tilt backwards.
To lock the chair seat in the upright or
vertical position, sit upright and push the
handle upward.
E. TO ADJUST FORWARD TILT
E TO ADJUST FORWARD TILT
With the seat tilt handle in the downward
position, lean back and reach under the
left hand side of the chair and lift up the
lever. This will allow the seat to tilt forward
beyond a level position. To release the
forward tilt position, lean back and push
the lever downward.
Downward position
Lock Unlock
BT-400

Tighten
Loosen
F. TO ADJUST TILT TENSION G. TO ADJUST SEAT DEPTH
H. TO ADJUST ARMREST HEIGHT I. TO ADJUST ARMREST WIDTH
F TO ADJUST TILT TENSION
Turn clockwise to tighten, making it more
difficult to tilt back.
Turn counter-clockwise to loosen, making
it easier to tilt back.
G TO ADJUST SEAT DEPTH
To move the seat forward or backward,
lift up the left lever and position the seat.
H TO ADJUST ARMREST HEIGHT
To raise/lower armrests, pull upwards/
downwards while holding down the trigger
located on the outer side of the arm.
I TO ADJUST ARMREST WIDTH
To adjust arm rest width, loose the round
knob while moving it in or out.
Adjust
Trigger
J. TO ADJUST ARM-PAD ANGLE K. TO ADJUST ARMPAD DEPTH TO ADJUST ARM-PAD ANGLE
The arm pad has 3 possible positions,
holding the front position of the arm pad as
required.
J
KTO ADJUST ARMPAD DEPTH
To adjust armpad depth, hold and push the
armpads forward or backward to a desired
position.

400
