EUTECH INSTRUMENTS EC TESTR - REV User manual

INSTRUCTION MANUAL
EC/TDS/SALT Testr
Large Screen
Waterproof Conductivity/TDS/Salt Tester
Introduction
Thank you for selecting our microprocessor-based waterproof EC / TDS / SALT tester with large
dual line display. You have one of the following models:
• ECTestrlow • ECTestrlow+ • ECTestrhigh • ECTestrhigh+ • ECTestrpure+
• TDSTestrlow • TDSTestrlow+ • TDSTestrhigh • TDSTestrhigh+ • TDSTestrpure+
• SALTTestr
The non plus models are designed with user-replaceable two-pin type sensor with many user friendly
features such as the Hold function, Automatic Temperature Compensation and Self-Diagnostic Messaging
capabilities. The plus models, with the user-replaceable cup type sensor, have more additional
features such as simultaneous temperature display, °C or °F selection, and have higher resolution
measurement.
This manual provides a step-by-step guide to operate the testers.
Before you begin:
Remove the electrode’s protective cap. Soak the electrode for a few minutes in alcohol to remove any
oil stains on the electrodes which will affect the accuracy of the tester. Rinse thoroughly with de-
ionized water and shake off dry.
Calibration
The tester is factory calibrated. However, to ensure accuracy, you can calibrate the tester on a regular
basis. Depending on the model selected, you can calibrate the Conductivity / TDS / Salt / Temperature
on a one point calibration using the appropriate calibration standard.
The following table lists each model allowable calibration range when selecting a calibration standard.
It is best to select a standard close to the test solution value.
This Instruction Manual is also available for download on our Web-site: eutechinst.com or 4oakton.com
ModelModel
ModelModel
Model ECTECT
ECTECT
ECTestrestr
estrestr
estrlolo
lolo
loww
ww
wECTECT
ECTECT
ECTestrestr
estrestr
estrlolo
lolo
low+w+
w+w+
w+ ECTECT
ECTECT
ECTestrhighestrhigh
estrhighestrhigh
estrhigh ECTECT
ECTECT
ECTestrhigh+estrhigh+
estrhigh+estrhigh+
estrhigh+ ECTECT
ECTECT
ECTestrestr
estrestr
estrpurpur
purpur
pure+e+
e+e+
e+
Calibration 200 to 1990 200 to 1999 2.00 to 19.90 2.00 to 19.99 20.0 to 199.9
Standard Range uS/cm uS/cm mS/cm mS/cm uS/cm
ModelModel
ModelModel
Model TDSTTDST
TDSTTDST
TDSTestrestr
estrestr
estrlolo
lolo
loww
ww
wTDSTTDST
TDSTTDST
TDSTestrestr
estrestr
estrlolo
lolo
low+w+
w+w+
w+ TDSTTDST
TDSTTDST
TDSTestrhighestrhigh
estrhighestrhigh
estrhigh TDSTTDST
TDSTTDST
TDSTestrhigh+estrhigh+
estrhigh+estrhigh+
estrhigh+ TDSTTDST
TDSTTDST
TDSTestrestr
estrestr
estrpurpur
purpur
pure+e+
e+e+
e+ SALSAL
SALSAL
SALTT
TT
Testrestr
estrestr
estr
Calibration 200 to 200 to 1.00 to 1.00 to 20.0 to 1.00 to
Standard Range 1990 ppm 1999 ppm 10.00 ppt 10.00 ppt 199.9 ppm 10.00 ppt
Measurement
1. Press the ON/OFF button to switch the tester on.
2. Dip the electrode into the test solution making sure that it is fully immersed. Stir to clear any
trapped air bubbles from the electrode and let the reading stabilize. For plus models, you
can opt for the cup style measurement by filling the electrode cup with sample of test solution.
3. Note the value or press HOLD button to freeze the reading. To release the reading, press HOLD
again.
4. Press ON/OFF to turn off tester. If you do not press a button for 8.5 minutes, the tester will
automatically shut off to conserve batteries.
Figure 2: Example of a Power Up Sequence
Figure 3: Example of HOLD Function
Temperature Mode Selection (Only for PLUS Models)
This feature lets you select either the Celsius (°C) or the Fahrenheit (°F) temperature mode
display.
From the measurement mode,
1. Press °C/°F button to select the desired temperature mode. The temperature
display will toggle between the Celsius reading and the Fahrenheit reading.
Figure 4: Example of a temperature mode selection
1. Organise your calibration standard solution in two beakers – one for rinsing and
the other for calibration. Prepare separate de-ionized water for electrode rinsing.
