EWM Phoenix 355 Progress puls LP MM TKM User manual

Operating instructions
EN
Welding machine
Phoenix 355 Progress puls LP MM TKM
099-005502-EW501
Observe additional system documents!
2.12.2022

General instructions
WARNING
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
• Read and observe the operating instructions for all system components, especially the sa-
fety instructions and warning notices!
• Observe the accident prevention regulations and any regional regulations!
• The operating instructions must be kept at the location where the machine is operated.
• Safety and warning labels on the machine indicate any possible risks.
Keep these labels clean and legible at all times.
• The machine has been constructed to state-of-the-art standards in line with any applicable
regulations and industrial standards. Only trained personnel may operate, service and re-
pair the machine.
• Technical changes due to further development in machine technology may lead to a dif-
fering welding behaviour.
In the event of queries on installation, commissioning, operation or special conditions at the
installation site, or on usage, please contact your sales partner or our customer service
department on [phone].
A list of authorised sales partners can be found at www.ewm-group.com/en/specialist-dealers.
Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No
other form of liability, regardless of type, shall be accepted. This exclusion of liability shall be deemed ac-
cepted by the user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods
are observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a result. For this
reason, we do not accept any responsibility or liability for losses, damages or costs arising from incorrect
installation, improper operation or incorrect usage and maintenance or any actions connected to this in
any way.
© EWM AG
Dr. Günter-Henle-Strasse 8
56271 Mündersbach Germany
Tel.: [phone], Fax: -244
Email: [email protected]
www.ewm-group.com
The copyright to this document remains the property of the manufacturer.
Copying, including extracts, only permitted with written approval.
The content of this document has been prepared and reviewed with all reasonable care. The information
provided is subject to change; errors excepted.
Data security
The user is responsible for backing up data of all changes from the factory setting. The user is liable for
erased personal settings. The manufacturer does not assume any liability for this.

Contents
Notes on using these operating instructions
099-005502-EW501
2.12.2022
3
1 Contents
1Contents .......................................................................................................................................... 3
2For your safety ............................................................................................................................... 7
2.1 Notes on using these operating instructions .......................................................................... 7
2.2 Explanation of icons ............................................................................................................... 8
2.3 Safety instructions .................................................................................................................. 9
2.4 Transport and installation .................................................................................................... 12
3Intended use ................................................................................................................................. 14
3.1 Applications .......................................................................................................................... 14
3.2 Documents which also apply ............................................................................................... 14
3.2.1 Warranty ............................................................................................................... 14
3.2.2 Declaration of Conformity ..................................................................................... 14
3.2.3 Welding in environments with increased electrical hazards ................................. 14
3.2.4 Service documents (spare parts and circuit diagrams) ........................................ 14
3.2.5 Calibration/Validation ........................................................................................... 14
3.2.6 Part of the complete documentation ..................................................................... 15
4Machine description – quick overview ...................................................................................... 16
4.1 Front view / rear view ........................................................................................................... 16
4.2 Inside view ........................................................................................................................... 18
4.2.1 Operating elements in the machine ...................................................................... 19
4.3 Machine control – Operating elements ................................................................................ 20
4.3.1 Welding data display ............................................................................................ 21
5Design and function ..................................................................................................................... 23
5.1 General ................................................................................................................................ 23
5.2 Transport and installation .................................................................................................... 24
5.2.1 Ambient conditions ............................................................................................... 24
5.2.2 Machine cooling .................................................................................................... 24
5.2.3 Workpiece lead, general ....................................................................................... 24
5.2.4 Notes on the installation of welding current leads ................................................ 25
5.2.5 Stray welding currents .......................................................................................... 26
5.2.6 Mains connection .................................................................................................. 27
5.2.6.1 Mains configuration ............................................................................... 27
5.2.7 Shielding gas supply (shielding gas cylinder for welding machine) ..................... 28
5.2.8 Pressure regulator connection ............................................................................. 28
5.2.8.1 Shielding gas hose connection ............................................................. 29
5.2.9 Shielding gas volume settings .............................................................................. 29
5.2.9.1 Gas test ................................................................................................. 30
5.2.9.2 Purge hose package ............................................................................. 30
5.2.10 Welding torch cooling system ............................................................................... 30
5.2.11 Cooling unit connection ........................................................................................ 30
5.2.12 Welding torch holder ............................................................................................ 31
5.2.13 Protective flap, welding machine control .............................................................. 32
5.2.14 Dirt filter ................................................................................................................ 32
5.3 MIG/MAG welding ................................................................................................................ 33
5.3.1 Assemble the wire guide ...................................................................................... 33
5.3.2 Welding torch and workpiece line connection ...................................................... 34
5.3.3 Wire feed .............................................................................................................. 34
5.3.3.1 Inserting the wire spool ......................................................................... 35
5.3.3.2 Changing the wire feed rollers .............................................................. 36
5.3.3.3 Inching the wire electrode ..................................................................... 38
5.3.3.4 Spool brake setting ............................................................................... 39
5.3.4 Definition of MIG/MAG welding tasks ................................................................... 40
5.3.5 Welding task selection .......................................................................................... 40
5.3.5.1 Basic welding parameters ..................................................................... 40
5.3.5.2 Operating mode .................................................................................... 41
5.3.6 Welding type ......................................................................................................... 41
5.3.7 Welding power (operating point) .......................................................................... 41
5.3.7.1 Accessory components for operating point setting ............................... 42
5.3.7.2 Arc length .............................................................................................. 42

