evertz CP-2200E User manual

CP-2200E
2RU Advanced Display Remote Control Panel
User Guide
© Copyright 2007 - 2008
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario, Canada
L7L 5Z9
Phone: [phone]
Sales Fax: [phone]
Tech Support Phone: [phone]
Tech Support Fax: [phone]
Internet: Sales: [email protected]
Tech Support: [email protected]
Web Page: http://www.evertz.com
Version 1.1 March 2009
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the CP-2200E. Evertz Microsystems expressly prohibits the use of
this manual for any purpose other than the operation of the device.
All rights reserved. No part of this publication may be reproduced without the express written permission of
Evertz Microsystems Ltd. Copies of this guide can be ordered from your Evertz products dealer or from Evertz
Microsystems.

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read these instructions
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has
two blades with one wider than other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC – SHOCK, DO NOT EXPOSE THIS APPARATUS TO
RAIN OR MOISTURE.
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT.
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE.
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE.

INFORMATION TO USERS IN EUROPE
NOTE
This equipment with the CE marking complies with both the EMC Directive (2004/108/EC) and the Low Voltage
Directive (2006/95/EC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European standards:
•EN60065 Product Safety
•EN55103-1 Electromagnetic Interference Class A (Emission)
•EN55103-2 Electromagnetic Susceptibility (Immunity)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to the
European Union EMC directive. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
EN60065 Safety
EN55103-1: 1996 Emission
EN55103-2: 1996 Immunity
EN504192 2005
Waste electrical products should not
be disposed of with household waste.
Contact your Local Authority for
recycling advice
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
WARNING
Changes or modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s authority to
operate the equipment. Use of unshielded plugs or cables may cause radiation interference. Properly shielded
interface cables with the shield connected to the chassis ground of the device must be used.
Evertz Microsystems Ltd
Tested to comply
with FCC
Standards
For Commercial Use
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may cause harmful interference, and this device must
accept any interference received, including interference that may
cause undesired operation.

CP-2200E
Advanced Display Remote Control Panel, 2RU
REVISION HISTORY
REVISION DESCRIPTION DATE
0.1 Preliminary Dec 07
0.2 Added information on configuring the CP-2200E and adding a system Jul 08
1.0 Release Version Oct 08
1.1 Updated Specifications and Safety/EMC Warnings Mar 09
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor
for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only
warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation
form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no
warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or
order confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If
you encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make
changes in equipment design or specifications.
Revision 1.1 Page i

CP-2200E
Advanced Display Remote Control Panel, 2RU
This page left intentionally blank
Page ii Revision 1.1

CP-2200E
Advanced Display Remote Control Panel, 2RU
TABLE OF CONTENTS
1. OVERVIEW .........................................................................................................................1
2. INSTALLATION ..................................................................................................................2
2.1. REAR PANEL............................................................................................................................ 2
2.2. FRONT CONTROL PANEL....................................................................................................... 3
2.3. POWER CONNECTIONS.......................................................................................................... 4
2.4. MOUNTING ............................................................................................................................... 4
3. FRONT PANEL CONTROL.................................................................................................5
3.1. CONFIGURING THE NETWORK SETTINGS........................................................................... 5
3.2. LOADING UPDATES ................................................................................................................6
3.2.1. Updates Via the Update Screen ......................................................................................... 6
3.3. TESTING THE CP-2200E.......................................................................................................... 6
3.3.1. Key Test.............................................................................................................................. 6
3.3.2. LCD Test............................................................................................................................. 7
3.4. PHYSICAL MONITORING OF THE CP-2200E......................................................................... 7
4. SYSTEM CONFIGURATION...............................................................................................8
4.1. UPGRADING THE CP-2200E PANEL ...................................................................................... 8
4.1.1. Requirements ..................................................................................................................... 8
4.1.2. Getting Started.................................................................................................................... 8
4.1.3. Upgrading Firmware on the CP-2200E............................................................................... 8
4.2. CONFIGURING THE CP-2200E TO CONTROL A QUARTZ/EVERTZ ROUTER USING
DIRECT ROUTER CONTROL OVER ETHERNET............................................................................10
5. ADDING AN EVERTZ SYSTEM TO CONTROL...............................................................19
5.1. CP-2200E CONTROL OF MVP SYSTEM............................................................................... 19
5.2. ADDING SNMP SERVICES .................................................................................................... 22
5.3. ADDING AN EQX SERVER .................................................................................................... 25
5.4. SETTING THE THUMBNAILS................................................................................................. 26
5.5. ADDING A DISCOVERY SYSTEM ......................................................................................... 27
Revision 1.1 Page iii

