EverFocus EZ930F User manual

EZ930F/950F eZ.HD Series
1080p Full High Definition
True Day/Night Outdoor IR Bullet Camera
User’s Manual
Copyright © EverFocus Electronics Corp.
Release Date: February 2016

2
Precautions
1. Do not install the camera near electric or magnetic fields. Install the camera away from
TV/radio transmitters, magnets, electric motors, transformers and audio speakers since the
electromagnetic fields generated from these devices may distort the video image or
otherwise interfere with camera operation.
2. Never disassemble the camera beyond the recommendations in this manual nor introduce
materials other than those recommended herein. Improper disassembly or introduction of
corrosive materials may result in equipment failure or other damage.
3. Try to avoid facing the camera toward the sun. In some circumstances, direct sunlight may
cause permanent damage to the sensor and/or internal circuits, as well as creating
unbalanced illumination beyond the capability of the camera to compensate.
4. Keep the power cable away from water and other liquids and never touch the power cord
with wet hands. Touching a wet power cord with your hands or touching the power cord
with wet hands may result in electric shock.
5. Never install the camera in areas exposed to oil, gas or solvents. Oil, gas or solvents may
result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning. For cameras with interchangeable lenses, do not touch the surface of the sensor
directly with the hands. Use lens tissue or a cotton tipped applicator and ethanol to clean
the sensor and the camera lens. Use a damp soft cloth to remove any dirt from the camera
body. Please do not use complex solvents, corrosive or abrasive agents for cleaning of any
part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power source
ratings. This camera is suitable for indoor operation only. Use the camera at temperatures
within -40°C~50°C (-40°F~122°F) and humidity between 20%~80%; this device is not rated as
submersible. The input power source is 12VDC or 24VAC. Be sure to connect the proper + / -
polarity and voltage, as incorrect polarity or too high a voltage will likely cause the camera
to fail, and such damage is not covered by the warranty.
8. Mounting. Use care in selecting a solid mounting surface which will support the weight of
the camera plus any wind, snow, ice or other loading, and securely attach the camera to the
mounting surface using screws and anchors which will properly support the camera. If
necessary (e.g. when mounting to drop ceilings) use a safety wire to provide additional
support for the camera.

3
Safety Notice
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.

4
Contents
1. Introduction...................................................................................................................... 5
1.1 Packing List .....................................................................................................................5
1.2 Features ..........................................................................................................................6
2. Cable Description.............................................................................................................. 7
3. Installation ....................................................................................................................... 8
3.1 Installation And Adjustment...........................................................................................8
4. Configuration In The Osd Menu........................................................................................12
5. Specifications...................................................................................................................16

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
5
1. Introduction
The EverFocus eZ.HD Series EZ930F/950F provides incredible performance in bright light or low light,
and the resolution listed in the specification from the actual camera you install. To take full
advantage of the amazing resolution available from this advanced imaging technology, the
EverFocus eZ.HD Series EZ930F/950F uses a vari-focal lens together with 1/2.9" SONY 2.24M pixels
CMOS to deliver 1080p high resolution together with a useable native low light sensitivity of 0.08lux
without using digital slow shutter. This camera truly provides optimized images without
compromising 1080p high resolution. The Digital Wide Dynamic Range function provides clear color
images in the most challenging of bright or unbalanced lighting conditions. The true day/night IR
enhances images in low light environments with guaranteed ZERO ghosting. The EZ930F/950F
cameras are equipped with an IP66 weather resistant housing and a 3-axis rotation mechanical
design that delivers wall or ceiling mounting flexibility. Users can take the advantage of vari-focal DC
iris lens to easily adjustable field of view from the cameras. The cameras also feature dual voltage
operation and a full suite of OSD Menu and DSP functions controllable at the camera (3DNR to save
DVR HDD space, privacy masking, mirroring, and much more). This is the camera that you have been
waiting for to create analog CCTV systems that produce astounding image clarity in a wide range of
outdoor applications at the widest range of light levels. The EZ930F/950F support both NTSC and
PAL scanning systems, which can be switched via OSD.
Model Image Sensor Resolution IR LEDs Lens Type IR Distance Day / Night
EZ930F 1/2.9" SONY
2.24M pixels
CMOS
1080p
80 Units 2.8-12mm DC
Iris with ICR 35m/115ft. True
Day/Night
EZ950F 8 Units 5-50mm DC
Iris with ICR 50m/165ft.
1.1 Packing List
Camera Body x 1 Hexagon Wrench x 1
User Manual x 1 Screw Driver x 1
Test Lead x 1 Plastic Anchor x 3
DC Power Pigtail Cable x 1
Screw x 3
Quick Installation Guide x 1
Template Plate x 1
Desiccant Bag x 1
Warning Label x 1

