EWM Drive 4X D200 Basic S User manual

Operating instructions
EN
Wire feed unit
Drive 4 Basic S
Drive 4X Steel Synergic S
Drive 4X Steel puls S
099-005593-EW501
Observe additional system documents!
10.01.2022

General instructions
WARNING
Read the operating instructions!
The operating instructions provide an introduction to the safe use of the products.
•Read and observe the operating instructions for all system components, especially the sa-
fety instructions and warning notices!
•Observe the accident prevention regulations and any regional regulations!
•The operating instructions must be kept at the location where the machine is operated.
•Safety and warning labels on the machine indicate any possible risks.
Keep these labels clean and legible at all times.
•The machine has been constructed to state-of-the-art standards in line with any applicable
regulations and industrial standards. Only trained personnel may operate, service and re-
pair the machine.
•Technical changes due to further development in machine technology may lead to a dif-
fering welding behaviour.
In the event of queries on installation, commissioning, operation or special conditions at the
installation site, or on usage, please contact your sales partner or our customer service
department on [phone].
A list of authorised sales partners can be found at www.ewm-group.com/en/specialist-dealers.
Liability relating to the operation of this equipment is restricted solely to the function of the equipment. No
other form of liability, regardless of type, shall be accepted. This exclusion of liability shall be deemed ac-
cepted by the user on commissioning the equipment.
The manufacturer is unable to monitor whether or not these instructions or the conditions and methods
are observed during installation, operation, usage and maintenance of the equipment.
An incorrectly performed installation can result in material damage and injure persons as a result. For this
reason, we do not accept any responsibility or liability for losses, damages or costs arising from incorrect
installation, improper operation or incorrect usage and maintenance or any actions connected to this in
any way.
© EWM AG
Dr. Günter-Henle-Strasse 8
56271 Mündersbach Germany
Tel.: [phone], Fax: -244
Email: [e-mail]
www.ewm-group.com
The copyright to this document remains the property of the manufacturer.
Copying, including extracts, only permitted with written approval.
The content of this document has been prepared and reviewed with all reasonable care. The information
provided is subject to change; errors excepted.
Data security
The user is responsible for backing up data of all changes from the factory setting. The user is liable for
erased personal settings. The manufacturer does not assume any liability for this.

Contents
Notes on using these operating instructions
099-005593-EW501
10.01.2022
3
1 Contents
1Contents.......................................................................................................................................... 3
2For your safety ............................................................................................................................... 5
2.1 Notes on using these operating instructions.......................................................................... 5
2.2 Explanation of icons............................................................................................................... 6
2.3 Safety instructions.................................................................................................................. 7
2.4 Transport and installation ....................................................................................................10
3Intended use.................................................................................................................................12
3.1 Applications..........................................................................................................................12
3.2 Use and operation solely with the following machines ........................................................12
3.3 Documents which also apply ...............................................................................................13
3.3.1 Warranty...............................................................................................................13
3.3.2 Declaration of Conformity.....................................................................................13
3.3.3 Service documents (spare parts and circuit diagrams)........................................13
3.3.4 Calibration/Validation............................................................................................13
3.3.5 Part of the complete documentation.....................................................................14
4Machine description –quick overview ...................................................................................... 15
4.1 Front view / side view from the right ....................................................................................15
4.2 Rear view / side view from left.............................................................................................17
5Design and function..................................................................................................................... 19
5.1 Transport and installation ....................................................................................................19
5.1.1 Ambient conditions ...............................................................................................19
5.1.2 Welding torch cooling system...............................................................................20
5.1.2.1 Permitted torch coolant.........................................................................20
5.1.2.2 Maximal hose package length ..............................................................20
5.1.3 Notes on the installation of welding current leads................................................21
5.1.4 Stray welding currents..........................................................................................22
5.2 Intermediate hose package connection...............................................................................22
5.2.1 Shielding gas supply (shielding gas cylinder for welding machine) .....................24
5.2.2 Pressure regulator connection .............................................................................24
5.2.2.1 Gas test.................................................................................................25
5.2.2.2 Purge hose package.............................................................................25
5.2.3 Protective flap, welding machine control..............................................................25
5.3 MIG/MAG welding................................................................................................................26
5.3.1 Assemble the wire guide ......................................................................................26
5.3.2 Welding torch connection.....................................................................................27
5.3.3 Wire feed ..............................................................................................................28
5.3.3.1 Inserting the wire spool.........................................................................28
5.3.3.2 Changing the wire feed rollers ..............................................................29
5.3.3.3 Inching the wire electrode.....................................................................32
5.3.3.4 Spool brake setting ...............................................................................33
5.3.4 Standard MIG/MAG torch.....................................................................................33
5.3.5 MIG/MAG special-torches ....................................................................................34
5.3.5.1 Switching between Push/Pull and intermediate drive...........................34
5.3.6 Welding task selection..........................................................................................34
5.4 MMA welding or gouging .....................................................................................................34
5.4.1 Connection of electrode holder or gouging torch .................................................34
5.4.2 Welding task selection..........................................................................................35
5.5 Remote control.....................................................................................................................35
6Maintenance, care and disposal.................................................................................................36
6.1 General ................................................................................................................................36
6.1.1 Cleaning ...............................................................................................................36
6.1.2 Dirt filter ................................................................................................................36
6.2 Maintenance work, intervals ................................................................................................37
6.2.1 Daily maintenance tasks.......................................................................................37
6.2.2 Monthly maintenance tasks..................................................................................37
6.2.3 Annual test (inspection and testing during operation)..........................................37
6.3 Disposing of equipment .......................................................................................................38

