EVA Logik ZW313 User manual

Federal Communications Commission (FCC) Statement
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may caus harmful interference to radio communications.However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.Increase the separation between the equipment and
receiver.Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.Consult the dealer or an experienced radio/TV technician for help.This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
IC Caution:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause undesired
operation of the device.
DECLARATION DE CONFORMITE D'INDUSTRIE CANADA
Ce périphérique a été testé et reconnu conforme aux limites spécifiées dans RSS-210.
Son utilisation est soumise aux deux conditions suivantes :
(1) il ne doit pas provoquer d'interférences gênantes et
(2) il doit tolérer les interférences re.ues, notamment cellessusceptibles d'en perturber le fonctionnement.
ZW313 Paddle Dimmer Switch Manual
ZW313 Paddle Dimmer Switch
WARRANTY
Show Home Products warrants this product to be free from manufacturing defects for
a period of two years from the original date of consumer purchase. This warranty is limited
to the repair or replacement of this product only and does not extend to consequential or
incidental damage to other products that may be used with this product.
This warranty is in lieu of all other warranties, expressed or implied. Some states do not
allow limitations on how long an implied warranty lasts or permit the exclusion or limitation
of incidental or consequential damage, so the above limitations may not apply to you.
This warranty gives you specific rights, and you may also have other rights which vary from
state to state. if the unit should prove defective within the warranty period.
SPECIFICATIONS WARNING
Model:ZW313
RISK OF FIRE
Power: 120 VAC, 60 Hz.
RISK OF ELECTRICAL SHOCK
Signal (Frequency): 908.42 MHZ.
RISK OF BURNS
Maximum Loads: 300W, 2-gang 200W or 3-gang
CONTROLLING APPLIANCES:
300W incandescent, 100W CFL/LED
EXERCISE EXTREME CAUTION WHEN USING Z-WAVE DEVICES TO CONTROL
APPLIANCES. OPERATION OF THE Z-WAVE DEVICE MAY BE IN A DIFFERENT
Range: Up to 100 feet line of sight between the Wireless Controller
ROOM THAN THE CONTROLLED APPLIANCE, ALSO ANUNINTENTIONAL ACTIVATION
and the closest Z-Wave receiver module.
MAY OCCUR IF THE WRONG BUTTON ON THE REMOTE IS PRESSED. Z-WAVE DEVICES
Operating Temperature Range: 32-104° F (0-40° C)
MAY AUTOMATICALLY BE POWERED ON DUE TO TIMED EVENT PROGRAMMING.
For Ourdoor use
DEPENDING UPON THE APPLIANCE, THESE UNATTENDED OR UNINTENTIONAL
Specifications subject to change without notice
OPERATIONS COULD POSSIBLY RESULT IN A HAZARDOUS CONDITION. FOR THESE
due to continuing product improvement
REASONS, WE RECOMMEND DO NOT RETURN THIS PRODUCT TO THE STORE
THE FOLLOWING:
Website:www.ishowlights.com
DO NOT USE Z-WAVE DEVICES TO CONTROL ELECTRIC
HEATERS OR ANY OTHER APPLIANCES WHICH MAY PRESENT
A HAZARDOUS CONDITION DUE TO UNATTENDED OR
UNINTENTIONAL OR AUTOMATIC POWER ON CONTROL.

Introduction:
The ZW313
is a Z-Wave enabled device and is fully compatible with any Z-Wave Plus enabled network.
around obstacles and radio dead spots to ensure that the signal is received at its intended destination.
ZW313 is a security enabled Z-Wave plus device. A security Enabled Z-Wave Plus Controller must be used in order to fully utilize the product.
Key Features:
---Remote ON/OFF control via the Z-Wave controller
---Manual ON/OFF control with the front panel push button
---Support Association Group and Auto Report switch status
---Support firmware upgrades via Over-the-air (need Gateways support)
Product Overview:
A. Up Push button
B. Down Push button
C. Load1 (Black)
D. Lin (Black) - Line in
E. Nin (White) - Nutral in
F. Load2 (Black)
ZW313 Installation Wiring Diagram
Key function description
Function 1: Press the up or down button to turn the output ON or OFF
Function 2
:
Hold Dimmer Up or Dimmer Down
Each module is designed to act as a repeater,which will re-transmit a radio frequency (RF) signal by routing the signal
A
B
F
Function 2
:
Hold Dimmer Up or Dimmer Down
Function
3
: Press the up or down button three times quickly to ADD and REMOVE
Function 4: Press the up or down button six times quickly to change Status LED Configuration
Function 5: When switch is off and quickly press UPPER paddle 2 times, switch turns on to 100% brightness
Function 6
: Press and hold the up or down button for 10 seconds to restore the device to the factory
L
ed Indicate Function
1:Flash three times
When configuration parameter succeed LED flash three times
2:quickly flash
When inclusion or exclusion or reset, LED will quickly flash till operate complete
Z-Wave Remote Control
ADD or Remove the ZW313 from the existing Z-Wave home control network with your primary controller.
---Refer to your primary controller instructions to process the inclusion / exclusion setup procedure.
Include ZW313 to/from a Z-Wave Gateway with supporting Security.The ZW313 can support the Primary Controller that implemented the security S2.
Notice: Including a node ID allocated by Z-WaveTM Controller means “Add” or “Inclusion”. Excluding a node ID allocated by
Z-WaveTM Controller means “Remove” or “Exclusion”.
z-wave protocol Command Class Node Info
COMMAND_CLASS_ZWAVEPLUS_INFO,
COMMAND_CLASS_SWITCH_MULTILEVEL,
COMMAND_CLASS_CONFIGURATION,
COMMAND_CLASS_ASSOCIATION,
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V2,
COMMAND_CLASS_ASSOCIATION_GRP_INFO,
COMMAND_CLASS_TRANSPORT_SERVICE_V2,
COMMAND_CLASS_VERSION,
COMMAND_CLASS_MANUFACTURER_SPECIFIC,
COMMAND_CLASS_DEVICE_RESET_LOCALLY,
COMMAND_CLASS_POWERLEVEL,
COMMAND_CLASS_SECURITY_2,
COMMAND_CLASS_SUPERVISION,
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
---When prompted by your primary controller, click the Up or Down button three times in one second.