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
6
1.2 Features
1080p full HD with high flexibility and performance for astounding image
1/2 . 9 ” Sony 2.24M pixels CMOS sensor, delivering amazing high sensitivity
Vari-focal 2.8~12mm(EZ930F)/ 5~50mm(EZ950F) DC iris lens to captures the
desired field of view
Extended IR range of up to 35m/115ft. with 80 LEDs (depending on scene IR reflectivity)
(EZ930F);
Up to 50m/165ft. with 8pcs 3G array IR LEDs (EZ950F)
D-WDR to improve the visibility under high contrast scene
3D Noise Reduction ensures less blurry moving subjects, vivid and high SN ratio
images even under low light environments
Supports 1080p, 720p & 960H analog signal output, which can be easily switched using
OSD Joystick
Internal wire system with anti-cut bracket
Weather Resistant IP66 and built-in heater
Supports ceiling mount and wall mount
eZ.Controller function: Control camera OSD settings and PTZ operation directly from DVR
end

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
7
2. Cable Description
No. Name Descriptions
1 Power Cable Connect to a 12VDC or 24VAC power source.
2 Video Output 1080p, 720p and 960H output, using a 75 Ohm BNC-type coaxial
cable.
3 Test Lead Connect to a monitor for setting image aim and focus.
4 DC Power Pigtail
Cable
Optional power pigtail cable. The red wire is positive (+); while the
black wire is negative (-).

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
8
3. Installation
3.1 Installation and Adjustment
Overview for EZ930F Overview for EZ950F
1. For Ceiling Mount / Wall Mount users: Stick the Template Plate on the position where you
want to attach the camera.

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
9
2. Drill three holes and insert the supplied Plastic Anchors into the holes, then screw the
camera to the ceiling or wall by using the supplied Screws.
3. Loosen the screw on the bracket with Hexagon Wrench, and adjust camera angles by
tilting or rotating the camera. Then fasten the bracket with the Hexagon Wrench
(Note: The bracket base can be rotated by 360o , the housing body also can be rotated by
360oand tilted by 90o).

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
10
4. Connect the camera to the 12VDC or 24VAC power source. (For 12VDC power source, you
can optionally use the supplied DC Power Pigtail Cable.
5. Loosen the screws on the bottom of housing, then pull out the OSD panel to configure
camera settings using the OSD Menu Joystick, connect one end of the Test lead to the
Test-out connector on the camera module and the other end to the portable monitor.
OSD indication as shown in the figure:
•Push the Joystick up / down to select
among menu items.
•Push the Joystick left / right to adjust the
level of the selected item.
•Press the Joystick to enter the submenu or
exit the OSD Setup Menu.

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
11
Note: The function button is using to control direction, and also to switch video format and
video output. Please follow the detailed instruction as below to switch the camera to:
Switch between 1080p and 720p (Default, 1080p): Press Upward for 5 Seconds
Switch from HD (1080p / 720p) to 960H: Press Left for 5 Seconds
Switch from 960H to HD (1080p / 720p): Press Right for 5 Seconds
Switch between NTSC and PAL: Press Downward for 5 Seconds
6. Enter the OSD setup menu and adjust the focus & zoom nuts inside the housing by using
the supplied Screw Driver.
7.Tear apart the outer packing ( figure 1) to take out the Desiccant Bag ( figure 2 ), and put it into
the camera housing ( figure 3 ).
Note: It’s recommended to close the OSD panel immediately in case of reducing the
absorption capacity of the Desiccant Bag inside the camera.
8. Screw back the OSD panel using the supplied Hexagon Wrench.