Contents
Notes on using these operating instructions
4
099-005502-EW501
2.12.2022
5.3.7.3 Arc dynamics (choke effect) .................................................................. 42
5.3.7.4 superPuls .............................................................................................. 42
5.3.7.5 Burn-back .............................................................................................. 43
5.3.8 Conventional MIG/MAG Welding (GMAW non synergic) ..................................... 44
5.3.8.1 Setting the operating point (welding output).......................................... 44
5.3.9 Welding power (operating point) ........................................................................... 45
5.3.9.1 Operating point setting via welding current, material thickness or wire
feed speed ............................................................................................. 45
5.3.9.2 Arc length .............................................................................................. 45
5.3.9.3 Accessory components for operating point setting ............................... 45
5.3.10 forceArc / forceArc puls ........................................................................................ 46
5.3.11 rootArc/rootArc puls .............................................................................................. 46
5.3.12 Operating modes (functional sequences) ............................................................. 47
5.3.12.1 Explanation of signs and functions ........................................................ 47
5.3.12.2 Automatic cut-out .................................................................................. 47
5.3.13 MIG/MAG program sequence ("Program steps" mode) ....................................... 53
5.3.13.1 Example, tack welding (non-latched) .................................................... 53
5.3.13.2 Example, aluminium tack welding (non-latched special) ...................... 53
5.3.13.3 Example, aluminium welding (latched special) ..................................... 53
5.3.14 Main program A mode .......................................................................................... 54
5.3.14.1 Selecting parameters (program A) ........................................................ 55
5.3.15 Standard MIG/MAG torch ..................................................................................... 55
5.3.16 MIG/MAG special-torches..................................................................................... 56
5.3.16.1 Program and up/down operation ........................................................... 56
5.3.16.2 Switching between Push/Pull and intermediate drive ........................... 56
5.4 MMA welding ........................................................................................................................ 57
5.4.1 Connecting the electrode holder and workpiece lead .......................................... 57
5.4.2 Welding task selection .......................................................................................... 58
5.4.3 Welding current setting ......................................................................................... 58
5.4.4 Arcforce................................................................................................................. 58
5.4.5 Hotstart ................................................................................................................. 58
5.4.6 Antistick................................................................................................................. 59
5.5 TIG welding .......................................................................................................................... 59
5.5.1 Preparing the TIG welding torch ........................................................................... 59
5.5.2 Welding torch and workpiece line connection ...................................................... 59
5.5.3 Welding task selection .......................................................................................... 60
5.5.4 Welding current setting ......................................................................................... 60
5.5.5 Arc ignition ............................................................................................................ 60
5.5.5.1 Liftarc ..................................................................................................... 60
5.5.6 Operating modes (functional sequences) ............................................................. 61
5.5.6.1 Explanation of signs and functions ........................................................ 61
5.5.6.2 Automatic cut-out .................................................................................. 61
5.6 Remote control ..................................................................................................................... 64
5.7 Power-saving mode (Standby) ............................................................................................. 64
5.8 Access control ...................................................................................................................... 65
5.9 Interfaces for automation ..................................................................................................... 65
5.9.1 Automation interface ............................................................................................. 65
5.9.2 Remote control connection socket, 19-pole ......................................................... 66
5.9.3 RINT X12 robot interface ...................................................................................... 67
5.9.4 BUSINT X11 industrial bus interface .................................................................... 67
5.10 PC interface ......................................................................................................................... 67
5.10.1.1 Connection ............................................................................................ 68
5.11 Special parameters (advanced settings) .............................................................................. 69
5.11.1.1 Selecting, changing and saving parameters ......................................... 69
5.11.2 Reset to factory settings ....................................................................................... 71
5.11.3 Special parameters in detail ................................................................................. 72
5.11.3.1 Ramp time for wire inching (P1) ............................................................ 72
5.11.3.2 Program "0", releasing the program block (P2) ..................................... 72
5.11.3.3 Display mode for Up/Down welding torch with one-digit 7-segment
display (P3) ........................................................................................... 72