The Below listed Command Class are all supported the Security S2
COMMAND_CLASS_VERSION,
COMMAND_CLASS_SWITCH_MULTILEVEL,
COMMAND_CLASS_CONFIGURATION,
COMMAND_CLASS_ASSOCIATION,
COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION_V2,
COMMAND_CLASS_ASSOCIATION_GRP_INFO,
COMMAND_CLASS_MANUFACTURER_SPECIFIC,
COMMAND_CLASS_DEVICE_RESET_LOCALLY,
COMMAND_CLASS_POWERLEVEL,
COMMAND_CLASS_SUPERVISION,
COMMAND_CLASS_FIRMWARE_UPDATE_MD_V2
Z-Wave Configuration Parameters
1:
Locally Button function
Paramter No: 1(0x01) Size:1 Byte Value: 00(default) Up Button ON,Down Button OFF
Value: 01 Up Button OFF,Down Button ON
2：
Status LED Configuration
Paramter No: 2(0x02) Size:1 Byte Value: 00(default) Output ON,Led OFF.
Value: 01 OutputOFF,Led ON.
Value: 02 Always OFF
Value: 03 Always ON
3
：
Enable
Auto Turn-OFF Timer
Parameter=3，Size=1，Value=0 Auto Turn-OFF Timer
Disabled (default);
Value=1 Auto Turn-OFF Timer
Enabled
4：
Count Down Configuration(Turn off the output by time
）
Paramter No: 4(0x04) Size:2 Byte Value: xx xx Turn off Output
Value Scope :0----65535Minutes (default:00 00 no timer)
5
：
Enable
Auto Turn-ON Timer
Parameter=5，Size=1，Value=0 Auto Turn-ON Timer
Disabled (default);
Value=1 Auto Turn-ON Timer
Enabled
6：
Count Down Configuration(Turn ON the output by time
）
Paramter No: 6(0x06) Size:2 Byte Value: xx xx Turn ON Output
Value Scope :0----65535Minutes (default:00 00 no timer)
You may use the below configuration parameters to change settings of the corresponding functionality.
Value Scope :0----65535Minutes (default:00 00 no timer)
7：
Association Setting Parameter
Paramter No: 7(0x07) Size:1 Byte Value: 00 None Value: 01 Local(Defaul)
Value: 02 3-way Value: 03 3-way&Local
Value: 04 z-wave hub Value: 05 z-wave hub&Local
Value: 06 z-wave hub&3-way Value: 07 z-wave hub&Local&3-way
Value: 08 Timer Value: 09 Timer&Local
Value: 10 Timer&3-way Value: 11 Timer&3-way&Local
Value: 12 Timer&z-wave hub Value: 13 Timer&z-wave hub&Local
Value: 14 Timer&z-wave hub&3-way Value: 15 All
8：
Restores state after power failure
Paramter No: 8(0x08) Size:1 Byte Value: 00 Output OFF.
Value: 01 Output ON.
Value: 02 (default) The state before a power outage.
9：
Dimmer Speed Parameter
Paramter No: 9(0x09) Size:1 Byte Value: 01(default) from 0x63 to 0x00 or from 0x00 to 0x63 need 1s
Value: 02 from 0x63 to 0x00 or from 0x00 to 0x63 need 2s
……………
Value: 99 from 0x63 to 0x00 or from 0x00 to 0x63 need 99s
10：
Multilevel minimum value can be set
（
The minimum luminance value of the dimming
）
Paramter No: 10(0x0A) Size:1 Byte Value: 00(default)
Value: 01
……………
Value: 99
11：
Multilevel maxmum value can be set
（
The maxmum luminance value of the dimming
）
Paramter No: 11(0x0B) Size:1 Byte Value: 00
Value: 01
……………
Value: 99 (default)
`
12：
when switch is off and quickly press UPPER paddle 2 times, switch turns on to x brightness
Paramter No: 12(0x0C) Size:1 Byte Value: 00 Turn ON to 99
Value: 01
Notice
:when parameter 12 value is 0,the parameter 11 can not be set , and the value always is 0

Support for Association Groups
ZW313 supports 3 association groups. A maximum of 5 node ID’s (nonmulti-channel devices) can be assigned to these association groups.
Association group_1:Z-Wave Plus Lifeline
Association group_1 is default to associate with the primary controller (Gateway/Hub/Controller) for ZW313 Status change report,
1. ZW313 will trigger AUTO report function if the Switch status had been changed.
2. When ZW313 high temperature alarm sends out notifications or releases notifications, ZW313 will auto report
Association group_2:basic set command
command. On (0xFF) or Off (0x00) to its associated group.
Restoring Factory Defaults
ZW313
is removed from the network and will be restored to the factory setting
All Configuration Parameters values and Association information will be restored to factory default settings and excluded from the network.
Remark : All the setting and data will be permanently deleted.
Please use this procedure only when the network primary controller is missing or otherwise inoperable.
When the output of the ZW313 is changed, On (0xFF) or Off (0x00). The ZW313 will automatically send out a related basic set
