Exabyte Mammoth Owner's manual

306484-002
([DE\WH0DPPRWK
Installation and
Operation

ii ExabyteMammoth
Copyright Copyright 1996–1999 by Exabyte Corporation. All rights reserved.
This item and the information contained herein are the property of
Exabyte Corporation. No part of this document may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated
intoanylanguageorcomputerlanguageinanyformorbyanymeans,
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise, without the express written permission of Exabyte
Corporation, 1685 38th Street, Boulder, Colorado 80301.
Disclaimer Exabyte Corporation makes no representation or warranties with
respect to the contents of this document and specifically disclaims
any implied warranties of merchantability or fitness for any
particular purpose. Further, Exabyte Corporation reserves the right
to revise this publication without obligation to notify any person or
organization of such revisions or changes.
Trademark
notices Exabyte, Exafacts, Exapak, Exasoft, and Exatape are registered
trademarks of Exabyte Corporation. Arrowhead, Eliant, and
SupportSuite are trademarks of Exabyte Corporation. All other
product names are trademarks or registered trademarks of their
respective owners.
Revision history
Note:The mostcurrent informationabout this product is availableat
Exabyte’s web site (www.exabyte.com).
Exabyte Corporation
1685 38th Street
Boulder, Colorado 80301
[phone]
306484-002
Revision Date Description
000 March 1996 Initial release.
001 July 1996 Updatefor new LCDinformation.
002 January 1999 Update for LVD SCSI
configuration.

Installation and Operation iii
Safety agency
standards When purchased from Exabyte, both the internal model and the
tabletop model of the Exabyte®Mammoth Tape Drive comply with
the following domestic and international product safety standards:
• UL Standard 1950, 1st Edition, Safety of Information Technology
Equipment
• CSAStandardC22.2No.950-95,SafetyofInformationTechnology
Equipment
• IEC 950/EN60950: A4 1997, Safety of Information Technology
Equipment including Electrical Business Equipment
The internal model ofthe tape drive is certified as a component only.
Certificationof thefinalintegratedproductistheresponsibilityofthe
system integrator.
Electro-
magnetic
compatibility
(EMC)
When properly installed in a shielded cabinet with shielded cables
and adequate grounding of the SCSI bus and input power, the tape
drive meets the requirements foremissions and immunity as defined
by the following standards:
For the tabletop tape drive, the requirement for a shielded cabinet is
met by the tabletop enclosure.
USA: FCC, CFR 47, Ch. I, Part 15, Subpart B, Class B
Canada: ICES-003, Class B
Australia: AS/NZ 3548, Class B
Taiwan: CNS-13438, Class A
Europe: EN55022/CISPR 22, Class B
EN50082-1: Residential, Commercial, and Light
Industry

iv ExabyteMammoth
FCC notice When installed inan Exabyte enclosure, the tabletop model has been
testedand foundto complywiththelimitsforaClassBdigitaldevice
pursuant to Part 15 of FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
interferenceto radioandtelevisioncommunications.However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to equipment
off and on, the useris encouraged to tryto correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Use shielded cables.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
According to FCC regulations, changes or modifications not
expressly approved by Exabyte Corporation could void your
authority to operate the equipment.
Industry Canada
notice per
ICES-003
ThisClassBdigitalapparatusmeetsallrequirementsoftheCanadian
Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences
du Règlement sur le matériel brouilleur du Canada.

Installation and Operation v
Contents
Welcome. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Available SCSI configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installing the tape drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing the internal model in an enclosure. . . . . . . . . . . . . . . . . . . . . . 3
Installing the tabletop model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Operating the tape drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Monitoring the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Monitoring the LCD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Selecting appropriate data cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Loading data cartridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Unloading data cartridges. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Resetting the tape drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Cleaning the tape drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using Tape Alert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Packing the tape drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Appendix. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

vi ExabyteMammoth
Notes

Welcome
Installation and Operation 1
Welcome
Congratulationson selectingtheExabyte®MammothTapeDrive.
Your new tape drive is designed for multimedia, imaging,
transaction processing, large databases, and other
storage-intensive applications.
The Mammoth tape drive provides storage capacities of up to
20 gigabytes (GB) native on a single 170m data cartridge.
The Mammoth tape drive is available as an internal model that
can be installed into an enclosure (shown on the right) or as a
tabletop model housed in its own enclosure (shown on the left).

