EUTECH INSTRUMENTS HIGHLOW TDS TESTER User manual

+
+
INC
DEC
•Waterproof & Floats
•ReplaceableElectrode
•Auto-off
•AutomaticTemperature
Compensation(ATC)
Diagram 1
Open this leaflet for calibration/testing/maintenance
instructions.
Changing Batteries
1. Open battery
compartment
lid (with
attached
lanyard loop).
2. Remove old
batteries;
replace
with fresh
ones. Note
polarity as
shown in battery compartment. See Diagram 1.
3. Recalibrate after battery change.
Warranty
Eutech Instruments warrants its meter free from
manufacturing defects for 2 years and electrode
module for 6 months. If repair, adjustment or
replacement is necessary and has not been the result
of abuse or misuse within the time period, please
return the tester – freight prepaid – and correction
will be made without charge. Out of warranty products
will be repaired on a charge basis.
Return Of Items
Authorization must be obtained from Eutech’s
distributor before returning items for any reason.
When applying for authorization, please include
information regarding the reason the item(s) are to
be returned.
Note: We reserve the right to make improvements in
design, construction and appearance of products
without notice. Prices are subject to change without
notice.

Waterproof ECScan High Instructions
Before You Begin
Remove electrode cap. Soak electrode for a few
minutes in alcohol to remove oils.
Calibration
Tester is factory calibrated. However, to ensure
accuracy, calibrate conductivity on a regular basis.
Select a calibration standard appropriate for the
ECScan High tester (between 2.00 mS and
19.90 mS). It is best to select a standard close
to the test solution value.
1. Open battery compartment lid (end with
lanyard loop).
2. Orientate the battery compartment as
shown in Diagram 1.
3. Rinse electrode in deionized water, then
rinse it in calibration standard, then dip it
into a container of calibration standard.
4. Switch unit on (ON/OFF key). Wait
several minutes for display to stabilize.
5. Press the INC or DEC key to adjust
reading to match the calibration
standard value.
6. After 3 seconds without a key press,
the display flashes 3 times, then
shows ‘ENT’. The tester accepts
calibration value; returns to
measurement mode.
7. Replace battery cap.
Conductivity Testing
1. Remove electrode cap. Switch unit on (ON/OFF
key).
2. Dip electrode into test solution. Make sure sensor
is fully covered.
3. Wait for reading to stabilize (Automatic
Temperature Compensation corrects for
temperature changes). Note reading.
4. Press ON/OFF to turn off tester. Replace electrode
cap. Note: Tester automatically shuts off after
8.5 minutes of non-use.
HOLD Function
Press HOLD key to freeze display. Press HOLD again
to release.
Tester Maintenance
• To improve performance, clean the electrode
by rinsing them in alcohol for 10 to 15 minutes.
• Replace all batteries if low battery indicator
appears, or if readings are faint or unstable.
• If you experience drift, periodically let electrode
fully dry.
When you need a new electrode, see “Electrode
Replacement” on insert in back of box.
Self-Diagnostic Messages
bAt Weak batteries–replace with fresh ones specified
by manufacturer.
Err Wrong keypress.
Or,Ur Over range/Under range signal, or electrode
is not in contact with solution, or electrode is failing.
---- Calibration mode activated but not performed.
68X247755 11/00 Rev 0

+
+
•Waterproof & Floats
•ReplaceableElectrode
•Auto-off
•AutomaticTemperature
Compensation(ATC)
INC
DEC
Diagram 1
Open this leaflet for calibration/testing/maintenance
instructions.
Changing Batteries
1. Open battery
compartment
lid (with
attached
lanyard loop).
2. Remove old
batteries;
replace with
fresh ones.
Note polarity
as shown in
battery compartment. See Diagram 1.
3. Recalibrate after battery change.
Warranty
Eutech Instruments warrants its meter free from
manufacturing defects for 2 years and electrode
module for 6 months. If repair, adjustment or
replacement is necessary and has not been the result
of abuse or misuse within the time period, please
return the tester – freight prepaid – and correction
will be made without charge. Out of warranty products
will be repaired on a charge basis.
Return Of Items
Authorization must be obtained from Eutech’s
distributor before returning items for any reason.
When applying for authorization, please include
information regarding the reason the item(s) are to
be returned.
Note: We reserve the right to make improvements in
design, construction and appearance of products
without notice. Prices are subject to change without
notice.

