Evonicfires E1030ds Manual

Important Safety Informaon
Always read this manual rst before aempng to install or use this
replace. For your safety, always comply with all warnings and safety
Instrucons contained in this manual to prevent personal injury or property
damage.
Please Note: This product is for well insulated spaces or
occasional use.
E1030ds -
Instrucon Guide

welcome to evonicres
evonicres is an award-winning brand of CK Fires Ltd, situated just outside Straord-
upon-Avon, we manufacture a range of Brish built electric res and are considered as
one of the most technically advanced manufacturers in the world, with oponal
controllers such as e-touch and a fully integrated APP available to download on both
or .
This guide is designed to aid in the installaon and connued performance of this
product. This product conforms with all health, safety, and environmental protecon
standards as indicated by a CE mark. For opmum performance this product requires
a well insulated locaon or occasional use.
Contents
1. Introducon 2
2. Important Instrucons 3/4
3. Installaon Requirements &
Product operaon 5/6
4. Installaon Method 7/8
6. E-Touch & App Template 9
7. Glass Removal 10
8. Troubleshoong & Specicaon 11
9. Warranty 12
2.

IMPORTANT INSTRUCTIONS:
When using electrical appliances, basic precauons should always be fol-
lowed to reduce the risk of re, electric shock, and injury to persons,
including the following:
① Read all instrucons before using this electric replace.
② This replace is hot when in use. To avoid burns, do not let bare skin
touch hot surfaces. The trim around the heater outlet becomes hot dur-
ing heater operaon. DANGER: High temperatures may be generated
under certain abnormal condions. Do not parally or fully cover or ob-
struct the front of this heater.
③ Extreme cauon is necessary when any heater is used by or near chil-
dren or people of reduced mobility and whenever the unit is le operang
and unaended.
④ Young children should be supervised to ensure that they do not play
with the appliance.
⑤ The appliance is not intended for use by young children or inrmed
persons without supervision.
⑥ In the event of a malfuncon, disconnect power at the service panel
and have the unit inspected by a reputable electrician before reusing.
⑦ If the supply cord is damaged, it must be replaced by the manufactur-
er, or its service agent, or a qualied person in order to avoid a hazard.
⑧ Do not use outdoors.
⑨ Never locate replace where it may fall into a bathtub or other water
container.
⑩ To disconnect the replace, turn the controls o, and turn o power to
heater circuit at main disconnect panel.
⑪ Do not run the cord under carpeng. Do not cover cord with throw
rugs, runners, or the like. Arrange cord away from trac area and where it
will not be tripped over.
⑫ Do not locate the heater immediately below a xed socket-outlet.
3.

㉑ Always use properly grounded, fused and polarized outlets.
㉒ Disconnect all power supply before performing any cleaning,
maintenance or relocaon of the unit.
㉓ When transporng or storing the unit and cord, keep in a dry
place, free from excessive vibraon and store so as to avoid
damage.
NOTE: Changes or modicaons not expressly approved by the
party responsible for compliance could void user's authority to
operate the equipment.
4.
⑬ Do not insert or allow foreign objects to enter any venlaon
or exhaust opening as this may cause an electric shock or re, or
damage to the heater.
⑭ To prevent a possible re, do not block air intakes or exhaust
in any manner.
⑮ All electrical heaters have hot and arcing or sparking parts
inside. Do not use in areas where gasoline, paint, or ammable
liquids are used or stored.
⑯ Use this replace only as described in this manual. Any other
use not recommended by the manufacturer may cause re, elec-
tric shock or injury to persons.
⑰ Do not change the plug in any way. Always plug heaters di-
rectly into a wall outlet/receptacle. Never use with an extension
cord or relocatable power tap (outlet/power strip).
⑱ Do not burn wood or other materials in the electric replace.
⑲ Do not strike the replace glass.
⑳ Always use a cered electrician should new circuits or out-
lets be required.

