1. OVERVIEW
The 7721DD SDI data deembedder extracts data that has been embedded into a 270 Mb/s SDI video
signal by the 7721DE data embedder and outputs it as an RS 232/422 data stream and GPO contact
closures. The data packets are first deembedded from the SDI video then deformatted from AES audio
packets into the original data stream. A data error detection and correction scheme is also applied to
maintain data integrity. At the embedded packet layer, data packets resemble and have the same group
DIDs as embedded audio packets.
Features:
•Automatic detection of 525 and 625 line SDI video input
•Automatic activation of internal 525 or 625 line black video generation at the loss of video input
•Deembedding mechanism based on SMPTE 272M-A
•Share the same group DIDs as for embedded audio, selectable from group 1 to 4
•Channel selection for extracting packetized data from one of four channels within a data group
•Deformats AES audio (sub-frame mode) to generic data content according to SMPTE 337M
•Supports data error detection and correction, or minimum delay mode without correction
•One RS232/422 serial output with automatic baud rate at 9600, 14,400, 19,200, 38,400 or 57,600
•Support serial output with regenerated parity matched to the upstream input
•Support serial output with regenerated BREAK character according to SMPTE 207M
•Six TTL level GPO signals activate when corresponding GPI inputs on 7721DE are activated.
•Clean or pass-through packets after de-embedding
•Removes packets with "Marked packets for deletion" and "Data end marker packet"
•EDH generation on video output
•Card edge LEDs indicate video signal and data presence, cable equalization and module fault.
Equalizer S / P
Audio
Present
Audio Group
Module
Status
Video
Present
Serial Input
270 Mb/s
(SMPTE 259M)
Cable
Driver
P / S
Embedded
Processor
RS232/422 data
and GPI signals
Serial Output
270 Mb/s
with embedded data
De-embedder
and
AES deformatter
Figure 1: 7721DD Block Diagram

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
7721DD-2 Revision 1.4.3
2. INSTALLATION
The 7721DD modules each come with a companion rear plate that has 3 BNCs and a high-density female
DB 15 connector. For information on mounting the rear plate and inserting the module into the frame see
section 3 of the 7700FR chapter.
Figure 2: 7721DD Rear Panel
2.1. VIDEO INPUTS AND OUTPUTS
SDI INPUT Input BNC connector for 10-bit serial digital video signals compatible with the SMPTE 259M
standard.
SDI OUTPUT There are two BNC connectors with reclocked serial component video outputs, compatible
with the SMPTE 259M standard. These outputs contain a reclocked copy of the input video.
The top output is protected by a bypass relay, which will activate in the event of power loss to
the module. The remaining output is not bypass protected.

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
Revision 1.4.3 7721DD-3
2.2. GENERAL PURPOSE INPUTS AND OUTPUTS
The following is the pinout of the female HD DB-15 connector labeled Data Out
DB-15 Name Description
1 GPO 6 GP Output
2 Tx-/Tx RS 422 Tx - / RS-232 TxD output
3 GPO 5 GP Output
4 GPO 3 GP Output
5GND Gnd
6 Rx-/Rx RS 422 Rx- / RS-232 RxD input
7 Tx+/CTS RS 422 Tx+ / RS-232 CTS output
8 GPO 4 GP Output
9GND GND
10 GP +5 General Purpose +5Volts Supply output
11 Rx+/RTS RS 422 Rx+ / RS-232 RTS input
12 GND Gnd
13 GPO 7 GP Output
14 GPO 8 GP Output
15 Vext Ext. Voltage Input to GPIO Circuitry
(input)
Table 1: Data Out DB 15 Connector Pinout
The GPOs are activated when the corresponding GPI inputs on the 7721DE Data Embedder are
avtivated. They can be used to pass simple contact closure information along with the video signal. The
GPOs are active low with an internal pull up (10k Ohm) resistor to the Vext pin. When active, the output
will go low and is able to sink up to 10mA. When inactive, the signal will go high (to the voltage applied to
the Vext pin). Do not attempt to source more than 100µA from the output.
GND
From Internal
Circuit
Chassis
Ground
10k
Ω
GPO
Vext
GP+5v + 5 Volts
Power
OK
500
Ω
Figure 3: Powering the General Purpose Output Opto Isolators from the Module