Waterproof ECScan Low Instructions
68X247754 11/00 Rev 0
Conductivity Testing
1. Remove electrode cap. Switch unit on (ON/OFF
key).
2. Dip electrode into test solution. Make sure
sensor is fully covered.
3. Wait for reading to stabilize (Automatic
Temperature Compensation corrects for
temperature changes). Note reading.
4. Press ON/OFF to turn off tester. Replace
electrode cap. Note: Tester automatically
shuts off after 8.5 minutes of non-use.
HOLD Function
Press HOLD key to freeze display. Press HOLD again
to release.
Tester Maintenance
•To improve performance, clean the electrode
by rinsing them in alcohol for 10 to 15 minutes.
• Replace all batteries if low battery indicator
appears, or if readings are faint or unstable.
• If you experience drift, periodically let electrode
fully dry.
When you need a new electrode, see “Electrode
Replacement” on insert in back of box.
Self-Diagnostic Messages
bAt Weak batteries–replace with fresh ones
specified by manufacturer.
Err Wrong keypress.
Or,Ur Over range/Under range signal, or electrode
is not in contact with solution, or electrode is failing.
---- Calibration mode activated but not performed.
Before You Begin
Remove electrode cap. Soak electrode for a few
minutes in alcohol to remove oils.
Calibration
Tester is factory calibrated. However, to ensure
accuracy, calibrate conductivity on a regular basis.
Select a calibration standard appropriate for the
ECScan Low tester (between 200 µS and
1990 µS). It is best to select a standard close
to the test solution value.
1. Open battery compartment lid (end with
lanyard loop).
2. Orientate the battery compartment as
shown in Diagram 1.
3. Rinse electrode in deionized water, then
rinse it in calibration standard, then dip it
into a container of calibration standard.
4. Switch unit on (ON/OFF key). Wait
several minutes for display to stabilize.
5. Press the INC or DEC key to adjust
reading to match the calibration
standard value.
6. After 3 seconds without a key
press, the display flashes 3 times,
then shows ‘ENT’. The tester accepts
calibration value; returns to
measurement mode.
7. Replace battery cap.

+
+
INC
DEC
•Waterproof & Floats
•ReplaceableElectrode
•Auto-off
•AdjustableTDS Factor
• AutomaticTemperature
Compensation(ATC)
Diagram 1
Open this leaflet for calibration/testing/maintenance
instructions.
Changing Batteries
1. Open battery
compartment
lid (with
attached
lanyard loop).
2. Remove old
batteries;
replace with
fresh ones.
Note polarity
as shown
in battery
compartment. See Diagram 1.
3. Recalibrate after battery change.
Tester Maintenance
• To improve performance, clean the electrode
by rinsing them in alcohol for 10 to 15 minutes.
• Replace all batteries if low battery indicator
appears, or if readings are faint or unstable.
• If you experience drift, periodically let electrode
fully dry.
When you need a new electrode, see “Electrode
Replacement” on insert in back of box.
Warranty
Eutech Instruments warrants its meter free from
manufacturing defects for 2 years and electrode
module for 6 months. If repair, adjustment or
replacement is necessary and has not been the result
of abuse or misuse within the time period, please
return the tester – freight prepaid – and correction
will be made without charge. Out of warranty products
will be repaired on a charge basis.
Return Of Items
Authorization must be obtained from Eutech’s
distributor before returning items for any reason.
When applying for authorization, please include
information regarding the reason the item(s) are to
be returned.
Note: We reserve the right to make improvements in
design, construction and appearance of products
without notice. Prices are subject to change without
notice.

