Ewbank Steam Dynamo SC1000 Manual

Care and Use Instructions
Customer Services, Ewbank Products Ltd,
Ashcombe Court, Woolsack Way, Godalming, GU7 1LQ, UK
Tel: [phone]
Email: [email protected]
www.ewbank.co.uk
Steam Dynamo
Model SC1000
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 1

2
Pack contents:
• Steam Dynamo - SC1000
• Jug
• Funnel
• Towel - EB0056
• Straight Adaptor - EB0048
• Steam Cap - EB0055
• Extension Wands - EB0047
• Floor Tool and Adaptor - EB0051
• Window/Tile Cleaner - EB0054
• Angled ozzle - EB0052
• Plastic Brushes,
Large and Small - EB0053
• Please note that some accessories are
stored at the front of the product under
the liftin section.
Read the instruction book before usin the
Steam Dynamo and make sure that…
• The cable is in perfect condition.
• All packaging materials are removed from the
product.
Thank you for purchasing your Steam Dynamo,
we hope you enjoy using it.
Please read the manual carefully to get the most
out of your product.
Steam D namo
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 2

WARNING - Risk of injur
Caution! - Steam 100˙C - Don’t direct at people or animals
Cleanin Fabrics:
A number of materials and fabrics are OT suitable to be cleaned by steam for example: Do not
use on leather, wax polished furniture or floors, synthetic fabrics, velvet, Dralon or other
delicate, steam-sensitive materials. All carpets and fabrics should be tested first before use.
Cleanin Glass/Mirrors:
Thermal shock can shatter glass. Before cleaning glass surfaces, carefully warm the surface by
directing the steam jet on the glass from a distance of no less than 6” or 15cm.
Safety Instructions - CAUTION
• Do not direct steam at people, animals or at
electrical devices.
• Do not operate machine without water in the
tank.
• Do not allow machine to run unattended at
any time.
• Close supervision is necessary when this
machine is used near children. Do not allow
it to be used as a toy.
• The machine is designed for household use
only, do not expose to rain.
• Do not overfill the water tank. The machine
contains a maximum of 1500ml of water only.
Excessive filling of the water tank may
cause damage or injury.
• ever turn the machine over or tilt more than
45 when it is switched on or if it’s still
producing steam.
• Use extra care when cleaning on stairs or
step-ladders.
• To provide continued protection against the
risk of electric shock connect properly
grounded outlets only.
• Use only genuine manufacturer’s parts.
• It is recommended that a RCD (residual
current device) rated at 30mA is fitted into the
mains supply socket for added protection
against electric shock.
• Do not immerse cord, plug or machine in
water or any other liquid.
• Do not drag or try to move boiler by pulling
either the hose or the mains lead.
• Do not operate with a damaged cord, keep
feet and all parts of body away from the jet
of steam. Do not operate machine in bare
feet or when wearing open toe shoes or
sandals.
• Do not pull or carry by cord, or use cord as a
handle, close door on cord or pull cord
around sharp edges or corners. Keep cord
away from heated surfaces.
• Unplug cleaner when not in use. Turn all
controls off before unplugging from electrical
outlet.
• Do not unplug by pulling on cord. Always
grasp the plug, not the cord. ever handle
plug or appliance with wet hands.
• Store in a dry place. Do not expose machine
to freezing temperatures.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• The boiler becomes hot in use. Move only by
using the carrying handle.
• Allow to cool completely before emptying
boiler.
• Do not stand on boiler or hose.
• The equipment must be unplugged after use
and before cleaning.
3
Steam D namo
o
®
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 3

4
Towel grips
Towel (EB0056)
Swivel-adaptor
(EB0049)
Floor brush/mop
tool (EB0051)
Window/tile cleaner
(EB0054)
Angle (EB0052), and
Plastic brushes
(EB0053)
Handle
Extension
wands x 2
(EB0047)
Straight Adaptor (EB0048) -
Please note that these
attachments slide onto the
straight adaptor (do not
twist)
How to put our Steam D namo together
Steam D namo
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 4

5
Cleanin Floors
Refilling the water tank
• Switch the machine off using the on/off
button (2).
• Disconnect the power cable from the
electrical outlet. Wait 5 minutes before
squeezing the safety trigger to make sure the
machine is no longer under pressure before
unscrewing the safety cap. DO OT unscrew
the safety cap until the steam has stopped.
• Fill the water tank as necessary using the
funnel provided. DO OT exceed 1500ml of
water before replacing the safety cap by
turning clockwise. Fasten cap tightly.
• You are now ready to switch the machine on
and resume steam cleaning.
RED ORANGE
34
Steam D namo
MAX 1500ML
1
3
4
2
5
66 7
Instructions for Use
• Make sure the machine is unplugged from
the electrical outlet.
• Unscrew the safety cap (1) by turning
anti-clockwise.
Please note the cap cannot be unscrewed
when the unit is pressurized.
• Using the measuring jug and funnel (6) fill
the machine with up to 1500ml of water. This
should be sufficient to steam clean for
approximately 45 minutes.
• Once full, replace the safety cap by turning
clockwise and fasten tightly.
• Attach the accessory or floor cleaning tool
you require to the machine. (See page 4)
• ow plug the machine into the electrical
outlet and switch on. Two lights should
illuminate. The red light (3) is a power
indicator. The orange light (4) indicates that
the machine is building steam pressure.
When the machine is first turned on this light
will illuminate. The machine takes up to 12
minutes to reach the correct pressure level
depending on the amount of water in the
tank.
• Once the orange light has gone out the
machine is ready to use. The orange light
may come back on when the machine is in
use. If this happens, release the safety trigger
and allow the steam pressure to build up
once again. This should take no longer than
40 seconds. If the safety trigger is pressed
when the orange light is on, hot water may
come out of the machine.
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 5