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
7721DD-4 Revision 1.4.3
The user can connect GP+5V supplied from the frame into the Vext pin to provide power to the GPO opto-
isolator circuitry. In this configuration the GPOs will be internally pulled up to 5 volts. (See Figure 3) Five
volts is available to the user to be used for driving external circuitry. Care must be taken to limit the load
to 0.5W so there is no affect on the power supply source on the module.
Alternately, the user can connect an external power source for the opto-isolator circuitry. The Vext voltage
must be greater than the voltage required by the GPO by at least 5v. Figure 4 shows how to wire the
GPOs from an external power supply.
Warning: Do not connect GP+5V from one module to another module’s
GP+5V.
GND
From Internal
Circuit
Chassis
Ground
10k
Ω
GPO
Vext
GP+5v + 5 Volts
5-50 VDC
n/c
Figure 4: Powering the General Purpose Output Opto Isolators from an External Power
Supply
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standard: SMPTE 259M C – 525 or 625 line component.
Connector: 1 BNC per IEC 169-8
Equalization: Automatic 300m @ 270 Mb/s with Belden 8281 or equivalent cable
Return Loss: > 15 dB up to 270 Mb/s
!

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
Revision 1.4.3 7721DD-5
3.2. SERIAL VIDEO OUTPUTS WITH EMBEDDED DATA
Number of Outputs: 2 (1 output bypass relay protected)
Standard: same as input
Connectors: BNC per IEC 169-8
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 470ps nominal
Overshoot: <10% of amplitude
Return Loss: > 15 dB up to 270 Mb/s
Wide Band Jitter: < 0.2 UI
3.3. DATA OUTPUT
Standard: RS-232 or RS-422 – Jumper Selectable
Connector: Female High Density DB-15
Baud Rate: 9600, 14400, 19200, 38400 or 57600 automatically set from embedded data
Format: 8 bits, parity (none, even or odd), 1 stop bit
3.4. GENERAL PURPOSE OUTPUTS
Number of Outputs: 6
Type: Opto-isolated, active low with internal pull-ups to user supplied voltage.
(provides +5V which may be used for this purpose)
Connector: Female High Density DB-15
Signal Level: +5V nominal
3.5. DE-EMBEDDING DELAY
3.5.1. Video I/O Delay
The video I/O delay is approximately 12µs
3.5.2. Delay For Data De-Embedding - Serial Output
Average latency (µs) +/- 20%
Baud rate Minimum Delay
Mode
Error Detection /
Correction Mode
9600 1600 1900
14400 1300 1600
19200 1100 1400
38400 800 1100
57600 700 1000

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
7721DD-6 Revision 1.4.3
3.5.3. Delay For Data De-Embedding - GPO signals
Average latency (µs) +/- 10%
GPO
Outputs
Minimum Delay
Mode
Error Detection /
Correction Mode
All 800 800
3.6. ELECTRICAL
Voltage: + 12VDC
Power: 6 Watts.
EMI/RFI: Complies with FCC Part 15, class A and EU EMC directive.
3.7. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1
Stand Alone Enclosure:
Dimensions: 14 “ L x 4.5 “ W x 1.9 “ H
(355 mm L x 114 mm W x 48 mm H)
Weight: approx. 1.5 lbs. (0.7 Kg)
4. STATUS LEDS
The location of the status LEDs is shown in Figure 5.
4.1. MODULE STATUS LEDS
MODULE OK This Green LED will be On when the module is operating properly
LOCAL FAULT This Red LED makes it easy to identify one module in a frame that is missing an
essential input or has another fault.
The LED will blink on and off if the microprocessor is not running.
The LED will be on solid when input video is missing, or audio is missing from both
AES inputs or there is a fault in the module power supply.
VIDEO PRESENT This Green LED will be On when there is a valid video signal present at the module
input.
EQ: This Yellow LED will be On when the cable equalizer detects that the cable length is
greater than a preset threshold. (Factory set for 250 meters of Belden 8281 or
equivalent cable). See section 6.4 for information on adjusting the cable equalizer
warning threshold.
DATA PRESENT This Green LED will be On solid when there is a valid data packet in the audio
group selected for de-embedding. This indicator is only valid when input video is
present.