CP-2200E
Advanced Display Remote Control Panel, 2RU
5.6. CREATING SOURCE-SERVICE MAPPING ...........................................................................28
6. TECHNICAL DESCRIPTION............................................................................................ 29
6.1. SPECIFICATIONS...................................................................................................................29
6.1.1. Control .............................................................................................................................. 29
6.1.2. Electrical ........................................................................................................................... 29
6.1.3. Physical ............................................................................................................................ 29
6.1.4. Compliance....................................................................................................................... 29
6.2. SERVICING INSTRUCTIONS .................................................................................................29
6.2.1. Changing the Fuses.......................................................................................................... 29
Figures
Figure 1-1: CP-2200E Control Panel............................................................................................... 1
Figure 2-1: CP2200E Rear Panel.................................................................................................... 2
Figure 2-2: CP-2200E Front Control Panel ..................................................................................... 3
Figure 4-1: CP2200e Main Screen .................................................................................................. 9
Figure 4-2: CP2200e Main Screen ................................................................................................ 10
Figure 4-3: CP2200e Configuration Screen .................................................................................. 11
Figure 4-4: Direct Router Control Configuration Welcome Screen................................................ 12
Figure 4-5: Login ........................................................................................................................... 12
Figure 4-6: Devices Tab ................................................................................................................ 13
Figure 4-7: Device List................................................................................................................... 13
Figure 4-8: Changes...................................................................................................................... 14
Figure 4-9: Aliases......................................................................................................................... 14
Figure 4-10: Import Aliases ........................................................................................................... 15
Figure 4-11: Prefixes ..................................................................................................................... 16
Figure 4-12: Destination Aliases.................................................................................................... 17
Figure 4-13: Source Aliases .......................................................................................................... 18
Figure 5-1: Configuration Page ..................................................................................................... 20
Figure 5-2: Creating a New MVP System...................................................................................... 21
Figure 5-3: Discovery Settings Page .............................................................................................22
Figure 5-4: Add SNMP Service ..................................................................................................... 23
Figure 5-5: Hardware Tree ............................................................................................................ 24
Figure 5-6: Add EQX Server.......................................................................................................... 26
Figure 5-7: Add Thumbnails .......................................................................................................... 26
Figure 5-8: Add Discovery ............................................................................................................. 27
Figure 5-9: Source-Service Mapping............................................................................................. 28
Page iv Revision 1.1

CP-2200E
Advanced Display Remote Control Panel, 2RU
1. OVERVIEW
The CP-2200E remote control panel features two high-resolution colour LCD display’s along side an
array of function assignable buttons and dynamic LCD buttons. The two LCD displays intelligently
interact with the panel’s buttons and rotary controls, updating automatically as different operation
facilities are selected. When a menu button is pressed some or all of the buttons change their function
and legend. Their operation is then defined by the configuration setup for this new menu. The selection
of a new menu can also be configured to change the graphical display of one or both the LCD screens.
The CP-2200E is the flagship panel of Evertz®advanced control system, allowing control of automated
tielines and path-finding, as well as advanced breakaway routing while still supporting basic routing
concepts, like levels and categories.
The CP-2200E panel incorporates advanced control of all of Evertz®’s SNMP enabled devices. Devices
or certain controls of devices can be grouped together and associated with sources and destinations on
routers so that when a particular source or destination is used the appropriate controls are loaded up
for interfacing on the panels LCD screens. This allows simple but powerful interfaces to be built to
control parameters and recall presets as well as integrate with the router systems for SNMP equipment
in your facility.
The CP-2200E enables users to have real-time control over an MVP®or VIP™ system. Get graphical
visualizations of layouts prior to loading them, control what signal is routed to what multi-viewer
window, select an audio to be monitored etc. The CP-2200E is a very sophisticated advanced panel
that allows you to create a very powerful and very simple interface for your entire system so users have
real-time control over signals, displays and router destinations.
Figure 1-1: CP-2200E Control Panel
Revision 1.1 Page 1