A
C
B
How to use the handle
A. Press the button in to attach the straight
adaptor or the extension tubes.
B. Squeeze the trigger on the handle for
steam.
C. Lock the trigger for constant steam.
How to use the tools
• The angled nozzle and the brush tool can be
used to get into awkward corners that are
normally difficult to clean.
• Use the brush tool to scrub and loosen
stubborn dirt from hard surfaces.
• Use the window/tile cleaner to clean grime
from tiles and windows.
• To use these tools, first fit the straight
adaptor. Depress the button on top of the
handle and push the straight adaptor on.
• ow you can push any of these three tools
onto the tip of the jet-nozzle. Please note that
these attachments slide onto the straight
adaptor (do not twist).
6
Steam D namo
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 6

7
• Attach the floor brush to the extension
wands, which snap together. Then attach the
extension wand to the steam gun. Do ensure
the extension wands are firmly connected.
• Before cleaning always remove dust from the
surface you wish to clean.
• To release the extension wands depress the
button on the hose connection.
Cleanin floors & carpets with cleanin
cloth.
• While the machine is switched off attach the
cleaning cloth to the floor brush via the
spring-loaded clips, Make sure the edges of
the cleaning cloth are secure.
DO OT attempt to do this while the machine
is still hot.
• ever remove the cleaning cloth while the
safety trigger is released or the machine is
warm to the touch.
WARNING - Risk of injury!
Fittin the Accessories
• The accessories may be fitted to the steam
gun (5) using adaptor (7).
When fitting the squeegee, adaptor (7) is
required.
When using the round brushes or
high-pressure nozzle, adaptor (7) is required.
Cleanin and Maintenance
• Cleaning and maintenance operations should
be carried out with the appliance
disconnected from the power supply.
• The machine should be allowed to
completely cool down before it is stored
away or cleaned.
• Clean the machine and its accessories with a
slightly damp cloth only.
• ever use a cleaning product or detergent.
• To ensure that your machine operates
correctly over a long period, rinse out the
water tank once a month to remove
lime-scale deposits. A vinegar solution or a
proprietory de-scaler solution can be used to
clean inside the water tank.
• There are no customer service parts to the
boiler unit, all repairs must be carried out by
a qualified person.
Steam D namo
1
3
4
2
5
66 7
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 7

•Water comes out of the Nozzle
The Steam Cleaner creates a large amount
of steam. This may condense as water or
water droplets in the Steam Hose and can
be expelled when used after a period of
cooling. This is normal and not a cause for
concern.
•No Steam comes out
Check that the hose has not become kinked
or blocked. Also check the power supply and
water level.
Troubleshooting
SteamDynamo
•2.5 metre power cord
•Water capacity - 1500ml
•Steam-up time – up to 12 minutes
depending on volume of water
•Working time – 45 minutes
•Tank material - Stainless Steel
•Power - 1500W
Technical data
•I can’t get the Pressure Cap off
Make sure that you have fully de-pressurized
the Boiler. See the section Refilling the
water tank.
•Steam flow is erratic; sometimes it
works well, other times it does not
If you have not used distilled or deionized
water, you may have a small blockage inside
your Steam Cleaner. Try descaling your unit.
Check all attachments are fitted correctly.
•I live in a hard water area, my Steam
Cleaner does not work as well
Empty the machine after use. In hard water areas
your Steam Cleaner may benefit from occasional
descaling. This can be done by using a kettle
descaler solution.
You can also use distilled or deionized water to
extend the life of the product.
INFORMATION ON THE DISPOSAL OF WASTE ELECTRICAL AND
ELECTRONIC EQUIPMENT KNOWN AS WEEE
Your attention is brought to new directives applicable to the disposal of this electrical
equipment,where in accordance with the legislation this product must not be disposed of
in your normal household waste. Instead it is your responsibility to dispose of this type of
waste by handing it over to special designated collection points for recovery and recycling.
This product is marked with a ‘Wheelie bin’ symbol with a cross on it to remind you of this
action. The objective of this directive is to help conserve resources and ensure that it is
recycled in a manner that protects human health and the environment. For more information
about where you can drop off your waste please contact your local authority, take back
facilities are free of charge.
Your Guarantee
This product is covered by a 12 month guarantee.
This does not cover normal wear and tear or abuse.
For guarantee purposes, please retain your original receipt as proof of purchase.
This guarantee does not affect your statutory rights.
For spares, service and further information please contact;
Customer Services, Ewbank Products Ltd, Ashcombe Court, Woolsack Way,
Godalming, Surrey, GU7 1LQ, UK
Tel: [phone], Email: [email protected]
Open from 08:30 - 17:00 Mon - Thur and 08:30 - 15:45 on Fri.
www.ewbank.co.uk
2014 © Ewbank Products Ltd
EB0028 03/15
8
EB0028 SC1000UK 0512_Layout 1 03/05/2012 16:44 Page 8
