Evonicfires Stora DS User manual

1
DOUBLE SIDEDDOUBLE SIDED
Evoflame & E-SmartEvoflame & E-Smart
INSTRUCTION MANUALINSTRUCTION MANUAL
Stora DSStora DS
Lindstrom DSLindstrom DS
EnglishEnglish
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

2
CONTENTS
EU Directives and UKCA Standards......................................................................3
Important Information and Health & Safety........................................................... 4
Components for Evoflame & E-Smart................................................................... 5
Installation........................................................................................................... 6
Model Dimensions...................................................................................... 7
Requirements and Checks.......................................................................... 8
Installation................................................................................................. 9
Log Layouts......................................................................................................... 11
Installing/Removing the Front Glass......................................................................13
Troubleshooting................................................................................................... 14
Warranty & Registration........................................................................................16
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

3
All Evonic Fires products are in conformity with the relevant UK Statutory InstrumentsAll Evonic Fires products are in conformity with the relevant UK Statutory Instruments
(and their amendments).(and their amendments).
2016 No. 1101 The Electrical Equipment (Safety) Regulations 20162016 No. 1101 The Electrical Equipment (Safety) Regulations 2016
2016 No. 1091 The Electromagnetic Compatibility Regulations 20162016 No. 1091 The Electromagnetic Compatibility Regulations 2016
2012 No. 3032 The Restriction Of Use Of Certain Hazardous Substances In2012 No. 3032 The Restriction Of Use Of Certain Hazardous Substances In
Electrical And Electronic Equipment Regulations 2012Electrical And Electronic Equipment Regulations 2012
EU DIRECTIVES
All Evonic Fires products meet the requirements of the EC Directives.All Evonic Fires products meet the requirements of the EC Directives.
These directives have been met by compliance with the following standards:These directives have been met by compliance with the following standards:
EU 2011-65/EU 2015/863 Restriction of Hazardous Substances.EU 2011-65/EU 2015/863 Restriction of Hazardous Substances.
References to the relevant designated standards used:References to the relevant designated standards used:
EN 55014-1:2006 + A1:2009 + A2:2011 Electromagnetic Compatibility.EN 55014-1:2006 + A1:2009 + A2:2011 Electromagnetic Compatibility.
EN 55014-2:2015 Electromagnetic Compatibility.EN 55014-2:2015 Electromagnetic Compatibility.
EN 61000-3-2:2014 Electromagnetic Compatibility (EMC). Limits. Limits forEN 61000-3-2:2014 Electromagnetic Compatibility (EMC). Limits. Limits for
Harmonic Current Emissions.Harmonic Current Emissions.
EN 61000-3-3:2013 Electromagnetic Compatibility (EMC). Limits. Limitation ofEN 61000-3-3:2013 Electromagnetic Compatibility (EMC). Limits. Limitation of
Voltage Changes, Voltage Fluctuations and Flicker.Voltage Changes, Voltage Fluctuations and Flicker.
EN 60335-1:2012 + A11:2014 Household and similar electrical appliances - SafetyEN 60335-1:2012 + A11:2014 Household and similar electrical appliances - Safety
EN 60335-2-30:2009+A11:2012 Household and similar electrical appliances. Safety.EN 60335-2-30:2009+A11:2012 Household and similar electrical appliances. Safety.
Particular requirements for room heatersParticular requirements for room heaters
UKCA STANDARDS
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