CP-2200E
Advanced Display Remote Control Panel, 2RU
2. INSTALLATION
2.1. REAR PANEL
Figure 2-1 shows the rear view of the CP-2200E control panel. The following is a list of the ports and
controls on the rear panel:
Figure 2-1: CP2200E Rear Panel
DVI OUTPUT: This DVI connector is used to connect the CP-2200E to a LCD monitor.
VIDEO OUTPUT: This connector is currently not supported.
Q-LINK 1 IN: This connector is currently not supported.
Q-LINK 2 IN: This connector is currently not supported.
REF INPUT: This connector is currently not supported.
LTC INPUT: This connector is currently not supported.
SERIAL A, B, C, D: This connector is currently not supported.
ETHERNET (A, B): This RJ45 connector is used for Network connections to the CP-2200E.
USB (A, B, C, D): These USB 2.0 Ports are used for USB-based mouse and/or keyboard
connections to the CP-2200E.
KEYBOARD: This connector is currently not supported.
MOUSE: This connector is currently not supported.
POWER: The power button on the rear of the unit enables the user to manually turn the
unit ON and OFF. To turn the unit ON, switch the power button down once. To
manually turn the unit OFF, hold the power button down for approximately 4
seconds. To reset the unit, switch the power button up.
Page 2 Revision 1.1

CP-2200E
Advanced Display Remote Control Panel, 2RU
2.2. FRONT CONTROL PANEL
There are two LCD displays located on the front control panel. The display window on the left is used
to select and control the desired module. The display window on the right is used to set the specific
control for the selected module. The group of buttons located in the center of the CP-2200E front
control panel are used to create pre-program selections.
The button operation is defined by the configuration setup for the new menu. The selection of a new
menu can also be configured to change the graphical display of one or both the LCD screens.
Figure 2-2: CP-2200E Front Control Panel
Please note that the labels in Figure 2-2 will NOT be displayed on the front panel of your CP-2200E
device. The labels listed above are for reference purposes only when describing the panel controls in
the following sections of the manual. The following chart describes the label and function of the
associated button.
Label(s) Description
D1 & D2
These labels identify the two display screens on the CP-2200E front panel. When
operating the panel, the content will be displayed on these screens. The D1 screen is
used to display the first level of information to the user and the D2 screen is used to
select the associated parameters.
B1 to B12
There are twelve soft-key buttons located on the front panel, which are labelled B1 to
B12 in Figure 2-2. These buttons can be used to select items or navigate through the
different screens. When an option is available, text will be displayed on the screen
beside one of the illuminated soft-key buttons. To select an option on the screen, press
the illuminated soft-key button beside the desired control.
S1 to S8 S1 to S8 identifies the eight shaft encoders that are available on the front panel. The
user can adjust parameters or toggle through items by turning the shaft encoder knobs
left and right. The user can also select items by pressing in the shaft encoder.
L1 to L12 There are twelve LCD buttons located on the front panel, which are labelled L1 to L12 in
Figure 2-2. These buttons are extremely versatile as the user can change their function
and legend.
Revision 1.1 Page 3

CP-2200E
Advanced Display Remote Control Panel, 2RU
Page 4 Revision 1.1
2.3. POWER CONNECTIONS
The Cp-2200E power supply operates on either 100-115 or 220-240 volts AC at 50 or 60 Hz and
automatically senses the input voltage. Power should be applied by connecting a 3-wire grounding
type power supply cord to the power entry module on the rear panel. The power cord should be
minimum 18 AWG wire size; type SVT marked VW-1, maximum 2.5 m in length.
The IEC 320 power entry module combines a standard power inlet connector, two 5 x 20 mm fuse
holders and an EMI line filter. See section 6.2.1 for information on changing the fuses.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, GROUNDING OF THE
GROUND PIN OF THE MAINS PLUG MUST BE MAINTAINED
2.4. MOUNTING
The CP-2200E is equipped with rack mounting angles and fits into a standard 19 inch by 3.5 inch by
12 inch (483 mm x 89 mm x 300mm) rack space. The mounting angles may be removed if rack
mounting is not desired.
Cooling is achieved by fan-assisted convection. Air is drawn into the left side of the chassis and
expelled as hot air from the right side of the chassis.
"
When installed in the equipment rack, ensure that the air flow from the left and right
side vents is not blocked or restricted.