Contents
Notes on using these operating instructions
4
099-005593-EW501
10.01.2022
7Rectifying faults............................................................................................................................39
7.1 Error messages (power source)...........................................................................................39
7.2 Warnings..............................................................................................................................42
7.3 Checklist for rectifying faults ................................................................................................44
7.4 Vent coolant circuit...............................................................................................................46
8Technical data...............................................................................................................................47
8.1 Drive 4 Basic S, -Steel Synergic S, -Steel puls S................................................................47
9Accessories ..................................................................................................................................48
9.1 General accessories ............................................................................................................48
9.1.1 Welding torch cooling system...............................................................................48
9.1.1.1 Coolant - type blueCool.........................................................................48
9.1.1.2 Coolant - type KF ..................................................................................48
9.2 19-pole remote control.........................................................................................................48
9.2.1 Connection cables ................................................................................................48
9.2.2 Extension cable ....................................................................................................48
9.3 Options.................................................................................................................................49
10 Replaceable parts.........................................................................................................................50
10.1 Wire feed rollers...................................................................................................................50
10.1.1 Wire feed rollers for steel wire..............................................................................50
10.1.2 Wire feed rollers for aluminium wire .....................................................................50
10.1.3 Wire feed rollers for cored wire.............................................................................51
10.1.4 Wire guide.............................................................................................................51
11 Appendix .......................................................................................................................................52
11.1 Searching for a dealer..........................................................................................................52

For your safety
Notes on using these operating instructions
099-005593-EW501
10.01.2022
5
2 For your safety
2.1 Notes on using these operating instructions
DANGER
Working or operating procedures which must be closely observed to prevent imminent
serious and even fatal injuries.
•Safety notes include the "DANGER" keyword in the heading with a general warning symbol.
•The hazard is also highlighted using a symbol on the edge of the page.
WARNING
Working or operating procedures which must be closely observed to prevent serious
and even fatal injuries.
•Safety notes include the "WARNING" keyword in the heading with a general warning sym-
bol.
•The hazard is also highlighted using a symbol in the page margin.
CAUTION
Working or operating procedures which must be closely observed to prevent possible
minor personal injury.
•The safety information includes the "CAUTION" keyword in its heading with a general warn-
ing symbol.
•The risk is explained using a symbol on the edge of the page.
Technical aspects which the user must observe to avoid material or equipment damage.
Instructions and lists detailing step-by-step actions for given situations can be recognised via bullet
points, e.g.:
•Insert the welding current lead socket into the relevant socket and lock.