Contents
Notes on using these operating instructions
099-005502-EW501
2.12.2022
5
5.11.3.4 Program limit (P4) ................................................................................. 72
5.11.3.5 Special cycle in the operating modes special latched and non-latched
(P5) ....................................................................................................... 72
5.11.3.6 Correction operation, threshold value setting (P7) ............................... 73
5.11.3.7 Switching programs with the standard torch trigger (P8) ...................... 74
5.11.3.8 Latched/special-latched tap start (P9) .................................................. 75
5.11.3.9 "Single or dual operation" (P10) setting ................................................ 75
5.11.3.10Latched special tapping time setting (P11) ........................................... 76
5.11.3.11JOB list switching (P12) ........................................................................ 76
5.11.3.12Lower and upper limits of the remote JOB changeover process (P13,
P14) ....................................................................................................... 77
5.11.3.13Hold function (P15) ............................................................................... 77
5.11.3.14Block JOB mode (P16) ......................................................................... 78
5.11.3.15Selecting programs with the standard torch trigger (P17) .................... 78
5.11.3.16Average value display for superPuls (P19) ........................................... 79
5.11.3.17Predefined execution of the pulsed arc welding process in the PA
program (P20) ....................................................................................... 79
5.11.3.18Predefined absolute value for relative programs (P21) ........................ 79
5.11.3.19Electronic gas flow control, type (P22) .................................................. 79
5.11.3.20Program settings for relative programs (P23) ....................................... 79
5.11.3.21Correction or nominal voltage display (P24) ......................................... 79
5.12 Machine configuration menu ................................................................................................ 80
5.12.1 Aligning the cable resistance ................................................................................ 81
5.13 Power-saving mode (Standby) ............................................................................................ 82
6Maintenance, care and disposal ................................................................................................. 83
6.1 General ................................................................................................................................ 83
6.1.1 Cleaning ............................................................................................................... 83
6.1.2 Dirt filter ................................................................................................................ 83
6.2 Maintenance work, intervals ................................................................................................ 84
6.2.1 Daily maintenance tasks ...................................................................................... 84
6.2.2 Monthly maintenance tasks .................................................................................. 84
6.2.3 Annual test (inspection and testing during operation) .......................................... 84
6.3 Disposing of equipment ....................................................................................................... 85
7Rectifying faults ........................................................................................................................... 86
7.1 Error messages (power source) .......................................................................................... 86
7.2 Checklist for rectifying faults ................................................................................................ 88
7.3 Vent coolant circuit ............................................................................................................... 89
7.4 Resetting JOBs (welding tasks) to the factory settings ....................................................... 90
7.4.1 Resetting a single JOB ......................................................................................... 90
7.4.2 Resetting all JOBs ................................................................................................ 90
8Technical data .............................................................................................................................. 91
8.1 Phoenix 355 Progress puls MM TKM .................................................................................. 91
9Accessories .................................................................................................................................. 92
9.1 Welding torch cooling system .............................................................................................. 92
9.1.1 Coolant - type blueCool ........................................................................................ 92
9.1.2 Coolant - type KF .................................................................................................. 92
9.2 Transport system ................................................................................................................. 92
9.3 Options ................................................................................................................................. 92
9.4 General accessories ............................................................................................................ 93
9.5 Remote control/connecting and extension cable ................................................................. 93
9.5.1 7-pole connection ................................................................................................. 93
9.5.2 19-pole connection ............................................................................................... 93
9.6 Computer communication .................................................................................................... 93
9.7 Networking / Xnet ................................................................................................................. 94
10 Replaceable parts ........................................................................................................................ 95
10.1 Wire feed rollers ................................................................................................................... 95
10.1.1 Wire feed rollers for steel wire .............................................................................. 95
10.1.2 Wire feed rollers for aluminium wire ..................................................................... 95
10.1.3 Wire feed rollers for cored wire ............................................................................ 96