CP-2200E
Advanced Display Remote Control Panel, 2RU
3. FRONT PANEL CONTROL
To enter the setup menu of the CP-2200E press and hold BOTH rotary encoders (S1 and S2) on the far
left side of the panel for approximately 6 seconds. You will then be presented with several menus which
allow testing and configuration of the panel.
3.1. CONFIGURING THE NETWORK SETTINGS
The Network screen enables the user to configure the network settings for network ports A and B. The
following procedure outlines how to set an IP address.
1. The user can configure the network settings by using the rotary encoders and soft-key buttons.
When the Network page is displayed, three options will be instantly highlighted on the screen:
Page, Select and Change.
•The Page> option is located in the top right hand corner of the monitor and can be
controlled by the Page> soft-key (B4) button. Press the Page> soft-key (B4) button to toggle
through the different pages.
•The Select option is located in the lower left hand corner of the screen and can be
controlled using the bottom left rotary encoder (S2).
•The Change option is located in the lower right hand corner of the screen and can be
controlled using the bottom right rotary encoder (S4).
2. To change the IP address, mask, broadcast, or gateway network settings toggle to the appropriate
number using the bottom left Select rotary encoder (S2). Turning the rotary encoder clockwise will
enable the user to advance forward and highlight the appropriate value. Turning the encoder
counter-clockwise will move the selection tool backwards.
3. Once the desired value is highlighted (the text will be bright yellow), use the bottom right rotary
encoder to adjust the value of the selected number. Turning the rotary encoder clockwise will
increase the number value, while turning the rotary encoder counter-clockwise will decrease the
number value.
4. If any of the Network values are changed, the Apply soft-key (B5) button will illuminate. If you
wish to apply your changed network settings, select the Apply soft-key (B5) button when
illuminated. The twelve LED buttons will illuminate to indicate that the settings are being applied.
Once the settings are applied the LCD buttons will not be illuminated and the Apply soft-key will
be greyed out.
5. Bonding may be chosen if you wish the CP-2200E to use the same IP address on BOTH Ethernet
ports. This setting is ONLY to be used if ONE Ethernet cable is plugged into a single network OR if
two completely isolated networks are in use. Using bonding, and plugging both ports into the same
switch will cause a network loop and unsavoury results on your network.
Revision 1.1 Page 5

CP-2200E
Advanced Display Remote Control Panel, 2RU
Page 6 Revision 1.1
3.2. LOADING UPDATES
The user can manually upload code onto the CP-2200E unit using the Update screen or the Web
Interface (see section 4.1). The following procedures outline how to manually update the device. This
practice is not recommended for typical users and should only be implemented when directed by Evertz
personnel.
3.2.1. Updates Via the Update Screen
"
This practice is not recommended for typical users and should only be used when
directed by Evertz personnel.
1. Plug a USB memory key into one of the USB ports on the rear panel of the CP-2200E.
2. Using the Page> soft-key (B4) button toggle to the Update screen.
3. The Update screen will display the updates available on the USB memory key. If there are no
files listed, press the Refresh soft-key (B2) button to refresh the list. If there are still no files
listed, try rebooting the system and ensure the correct files are loaded on your USB memory
key.
4. If the available files are listed on the display screen (D1), toggle through the list using the
bottom left rotary encoder (S4).
5. Once the desired file is highlighted, select the Install soft-key (B5) button.
6. The Install Update screen will appear after a few seconds enabling the user to select whether
they would like to update the code. Select the Yes soft-key (B3) button to apply the update, or
select the No soft-key (S6) button if you do not wish to update the code.
7. Once the Yes option is selected, the user can remove the USB memory key from the rear of the
CP-2200E device. The CP-2200E device will automatically reboot. This may take
approximately 2 to 3 minutes.
3.3. TESTING THE CP-2200E
The Test screen enables the user to test the functionality of the LCD screens and LCD buttons. The
user can navigate to the Test screen using the right Page > soft-key (B4) or left <Page soft-key (B1)
buttons. Once the Test screen is displayed there are two main Test options: Key Test and LCD Test.
3.3.1. Key Test
Selecting the Key Test option enables the user to test the functionality of the twelve LCD buttons. To
perform a Key Test, select the Key Test soft-key (B2) button. The Key Test screen will be displayed
and the user will be able to change the colour of the twelve LCD buttons.
To exit the Key Test screen, simultaneously hold down the top and bottom rotary encoders (S1 and S2)
on the left hand side of the screen until the Test setup screen is displayed.

CP-2200E
Advanced Display Remote Control Panel, 2RU
3.3.2. LCD Test
Selecting the LCD Test option enables the user to test the LCD monitors. To perform a LCD Test,
select the LCD Test soft-key (B3) button. The LCD screens will cycle through a variety of solid
coloured and gradient screens. The screens will continue to cycle until the LCD Test is exited.
To exit the LCD Test, simultaneously hold down the top and bottom rotary encoders on the left hand
side of the screen until the Test setup screen is displayed.
3.4. PHYSICAL MONITORING OF THE CP-2200E
The Monitor screen displays information pertaining to the performance of the CP-2200E. The user can
navigate to the Test screen using the Page > soft-key (B4) or <Page soft-key (B1) buttons.
•Main Temperature: Monitors the temperature of the CPU in degrees Celsius and Fahrenheit.
•System Temperature: Monitors the temperature of the system in degrees Celsius and
Fahrenheit.
•Fan Speed: Monitors the fan speed.
•Workload: Monitors the workload.
Revision 1.1 Page 7