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
Revision 1.4.3 7721DD-7
4.2. AUDIO/DATA GROUP STATUS LEDS
Four LEDs located on the lower end of the module (opposite the DIP switch) indicate the status of the
audio/data groups. Group LED 1 is located closest to the center of the module.
Group
LED
Color Group Status
1Off There is no group 1 audio/data on the video input.
On Group 1 audio/data is present on the video input.
Flashing Group 1 audio/data on the video input is being de-embedded.
2Off There is no group 2 audio/data on the video input.
On Group 2 audio/data is present on the video input.
Flashing Group 2 audio/data on the video input is being de-embedded.
3Off There is no group 3 audio/data on the video input.
On Group 3 audio/data is present on the video input.
Flashing Group 3 audio/data on the video input is being de-embedded.
4Off There is no group 4 audio/data on the video input.
On Group 4 audio/data is present on the video input.
Flashing Group 4 audio/data on the video input is being de-embedded.
Table 2: Group Status LEDs
5. CARD EDGE CONTROLS
The 7721DD is equipped with an 8 position DIP switch to allow the user to select various functions. All
positions are assigned sequentially such that the first position is located at the top of the DIP switch
(farthest from to the card ejector). Sections 5.1 to 5.2 show the assigned DIP switch functions. The On
position is down, or closest to the printed circuit board. Table 3 gives an overview of the DIP switch
functions.
DIP Switch Function
1
2
Audio Group Selection for Data
De-embedding
3
4
Primary Audio Channel Selection within the
selected group for Data De-embedding
5Select internal 525 and 625 line black video
generation
6Select minimum delay or error detection and
correction processing
7 Reserved for future use (default off)
8Select clean all or pass-through de-
embedding
Table 3: DIP Switch Functions

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
7721DD-8 Revision 1.4.3
5.1. SELECTING THE AUDIO GROUP AND CHANNEL WHERE THE DATA WILL BE
DE-EMBEDDED
The SMPTE 272M standard permits up to 4 groups of 4 audio/data channels to be embedded into the 270
Mb/s video bitstream.
The model 7721DD de-embeds one group of audio packets containing data (selected by switches 1 and 2)
onto the Data output port. Switches 3 and 4 select the channel within the group where data will be
extracted from.
DIP 1 DIP 2 Audio Group ID
Off Off 1 (default)
On Off 2
Off On 3
On On 4
Table 4: Audio Group Assignment for Data Extraction Switch Settings
DIP switches 3 and 4 are used to select which channel within the selected group will be the primary
channel where data is extracted from.
DIP 3 DIP 4 Audio Channel
Off Off 1 (default)
On Off 2
Off On 3
On On 4
Table 5: Audio Channel Assignment for Data Extraction Switch Settings
5.2. SELECTING LINE STANDARD OF THE INTERNAL BLACK VIDEO SOURCE
DIP switch 5 is used to select the default line standard of the internal black video source at the loss of
video input.
DIP 5 Line Standard
Off 625 lines
On 525 lines
Table 6: Default Line Standard Selection Switch Settings
5.3. SELECTING MINIMUM DELAY OR ERROR DETECTION AND CORRECTION MODE
DIP switch 6 controls whether the data deembedder will perform error detection and correction as it de-
embeds the data. Data verification causes a data error detection and correction scheme to be applied to
the extracted data to maintain data integrity. When data verification is enabled, there is an additional
delay before the extracted data can be sent to the data output serial port.

