evertz 5600ACO User manual

Model 5600ACO Automatic Changeover Unit
Version 1.5
Model 5600ACO
Automatic Changeover
Instruction Manual
© Copyright 2003, 2004, 2005
EVERTZ MICROSYSTEMS LTD.
5288 John Lucas Drive,
Burlington, Ontario,
Canada L7L 5Z9
Phone: [phone]
Sales: [email protected] Fax: [phone]
Tech Support: [e-mail] Fax: [phone]
Web Page: http://www.evertz.com
Version 1.5 June 2005
The material contained in this manual consists of information that is the property of Evertz Microsystems and is
intended solely for the use of purchasers of the 5600ACO Automatic Changeover. Evertz Microsystems
expressly prohibits the use of this manual for any purpose other than the operation of the 5600ACO.
All rights reserved. No part of this publication may be reproduced without the express written permission of
Evertz Microsystems Ltd. Copies of this manual can be ordered from your Evertz dealer or from Evertz
Microsystems.

Model 5600ACO Automatic Changeover Unit
Version 1.5
This page left intentionally blank

Model 5600ACO Automatic Changeover Unit
Version 1.5
IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equi-lateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature ac-companying the product.
• Read this information
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
blades with one wider than other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer
• Unplug this apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC – SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOSITURE”
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, ARE PLACED ON THE EQUIPMENT”
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE”
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERALBLE”

Model 5600ACO Automatic Changeover Unit
Version 1.5
INFORMATION TO USERS IN EUROPE
NOTE
This equipment with the CE marking complies with both the EMC Directive (89/336/EEC) and the Low
Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European standards:
• EN60065 Product Safety
• EN55103-1 Electromagnetic Interference Class A (Emission)
• EN55103-2 Electromagnetic Susceptibility (Immunity)
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to the European Union EMC directive. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
WARNING
Changes or Modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used

Model 5600ACO Automatic Changeover Unit
Version 1.5
REVISION HISTORY
REVISION DESCRIPTION DATE
0.1 Preliminary version Feb 03
1.0 First Release Mar 03
1.1 Added Table 2-3 – WA05600SYNCHRO Cable diagram Aug 03
1.1.1 Added warning about proper termination of sync outputs in section 2.4.1 Sep 03
1.2 Added info about connecting 500ACO2-HDSD cards in ACO Extension mode Sep 03
1.2.1 Added clarification on ACO Extension mode in sections 2.6 and 3.2.1 Dec 03
1.3 Added info in sections 2.5 and 3.4 about new dual GPI mode Jan 04
(available in firmware version 1.3 and later)
1.4 Added info in sections 3.3.1 and 3.3.2 about fast switching and Bank A priority Feb 04
(available in firmware version 1.4 and later)
1.5 Updated Safety Instructions, fixed minor typographical errors Jun 05
Added Firmware upgrade instructions
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor
for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only
warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation
form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no
warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or
order confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If
you encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make
changes in equipment design or specifications.

Model 5600ACO Automatic Changeover Unit
Version 1.5
This page left intentionally blank

Model 5600ACO Automatic Changeover Unit
Version 1.5
TABLE OF CONTENTS
1. OVERVIEW..................................................................................................................................1-1
1.1. HOW TO USE THIS MANUAL............................................................................................1-3
2. INSTALLATION...........................................................................................................................2-1
2.1. REAR PANEL .....................................................................................................................2-1
2.1.1. Coaxial Connections................................................................................................2-1
2.1.2. Linear Time Code, Parallel Remote Control and Auxiliary Connections..................2-1
2.1.3. Power Connections..................................................................................................2-2
2.2. MOUNTING.........................................................................................................................2-2
2.3. POWER REQUIREMENTS ................................................................................................. 2-3
2.4. 5600MSC CONNECTIONS ................................................................................................. 2-3
2.4.1. Sync Outputs ...........................................................................................................2-3
2.4.2. 10 MHz Output.........................................................................................................2-3
2.4.3. DARS Outputs .........................................................................................................2-3
2.4.4. LTC and GPIO Connections....................................................................................2-4
2.4.5. Synchronizing the Menu Settings Of The Two 5600MSC Units ..............................2-4
2.5. CONNECTING THE GENERAL PURPOSE INPUTS AND OUTPUTS .............................. 2-5
2.6. CONNECTING 500ACO2-HD/SD AUTO CHANGEOVER MODULES............................... 2-6
3. HOW TO OPERATE THE AUTOMATIC CHANGEOVER...........................................................3-1
3.1. AN OVERVIEW OF THE STATUS INDICATORS .............................................................. 3-1
3.1.1. Operating Mode Indicators.......................................................................................3-1
3.1.2. Input Indicators ........................................................................................................3-2
3.1.3. Power Supply Indicators..........................................................................................3-2
3.2. FRONT PANEL CONTROL ................................................................................................3-2
3.2.1. Automatic Changeover Mode ..................................................................................3-2
3.2.2. Manual GPI Changeover Mode ...............................................................................3-3
3.2.3. Manual Front Panel Changeover Mode................................................................... 3-3
3.3. DIP SWITCHES...................................................................................................................3-3
3.3.1. Setting the Switchover Detection Speed..................................................................3-4
3.3.2. Setting the Switching Priority Mode.........................................................................3-4
3.4. GPI INPUTS ........................................................................................................................3-5
3.5. GPO TALLY OUTPUTS...................................................................................................... 3-6