For your safety
Explanation of icons
6
099-005593-EW501
10.01.2022
2.2 Explanation of icons
Symbol
Description
Symbol
Description
Indicates technical aspects which the u-
ser must observe.
Activate and release / Tap / Tip
Switch off machine
Release
Switch on machine
Press and hold
Switch
Incorrect / Invalid
Turn
Correct / Valid
Numerical value –adjustable
Input
Signal light lights up in green
Navigation
Signal light flashes green
Output
Signal light lights up in red
Time representation (e.g.: wait 4 s / ac-
tuate)
Signal light flashes red
Interruption in the menu display (other
setting options possible)
Tool not required/do not use
Tool required/use

For your safety
Safety instructions
099-005593-EW501
10.01.2022
7
2.3 Safety instructions
WARNING
Risk of accidents due to non-compliance with the safety instructions!
Non-compliance with the safety instructions can be fatal!
•Carefully read the safety instructions in this manual!
•Observe the accident prevention regulations and any regional regulations!
•Inform persons in the working area that they must comply with the regulations!
Risk of injury from electrical voltage!
Voltages can cause potentially fatal electric shocks and burns on contact. Even low vol-
tages can cause a shock and lead to accidents.
•Never touch live components such as welding current sockets or stick, tungsten or wire
electrodes!
•Always place torches and electrode holders on an insulated surface!
•Wear the full personal protective equipment (depending on the application)!
•The machine may only be opened by qualified personnel!
•The device must not be used to defrost pipes!
Hazard when interconnecting multiple power sources!
If a number of power sources are to be connected in parallel or in series, only a techni-
cal specialist may interconnect the sources as per standard IEC 60974-9:2010: Installa-
tion and use and German Accident Prevention Regulation BVG D1 (formerly VBG 15) or
country-specific regulations.
Before commencing arc welding, a test must verify that the equipment cannot exceed
the maximum permitted open circuit voltage.
•Only qualified personnel may connect the machine.
•When taking individual power sources out of operation, all mains and welding current leads
must be safely disconnected from the welding system as a whole. (Hazard due to reverse
polarity voltage!)
•Do not interconnect welding machines with pole reversing switch (PWS series) or machines
for AC welding since a minor error in operation can cause the welding voltages to be com-
bined, which is not permitted.
Risk of injury due to radiation or heat!
Arc radiation can lead to skin and eye injuries.
Contact with hot workpieces and sparks can lead to burns.
•Use hand shield or welding helmet with the appropriate safety level (depends on the appli-
cation).
•Wear dry protective clothing (e.g. hand shield, gloves, etc.) in accordance with
the applicable regulations of your country.
•Persons who are not directly involved should be protected with a welding curtain or suitable
safety screen against radiation and the risk of blinding!

For your safety
Safety instructions
8
099-005593-EW501
10.01.2022
WARNING
Risk of injury due to improper clothing!
During arc welding, radiation, heat and voltage are sources of risk that cannot be
avoided. The user has to be equipped with the complete personal protective equipment
at all times. The protective equipment has to include:
•Respiratory protection against hazardous substances and mixtures (fumes and vapours);
otherwise implement suitable measures such as extraction facilities.
•Welding helmet with proper protection against ionizing radiation (IR and UV radiation) and
heat.
•Dry welding clothing (shoes, gloves and body protection) to protect against warm environ-
ments with conditions comparable to ambient temperatures of 100 °C or higher and arcing
and work on live components.
•Hearing protection against harming noise.
Explosion risk!
Apparently harmless substances in closed containers may generate excessive pressure
when heated.
•Move containers with inflammable or explosive liquids away from the working area!
•Never heat explosive liquids, dusts or gases by welding or cutting!
Fire hazard!
Due to the high temperatures, sparks, glowing parts and hot slag that occur during
welding, there is a risk of flames.
•Be watchful of potential sources of fire in the working area!
•Do not carry any easily inflammable objects, e.g. matches or lighters.
•Ensure suitable fire extinguishers are available in the working area!
•Thoroughly remove any residue of flammable materials from the workpiece prior to starting
to weld.
•Only further process workpieces after they have cooled down. Do not allow them to contact
any flammable materials!