Available SCSI configurations
2
ExabyteMammoth
Available SCSI configurations
The Mammoth tape drive is available in the following fast SCSI-2
configurations:
Narrow, single-ended
Wide, single-ended
Wide, high-voltage differential (HVD)
Wide, low-voltage differential (LVD)
The LVDtape driveusesan LVDinterface thatisUltraand Ultra2
SCSI compatible. The LVD interface allows the tape drive to be
placed on the same bus as Ultra and Ultra2 SCSI devices without
slowing the performance of these devices.

Installing the tape drive
Installation and Operation 3
Installing the tape drive
If you have the internal model of the tape drive, follow the
instructions below. If you have the tabletop model, follow the
instructions beginning on page 13.
Installing the internal model in an enclosure
ESD protection
Protect the tape drive from electrostatic discharge (ESD) by
following these precautions:
Use an antistatic mat and wristband, if possible.
Leave the tape drive in its packaging until you are ready to
install it.
Touch a known grounded surface before handling the tape
drive.
Do not place the tape drive on a metallic surface.

Installing the tape drive
4
ExabyteMammoth
Location of components
When installing the tape drive, refer to the following figures for
the location of back-panel components.
Narrow SCSI configuration:
Wide SCSI configuration:

Installing the tape drive
Installation and Operation 5
Step 1 – Set the SCSI ID
To set the SCSI ID, remove and reposition the jumpers to obtain
thedesiredID.(Ifnecessary,useapairofflat-noseplierstoremove
the jumpers.)
The following figures show how to position the jumpers for
narrow and wide SCSI configurations.
Narrow SCSI configuration (SCSI IDs 0–7):
If you need additional jumpers, use 0.1-inch jumpers for narrow
SCSI (AMP part number 531220-2).

Installing the tape drive
6
ExabyteMammoth
Wide SCSI configuration (SCSI IDs 0–15):
If you need additionaljumpers, use 2 mm mini jumpers for wide
SCSI (AMP part number 382575-2).
Note: You can alsoset the SCSIIDbyremoving the jumpersand
connecting your own remote switch.
Step 2 – Connect the drive to the SCSI bus
Before connecting the tape drive to the SCSI bus, be aware of the
following:
You can connect single-ended and LVD SCSI tape drives to
the same SCSI bus. Be aware that mixing the two types of
devices will result in all devices on the bus operating as
single-ended devices.

Installing the tape drive
Installation and Operation 7
Do not connect a single-ended wide or LVD tape drive to an
HVD wide SCSI bus or your SCSI bus may hang.
The LVD tape drive uses an LVD interface that is Ultra and
Ultra2 SCSI compatible. The LVD interface allows the tape
drive to be placed on the same bus as Ultra and Ultra2 SCSI
devices without slowing the performance of these devices.
The product ID label, shown below, displays the SCSI
configuration: LVD, DIFF (HVD), or SE.
To connect the tape drive to the SCSI bus:
1. Connect an internal SCSI cable to the tape drive’s SCSI
connector and to the next SCSI device in the enclosure (for
example, a SCSI adapter card).
CAUTION
Connecting a single-ended wide or LVD tape
drive to an HVD wide SCSI bus may cause your
SCSI bus to hang.