Model 5600ACO Automatic Changeover Unit
Version 1.5
4. TECHNICAL DESCRIPTION .......................................................................................................4-1
4.1. SPECIFICATIONS...............................................................................................................4-1
4.1.1. LTC Outputs.............................................................................................................4-1
4.1.2. Coaxial Inputs and Outputs......................................................................................4-1
4.1.3. ACO General Purpose Inputs and Output ...............................................................4-1
4.1.4. MSC General Purpose Inputs and Output...............................................................4-2
4.1.5. Changeover Conditions: ..........................................................................................4-2
4.1.6. Electrical ..................................................................................................................4-2
4.1.7. Physical....................................................................................................................4-2
4.2. SERVICING INSTRUCTIONS.............................................................................................4-2
4.2.1. Changing the Fuses.................................................................................................4-3
4.2.2. UPGRADING THE FIRMWARE...............................................................................4-3
4.2.2.1. Overview ...................................................................................................4-3
4.2.2.2. Terminal Program Setup...........................................................................4-4
4.2.2.3. Initiating Firmware Upgrade Mode From The Terminal Program..............4-5
4.2.2.4. Uploading the new firmware......................................................................4-6
4.2.2.5. Completing the Upgrade...........................................................................4-6
Figures
Figure 1-1: Redundant Master Clock/SPG with Auto Changeover System Diagram....................................1-2
Figure 2-1: 5600ACO Rear Panel..................................................................................................................2-1
Figure 2-2: Typical GPI Circuitry....................................................................................................................2-5
Figure 2-3: Typical GPO Circuitry..................................................................................................................2-6
Figure 2-4: ACO Extension Mode Diagram ...................................................................................................2-7
Figure 3-1: Model 5600ACO Front Panel Layout...........................................................................................3-1
Tables
Table 2-1: AUX I/O Pin Definitions.................................................................................................................2-2
Table 2-2: ACO CTRL/STATUS and MSC GPIO Terminal Strip Pin Definitions...........................................2-2
Table 2-3: WA05600Synchro Cable ..............................................................................................................2-5
Table 3-1: Primary Input Preference Behaviour.............................................................................................3-3
Table 3-2: DIP Switch Functions....................................................................................................................3-4
Table 3-3: Switchover Detection Speed Switch Settings...............................................................................3-4
Table 3-4: Primary Reference Mode Switch Settings....................................................................................3-4
Table 3-5: GPI Input Mode Switch Settings...................................................................................................3-5
Table 3-6: Single GPI mode operation...........................................................................................................3-5
Table 3-7: Dual GPI mode operation .............................................................................................................3-5
Table 4-1: 7700 Series or 5600ACO Upgrade Cable (Evertz part #WA-S76)...............................................4-3

Model 5600ACO Automatic Changeover Unit
OVERVIEW Version 1.5 Page 1-1
1. OVERVIEW
The 5600ACO Automatic Changeover is intended for use with two 5600MSC Master Clock / Sync
Generators. The 5600ACO system uses latching relays to ensure maximum reliability and minimal
disruption in the event of any failure. The complete system provides the highest level of security for
television station video and time synchronization systems. Two power supplies are included as a
standard feature, to alleviate any single point of failure concerns.
The front panel has three switches, recessed into the panel for added security. There is an AUTO /
MANUAL switch, a GPI / FRONT PANEL switch and an A / B select switch for manual changeover. In
automatic mode, all signals from both 5600MSCs are scrutinized to detect any abnormal signals. For
example if a level, pulse width, phase, time code error or other abnormality is detected, the 5600ACO
circuitry will trigger and the entire bank of signals will be switched to the backup 5600MSC. In manual
mode the changeover can be operated from a GPI or from the front panel switch. Twenty-two LEDs
provide status information as to the health of the two 5600MSCs, together with indication as to which
one is active. In addition two GPO outputs indicate which master is active and when the inputs from
both masters are not the same.
The 5600ACO offers connections for 6 colour black, (or bi-level or tri-level sync signals), 10MHz, DARS
and two linear time codes (LTC) to each of the two Master 5600MSCs. Each 5600MSC Master offers
two LTC outputs that may be used for different time codes. All four LTC signals are fed to the 5600ACO
on two 'D' connectors, one for each Master. The LTC outputs from the selected master are available on
two XLR connectors.
Each 5600MSC is equipped with 2 GPI inputs and 2 GPO outputs. To facilitate installation, these
connections are through to a 2 x 6 pin terminal block on the 5600ACO. The outputs from the
5600MSCs are passed straight through the 5600ACO. The inputs to the 5600MSCs are internally split
by a 'Y' connector, to ensure that both 5600MSCs receive the same GPI contact closures.
In the event of a changeover occurrence, it is necessary that all outputs on one 5600MSC have the
same timing as those on the other. Identical timing for both 5600MSCs is assured by locking both to the
same frequency and phase source (e.g. GPS or by genlocking one 5600MSC to the other). Identical
phasing of the independent black outputs is assured by implementing the Syncro mode in the
5600MSCs. To use this mode, both 5600MSC communication ports are connected together using the
link cable supplied with the 5600ACO. With both 5600MSCs operating in Syncro mode, timing
adjustments made to one 5600MSC will be automatically applied to both. The link cable is connected
permanently, so that any system re-timing will be applied to both 5600MSC units.

