evplug EV30003 User manual

Page | 1 User manual for evplug charger 7.4kW PN. EV30003 www.evplugchargers.com
Portable EV charger manual
7.4kW PN. EV30003
Features
Charging plug meet IEC 62196-2 standard.
Control box meet IEC 62196-2 control principle.
Excellent protection performance
Protection Grade IP55-Working condition.
Operating temperature: -30C to +50C
Rated voltage: 230V
Current adjustable range: 10A-16A-20A-24A-32A
Cable Length: 5M black color cable
Vehicle Side Connector: Type2
Wall Power Supply Plug: 32A CEE Plug
HMI: LED indicator + display screen + press
button
Mechanical Properties
Mechanical life: no-load plug in / pull out >
10000times
Impact of external force: can afford 1m drop and
2T vehicle run over pressure
Electric Performance
Rated Current and Voltage: 250V AC 32A
﹒Insulation Resistance: >1000MΩ(DC500V)
﹒Terminal Temperature Rise: < 50K
﹒Contact impedance: 0.5 mΩ Max
Control Box Function
Leakage protection (restart recover).
﹒Over voltage under-voltage protection (self-

Page | 2 User manual for evplug charger 7.4kW PN. EV30003 www.evplugchargers.com
checking recover).
﹒Lightning protection.
﹒Over current protection.
﹒Overheat protection.
Charger Cord
Specification: 3G6mm² + 0.5mm²
Meets Standards
IEC 62196-2.
Cautions
﹒DO not put the device in the water.
﹒DO not step on the cable, do not pull it, do not
fold it up.
﹒Do not use the charger plugged into electrical
adapters with power less than 7.4W or electric
current limit under 32 A.
﹒DO not drop the control unit or put heavy
things on it.
﹒DO not place the charging cable near high-
temperature objects.
﹒DO not place the unit in the car or in a closed
room while charging.
﹒DO not use the device in extreme
temperatures (normal operating range (-30C to
+50C).
﹒The power supply input cable should have at
least 3*6mm² with a standard 32A jack. It is
proposed to complete the distribution of
electricity by professionals.
﹒Make sure that the charging plug, the cable
and the control box are free from any signs of
scratches, rust, cracks, etc.
﹒DO not charge if the power outlet is damaged,
rusted, cracked or loosely connected.
﹒Before charging, make sure the power plug
and outlet are compatible.
﹒The Green Power LED indicator is always on
when the battery is fully charged.
Warnings
﹒Carefully read these instructions and your
vehicle owner’s handbook before charging your
EV.
﹒Use only on the mains with fault current
circuit breaker.
﹒DO not use this product if the EV charging
cable is damaged.
﹒For use with EV charging only.
﹒The product must be grounded.
﹒DO not use this unit with an extension cord or
adapter.
﹒DO not insert any fingers into the charging
plug.
﹒The unit contains no user serviceable parts.
DO not try to repair or service the device
yourself.
﹒If the unit does not work properly in
accordance with the operating instructions, do
not use this unit. Contact your dealer for a repair
or replacement.
﹒Use the product under normal away from high
temperature erosive materials or ignition source.
﹒DO not contact metal conductor to prevent
electric shock accident.
﹒Product shell is made of thermoplastic, please
do not pound it to avoid reducing performances.
Charge
1. Check the power distribution cable for
damage before powering up.
2. Plug the mains plug into the socket.
3. Select the charging power with the
button on the front 10A-16A-20A-24A-
32A (For your safety, the electric
current cannot be modified with the
vehicle plugged in).
4. Make sure that the power outlet
complies with national standards and
that the socket is 32A.
5. Plug the vehicle plug into the socket of
your vehicle.
6. Make sure that the vehicle connector
is fully inserted until it clicks into
place.
7. The charger works automatically.
8. When the charger show that the
charging process is finished.
9. Disconnect the plug.
10. Disconnect the charging cable.
11. Cover the connector cover to you plug.
12. Insert the charging cable into the
carrying case.

Page | 3 User manual for evplug charger 7.4kW PN. EV30003 www.evplugchargers.com
Warranty:
Damage caused for the following reasons is
not covered by the warranty:
1. Improper handling, installation, use and
maintenance by the user.
2. Product falls into the water.
This warranty is for the original purchaser
only and is NOT transferable.
PLEASE NOTE: This document includes the
latest information at the time of printing.
EVplug Chargers, S.L. reserves the right to
make changes to this product without
further notice. Changes or modifications to
this product by other than an authorized
service facility could void the product
warranty
Failure mode:
Failure mode identifies that there is an error in the upload process.
It can occur for the following reasons:
1. Differential protection: Error in the ground connection, connector, cables or very
humid or wet vehicle battery.
2. High or low voltage: the supply voltage is too high or too low.
3. Temperature above or below the working limits.
4. High current or short circuit in charging circuit.
In the event of this error, unplug the charger and reconnect it. In case the error persists,
contact an authorized electrical installer.
Green (1 flash) Green (2 flash) Green (3 flash) Red Fault
Initial Mode On Off Off Off
Waiting conection On Flash (1s) Off Off
Charging mode Flashing Flashing Flashing Off
Charging Complete On On On Off
Fault Mode Off Off Off On
LED Display Status Code
Condition