Contents
Notes on using these operating instructions
6
099-005502-EW501
2.12.2022
10.1.4 Wire guide ............................................................................................................. 96
11 Appendix ....................................................................................................................................... 97
11.1 JOB-List................................................................................................................................ 97
11.2 Parameter overview – setting ranges .................................................................................. 98
11.2.1 MIG/MAG welding ................................................................................................. 98
11.2.2 MMA welding ........................................................................................................ 98
11.3 Searching for a dealer .......................................................................................................... 99

For your safety
Notes on using these operating instructions
099-005502-EW501
2.12.2022
7
2 For your safety
2.1 Notes on using these operating instructions
DANGER
Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
• Safety notes include the "DANGER" keyword in the heading with a general warning symbol.
• The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
• Safety notes include the "WARNING" keyword in the heading with a general warning sym-
bol.
• The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
• The safety information includes the "CAUTION" keyword in its heading with a general warn-
ing symbol.
• The risk is explained using a symbol on the edge of the page.
Technical aspects which the user must observe to avoid material or equipment damage.
Instructions and lists detailing step-by-step actions for given situations can be recognised via bullet
points, e.g.:
• Insert the welding current lead socket into the relevant socket and lock.

For your safety
Explanation of icons
8
099-005502-EW501
2.12.2022
2.2 Explanation of icons
Symbol
Description
Symbol
Description
Indicates technical aspects which the
user must observe.
Activate and release / Tap / Tip
Switch off machine
Release
Switch on machine
Press and hold
Incorrect / Invalid
Switch
Correct / Valid
Turn
Input
Numerical value – adjustable
Navigation
Signal light lights up in green
Output
Signal light flashes green
Time representation (e.g.: wait 4 s / ac-
tuate)
Signal light lights up in red
Interruption in the menu display (other
setting options possible)
Signal light flashes red
Tool not required/do not use
Signal light lights up in blue
Tool required/use
Signal light flashes blue