INSTALLATION REQUIREMENTS:
Review and consider all of the following condions before installaon:
This appliance must only be connected to a 230/240 Volts AC 50Hz supply. Before connecng
the re, check that the supply voltage is the same as stated on the re. This appliance must
only be used on a AC supply, fuse rang 13Amp.
The wires in the mains lead are coloured in accordance with a standard UK supply, these
being:
GREEN/YELLOW – EARTH
BLUE – NEUTRAL
BROWN – LIVE
Ensure the power cord is not installed so that it is pinched or against a sharp edge and ensure
that the power cord is stored or secured to avoid tripping or snagging to reduce the risk of
re, electric shock or injury to persons. Construcon and electrical outlet wiring must comply
with local building codes and other applicable regulaons to reduce the risk of re, electric
shock and injury to persons.
WARNING: To reduce the risk of re, do not store or use gasoline or other ammable vapours
or liquids in the vicinity of the heater.
1. Select a locaon that is not suscepble to moisture and is away from drapes, furniture
and high trac.
2. For ease of electrical hook up you may wish to locate the replace near an exisng
outlet (for plug-in convenience).
3. Remove electric replace, front glass and hardware from the box and remove all
packaging materials before installaon.
4. Store the replace in a safe, dry and dust free locaon unl you are ready to install the
replace.
5.

Grounding Instrucons:
This product must be grounded. If it should malfuncon or breakdown,
grounding provides a path of least resistance for electric current to reduce the
risk of electric shock.
This product is equipped with a cord having an equipment-grounding conduc-
tor and a grounding plug. The plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and
ordinances.
DANGER: Improper connecon of the equipment-grounding conductor can
result in a risk of electric shock. Check with a qualied electrician or service-
man if you are in doubt as to whether the product is properly grounded. Do
not modify the plug provided with the product – if it will not t the outlet,
have a proper outlet installed by a qualied electrician.
WARNING: Do not aempt to wire your own new outlets or circuits. To reduce
the risk of re, electric shock or injury to persons, always use a licensed electri-
cian.
6.
HEATER UNIT CUT OUT—This is a safety feature to safe guard against further
damage to the product.
If the airow is restricted the heater will automacally turn o. This can occur
due to incorrect installaon or obstrucon. To reset the heater funcon;
• Isolate from main power supply
• Leave product to cool
• Aer suitable cooling down period, remove the obstrucon if obstructed
and check installaon
• Aer 10 minutes the thermo switch (cut-out) in the heater will reset.
Please note that both the eect fan and heater fan omit a low decibel noise,
both of which are normal operang characteriscs.
The appliance is operated by the e-touch App, the main standby power switch
to the e-series product is located to the right of the heater outlet, which is
marked with a light bulb image, to acvate the product, this switch must be
switch to the “ON” posion.
The rst me the e-series product is acvated both the illuminaon and heater
will funcon, to switch the heater “O” simply reduce the Room Temperature
down to 10 degrees on the App control.

Installaon Method
This product is designed to be assembled into our E-mod installaon
units or an exisng ue or suitable wall space.
Please seek advice from a professional, with reference to the
structural integrity of the installaon site.
if the products is to be installed into a open chimney or ue, it is
important that the chimney/ue is blocked o to prevent any up/
down draughts and falling debris which could restrict and alter the
airow to the product.
It is also important to ensure that the product has a minimum internal
clearance directly above and below the product of 100mm, this is to
ensure that the product can circulate the required airow for the
heater unit.
The product should never be sealed into a opening with the use of
silicones or adhesives as this can also alter the airow and hinder any
further servicing of the product.
If being installed into an E-mod, it is important to follow the E-mod
instrucons prior to installing the replace. This is to ensure the
replace is being ed into the correct secon of the E-mod.
The replace is also available in GF3 or GF4 models. You will need to
idenfy which model you are installing to ensure successful ng of
the appliance.
7.
1. In order to successfully install
this appliance, you must rst
make sure the plaster kit is
properly assembled onto the
re . This is to ensure the main
body of the re can rest
suitably onto a ledge and hold
the weight of the re.
Fig 1 shows the locaon of both the
side plaster kits and the front plaster
kit.
Fig 1.