2. Twist off and open the battery compartment lid (the cap with the lanyard loop).
You will see two switches – the INC (increment) and DEC (decrement) keys.
3. Switch on the unit using the ON/OFF key.
4. Rinse the electrode in de-ionized water and then rinse with the calibration
standard.
5. Dip the electrode to the calibration standard intended for calibration
and swirl gently to create a homogenous sample. Wait for the reading
to stabilize.
6. Press the INC or DEC key to enter calibration mode and to adjust the
reading to the calibration standard value. The upper display will be the
adjustable reading for calibration whereas the lower display will be the
default reading of the standard.
Note: At this point, the non-plus models will have its upper and lower display showing readings
with resolution of its plus version. Reading adjustment can then be made from its last significant
digit. Upon confirming the calibration, the reading changes back to its original resolution.
7. Wait for 5 seconds for the tester to automatically confirm the calibration value by displaying
“CO” and return to the measurement mode.
8. Replace the battery compartment lid. The tester is now ready for measurement.
Note: To exit this program without confirming the calibration, press the HOLD button before the
automatic confirmation takes place.
Note: The tester will exit calibration mode with “Er.0” message if the temperature is outside the
0 to 50°C range. Please refer to information under ’Self Diagnostic Messages’.
Note: The calibration window is +/- 50% from the default reading of the standard.
HOLD Function
This feature lets you freeze the display for a delayed observation.
1. Press HOLD button to freeze the measurement. A ‘HOLD’ indicator will be displayed and the
measurement will be frozen.
2. Press HOLD again to release the measurement. The ‘HOLD’ indicator will not be displayed
anymore indicating the held measurement is released.
Figure 1: Example of a calibration sequence using 2764 µS calibration standard
Table 1
+
-
INC Key
TDS Factor Setting (Only for TDS Models)
The TDS models features includes the setting of the TDS factor. You can adjust the TDS factor from 0.4
to 1.0.
From the measurement mode,
1. Press HOLD button to bring the tester to the HOLD mode.
2. Press either the INC or DEC key to enter the TDS Factor Setting mode. The upper display will
be the adjustable TDS factor whereas the lower display will be the last TDS Factor setting.
3. Use the INC or DEC key to set the correct TDS factor for your sample measurement.
4. Wait for 5 seconds for the tester to automatically confirm the new setting by displaying “CO”
and return to the measurement mode.
Figure 5: Example of setting the TDS Factor
Electrode Maintenance
1. Always keep the sensor electrodes clean. Rinse the electrodes with de-ionized water and
wipe them dry with clean cloth before storing with its protective cap. For the plus models,
remove the white plastic cup insert to thoroughly clean viscous solutions. Never scratch
the electrodes with a hard substance.
2. For better performance, soak the electrode in alcohol for 10 to 15 minutes and rinse with
de-ionized water before starting any measurement process. This is to remove dirt and oil
stains on the electrode which may affect the accuracy of the measurements.
After5 sec,
“CO” is
displayed
signifying
automatic
confirmation
INC
DEC
INC
DEC
After5 sec,
“CO” is
displayed
signifying
automatic
confirmation
INC
DEC
INC
DEC
ON/OFF

68X068050 09/04 Rev 0
+
-
INC Key
3 Bars indicates Battery is full (100%)
2 Bars indicates 50% of the battery life is left
1 Bar indicates 25% of the battery life is left
Blinking battery casing indicates the need to replace
batteries with fresh ones as specified by manufacturer
The sensor electrodes have short circuited.
Replacement sensor is not connected properly to the
tester during sensor replacement
Measured value or temperature value (for plus models)
exceeds its specified maximum or minimum value
Blinking ‘ATC’, ‘Or’ or ‘Ur’ indicates that there is a short
or open circuit at the built in temperature sensor
Calibration error due to temperature value not within the
specified range
Calibration error due to Conductivity/TDS/Salt value not
within the specified calibration standard range
Self-Diagnostic Messages
ErEr
ErEr
Er.1.1
.1.1
.1
Low battery
indicator
Or / UrOr / Ur
Or / UrOr / Ur
Or / Ur
(Still)
Over range /
Under range
signal
ATC / Or /ATC / Or /
ATC / Or /ATC / Or /
ATC / Or /
UrUr
UrUr
Ur (Blinking)
ErEr
ErEr
Er.0.0
.0.0
.0
Error
Message
Electrode Replacement
You can replace the electrode module at the fraction of the cost of a new tester. When the tester fails
to calibrate or gives fluctuating readings in calibration standards, you need to change the electrode.