4
IMPORTANT INFORMATION AND HEALTH & SAFETY
When using electrical appliances, basic precautions should always be followed to reduce
the risk of fire, electric shock, and injury to persons, including the following:
• Read all of the instructions carefully before using the appliance, only use this appliance
as described in this manual. Any other use not recommended by the manufacturer mayAny other use not recommended by the manufacturer may
cause injury to persons, or damage to the appliance.cause injury to persons, or damage to the appliance.
• Remove all packaging and dispose of it at an appropriate recycling facility.
•• When transporting or storing the appliance and power lead, keep in a dry place, awayWhen transporting or storing the appliance and power lead, keep in a dry place, away
from excessive vibration and store so as to avoid damage.from excessive vibration and store so as to avoid damage.
• This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot
surfaces. The trim around the heater outlet becomes hot during heater operation.
DANGER: High temperatures may be generated under certain abnormal conditions.
• Do not install this appliance immediately in front of a fixed socket outlet.
• Do not install this appliance in the immediate surroundings of a bath, shower,
swimming pool or any other area where the appliance could come into contact with
water or humidity, e.g. a bathroom.
•• Do not use in areas where gasoline, paint, or any flammable liquids are used or stored.Do not use in areas where gasoline, paint, or any flammable liquids are used or stored.
• This appliance is only suitable for indoor use, do not use outdoors.
• Do not cover the appliance, or let the air inlet/outlet to be obstructed in any way as it
may overheat.
• Keep the power lead away from hot surfaces and the heater outlet. Do not route the
power lead in front of the appliance, or under any carpets or rugs.
• A maintenance hatch must be installed into the surrounding installation to allow future
access.
• Always use a certified electrician should new circuits or outlets be required. And
always use properly grounded, fused and polarised outlets.
• Where the power lead passes through any masonry wall, stone surround etc. ensure
that suitable rubber bushes are fitted at any possible wear points.
• If the power lead is damaged do not use the appliance until it has been replaced.
• Do not use any external switching device, timers, or extension leads. Do not connect
the appliance to a circuit that is frequently switched on and off by the utility.
•• In the event of a malfunction, switch off the appliance, and disconnect it from theIn the event of a malfunction, switch off the appliance, and disconnect it from the
mains power supply. Have the appliance inspected by a certified electrician beforemains power supply. Have the appliance inspected by a certified electrician before
reusing.reusing.
• Do not use the appliance if it is damaged. In the event of any damage to the appliance,
please contact the retailer from whom the appliance was purchased.
• Any repairs must only be performed by a certified electrician.
• Extreme caution is necessary when any heater is used by, located near children or
people of reduced mobility, and whenever the unit is left operating and unattended.
• Young children should be supervised to ensure that they do not play with the appliance.
•• Disconnect from the power supply before performing any cleaning, maintenance orDisconnect from the power supply before performing any cleaning, maintenance or
relocation of the unit. Do not use steam cleaners, or aerosols near the appliance.relocation of the unit. Do not use steam cleaners, or aerosols near the appliance.
• Do not burn wood or anything else in this appliance.
• Do not strike the glass.
• Do not drill or screw any new holes into the appliance.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

5
COMPONENTS
ModelModel
Log Sets & QuantityLog Sets & Quantity
Glass Stones Clear &Glass Stones Clear &
AmberAmber
BlackBlack
VermiculiteVermiculite
SuctionSuction
LifterLifter Electrical LeadElectrical Lead E-Series InstructionE-Series Instruction
ManualManual
WoodlandWoodland
or Silver Birchor Silver Birch
Lindstrom DSLindstrom DS 4 x large4 x large 4 x Clear4 x Clear
4 x Amber4 x Amber 5 x5 x 1 x1 x 1 x1 x 1 x1 x
Stora DSStora DS 4 x small4 x small 2 x Clear2 x Clear
2 x Amber2 x Amber 4 x4 x 1 x1 x 1 x1 x 1 x1 x
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

6
INSTALLATIONINSTALLATION
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

7
MODEL DIMENSIONS
Scan the QR code for more detailed specification drawings.
Model Width Height Depth
Overall unit
(A)(A)
Overall unit
(B)(B)
Openings
(C)(C)
Overall unit
(D)(D)
Lindstrom DS 1056mm 558mm 355mm 530mm
Stora DS 864mm 1208mm 1002mm 535mm
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

8
Before installing the appliance please read
and take into account the following impor-
tant requirements;
• Consult a qualified professional to check
the structure of the installation site.
• The appliance must not be installed any-
where that it may come into contact with
water, i.e. a bathroom.
• Do not use silicones or adhesives to seal
in the appliance, and do not apply wet
plaster directly to the appliance.
INSTALLATION REQUIREMENTS
INSTALLATION
CHECKS BEFORE INSTALLATION
We recommend turning on the appliance
before installation, connect the appliance to
a power source using the provided electrical
lead, and depress the right side of the rocker
switch.
Remove the electrical lead from the wall and
continue with the installation.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

9
TOOLS REQUIRED
• Tape Measure
• Pencil
• Spirit Level
• Screwdriver
• PZ2 Screw Bit
INSTALLATION STEPS
1Remove the two bottom mounted transit brackets from both sides. You will not
need these for the installation.
2
Determine the finished height and position that you want the appliance to
be located. Build your base support taking into consideration the 50mm
ventilation gap under the appliance. Then place the appliance onto the support
and check that it is well supported.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

10
3Your plasterboard can now line up with the plaster kits on the edge of the
appliance.
4Your installation is now complete and you can set up your logs.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

11
LOG LAYOUTSLOG LAYOUTS
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

12
LOG LAYOUTS
When you have your appliance installed you can set up your log sets. If your model
comes with Chippings, Glass Stones and/or Vermiculite lay this on the fuel bed first, then
continue with laying out your logs. The following images show an example of how you
could lay them out.
4 x Small Woodland / Silver Birch
Stora
4 x Large Woodland / Silver Birch
Lindstrom
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

13
INSTALLING / REMOVING THE FRONT GLASS
1Unscrew and remove the glass retainer panel.
2Apply the Suction Lifter to the glass and place the bottom edge in first, then
angle the top edge into the appliance. Then replace the top retainer panel.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