Fig 2 shows the re
ed into an E-mod as-
sembly. Idened are
the plaster kit sides, and
how they are used to
support the body of the
re in place.
Fig 2.
Fig 3.
Fig 3 indicates the top
secon of the plaster
kit. Once the re has
been ed into place,
the top plaster kit is
used to support the E-
mod case that sits
above the re.
8.

E-Touch & App Template
The Appliance is operated using the E-Touch App Control.
The App Control can be used on either OS or Android operang systems.
To obtain the App please visit either the OS App Store Or Google Play and follow
the on screen instrucons.
Screen shot taken from Apple App Store. Home Screen shot taken from E-Touch App
13.

Glass Removal:
1. Remove the 2 screws
located in the boom glass
retaining bar. Repeat this
process on either side of
the re.
2. Remove the boom glass
retaining bar. Again, repeat
this on both sides of the re.
3. Remove the glass by pulling
the second retaining bar away
from the body of the re.
Ensure that the glass is
supported at all mes. A
sucon cup has been provided
to aid with this step.
Please note: The sucon cup is
provided for support only, not
to hold the full weight of the
glass.
Please note: It is
recommended that this step is
carried out by 2 persons.
4. Once the front glass
is removed
successfully, slide the 4
side glass panels
downward to remove .
14.

Problem solving
• No power to the re: Check the wall socket, plug and fuse.
• No illuminaon: Make sure the re is turned on. Check
heater is working, if so check that the dimmer control is set
to full on the e-touch app/e-touch controller.
• Illuminaon but no heat: The safety cut has operated see
note on operang the Fire.
• Noise when illuminated: Due to moving parts, the electric
re will make a noise.
• Noise from the heater when in use: The sound of rushing
air is normal.
• Reporng a fault: If a product is encountering a fault with
the operaon and a service engineer is required, please
visit : www.evonicres.co.uk and complete the elds re-
quired under the Report a Fault secon. Please refer to
the terms of your warranty.
MODEL WIDTH DEPTH HEIGHT
e1030DS 1002mm 500mm 556mm
Technical Specicaon
15.
E-MOD SPEC WIDTH DEPTH HEIGHT
E-MOD 1 1050mm 305mm 420mm
E-MOD 2 1050mm 305mm 470mm

Condions of warranty:
If this appliance should prove to be defecve due to faulty de-
sign, materials or workmanship within 12 months of purchase,
the product will be repaired free of charge, subject to the
following condions:
The electric re shall have been purchased and used solely
within the UK and Ireland for domesc purposes and in ac-
cordance with the Users operang instrucons.
It is the purchasers responsibility to prove that the unit is un-
der warranty, e.g. receipt of purchase.
All warranes, will be invalidated if unauthorised repairs or
modicaons are made to the electric re, or in case of acci-
dent, misuse or damage caused by improper installaon, or to
damage occurring during transit to or from the repairer and
altered or missing serial numbers.
Any parts, which have been replaced under this warranty, shall
become our property.
The company shall not be liable for any consequenal loss or
damage what so ever, arising from or in connecon with this
electric re.
This Warranty does not apply to Heang elements, Bulbs or
fuses.
‘No fault found’, service calls and installaon errors are not
covered under the manufacturers warranty and will result in a
charge being made for the Call-Out by our appointed service
engineer.
Registering product:
To register a product please visit: www.evonicres.co.uk
and complete the elds required under the Register a Prod-
uct Secon. By registering your appliance, an extra 12
months is added to your warranty
CK Fires Ltd / Evonic Fires
1 Evonic house, Clifford park, Clifford lane, Stratford-Upon-
Avon, CV37 8HW
Tel: [phone] Fax: [phone]
16.