1. With dry hands, grip the ribbed tester collar with electrode facing you. Twist the collar counter
clockwise (see picture A). Save the ribbed tester collar and O-ring for later use.
2. Pull the old electrode module away from the tester.
3. Align the four tabs on the new module so that they match the four slots on the tester (see
picture B).
4. Gently push the module onto the slots to sit it in position. Push the smaller O-ring fully onto
the new electrode module. Push the collar over the module and thread it into place by firmly
twisting clockwise.
Note: It is necessary that you recalibrate your tester prior to measurement after an electrode
replacement.
Figure 7: Removal of collar from tester
Applications
Water quality testing • pools • aquaculture • hydroponics • ecology studies • water and
wastewater treatment • boilers • labs and more!
Accessories
Item Eutech Instruments Order Code Oakton Instruments Order Code
ECTESTR, TDSTESTR & SALTESTR ECTDSWPSENNEW OKTDSWPSENNEW
replacement sensor
ECTESTR+ & TDSTESTR+ ECTDSWPSENPLUS OKTDSWPSENPLUS
replacement sensor
Warranty
These waterproof Conductivity/TDS/Salt tester series - ECTestr, TDSTestr and SALTTestr are
warranted to be free from manufacturing defects for 2 years and electrode module for 6 months.
If repair, adjustment or replacement is necessary and has not been the result of abuse or misuse
within the time period, please return the tester – freight prepaid – and correction will be made
without charge. Out of warranty products will be repaired on a charge basis.
Return of Items
Authorization must be obtained from your distributor before returning items for any reason.
When applying for authorization, please include information regarding the reason the item(s) are
to be returned.
Note: We reserve the right to make improvements in design, construction and appearance of
products without notice. Prices are subject to change without notice.
Large ScreenLarge Screen
Large ScreenLarge Screen
Large Screen ECTestrlowECTestrlow
ECTestrlowECTestrlow
ECTestrlow ECTestrlow+ECTestrlow+
ECTestrlow+ECTestrlow+
ECTestrlow+ ECTestrhighECTestrhigh
ECTestrhighECTestrhigh
ECTestrhigh ECTestrhigh+ECTestrhigh+
ECTestrhigh+ECTestrhigh+
ECTestrhigh+ ECTestrpure+ECTestrpure+
ECTestrpure+ECTestrpure+
ECTestrpure+
EC TesterEC Tester
EC TesterEC Tester
EC Tester
Range 0 to 1990 uS/cm 0 to 1999 uS/cm 0 to 19.90 mS/cm 0 to 19.99 mS/cm 0 to 199.9 uS/cm
Resolution 10 uS/cm 1 uS/cm 0.10 mS/cm 0.01 mS/cm 0.1 uS/cm
Accuracy +/- 1% FS
Calibration point 1 point (± 50% window from factory default)
Calibration 200 to 1990 200 to 1999 2.00 to 19.90 2.00 to 19.99 20.0 to 199.9
Standard Range uS/cm uS/cm mS/cm mS/cm uS/cm
Temperature
NA
Yes
NA
Yes
Range in °C 0.0 to 50.0°C 0.0 to 50.0°C
Range in °F 32.0 to 122°F 32.0 to 122°F
Resolution 0.1°C (0.1°F) 0.1°C (0.1°F)
Accuracy ±0.5°C (±0.9°F) ±0.5°C (±0.9°F)
Calibration point 1 point 1 point
Calibration Window ± 5°C (± 9°F) ± 5°C (± 9°F)
from factory default from factory default
ATC 0 to 50°C
Temp Coefficient 2% per °C
Normalization Temp 25.0°C
Auto Off 8.5 minutes after last key press
Operating Temp 0 to 50°C
Power Battery 4 X 1.5V”A76" micro alkaline battery
Battery Life >150 hrs
LCD Display Custom Dual Display27mm(H)X21mm(W)
Dimensions Tester: 16.5 cm X 3.8 cm; 90g
Weight Boxed: 22cm X 6cmX 5cm; 170 g
ECTestr Specifications
TDSTestr Specifications
Large ScreenLarge Screen
Large ScreenLarge Screen
Large Screen TDSTestrlowTDSTestrlow
TDSTestrlowTDSTestrlow
TDSTestrlow TDSTestrlow+TDSTestrlow+
TDSTestrlow+TDSTestrlow+
TDSTestrlow+ TDSTestrhighTDSTestrhigh
TDSTestrhighTDSTestrhigh
TDSTestrhigh TDSTestrhigh+TDSTestrhigh+
TDSTestrhigh+TDSTestrhigh+
TDSTestrhigh+ TDSTestrpure+TDSTestrpure+
TDSTestrpure+TDSTestrpure+
TDSTestrpure+
TDS TesterTDS Tester
TDS TesterTDS Tester
TDS Tester