Model 5600ACO Automatic Changeover Unit
OVERVIEW Version 1.5 Page 1-2
Features:
• Relay switches for all the system critical outputs from two 5600MSC units
• 8 video/sync/DARS or other coaxial signals
• 10MHz frequency reference output
• Time Code outputs
• Automatic changeover is a voting system based on which source has the most valid signals and
that the good signals on the present master are also on the backup.
• Three front panel switches select automatic, front panel or GPI activation of changeover
• Front panel switches are recessed to prevent accidental operation
• 20 Front panel status LEDs show the health of each of the inputs
• 10 Front panel status LEDs show the operational modes of the changeover
• Redundant power supply
AUX I/OGPSCOM
FUSE :
1.0 A
MODEL
5600MSC
ETHERNET
LN ACT 10/100
MODEM
123 45 6
IN LTC OUTOUT
10MHz
DARS / AE S / ANALOG
ANALOG TG OUT AES OUT
BA NK 1 SY NC OUT BAN K 2 SYN C OUT
SDI BLACK
21
2121
TG GENLOCK
MICROSYSTEMS LTD.
MADEIN CANADA SDI TG OUT
21
SD
DARS OU T
SD
SDI TGOUT
HD
SDI BLACK
HD
DA LR
GEN L OC K
10Mhz
6 Timeable
Black Burst DARS
TestSignals
SDI and
HDSDI
Modem
Computer
NTP
TestSignals
AnalogVideo
and Audio
BalancedAudio
GPS
LTC 1
Dual
AC
LTC 1
LTC 2
GPI out for ACO
GPI in/out for MSC
TestSignals
SDIand
HDSDI
Modem
NTP
TestSignals
AnalogVideo
and Audio
BalancedAudio
GPS
LTC 1
Dual
AC
Dual
AC
5600MSC
5600MSC
5600ACO
AUX I/ OGPSCOM
FUSE:
1.0 A
MODE L
5600MSC
ETHERNET
LN ACT 10/100
MODEM
123 45 6
IN LTC OUTOUT
10MHz
DA R S / AE S / A NA LO G
ANALOG TG OUT AES OU T
BANK 1 SYNC OU T BANK 2 SYN C OUT
SDI BLACK
21
2121
TG GENLOCK
MICROSYSTEMS LTD.
MAD E IN CA NA DA SDI TG O UT
21
SD
DARSOUT
SD
SDI TGOUT
HD
SDI BLACK
HD
DALR
GENLOCK
Figure 1-1: Redundant Master Clock/SPG with Auto Changeover System Diagram

Model 5600ACO Automatic Changeover Unit
OVERVIEW Version 1.5 Page 1-3
1.1. HOW TO USE THIS MANUAL
This manual is organized into 4 chapters: Overview, Installation, Operation, and Technical Information.
There are individual tables of contents at the beginning of each chapter as well as an overall table of
contents at the beginning of the manual to aid in finding the information you want.
"This symbol is intended to alert the user to important operating
instructions.
The exclamation point within an equi-lateral triangle is intended to alert the
user to the presence of important safety related operating and maintenance
(Servicing) instructions in this manual.

Model 5600ACO Automatic Changeover Unit
OVERVIEW Version 1.5 Page 1-4
This page left intentionally blank

Model 5600ACO Automatic Changeover Unit
INSTALLATION Version 1.5 Page 2-1
2. INSTALLATION
2.1. REAR PANEL
Figure 2-1: 5600ACO Rear Panel