For your safety
Safety instructions
099-005502-EW501
2.12.2022
9
2.3 Safety instructions
WARNING
Risk of accidents due to non-compliance with the safety instructions!
Non-compliance with the safety instructions can be fatal!
• Carefully read the safety instructions in this manual!
• Observe the accident prevention regulations and any regional regulations!
• Inform persons in the working area that they must comply with the regulations!
Risk of injury from electrical voltage!
Voltages can cause potentially fatal electric shocks and burns on contact. Even low vol-
tages can cause a shock and lead to accidents.
• Never touch live components such as welding current sockets or stick, tungsten or wire
electrodes!
• Always place torches and electrode holders on an insulated surface!
• Wear the full personal protective equipment (depending on the application)!
• The machine may only be opened by qualified personnel!
• The device must not be used to defrost pipes!
Hazard when interconnecting multiple power sources!
If a number of power sources are to be connected in parallel or in series, only a techni-
cal specialist may interconnect the sources as per standard IEC 60974-9:2010: Installa-
tion and use and German Accident Prevention Regulation BVG D1 (formerly VBG 15) or
country-specific regulations.
Before commencing arc welding, a test must verify that the equipment cannot exceed
the maximum permitted open circuit voltage.
• Only qualified personnel may connect the machine.
• When taking individual power sources out of operation, all mains and welding current leads
must be safely disconnected from the welding system as a whole. (Hazard due to reverse
polarity voltage!)
• Do not interconnect welding machines with pole reversing switch (PWS series) or machines
for AC welding since a minor error in operation can cause the welding voltages to be com-
bined, which is not permitted.
Risk of injury due to radiation or heat!
Arc radiation can lead to skin and eye injuries.
Contact with hot workpieces and sparks can lead to burns.
• Use hand shield or welding helmet with the appropriate safety level (depends on the appli-
cation).
• Wear dry protective clothing (e.g. hand shield, gloves, etc.) in accordance with
the applicable regulations of your country.
• Persons who are not directly involved should be protected with a welding curtain or suitable
safety screen against radiation and the risk of blinding!

For your safety
Safety instructions
10
099-005502-EW501
2.12.2022
WARNING
Risk of injury due to improper clothing!
During arc welding, radiation, heat and voltage are sources of risk that cannot be
avoided. The user has to be equipped with the complete personal protective equipment
at all times. The protective equipment has to include:
• Respiratory protection against hazardous substances and mixtures (fumes and vapours);
otherwise implement suitable measures such as extraction facilities.
• Welding helmet with proper protection against ionizing radiation (IR and UV radiation) and
heat.
• Dry welding clothing (shoes, gloves and body protection) to protect against warm environ-
ments with conditions comparable to ambient temperatures of 100 °C or higher and arcing
and work on live components.
• Hearing protection against harming noise.
Explosion risk!
Apparently harmless substances in closed containers may generate excessive pressure
when heated.
• Move containers with inflammable or explosive liquids away from the working area!
• Never heat explosive liquids, dusts or gases by welding or cutting!
Fire hazard!
Due to the high temperatures, sparks, glowing parts and hot slag that occur during
welding, there is a risk of flames.
• Be watchful of potential sources of fire in the working area!
• Do not carry any easily inflammable objects, e.g. matches or lighters.
• Ensure suitable fire extinguishers are available in the working area!
• Thoroughly remove any residue of flammable materials from the workpiece prior to starting
to weld.
• Only further process workpieces after they have cooled down. Do not allow them to contact
any flammable materials!