Range 0 to 1990 ppm 0 to 1999 ppm 0 to 10.00 ppt 0 to 10.00 ppt 0 to 199.9 ppm
Resolution 10 ppm 1 ppm 0.10 ppt 0.01 ppt 0.1ppm
Accuracy +/- 1% FS
TDS Factor 0.4 to 1.0
Calibration point 1 point (± 50% window from factory default)
Calibration 200 to 1990 200 to 1999 1.00 to 10.00 ppt 20.0 to 199.9
Standard Range ppm ppm ppm
Temperature NA Yes NA Yes
Range in °C 0.0 to 50.0 °C 0.0 to 50.0 °C
Range in °F 32.0 to 122 °F 32.0 to 122 °F
Resolution 0.1 °C (0.1°F) 0.1 °C (0.1°F)
Accuracy ±0.5 °C (±0.9 °F) ±0.5 °C (±0.9 °F)
Calibration point 1 point 1 point
Calibration Window ± 5°C (± 9°F) ± 5°C (± 9°F)
from factory default from factory default
ATC 0 to 50°C
Temp Coefficient 2% per °C
Normalization Temp 25.0°C
Operating Temp 0 to 50°C
PowerBattery 4 X 1.5V”A76" micro alkaline battery
Battery Life >150 hrs
LCD Display Custom Dual Display27mm(H)X21mm(W)
Dimensions Tester: 16.5 cm X 3.8 cm; 90g
Weight Boxed: 22cm X 6cmX 5cm; 170 g
SALTTestr Specifications
Large Screen TDS Tester SALTTESTR
Range 0 to 10.00 ppt
Resolution 0.10 ppt
Accuracy +/- 1% FS
Calibration point 1 point (± 50% window from factory default)
Calibration Standard Range 1.00 to 10.00 ppt
ATC 0 to 50°C
Temperature Coefficient 2% per °C
Normalization Temperature 25.0°C
Operating Temperature 0 to 50°C
Power Battery 4 X 1.5V”A76" micro alkaline battery
Battery Life >150 hrs
LCD Display Custom Dual Display27mm(H)X21mm(W)
Dimensions Tester: 16.5cm X 3.8cm; 90g
Weight Boxed: 22cm X 6cm X 5cm; 170g
Temperature Calibration (Only for PLUS Models)
Temperature calibration need not be performed every time, unless the temperature reading differs
from that of an accurate thermometer. If temperature calibration is performed, Conductivity/TDS/Salt
calibration is mandatory.
From the measurement mode,
1. Press the °C/°F button to select the desired temperature mode (Celsius or Fahrenheit).
2. Dip the tester into a solution of known temperature and allow time for the in built temperature
sensor to stabilize.
3. Press either the INC or DEC key to bring the tester to the calibration mode.
Note: At this stage, if the Conductivity/TDS/Salt reading is outside the specified range (showing Or
or Ur), the tester will show an error message of “Er.1”. You can still proceed with the temperature
calibration by continuing with step 4 or if the °C/°F button is not pressed within 2 seconds, the tester
will exit the calibration mode and return to the measurement mode.
4. Immediately press the °C/°F button to switch to the temperature calibration mode. The upper
display shows the current measured temperature reading based on the last set offset and the
lower display shows the current measured temperature reading based on factory default calibration.
5. Use the INC and DEC key to adjust the upper temperature reading to the known temperature value.
6. Wait for 5 seconds for the tester to automatically confirm the temperature calibration value by
displaying “CO” and return to the measurement mode.
Note: To exit this program without confirming the calibration, press the °C/°F button or the HOLD
button before the automatic confirmation takes place.
Note: The tester will exit calibration mode with “Er.0” message if the temperature is outside the 0 to
50°C range. Please refer to information under ’Self Diagnostic Messages’.
Notes: The temperature calibration window is +/- 5°C (+/- 9°F) from the default temperature reading.
Figure 6: Example of a temperature calibration sequence
Changing Batteries
1. Open the battery compartment lid (with attached lanyard loop).
2. Remove old batteries; replace with fresh ones. Note polarity
(shown in diagram below).
INC
DEC
INC
DEC
After5 sec,
“CO” is
displayed
signifying
automatic
confirmation
Roatecollar
awayfrom you
Ribbedcollar
LargeO-Ring
ElectrodeModule
SmallO-Ring SmallTab Large Tab
InsertElectrode Module