For your safety
Safety instructions
099-005593-EW501
10.01.2022
9
CAUTION
Smoke and gases!
Smoke and gases can lead to breathing difficulties and poisoning. In addition, solvent
vapour (chlorinated hydrocarbon) may be converted into poisonous phosgene due to
the ultraviolet radiation of the arc!
•Ensure that there is sufficient fresh air!
•Keep solvent vapour away from the arc beam field!
•Wear suitable breathing apparatus if appropriate!
Noise exposure!
Noise exceeding 70 dBA can cause permanent hearing damage!
•Wear suitable ear protection!
•Persons located within the working area must wear suitable ear protection!
According to IEC 60974-10, welding machines are divided into two classes of
electromagnetic compatibility (the EMC class can be found in the Technical
data) > see 8 chapter:
Class A machines are not intended for use in residential areas where the power supply comes
from the low-voltage public mains network. When ensuring the electromagnetic compatibility of
class A machines, difficulties can arise in these areas due to interference not only in the supply
lines but also in the form of radiated interference.
Class B machines fulfil the EMC requirements in industrial as well as residential areas, inclu-
ding residential areas connected to the low-voltage public mains network.
Setting up and operating
When operating arc welding systems, in some cases, electro-magnetic interference can occur
although all of the welding machines comply with the emission limits specified in the standard.
The user is responsible for any interference caused by welding.
In order to evaluate any possible problems with electromagnetic compatibility in the
surrounding area, the user must consider the following: (see also EN 60974-10 Appendix A)
•Mains, control, signal and telecommunication lines
•Radios and televisions
•Computers and other control systems
•Safety equipment
•The health of neighbouring persons, especially if they have a pacemaker or wear a hearing
aid
•Calibration and measuring equipment
•The immunity to interference of other equipment in the surrounding area
•The time of day at which the welding work must be carried out
Recommendations for reducing interference emission
•Mains connection, e.g. additional mains filter or shielding with a metal tube
•Maintenance of the arc welding system
•Welding leads should be as short as possible and run closely together along the ground
•Potential equalization
•Earthing of the workpiece. In cases where it is not possible to earth the workpiece directly,
it should be connected by means of suitable capacitors.
•Shielding from other equipment in the surrounding area or the entire welding system
Electromagnetic fields!
The power source may cause electrical or electromagnetic fields to be produced which
could affect the correct functioning of electronic equipment such as IT or CNC devices,
telecommunication lines, power cables, signal lines and pacemakers.
•Observe the maintenance instructions > see 6.2 chapter!
•Unwind welding leads completely!
•Shield devices or equipment sensitive to radiation accordingly!
•The correct functioning of pacemakers may be affected (obtain advice from a doctor if nec-
essary).

For your safety
Transport and installation
10
099-005593-EW501
10.01.2022
CAUTION
Obligations of the operator!
The respective national directives and laws must be complied with when operating the
machine!
•Implementation of national legislation relating to framework directive 89/391/EEC on the int-
roduction of measures to encourage improvements in the safety and health of workers at
work and associated individual guidelines.
•In particular, directive 89/655/EEC concerning the minimum safety and health requirements
for the use of work equipment by workers at work.
•The regulations applicable to occupational safety and accident prevention in the country
concerned.
•Setting up and operating the machine as per IEC 60974.-9.
•Brief the user on safety-conscious work practices on a regular basis.
•Regularly inspect the machine as per IEC 60974.-4.
The manufacturer's warranty becomes void if non-genuine parts are used!
•Only use system components and options (power sources, welding torches, electrode hold-
ers, remote controls, spare parts and replacement parts, etc.) from our range of products!
•Only insert and lock accessory components into the relevant connection socket when the ma-
chine is switched off.
Requirements for connection to the public mains network
High-performance machines can influence the mains quality by taking current from the mains
network. For some types of machines, connection restrictions or requirements relating to the
maximum possible line impedance or the necessary minimum supply capacity at the interface
with the public network (Point of Common Coupling, PCC) can therefore apply. In this respect,
attention is also drawn to the machines' technical data. In this case, it is the responsibility of the
operator, where necessary in consultation with the mains network operator, to ensure that the
machine can be connected.
2.4 Transport and installation
WARNING
Risk of injury due to improper handling of shielding gas cylinders!
Improper handling and insufficient securing of shielding gas cylinders can cause seri-
ous injuries!
•Observe the instructions from the gas manufacturer and any relevant regulations concern-
ing the use of compressed air!
•Do not attach any element to the shielding gas cylinder valve!
•Prevent the shielding gas cylinder from heating up.