For your safety
Safety instructions
099-005502-EW501
2.12.2022
11
CAUTION
Smoke and gases!
Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent
vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to
the ultraviolet radiation of the arc!
• Ensure that there is sufficient fresh air!
• Keep solvent vapour away from the arc beam field!
• Wear suitable breathing apparatus if appropriate!
Noise exposure!
Noise exceeding 70 dBA can cause permanent hearing damage!
• Wear suitable ear protection!
• Persons located within the working area must wear suitable ear protection!
According to IEC 60974-10, welding machines are divided into two classes of
electromagnetic compatibility (the EMC class can be found in the Technical
data) > see 8 chapter:
Class A machines are not intended for use in residential areas where the power supply comes
from the low-voltage public mains network. When ensuring the electromagnetic compatibility of
class A machines, difficulties can arise in these areas due to interference not only in the supply
lines but also in the form of radiated interference.
Class B machines fulfil the EMC requirements in industrial as well as residential areas, inclu-
ding residential areas connected to the low-voltage public mains network.
Setting up and operating
When operating arc welding systems, in some cases, electro-magnetic interference can occur
although all of the welding machines comply with the emission limits specified in the standard.
The user is responsible for any interference caused by welding.
In order to evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user must consider the following: (see also EN 60974-10 Appendix A)
• Mains, control, signal and telecommunication lines
• Radios and televisions
• Computers and other control systems
• Safety equipment
• The health of neighbouring persons, especially if they have a pacemaker or wear a hearing
aid
• Calibration and measuring equipment
• The immunity to interference of other equipment in the surrounding area
• The time of day at which the welding work must be carried out
Recommendations for reducing interference emission
• Mains connection, e.g. additional mains filter or shielding with a metal tube
• Maintenance of the arc welding system
• Welding leads should be as short as possible and run closely together along the ground
• Potential equalization
• Earthing of the workpiece. In cases where it is not possible to earth the workpiece directly,
it should be connected by means of suitable capacitors.
• Shielding from other equipment in the surrounding area or the entire welding system
Electromagnetic fields!
The power source may cause electrical or electromagnetic fields to be produced which
could affect the correct functioning of electronic equipment such as IT or CNC devices,
telecommunication lines, power cables, signal lines and pacemakers.
• Observe the maintenance instructions > see 6 chapter!
• Unwind welding leads completely!
• Shield devices or equipment sensitive to radiation accordingly!
• The correct functioning of pacemakers may be affected (obtain advice from a doctor if nec-
essary).

For your safety
Transport and installation
12
099-005502-EW501
2.12.2022
CAUTION
Obligations of the operator!
The respective national directives and laws must be complied with when operating the
machine!
• Implementation of national legislation relating to framework directive 89/391/EEC on the int-
roduction of measures to encourage improvements in the safety and health of workers at
work and associated individual guidelines.
• In particular, directive 89/655/EEC concerning the minimum safety and health requirements
for the use of work equipment by workers at work.
• The regulations applicable to occupational safety and accident prevention in the country
concerned.
• Setting up and operating the machine as per IEC 60974.-9.
• Brief the user on safety-conscious work practices on a regular basis.
• Regularly inspect the machine as per IEC 60974.-4.
The manufacturer's warranty becomes void if non-genuine parts are used!
• Only use system components and options (power sources, welding torches, electrode hold-
ers, remote controls, spare parts and replacement parts, etc.) from our range of products!
• Only insert and lock accessory components into the relevant connection socket when the ma-
chine is switched off.
Requirements for connection to the public mains network
High-performance machines can influence the mains quality by taking current from the mains
network. For some types of machines, connection restrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can therefore apply. In this respect,
attention is also drawn to the machines' technical data. In this case, it is the responsibility of the
operator, where necessary in consultation with the mains network operator, to ensure that the
machine can be connected.
2.4 Transport and installation
WARNING
Risk of injury due to improper handling of shielding gas cylinders!
Improper handling and insufficient securing of shielding gas cylinders can cause seri-
ous injuries!
• Observe the instructions from the gas manufacturer and any relevant regulations concern-
ing the use of compressed air!
• Do not attach any element to the shielding gas cylinder valve!
• Prevent the shielding gas cylinder from heating up.