68X247753 11/00 Rev 0
WP TDScan High Instructions
Before You Begin
Remove electrode cap. Soak electrode for a few
minutes in alcohol to remove oils.
Calibration
Tester is factory calibrated. However, to ensure
accuracy, calibrate TDS on a regular basis.
Select a calibration standard appropriate for the
TDScan High tester (between 2.00 ppt and
10.00 ppt). It is best to select a standard close
to the test solution value.
1. Open battery compartment lid (end with
lanyard loop).
2. Orientate the battery compartment as
shown in Diagram 1.
3. Rinse electrode in deionized water, then
rinse it in calibration standard, then dip it
into a container of calibration standard.
4. Switch unit on (ON/OFF key). Wait
several minutes for display to stabilize.
5. Press the INC or DEC keys to adjust
reading to match the calibration
standard value.
6. After 3 seconds without a key press,
the display flashes 3 times, then shows
‘ENT’. The tester accepts calibration
value; returns to measurement mode.
7. Replace battery cap.
TDS Testing
1. Remove electrode cap. Switch unit on (ON/OFF
key).
2. Dip electrode into test solution. Make sure sensor
is fully covered.
3. Wait for reading to stabilize (Automatic
Temperature Compensation corrects for
temperature changes). Note reading.
4. Press ON/OFF to turn off tester. Replace electrode
cap. Note: Tester automatically shuts off after
8.5 minutes of non-use.
HOLD Function
Press HOLD key to freeze display. Press HOLD
again to release.
Setting TDS Factor
This tester lets you select a TDS factor of 0.4 to 1.0.
1. Open battery compartment. With meter on,
press the HOLD key, then press the INC key
See Diagram 1.
2. Press the INC or DEC key to adjust the TDS factor.
3. After 3 seconds without a key press, the display
flashes 3 times, then shows ‘ENT’. Tester accepts
TDS factor and returns to measurement mode.
4. Replace battery cap.
Self-Diagnostic Messages
bAt Weak batteries–replace with fresh ones
specified by manufacturer.
Err Wrong keypress.
Or,Ur Over range/Under range signal, or electrode
is not in contact with solution, or electrode is failing.
---- Calibration mode activated but not performed.

+
+
INC
DEC
•Waterproof & Floats
•ReplaceableElectrode
•Auto-off
•AdjustableTDS Factor
• AutomaticTemperature
Compensation(ATC)
Diagram 1
Open this leaflet for calibration/testing/maintenance
instructions.
Changing Batteries
1. Open battery
compartment
lid(with
attached
lanyard loop).
2. Remove old
batteries;
replace with
fresh ones.
Note polarity
as shown
in battery
compartment. See Diagram 1.
3. Recalibrate after battery change.
Tester Maintenance
• To improve performance, clean the electrodes
by rinsing them in alcohol for 10 to 15 minutes.
• Replace all batteries if low battery indicator
appears, or if readings are faint or unstable.
• If you experience drift, periodically let electrode
fully dry.
When you need a new electrode, see “Electrode
Replacement” on insert in back of box.
Warranty
Eutech Instruments warrants its meter free from
manufacturing defects for 2 years and electrode
module for 6 months. If repair, adjustment or
replacement is necessary and has not been the result
of abuse or misuse within the time period, please
return the tester – freight prepaid – and correction
will be made without charge. Out of warranty products
will be repaired on a charge basis.
Return Of Items
Authorization must be obtained from Eutech’s
distributor before returning items for any reason.
When applying for authorization, please include
information regarding the reason the item(s) are to
be returned.
Note: We reserve the right to make improvements in
design, construction and appearance of products
without notice. Prices are subject to change without
notice.