CP-2200E
Advanced Display Remote Control Panel, 2RU
4. SYSTEM CONFIGURATION
4.1. UPGRADING THE CP-2200E PANEL
4.1.1. Requirements
1. The user must have a laptop or PC connected to the same network as the CP-2200E.
2. The user must obtain upgrade files from Evertz Personnel.
a. Your computer must be running the Mozilla firefox web browser located at:
http://www.mozilla.com/en-US/firefox/
b. This browser is also available in Chinese simplified and traditional, if preferred, by
clicking the “other languages…” option under the download link.
3. The user must have the Java runtime environment installed on their machine. The JRE must be
installed AFTER firefox. This file can be downloaded from the following location:
http://java.com/
4.1.2. Getting Started
1. Set the IP address of the CP-2200E by holding down both rotary encoders (S1 and S2) on the
far left of the panel for 6 seconds.
a. Using the rotary encoders, toggle to the “Network” page.
b. Set the IP address for the A port and ensure “bonding” is on (a green dot should appear
next to it).
c. Click Apply, then press the setup button.
2. Set the IP of your laptop or PC in the same range as the panel.
3. Ensure that firefox is installed on your machine. If not, please review section 4.1.1 for
instructions on installing firefox.
4. Ensure that java JRE is installed on your machine. If not, please review section 4.1.1 for
instructions on installing the java JRE file.
4.1.3. Upgrading Firmware on the CP-2200E
1. To upgrade firmware using the web interface, open a firefox web browser and enter the IP
address of the CP-2200E, then press the <enter> key. The CP2200e screen will appear, as
shown in Figure 4-1.
Page 8 Revision 1.1

CP-2200E
Advanced Display Remote Control Panel, 2RU
Revision 1.1 Page 9
Figure 4-1: CP2200e Main Screen
2. Using the Firmware Manager, select the Browse button and load the file to be updated
(Example:CP2200e-1.1_rc18.efp)
3. If a reboot is required the panel should automatically reboot on its own otherwise you may
reboot it using the front panel.
4. Once the panel has rebooted you are ready to configure the CP-2200E.

CP-2200E
Advanced Display Remote Control Panel, 2RU
4.2. CONFIGURING THE CP-2200E TO CONTROL A QUARTZ/EVERTZ ROUTER USING
DIRECT ROUTER CONTROL OVER ETHERNET
Direct Router control is only used in a system where a CP-2200E is to be DIRECTLY CONNECTED via
Ethernet, to an EQX or Xenon router. Most systems employ a control system (EQX Server) which the
panel connects to in lieu of a direct connection to the router. If you have purchased an EQX server and
the system is operating, please proceed to section 5.3 to configure the CP-2200E for connection to the
EQX Server.
1. Open a Firefox web browser and enter the IP address of the CP-2200E into the address field,
then press the <enter> button. The CP2200e screen will appear enabling the user to configure
the device.
Figure 4-2: CP2200e Main Screen
2. Click on the Configuration tab. The CP2200e configuration screen will appear as shown in
Figure 4-3.
Page 10 Revision 1.1

CP-2200E
Advanced Display Remote Control Panel, 2RU
Revision 1.1 Page 11
Figure 4-3: CP2200e Configuration Screen
3. Select the Direct Router Control tab from the top menu bar.
4. The Direct Router Control Configuration window will appear as shown in Figure 4-4. Select the
LOGIN button located in the top left of the screen.

CP-2200E
Advanced Display Remote Control Panel, 2RU
Page 12 Revision 1.1
Figure 4-4: Direct Router Control Configuration Welcome Screen
5. Enter in your username and password. If you do not have your own login information, enter in
admin for the username and password.
Figure 4-5: Login
6. Under the Devices option,select the Devices tab and add the EQX router parameters. The
following information should be entered:
a. Short Name: The name used to build default names for source destinations and tielines.
b. Long Name: The name used to refer to the router in the WCT.
c. Device Type: The router type to be controlled.
d. Inputs/Outputs: The size of I/O available on the router to be controlled.
e. FC IP address (primary)/Port: The network information of the primary FC is required for
the router to be controlled.
f. FC IP address (secondary)/Port: The network information of the secondary FC is
optional.
g. Location: Information pertaining to the physical location (Los Angeles or ER-227) can
be optionally entered here.