For your safety
Transport and installation
099-005502-EW501
2.12.2022
13
CAUTION
Risk of accidents due to supply lines!
During transport, attached supply lines (mains leads, control cables, etc.) can cause
risks, e.g. by causing connected machines to tip over and injure persons!
• Disconnect all supply lines before transport!
Risk of tipping!
There is a risk of the machine tipping over and injuring persons or being damaged itself
during movement and set up. Tilt resistance is guaranteed up to an angle of 10° (ac-
cording to IEC 60974-1).
• Set up and transport the machine on level, solid ground.
• Secure add-on parts using suitable equipment.
Risk of accidents due to incorrectly installed leads!
Incorrectly installed leads (mains, control and welding leads or intermediate hose pack-
ages ) can present a tripping hazard.
• Lay the supply lines flat on the floor (avoid loops).
• Avoid laying the leads on passage ways.
Risk of injury from heated coolant and its connections!
The coolant used and its connection or connection points can heat up significantly
during operation (water-cooled version). When opening the coolant circuit, escaping
coolant may cause scalding.
• Open the coolant circuit only when the power source or cooling unit is switched off!
• Wear proper protective equipment (protective gloves)!
• Seal open connections of the hose leads with suitable plugs.
The units are designed for operation in an upright position!
Operation in non-permissible positions can cause equipment damage.
• Only transport and operate in an upright position!
Accessory components and the power source itself can be damaged by incorrect connection!
• Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
• Comprehensive descriptions can be found in the operating instructions for the relevant ac-
cessory components.
• Accessory components are detected automatically after the power source is switched on.
Protective dust caps protect the connection sockets and therefore the machine against dirt and
damage.
• The protective dust cap must be fitted if there is no accessory component being operated on
that connection.
• The cap must be replaced if faulty or if lost!

Intended use
Applications
14
099-005502-EW501
2.12.2022
3 Intended use
WARNING
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and stand-
ards applicable for use in industry and trade. It may only be used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons, animals and material
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
• The equipment must only be used in line with its designated purpose and by trained or
expert personnel!
• Do not improperly modify or convert the equipment!
3.1 Applications
Arc welding machine for standard and pulsed gas-shielded metal-arc welding with TIG welding and lift arc
(touch starting) or MMA welding as secondary process. It may be possible to expand the functionality by
using accessories (see the documentation in the relevant chapter).
3.2 Documents which also apply
3.2.1 Warranty
For more information refer to the "Warranty registration" brochure supplied and our information regarding
warranty, maintenance and testing at www.ewm-group.com!
3.2.2 Declaration of Conformity
This product corresponds in its design and construction to the EU directives listed in the decla-
ration. The product comes with a relevant declaration of conformity in the original.
The manufacturer recommends carrying out the safety inspection according to national and in-
ternational standards and guidelines every 12 months (from commissioning).
3.2.3 Welding in environments with increased electrical hazards
Power sources with this marking can be used for welding in an environment with increased
electrical hazard (e.g. boilers). For this purpose, appropriate national or international regulations
must be followed. The power source must not be placed in the danger zone!
3.2.4 Service documents (spare parts and circuit diagrams)
WARNING
No improper repairs and modifications!
To prevent injuries and damage to the machine, only competent personnel (authorised
service personnel) are allowed to repair or modify the machine.
Unauthorised manipulations will invalidate the warranty!
• Instruct competent personnel (authorised service personnel) to repair the machine.
Original copies of the circuit diagrams are enclosed with the unit.
Spare parts can be obtained from the relevant authorised dealer.
3.2.5 Calibration/Validation
An original certificate is enclosed with the product. The manufacturer recommends calibration / validation
at intervals of 12 months (from commissioning).

Intended use
Documents which also apply
099-005502-EW501
2.12.2022
15
3.2.6 Part of the complete documentation
This document is part of the complete documentation and valid only in combination with all other
parts of these instructions! Read and observe the operating instructions for all system
components, especially the safety instructions!
The illustration shows a general example of a welding system.
Figure 3-1
Item
Documentation
A.1
Transport vehicle
A.2
Power source
A.3
Cooling unit
A.4
Welding torch
A.5
Remote control
A.6
Control
A
Complete documentation

Machine description – quick overview
Front view / rear view
16
099-005502-EW501
2.12.2022
4 Machine description – quick overview
4.1 Front view / rear view
Figure 4-1