14
TROUBLESHOOTINGTROUBLESHOOTING
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

15
Evoflame Only - LED Strip Replacement
Scan the QR code to be taken to a video in our maintenance series.
Please note; this video shows an old method of removing the front
glass panel. Refer to page 25 for the new method.
Fan Re-setting & Replacement
Scan the QR code to be taken to a video in our maintenance series.
Please note; this video shows an old method of removing the front
glass panel. Refer to page 25 for the new method.
Heater Access & Replacement
Scan the QR code to be taken to a video in our maintenance series.
Please note; this video shows an old method of removing the front
glass panel. Refer to page 25 for the new method.
E-Smart Only - E-Smart LED Replacement
Scan the QR code to be taken to a video in our maintenance series.
Please note; this video shows an old method of removing the front
glass panel. Refer to page 25 for the new method.
REPORT A FAULT
If you have any difficulties or problems with your appliance then please get in touch so
that we can assist you. Please scan the QR code to be taken to our websites Report a Fault
page, we will then be in touch with you shortly.
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12

16 EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12
WARRANTY
Evonic Fires 5-year warranty – 1 year parts & labour + 4 years parts supplied.
The above warranty terms and conditions, as of 1st May 2022, are applicable for all relevant
products purchased after this date. Appliances despatched prior to this date will have an alternative
warranty as set out within the Installation and User Instructions that was supplied with the product,
this was usually a standard 2-year warranty.
To receive your Extended Warranty your Evonic Fires product must have been purchased from
an authorised stockist within our Retailer Network and your warranty registered with Evonic Fires
through the online form - evonicres.co.uk/register-your-product. The commencement date for
the warranty period is the date of purchase.
The product must be adequately serviced and maintained. Evonic Fires provide maintenance call
outs at a cost, and information on this can be obtained by contacting our head o󰀩ce. Please see
your Evonic Installation Instructions for further information on how to service and maintain your
appliance.
During your extended warranty period, only parts supplied or authorised by Evonic Fires can be
used to repair your replace, and these spare parts can be obtained by contacting our service
department at service@evonicres.co.uk or calling 01789 263868.
Consumable items such as glass, screens, LED’s, LED boards, lters and power supplies which
are either subject to normal wear and tear or parts that require replacement in connection with
normal maintenance are not covered within the extended warranty. These items are covered for
the rst 12 months.
To make a warranty claim, evidence must be supplied to our service department in the form of
pictures, videos, or both. Failure to supply evidence to support your warranty claim may invalidate or
delay the claim. Any visit by an Evonic Fires engineer will incur a service charge after the rst year.
We will not accept or reimburse the cost(s) of any third party who undertakes any work carried out
on the product or ts parts, unless we have approved such work in advance of it being carried out.
WARRANTY EXCLUSIONS AND LIMITATIONS
The Evonic Extended Warranty does not cover:
1. Damage resulting from installation and usage where the appliance has not been installed
or used in accordance with the CK Fires Ltd installation and operation instructions, or if the
installation does not conform to local building, re, and safety regulations.
2. Issues with mains/spur connections of power supply.
3. Damage resulting from the product not being adequately maintained. (Please see your CK
Fires Ltd Installation and Operating Instructions for further information on how to service and
maintain your appliance).
4. Damage caused by unauthorised modications, use or repair.
5. Damage or defects caused by the product being stored in a damp, unheated environment.
6. Consequential loss (to the extent permitted by the law) relating to other associated products
that have not been supplied by CK Fires Ltd.
7. Consequential loss (to the extent permitted by law) related to decorations, furnishings, or
other household assets.
8. Removal and re-installation costs.

17
EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1EVONIC - 104 INSTRUCTION MANUAL TEMPLATE ISS. 1 DS ISS. 12DS ISS. 12
CK Fires Ltd / Evonic Fires
1, Evonic House, Clifford Park, Clifford Lane,
Stratford-on-Avon, CV37 8HW
Tel: [phone] Fax: [phone]
Email: [e-mail]
www.evonicfires.co.uk
Follow us on:
Instagram | Facebook | Twitter | LinkedIn
@evonicfires
WARRANTY EXCLUSIONS AND LIMITATIONS
Repaired or replaced products are covered only for the remainder of the original warranty period.
In the event of a claim being made, this must be reported to your retailer or CK Fires Ltd within 14
days of the fault occurring/being noticed. In the event of a product fault occurring during the
warranty period years 2-5, CK Fires Ltd will send the appropriate component or goods necessary
to rectify the fault, free of charge.
Nothing in the Extended Warranty shall make CK Fires Ltd liable for any or special, incidental, or
consequential damages, injury to persons or property, or any other consequential loss beyond the
consumer’s statutory rights. The liability on these issues is covered by our Terms and Conditions
of Sale.
CK Fires Ltd total liability extends only to the purchase price paid for the goods, except where
such a limitation is prohibited by statute. CK Fires Ltd, in the event of a warranty claim, reserves
the right either to replace the goods in question or to refund the purchase price of the goods.
For product sold outside the UK and Ireland, UK law will prevail.
The Evonic Fires Extended Warranty does not a󰀨ect your statutory rights.