For your safety
Transport and installation
099-005593-EW501
10.01.2022
11
CAUTION
Risk of accidents due to supply lines!
During transport, attached supply lines (mains leads, control cables, etc.) can cause
risks, e.g. by causing connected machines to tip over and injure persons!
•Disconnect all supply lines before transport!
Risk of tipping!
There is a risk of the machine tipping over and injuring persons or being damaged itself
during movement and set up. Tilt resistance is guaranteed up to an angle of 10° (ac-
cording to IEC 60974-1).
•Set up and transport the machine on level, solid ground.
•Secure add-on parts using suitable equipment.
Risk of accidents due to incorrectly installed leads!
Incorrectly installed leads (mains, control and welding leads or intermediate hose pack-
ages ) can present a tripping hazard.
•Lay the supply lines flat on the floor (avoid loops).
•Avoid laying the leads on passage ways.
Risk of injury from heated coolant and its connections!
The coolant used and its connection or connection points can heat up significantly
during operation (water-cooled version). When opening the coolant circuit, escaping
coolant may cause scalding.
•Open the coolant circuit only when the power source or cooling unit is switched off!
•Wear proper protective equipment (protective gloves)!
•Seal open connections of the hose leads with suitable plugs.
The units are designed for operation in an upright position!
Operation in non-permissible positions can cause equipment damage.
•Only transport and operate in an upright position!
Accessory components and the power source itself can be damaged by incorrect connection!
•Only insert and lock accessory components into the relevant connection socket when the
machine is switched off.
•Comprehensive descriptions can be found in the operating instructions for the relevant ac-
cessory components.
•Accessory components are detected automatically after the power source is switched on.
Protective dust caps protect the connection sockets and therefore the machine against dirt and
damage.
•The protective dust cap must be fitted if there is no accessory component being operated on
that connection.
•The cap must be replaced if faulty or if lost!

Intended use
Applications
12
099-005593-EW501
10.01.2022
3 Intended use
WARNING
Hazards due to improper usage!
The machine has been constructed to the state of the art and any regulations and stand-
ards applicable for use in industry and trade. It may only be used for the welding proce-
dures indicated at the rating plate. Hazards may arise for persons, animals and material
objects if the equipment is not used correctly. No liability is accepted for any damages
arising from improper usage!
•The equipment must only be used in line with its designated purpose and by trained or
expert personnel!
•Do not improperly modify or convert the equipment!
3.1 Applications
MMA welding system for GMAW-pulse and standard welding as a MMA welding secondary process. It
may be possible to expand the range of functions by using accessories (see the documentation in the
relevant chapter).
3.2 Use and operation solely with the following machines
A suitable wire feed unit (system component) is required in order to operate the welding machine!
The following system components can be combined:
Drive 4X / D200
Basic S
Drive 4X / D200
Steel Synergic S
Drive 4X / D200
Steel puls S
Taurus xx5 Basic S
Taurus xx5 Steel Synergic S
Taurus xx5 Steel puls S