Installing the tape drive
8
ExabyteMammoth
2. If the tape drive is the last device on the SCSI bus, you must
terminate the bus by installing a pass-through terminator on
the tape drive’s SCSI connector. Or, if there is an unused
connector at the end of the SCSI cable, you can terminate the
bus there.
Use one of the terminator types listed in the following table.
➤Important Exabyte recommends using active
termination.Exabyte testing hasshown that older
passive termination does not provide rising edge
transitionsthatarefastorcleanenoughatfastSCSI
speeds.
Narrow SCSI configuration Wide SCSI configuration
Single-ended*
*Terminators for single-ended, HVD, and LVD buses are not identical. Do not mix the variants.
AMP 750381-1 AMP 859516-1
HVD* N/A AMP 869515-1
LVD* N/A AMP 796051-1

Installing the tape drive
Installation and Operation 9
Step 3 – Connect ground
To protect the tape drive from electrostatic discharge (ESD), you
must attach the tape drive to the enclosure’smetal chassis (using
the mounting holes shown on page 11). If you need additional
chassis grounding, use either of the following methods:
Connect a 1/4-inch female spade connector to the ground tab
(shown below).
Connect an M3 ×0.5 ×6 mm self-tapping screw to the
grounding hole (shown below).
Note: The power supply returns are connected to the chassis, so
you cannot isolate the logic common ground from the
chassis ground.

Installing the tape drive
10
ExabyteMammoth
Step 4 – Connect power
To connect power to the tape drive:
1. Connect the enclosure’s internal power cable to the tape
drive’s power connector. (Use an AMP 1-480424-0 series or
equivalent female power connector.)
2. Power on the enclosure.
Thetapedriveperformsitspower-onself-testinabout30seconds.
When the tape drive is ready to accept a cartridge, the LEDs turn
off.
➤Important Do not insert a cartridge into the
tape drive during the power-on self-test. The tape
drive will eject the cartridge.
CAUTION
Do not force the power cable into the tape
drive’s power connector. If the power cable is
upsidedownandyouforcetheconnection,you
may damage the drive when you power it on.

Installing the tape drive
Installation and Operation 11
Step 5 – Mount the tape drive
The single-ended and HVD internal tape drives meet
industry-standard, 5.25-inch half-high form factor mounting
requirements. The LVD internal tape drive is approximately
0.36 inches (9.2 mm) longer than the standard form factor. The
tape drive can be mounted either horizontally or vertically and in
a stationary or sliding position.
As shown in the following figure, the main housing of the tape
drive includes three sets of four mounting holes to allow for a
number of mounting positions (two sets on the sides, set Aand
set B, and one set on the bottom, set C).

Installing the tape drive
12
ExabyteMammoth
When mounting the tape drive, follow these guidelines:
Use oneset of mounting holes. (Use all four holes in whichever
set you choose; do not use combinations of mounting holes
from different sets.)
Use M3 ×0.5 ×6 mm screws. For proper mounting, use the
correct screw length.
Ensure that no objects such as screw heads,cables, oradjacent
devices are pressing against the frame.
Do not obstruct the ventilation slots on the bottom and at the
rear of the tape drive.
Allow sufficient space for accessing the tape drive’s front
panel controls.

Installing the tape drive
Installation and Operation 13
Installing the tabletop model
Location of components
When installing the tabletop tape drive, refer to the following
figure for the location of the back-panel components.
Step 1 – Set the SCSI ID
Tosetthe SCSIIDforthe tapedrive,usea pen orotherfine-tipped
instrument to press the SCSI ID switch until the desired number
is displayed (0–7 for narrow SCSI or 0–15 for wide SCSI).
Note: Changes in the SCSI ID setting take effect after a normal
power-on or SCSI bus reset.

Installing the tape drive
14
ExabyteMammoth
Step 2 – Install the orientation pads
The tabletop model includes adhesive pads that you must apply
to either the base or the right side, depending on how you plan
to position the tape drive. These pads protect the tape drive’s
surface and allow air to flow through the vents when the tape
drive is positioned on its side.
To install the pads:
1. Remove the backing from four pads. (Five pads are shipped
with the tape drive.)
2. Affix the padsto each corner, approximately 1/2-inch (1.3 cm)
from the sides.
For a horizontal orientation, place the pads on the bottom. For a
vertical orientation, place the pads on the right side (the side
with the external vents).