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
12
4. Configuration in the OSD Menu
You can use the Joystick on the bottom housing of the camera to configure camera settings in the
OSD menu. The OSD menu structure is as below:
No. Main Sub
Menu Sub Menu / Function
1 Lens DC Mode
Indoor
Outdoor
Min Shu. NTSC: 1/30
PAL : 1/2 5
Max. Shu.
NTSC: 1/60,FLK,1/240,
1/480,1/1000,
1/2000,1/5000,
1/10000, 1/50000
PAL: 1/50,FLK,1/200,
1/400,1/1000,
1/2000*,1/5000,
1/10000, 1/50000
Iris Speed 0 – 15
Manual
2 Exposure
Shutter
NTSC: 1/30, 1/60, FLK, 1/240, 1/480,
1/1000, 1/2000, 1/5000, 1/10000,
1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
PAL: 1/25, 1/50, FLK, 1/200, 1/400, 1/1000, 1/2000, 1/5000, 1/10000,
1/50000, X2, X4, X6, X8, X10, X15, X20, X25, X30, Auto
AGC 0 – 15
Sens-up Off
Auto Sens-up X2, X4, X6, X8, X10, X15, X20, X25, X30
Brightne
ss 1-100
D-WDR
Off
On Level 0-8
Auto
Defog
Off
Auto
Pos/Size Position, Size,↑,↓,→,←
Gradation 0-2
Default
3 Backlight Off
BLC Level Middle, High, Low

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
13
Area Position, Size,↑,↓,→,←
Default
HSBLC
Select Area1, Area2, Area3, Area4
Display Off
On Position, Size,↑,↓,→,←
Black Mask On/Off
Level 0-100
Model All Day
Night AGC Level 0-255
Default
4White
Balance
ATW
AWC→SET
Indoor
Outdoor
Manual Blue 1-500
Red 0-100
AWB
5
Day &
Night
Ext D→N(Delay) 0-60
N→D(Delay) 0-60
Auto
D→N(AGC) 1-255
D→N(Delay) 0-60
N→D(AGC) 1-255
N→D(Delay) 0-60
Color
B/W
Burst Off/On
IR Smart
Off
On
Level 0-15
Area Position, Size,↑,
↓,→,←
IR PWM Off
0-100
6 NR 2DNR Middle/Low/Off/High
3DNR Middle/Low/Off/High
7 Special
Cam Title
Off
On 0123456789ABCDEFGHIJKLMNOPQRSTUVWXYZ▶→
←↑↓()ˉ-_▊/=&:~,.
D-effect Freeze Off/On
Mirror Off, Mirror, V-flip, Rotate

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
14
Neg. Image Off/On
Motion
Off
On
Select Area1,Area2,Area3,Area4
Display On Position, Size,↑,↓,→,←
Off
Sensitiv
ity 0-100
Color Green, Blue, White, Red
Trans 1.00,0.75,0.50,
0.25
Alarm
View Type Off, Block, Outline, All
OSD View On/Off
Alarm Out On/Off
Time 1-15
Default
Privacy
Off
On
Select Area1,Area2,Area3,Area4
Display
Off
Color Position, Size,↑,↓,→,←
Mosaic Position, Size,↑,↓,→,←
Inv Position, Size,↑,↓,→,←
Color White, Black, Red, Blue, CYAN, Yellow,
Green
Trans 1.00,0.75,0.50,
0.25
Default
Language ENG/CHN1/CHN2/GER/FRA/ITA/SPA/POL/RUS/POR/NED/TUR
Defect
Live DPC
Off
On AGC level 0-255
Level 0-100
White DPC
Off
On
Pos/Size Position, Size,↑,↓,→,←
Start Close the iris then press
DPC View Off/On
Level 0-60
AGC 0-14
Sens-up x2, x4, x6, x8,x10, x15, x20,

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
15
x25, x30
Black DPC
Off
On
Pos/Siz Position, Size,↑,↓,→,←
Start Press Enter
DPC View Off/On
Level 0-255
RS485
CAM ID 0-255
ID Display Off/On
Baud Rate 2400,4800,9600,19200 ,38400
8 Adjust
Sharpness
Off
Auto
Level 0-10
Start AGC 0-255
End AGC 0-255
Monitor
CRT Blue Gain 0-100
Red Gain 0-255
LCD
Gamma
User,0.45,0.50,0.55,0.60,0.6
5,0.70,0.75,0.80,0.85,0.90,
0.95,1.00
Blue Gain 0-100
Red Gain 0-100
LSC Off/On
Video. Out PAL/NTSC
9 AF
AF Mode
Semi.
Auto
Manual
One Shot AF
TDN AF On
Off
Lens Init.
10 Exit Save& END /Reset/Not Saved