Machine description – quick overview
Front view / rear view
099-005502-EW501
2.12.2022
17
Item
Symbol
Description 0
1
Carrying handle
2
Machine control > see 4.3 chapter
3
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
4
Welding torch connection (Euro or Dinse torch connector)
Welding current, shielding gas and torch trigger integrated
5
Park socket, polarity selection plug
Retainer for the polarity selection plug in MMA mode or for transport.
6
Main Switch
Switching the machine on or off.
7
Connection thread - G¼"
Shielding gas connection (inlet)
8
Connection socket- 19-pole, analogue - optional
Interface for automated welding > see 5.9.1 chapter
9
Cooling air inlet
10
Machine feet
11
External wire feed inlet
Pre-cut casing inlet for external wire feed.
12
Mains connection cable > see 5.2.6 chapter
13
7-pole connection socket (digital)
For connecting digital accessory components (documentation interface, robot interface
or remote control, etc.).
14
8-pole connection socket
Cooling unit control lead
15
4-pole connection socket
Cooling unit voltage supply
16
Welding current cable, polarity selection
Welding current to Euro torch connector/torch, for polarity selection
• ----------- MIG/MAG: Connection socket for “+” welding current
• ----------- Self-shielding flux cored wire/TIG: Connection socket, “-” welding current
• ----------- MMA: Park socket
17
"-" welding current connection socket
• ----------- MIG/MAG welding: Workpiece connection
• ----------- TIG welding: Welding current connection for welding torch
• ----------- MMA welding: electrode holder connection
18
Connection socket, "+" welding current
• ----------- MIG/MAG cored wire welding: Workpiece connection
• ----------- TIG welding: Workpiece connection
• ----------- MMA welding: Workpiece connection
19
Cooling air inlet
20
Key switch for protection against unauthorised use (ex works option)
Position “1” > changes possible,
Position “0” > changes not possible.
> see 5.8 chapter.
21
Protective cap > see 5.2.13 chapter

Machine description – quick overview
Inside view
18
099-005502-EW501
2.12.2022
4.2 Inside view
Figure 4-2
Item
Symbol
Description 0
1
Protective cap
Cover for the wire feed mechanism and other operating elements. Depending on the
machine series, there are added information stickers on the inside of the flap for the
operation and maintenance of the machine.
2
Slide latch, lock for the protective cap
3
Wire spool inspection window
Check wire supply
4
Operating elements > see 4.2.1 chapter
5
Wire spool holder
6
Wire feed unit > see 5.3.3 chapter
7
Connection socket (9-pole) - D-Sub
PC interface > see 5.10 chapter

Machine description – quick overview
Inside view
099-005502-EW501
2.12.2022
19
4.2.1 Operating elements in the machine
Figure 4-3
Item
Symbol
Description 0
1
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
2
Welding torch function changeover switch (special welding torch required)
---- Changing over programs or JOBs
---- Infinite adjustment of welding performance.
3
Push-button gas test / rinse hose package > see 5.2.7 chapter
4
Wire inching push-button
Potential and gas-free inching of the wire electrode > see 5.3.3.3 chapter.

Machine description – quick overview
Machine control – Operating elements
20
099-005502-EW501
2.12.2022
4.3 Machine control – Operating elements
Figure 4-4
Item
Symbol
Description 0
1
Push-button, welding task selection (JOB)
SP1/2/3 - Special JOBs (Phoenix Expert only). Pressing the push-button longer: special
JOB selection. Pressing the push-button briefly: switching between special
JOBs.
JOB-LIST Select the welding task using the welding task list (JOB-LIST)) (not applicable
for Phoenix Expert). The list can be found inside the protective cap of the wire
feed mechanism and in the appendix to these operating instructions.
2
Display, left
Welding current, material thickness, wire speed, hold values
3
Push-button, parameter selection left/power-saving mode
AMP ----- Welding current
--------- Material thickness > see 5.3.9 chapter
--------- Wire feed speed
Hold ----- After welding, the values used last are shown from the main program. The
signal light is illuminated.
STBY ---- Press for 2 s to put machine into power-saving mode.
To reactivate, activate one of the operating elements > see 5.7 chapter.
4
Display, JOB
Shows the currently selected welding task (JOB number). Phoenix Expert machines will
display the special JOB selected (SP1, 2 or 3), if applicable.
