Evoaq Aq60 User manual

EVOAQ

Air Quality Innovation

Home Ventilation

Installation Manual

Please take the time to read these instructions in full before

commencing your installation.

Careful planning prior to starting work will guarantee the

fastest and best results regarding the installation.

Working in the ceiling space can be a hazard, and all

safety precautions should be used to ensure the

safety of yourself and any others.

System Models

AQ60, AQ220, AQ300

Software Version

V3.2

Manual Version

V3.5.0 10-2023

Standard

Ventilation

Installation Manual

EVOAQ Standard Home Ventilation

Thank you for your purchase of our company’s product. It has been manufactured following

current technical safety regulations and is in compliance with AS/NZ60335 standard.

Please read this instruction booklet carefully before installing or starting up the

product.

It contains important information on personal and user safety measures to be followed while

installing, using, and carrying out maintenance work on the equipment. Once the product

has been installed, please hand this booklet to the end user.

The fan included with this ventilation system is designed as simply plug in and go

without requiring user intervention.

The smart in-built electronics are constantly monitoring the incoming air quality. The fan will

vary its speed between very low and very high rates (10 - 100%) depending on air quality

and the operating mode to maintain a comfortable and moisture-free indoor environment.

This system is capable of ventilating at very low rates while still bringing in enough fresh air

into the house in situations where other systems would simply switch off. Maintaining correct

ventilation of the house is important in order to prevent heat and energy losses and to allow

you to enjoy a healthier indoor environment.

INSTALLATION OVERVIEW

Before commencing installation, select a suitable place for the fan to be installed in the

ceiling cavity. It is recommended to place the filter and fan near the manhole for easy access

when carrying out maintenance to the system. Place the filter before the fan to protect the

fan from dust and dirt buildup. Suspend the fan from the ceiling framing with the chain and

cable ties provided in order to minimise the sound levels resonating through the ceiling

framing.

If the system will be taking air from outside or the fan or air inlet is installed in external

walls, care must be taken to avoid the backflow of gases into the system from gas califonts,

open gas flues, or other open-fire appliances.

Attach the inlet side of the fan to the filter frame using the duct tape provided. Connect the

acoustic ducting to the outlet of the fan. The acoustic ducting should be 1-1.5m long and

placed after the fan to eliminate sounds from the fan motor inside the ducting system.

Spending time planning the layout of the ducting system is important. See the inside page

of this instruction manual for further details and example layouts.

Some simple rules to apply to ensure the best possible results:

•

If a wall controller is included with the system, this is connected to the fan via the supplied

network cable. The controller is low-voltage only, however to prevent any damage to both

the fan and controller, please ensure that the fan is disconnected from the mains supply

before connecting the controller.

Please note:

The inlet of the fan unit is on the side of the fan blades, the side that is not obstructed by

the fan frame. There are also arrows on the unit and rating label showing airflow direction.

Please be aware that the system is designed for air to flow from the filter, through the fan,

and into the house. Ensure the fan is oriented correctly for this during installation.

Important information for the safety of installers and user:

Installation must only be carried out by qualified persons. Make sure that the installation

complies with the applicable building and electrical regulations. This apparatus must not be

used in explosive or corrosive atmospheres.

This appliance is not intended for use by young children or infirm persons unless they have

been adequately supervised by a responsible person to ensure that they can use the

appliance safely. Young children should be supervised to ensure that they do not play with

the appliance.

TRANSPORT AND MANIPULATION

The packaging used for this apparatus has been designed to support normal transporting

conditions. The apparatus must always be transported in its original packaging as not doing

so could deform or damage the product. Do not place heavy weights on the packed product

and avoid knocking or dropping it.

The product should be stored in a dry place in its original packaging, protected from dust

and dirt until it is installed in its final location. Do not accept delivery if the apparatus is not

in its original packaging or shows clear signs of having been manipulated in any way.

Check that the apparatus is in perfect condition while unpacking. Any fault or damage

caused in origin is covered by our company guarantee. Please make sure that the apparatus

coincides with the product you have ordered and that the details on the rating label fulfil

your requirements.