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
Revision 1.4.3 7721DD-9
DIP 6 FUNCTION DESCRIPTION
Off Minimum
Delay Mode
Extracted data is passed through to the data output port with
minimum delay.
On Data
Verification
Mode (default)
Data error detection and correction is performed before data is
sent to the data output port. This mode requires additional delay
before the data is available on the output port.
Table 6: Data Verification Mode Switch Settings
5.4. SELECTING WHETHER EXISTING AUDIO/DATA WILL BE REMOVED
DIP switch 8 controls whether existing audio/data packets will be passed or removed from the video
stream.
DIP 8 FUNCTION DESCRIPTION
Off Clean De-embed incoming audio/data packets with the group ID selected
by DIP switches 1 & 2. Removes all audio/data packets. The H
blanking period after EAV is filled with the default blanking value.
On Pass
(default)
De-embed and remove incoming audio/data packets with the
group ID selected by DIP switches 1 & 2. Left justify remaining
packets.
Table 7: Embedded Audio Cleaning Switch Settings
6. JUMPERS AND USER ADJUSTMENTS
MODULE STATUS
SIGNAL PRESENT
EQ
SFF POWER +12V
Run
Upgrade
J16
J24
J22
FRAME
STATUS
ON
OFF
EVERTZ (A) 7700PB2
EQ
WARNING
J8
GND
DATA
J17J18
Figure 5: Location of Jumpers on 7700PB2 Boards

7700 MultiFrame Manual
7721DD Serial Digital Data De-Embedder
7721DD-10 Revision 1.4.3
6.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
FRAME STATUS The FRAME STATUS jumper located at the front of the module determines whether
local faults (as shown by the Local Fault indicator) will be connected to the 7700FR
frame's global status bus.
To monitor faults on this module with the frame status indicators (on the PS FRAME
STATUS LED's and on the Frame's Fault Tally output) install this jumper in the On
position. (Default)
When this jumper is installed in the Off position, local faults on this module will not
be monitored.
6.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES
UPGRADE The UPGRADE jumper J16 located at the front of the module is used when firmware
upgrades are being done to the module. For normal operation it should be installed
in the RUN position. See the Upgrading Firmware section of this manual for more
information.
To upgrade the firmware in the module unit pull it out of the frame. Move Jumper
J16 into the UPGRADE position. Install the Upgrade cable provided (located in the
vinyl pouch in the front of this manual) onto header J24 at the card edge. Re-install
the module into the frame. Run the upgrade as described in the Upgrading
Firmware section of this manual. Once the upgrade is completed, remove the
module from the frame, move J16 into the RUN position, remove the upgrade cable
and re-install the module. The module is now ready for normal operation.
6.3. CONFIGURING THE SERIAL PORT FOR RS 232 OR RS 422 OPERATION
J17 Jumper J17 located at the side of the module is used to select whether the serial
port receiver/driver hardware is configured for balanced RS422 or RS232 with flow
control. For RS 422 operation install jumper J17. For RS 232 operation remove
jumper J17. For convenience you may re-install the jumper so that only one side is
connected.
6.4. SETTING THE EQUALIZER WARNING THRESHOLD
The Cable Length Warning Adj trimpot located near the Signal Present LED is used to set the threshold of
the cable equalizer warning. The equalizer warning is factory set to 250 meters of Belden 8281 cable, but
may be adjusted for other cable types or cable lengths. To adjust the cable equalizer warning threshold,
connect a signal to the input of the module using the required length of cable. Adjust the trimpot slowly
until the Equalizer warning LED comes on. You can verify that the equalizer warning is operating correctly
by removing a few meters of cable from the input. The LED should go off.