Intended use
Documents which also apply
099-005593-EW501
10.01.2022
13
3.3 Documents which also apply
3.3.1 Warranty
For more information refer to the "Warranty registration" brochure supplied and our information regarding
warranty, maintenance and testing at www.ewm-group.com!
3.3.2 Declaration of Conformity
This product corresponds in its design and construction to the EU directives listed in the decla-
ration. The product comes with a relevant declaration of conformity in the original.
The manufacturer recommends carrying out the safety inspection according to national and in-
ternational standards and guidelines every 12 months.
3.3.3 Service documents (spare parts and circuit diagrams)
WARNING
Do not carry out any unauthorised repairs or modifications!
To avoid injury and equipment damage, the unit must only be repaired or modified by
specialist, skilled persons!
The warranty becomes null and void in the event of unauthorised interference.
•Appoint only skilled persons for repair work (trained service personnel)!
Original copies of the circuit diagrams are enclosed with the unit.
Spare parts can be obtained from the relevant authorised dealer.
3.3.4 Calibration/Validation
An original certificate is enclosed with the product. The manufacturer recommends calibration / validation
at intervals of 12 months.

Intended use
Documents which also apply
14
099-005593-EW501
10.01.2022
3.3.5 Part of the complete documentation
This document is part of the complete documentation and valid only in combination with all other
parts of these instructions! Read and observe the operating instructions for all system
components, especially the safety instructions!
The illustration shows a general example of a welding system.
Figure 3-1
Item
Documentation
A.1
Wire feeder
A.2
Conversion instructions
A.3
Power source
A.4
Cooling unit, voltage converter, tool box etc.
A.5
Trolley
A.6
Welding torch
A.7
Remote control
A.8
Control
A
Complete documentation

Machine description –quick overview
Front view / side view from the right
099-005593-EW501
10.01.2022
15
4 Machine description – quick overview
4.1 Front view / side view from the right
Figure 4-1

Machine description –quick overview
Front view / side view from the right
16
099-005593-EW501
10.01.2022
Item
Symbol
Description 0
1
Carrying handle
2
Protective cap, welding machine control > see 5.2.3 chapter
3
Welding torch connection (Euro or Dinse torch connector)
Welding current, shielding gas and torch trigger integrated
4
Turning mandrel support
The wire feeder is placed onto the power source turning mandrel using this support to
enable horizontal pivoting of the machine.
5
Sliding rails
6
Intermediate hose package strain relief > see 5.2 chapter
7
Slide latch, lock for the protective cap
8
Welding current connection socket (depending on variant)
Welding current potential of the torch connector for MMA welding or gouging
9
19-pole connection socket (analogue)
For connecting analogue accessory components (remote control, welding torch control
lead, etc.)
10
Quick connect coupling (red)
coolant return
11
Quick connect coupling (blue)
coolant supply
12
Machine control (see the relevant control operating instructions)

Machine description –quick overview
Rear view / side view from left
099-005593-EW501
10.01.2022
17
4.2 Rear view / side view from left
Figure 4-2

Machine description –quick overview
Rear view / side view from left
18
099-005593-EW501
10.01.2022
Item
Symbol
Description 0
1
Power source welding current connector plug
Welding current connection between power source and wire feeder
2
Connection thread - G¼"
Shielding gas connection (inlet)
3
7-pole connection socket (digital)
•Control lead for wire feed unit
4
Quick connect coupling (red)
coolant return
5
Quick connect coupling (blue)
coolant supply
6
Wire spool protective cap
7
Wire spool holder
8
Wire feed unit
9
Lighting, inside
10
Push-button gas test / rinse hose package > see 5.2.1 chapter
11
Wire inching push-button
For potential- and gas-free inching of the wire electrode through the hose package to
the welding torch.
12
Protective cap, wire feed mechanism
On the inside of the protective cap the welding task lists (JOB-List) for the relevant
welding machine series can be found.