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
16
5. Specifications
Specifications and designs are subject to change for improving the functionality of this product
without notice.
P/N
EZ930F
EZ950F
Pickup Device
1/2.9" SONY 2.24M pixels CMOS
Video Format
NTSC and PAL( can be switched via OSD)
Effective Pixels 1920 (H)*1080 (V)
Scanning System
Progressive Scan
Sensitivity 0 lux with IR on
S/N Ratio
Over 48 dB (AGC OFF)
Electronic Shutter
AUTO, Manual (X30~1/ 50000), FLK
Video Output
BNC 1.0Vp-p 75Ω
Gamma Correction
0.45
Lens Type
DC Iris 2.8-12mm, F1.4
DC Iris 5-50mm, F1.4
BLC
OFF/BLC/HS BLC Selectable
AGC 0~15 Levels
White Balance
ATW/AWC-SET/INDOOR/OUTDOOR/MANUAL/AWB
Sync Mode Internal
Day/Night
Ext, Auto, Color, B/W
IR LED
80 Units
8 Units
IR Distance
Up to 35m/115ft.
Up to 50m/165ft.
OSD Languages 12-Language
DNR
2DNR/3DNR, Off
DEFOG
Off/Auto(under B/W mode)
D-WDR
On/Off
Sens-up
Off/On(x2~x30)
Mirror Off, Mirror, V-flip, Rotate
Motion Detection
Off/On for 4 selectable zones
Privacy Mask Off/On for 4 selectable zones
Environmental
IP66 Weather Resistant
Power Source
12VDC/24VAC
Power Source
12VDC: 12w max./ 24VAC: 13w
max.
12VDC: 15w max./ 24VAC: 14.5w
max.
Operating
Temperature -40°C~50°C / -40°F~122°F
Humidity
20%~80%
Dimensions
236 x 84 x 110mm / 9.3” x 3.3" x 4.3"
Weight
1100g/2.42lbs
Certifications
CE/FCC/ RoHS

EZ930F/9 5 0 F eZ.HD Outdoor IR Bullet Camera
EverFocus Electronics Corp.
EverFocus Taiwan:
12F-1, No.79, Sec. 1, Shin-Tai Wu Road,
Hsi-Chih, New Ta ip ei City, Taiwan
TEL: [phone]
FAX: [phone]
www.everfocus.com.tw
[e-mail]
EverFocus Europe - Germany:
Albert-Einstein-Strasse 1, D-46446
Emmerich, Germany
TEL: [phone]
FAX: [phone]
www.everfocus.de
[e-mail]
EverFocus China - Beijing:
Room 609, Technology Trade Building,
Shangdi Information Industry Base,
Haidian District, Beijing 100085, China
TEL: [phone]~39
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus China - Shenzhen:
4F, No. 2, D4 Building, Wan Yelong
Industrial Park, Tangtou Road, Shiyan,
Baoan, Shenzhen, Guangdong 518101, China
TEL: [phone]
FAX: [phone]
www.everfocus.com.cn
[e-mail]
EverFocus USA - California:
1801 Highland Avenue, Unit A, Duarte, CA 91010,
USA
TEL: [phone]
FAX: [phone]
www.everfocus.com
[e-mail]
EverFocus Japan:
3F Kuramochi, Buildingll 2-2-3 Koto-Bashi,
Sumida-Ku Tokyo, 130-0022, Japan
TEL: [phone]
FAX: [phone]
www.everfocus.co.jp
[e-mail]
Your EverFocus product is designed
and manufactured with high quality
materials and components which can
be recycled and reused.
This symbol means that electrical and
electronic equipment, at their
end-of-life, should be disposed
ofseparately from your household
waste.
Please, dispose of this equipment at
your local community waste
collection/recycling centre.
In the European Union there are
separate collection systems for used
electrical and electronic product.
Please, help us to conserve the
environment we live in!
Ihr EverFocus Produkt wurde
entwickelt und hergestellt mit
qualitativ hochwertigen Materialien
und Komponenten, die recycelt und
wieder verwendet werden können.
Dieses Symbol bedeutet, dass
elektrische und elektronische Geräte
am Ende ihrer Nutzungsdauer vom
Hausmüll getrennt entsorgt werden
sollen.
Bitte entsorgen Sie dieses Gerät bei
Ihrer örtlichen kommunalen
Sammelstelle oder im Recycling
Centre.
Helfen Sie uns bitte, die Umwelt zu
erhalten, in der wir leben!