68X247752 11/00 Rev 0
TDS Testing
1. Remove electrode cap. Switch unit on (ON/OFF
key).
2. Dip electrode into test solution. Make sure sensor
is fully covered.
3. Wait for reading to stabilize (Automatic
Temperature Compensation corrects for
temperature changes). Note reading.
4. Press ON/OFF to turn off tester. Replace electrode
cap. Note: Tester automatically shuts off after
8.5 minutes of non-use.
HOLD Function
Press HOLD key to freeze display. Press HOLD again
to release.
Setting TDS Factor
This tester lets you select a TDS factor of 0.4 to 1.0.
1. Open battery compartment. With meter on,
press the HOLD key, the press the INC key
See Diagram 1.
2. Press the INC or DEC key to adjust the TDS factor.
3. After 3 seconds without a key press, the display
flashes 3 times, then shows ‘ENT’. Tester accepts
TDS factor and returns to measurement mode.
4. Replace battery cap.
Self-Diagnostic Messages
bAt Weak batteries–replace with fresh ones specified
by manufacturer.
Err Wrong keypress.
Or,Ur Over range/Under range signal, or electrode
is not in contact with solution, or electrode is failing.
---- Calibration mode activated but not performed.
Before You Begin
Remove electrode cap. Soak electrode for a few
minutes in alcohol to remove oils.
Calibration
Tester is factory calibrated. However, to ensure
accuracy, calibrate TDS on a regular basis.
Select a calibration standard appropriate for the
TDScan Low tester (between 200 ppm and
1990 ppm). It is best to select a standard
close to the test solution value.
1. Open battery compartment lid (end with
lanyard loop).
2. Orientate the battery compartment as
shown in Diagram 1.
3. Rinse electrode in deionized water, then
rinse it in calibration standard, then dip it
into a container of calibration standard.
4. Switch unit on (ON/OFF key). Wait
several minutes for display to stabilize.
5. Press the INC or DEC keys to adjust
reading to match the calibration
standard value.
6. After 3 seconds without a key
press, the display flashes 3 times,
then shows ‘ENT’. The tester accepts
calibration value; returns to
measurement mode.
7. Replace battery cap.
WP TDScan Low Instructions

A
B
REMOVE THE OLD ELECTRODE
REPLACE THE ELECTRODE
(Picture B)
(Picture A)
Electrode Replacement
You can replace the electrode module at
the fraction of the cost of a new tester.
When the tester fails to calibrate or gives
fluctuating readings in calibration
standards, you need to change the
electrode.
1. With dry hands, grip the ribbed tester
collar with electrode facing you. Twist the
collar counter clockwise (see picture A).
Save the ribbed tester collar and O-ring
for later use.
2. Pull the old electrode module away from
the tester.
3. Align the four tabs on the new module
so that they match the four slots on the
tester (see picture B).
4. Gently push the module onto the slots
to sit it in position. Push the smaller O-
ring fully onto the new electrode module.
Push the collar over the module and thread
it into place by firmly twisting clockwise.
Water quality testing • water and
Wastewater treatment • hydroponics
• labs • boilers • factories
• ecology studies • and more!
Applications
Tester TDScan TDScan ECScan ECScan
Low High Low High
Range 0 to 0 to 0 to 0 to
1990 10.00 1990 19.90
ppm ppt µS/cm mS/cm
Resolution 10 0.10 10 0.10
ppm ppt µS/cm mS/cm
Accuracy ±1% Full Scale
TDS factor 0.4 to 1.0 selectable -
Calibration 200 to 2 .00 to 200 to 2.00 to
Standard 1990 10.00 1990 19.90
Range ppm ppt µS/cm mS/cm
Calibration 1 point (calibration range is ±30%
of factory default parameter)
ATC 0 to 50 °C
Temp 2% per °C
Coefficient
Operating 0 to 50 °C
Temp
Power Four X 1.5V
Battery (Type: A76, LR 44 or V136A);
> 140 hrs continuous use
Dimension; Tester: 16.5 cm x 3.8 cm; 90 g
Weight Boxed: 22 cm x6 cm x 5 cm; 170 g
•Push-button calibration
•Fast, stable, repeatable readings
•Available through authorized distributors
SPECIFICATIONS
Lanyard
connection
Replaceable
Sensor
Twist-off
Battery
Compartment
Manufactured By:
Eutech Instruments Pte Ltd
Blk 55, Ayer Rajah Crescent,
#04-14/24, Singapore 139949
Tel: [phone] Fax: [phone]
E-Mail: [email protected]
Web-Site: http://www.eutechinst.com
Made in Singapore
68X247828 11/00 Rev 0