ELECTRICAL CONNECTION

The ventilation fan must be connected to a single-phase mains network, with the specific

voltage and frequency according to the specifications on the fan rating label and in

accordance with New Zealand electrical standards.

If the fan model you have purchased is fitted with a power plug then please note removing

this plug will void the warranty of the fan.

In case of damage to the power plug, cord, or device itself, switch off the device and do not

tamper with it. Damaged product must only be repaired or replaced exclusively by the

manufacturer or by an appointed representative. Failure to comply with the above may

endanger the safety of people and cause possible damage to the whole system.

SAFETY DURING INSTALLATION

Make sure there are no loose elements near the fan, as they could run the risk of being

sucked up by it. When connecting the fan to the ducting, check that the ducting is clean of

any element that could be sucked up by the fan. When installing the fan, make sure that all

the fittings are in place and that the structure which supports it is resistant enough to bear

its weight at full functioning power.

Before installing the fan, make sure the mains supply is disconnected, even if the system is

switched off.

FAN INSTALLATION

Some things to consider when installing the fan and the filter:

•

The fan should fit on the filter directly and does not require any ducting to be placed in

between. However if the construction of the roof does not provide enough space to mount

the fan directly onto the filter, you can use a short piece of ducting (recommended length

<500mm) to connect between the two. This ducting does not have to be acoustic ducting.

STARTING UP THE FAN

Fans may have delayed startup, or may operate under the control of the inbuilt controlling

electronics included with the fan. Always take extreme care as the fan may start

unexpectedly. Before carrying out any maintenance, make sure the mains supply is

disconnected, even if the machine is switched off. Never insert your hands into the inlet side

of the fan without first unplugging the fan.

Before starting up the fan, ensure that:

•

When starting up the fan, ensure that:

•

If the circuit protection device is tripping during operation, the apparatus must be quickly

disconnected from the mains supply. The whole installation should be carefully checked

before trying to start up the machine again.

MAINTENANCE AND REPAIR

Before servicing the fan, make sure it is disconnected from the mains supply - even if it has

previously been switched off. Avoid the risk of anyone else plugging it in while you’re

working on it.

The fan must be regularly inspected. These inspections should consider the fan’s working

conditions, ensuring no dirt or dust builds up on the propeller, turbine, motor or grilles. This

could be dangerous and perceptibly shorten the fan’s lifespan. While cleaning, take extra

care not to damage the propeller. The filters should be checked at least every 12 months, and

replaced at least every 2 years, or earlier if necessary. Any and all maintenance work should

be carried out in strict compliance with New Zealand safety regulations.

All our products contain repairable or replaceable parts. Repair or replacement of these parts

should only be handled by the manufacturer. In the case of damage or malfunction of the

fan, please contact the manufacturer or installer to arrange for repair. Please note that a

small fee may apply for repair services not covered under warranty.

SYSTEM WIRING

This system should be permanently powered via the ventilation fan. The ventilation fan is

fitted with a power plug; if there is no power point available for the fan one should be

installed by a registered electrician. The wall controller is connected to the fan via a network

cable; as this cable is low-voltage it does not need to be wired by an electrician.

SYSTEM WIRING (CONTINUED)

If your system includes add-ons such as an EVOAQ Summer Upgrade Kit please note that

wiring may differ from the below image; please refer to the respective upgrade kit manual

for correct wiring.

For further information, please contact EvolutionFX NZ Limited

email: info@evolutionfx.co.nz

phone: +64 9 558 5590

EVOAQ

Air Quality Innovation

EVOAQ Home Ventilation

Page 2 www.evoaq.co.nz

Place the filter and fan near the manhole for easy access;

Lay the ducting so there is a similar length of ducting to each diffuser where possible;

Ensure the shortest length of ducting is no shorter than 3 metres;

Avoid tight bends in the ducting;

Ensure the ducting is stretched out fully. Cut the ducting where needed;

Avoid installing the ducting where it may be crushed or damaged by you or other

tradespeople;

Avoid installing the diffusers near doors/hallways and directly above beds or

couches.