Design and function
Transport and installation
099-005593-EW501
10.01.2022
19
5 Design and function
WARNING
Risk of injury from electrical voltage!
Contact with live parts, e.g. power connections, can be fatal!
•Observe the safety information on the first pages of the operating instructions!
•Commissioning must be carried out by persons who are specifically trained in handling
power sources!
•Connect connection or power cables while the machine is switched off!
CAUTION
Risk from electrical current!
If welding is carried out alternately using different methods and if a welding torch and
an electrode holder remain connected to the machine, the open-circuit/welding voltage
is applied simultaneously on all cables.
•The torch and the electrode holder should therefore always be placed on an insulated
surface before starting work and during breaks.
Read and observe the documentation to all system and accessory components!
5.1 Transport and installation
WARNING
Risk of accident due to improper transport of machines that must not be lifted!
Do not lift or suspend the machine! The machine can drop and cause injuries! The
handles, straps or brackets are suitable for transport by hand only!
•The machine must not be suspended or lifted using a crane.
•Depending on machine type, equipment for lifting by crane or use while suspended is
available as a retrofitting option > see 9 chapter.
5.1.1 Ambient conditions
The machine must not be operated in the open air and must only be set up and operated on a
suitable, stable and level base!
•The operator must ensure that the ground is non-slip and level, and provide sufficient lighting
for the place of work.
•Safe operation of the machine must be guaranteed at all times.
Equipment damage due to contamination!
Unusually high amounts of dust, acids, corrosive gases or substances can damage the machine
(observe maintenance intervals > see 6.2 chapter).
•Avoid large amounts of smoke, steam, oily fumes, grinding dust and corrosive ambient air!
In operation
Temperature range of the ambient air:
•-25 °C to +40 °C (-13 °F to 104 °F) [1]
Relative humidity:
•up to 50 % at 40 °C (104 °F)
•up to 90 % at 20 °C (68 °F)
Transport and storage
Storage in a closed room, temperature range of the ambient air:
•-30 °C to +70 °C (-22 °F to 158 °F) [1]
Relative humidity
•up to 90 % at 20 °C (68 °F)
[1] Ambient temperature dependent on coolant! Observe the coolant temperature range of the torch coo-
ling

Design and function
Transport and installation
20
099-005593-EW501
10.01.2022
5.1.2 Welding torch cooling system
Material damage due to unsuitable coolants!
Unsuitable coolant, coolants mixed with other types / liquids or use in an unsuitable tempera-
ture range will result in material damage and loss of the manufacturer's warranty!
•Operation without coolant is not permitted! Dry running will destroy the cooling components
such as the coolant pump, welding torch and hose packages.
•Only use the coolants described in these instructions for the specified ambient conditions
(temperature range) > see 5.1.2.1 chapter.
•Do not mix coolants of different types (including those described in these instructions).
•When changing the coolant, all liquid must be replaced and the cooling system flushed.
Dispose of the coolant in accordance with local regulations and the material safety data sheets.
5.1.2.1 Permitted torch coolant
Coolant
Temperature range
blueCool -10
-10 °C to +40 °C (14 °F to +104 °F)
KF 23E (Standard)
-10 °C to +40 °C (14 °F to +104 °F)
KF 37E
-20 °C to +30 °C (-4 °F to +86 °F)
blueCool -30
-30 °C to +40 °C (-22 °F to +104 °F)
5.1.2.2 Maximal hose package length
All information relates to the total hose package length of the complete welding system and presents
exemplary configurations (of components of the EWM product portfolio with standard lengths). A straight
kink-free installation is to be ensured, taking into account the max. delivery height.
Pump: Pmax = 3,5 bar (0.35 MPa)
----------------------------------------------------------------------------------------------------------------------►
Power source
Hose package
Wire feeder
miniDrive
Welding torch
Max.
Compact
(25 m / 82 ft.)
(5 m / 16 ft.)
30 m
98 ft.
(20 m / 65 ft.)
(5 m / 16 ft.)
Decompact
(25 m / 82 ft.)
(5 m / 16 ft.)
(15 m / 49 ft.)
(10 m / 32 ft.)
(5 m / 16 ft.)
Pump: Pmax = 4.5 bar (0.45 MPa)
----------------------------------------------------------------------------------------------------------------------►
Power source
Hose package
Wire feeder
miniDrive
Welding torch
Max.
Compact
(25 m / 82 ft.)
(5 m / 16 ft.)
30 m
98 ft.
(30 m / 98 ft.)
(5 m / 16 ft.)
40 m
131 ft.
Decompact
(40 m / 131 ft.)
(5 m / 16 ft.)
45 m
147 ft.
(40 m / 131 ft.)
(25 m / 82 ft.)
(5 m / 16 ft.)
70 m
229 ft.
